Wear & Hear HearLink Plus BT5805A User manual

For more information
visit our Web site
www.WearAndHear.com
Model: BT5805A
Quick Start
Guide
HearLink Plus
device
USB power
cable
3.5mm stereo
audio cable
RCA-to-3.5mm
adapter
Optical fiber
audio cable
This quick
start guide
Quick Start
Quide
Package Contents
1
5
6
12 3 4
897
Remove for
Bypass use
1 – Power button
2 – Bluetooth function button
3 – Previous track/volume down
4 Next track/volume up –
5 – Front display panel with
LED indicators
6 – Mode switch
7 – Micro USB power input
8 – AUX stereo input
9 – Optical input
Device Details
2

The active connection type is indicated by the
illuminated text ( or ) on the HearLink PLUS
front display panel.
OPT AUX
Make sure to remove the plastic protectors from
the optical cable terminals prior to insertion.
Remove for
Bypass use
AUX OPT
3. Connect the HearLink PLUS TX port to the TV (or other
media device) via the supplied optical or 3.5mm audio
cable.
TX
2. Ensure that the Mode switch is set
to the TX position.
Purchased separately
1. Connect HearLink PLUS to a power outlet (A) or the TV
set’s USB port (B) using the supplied USB power cable.
HearLink PLUS will turn ON automatically.
Setting Up HearLink PLUS
3
Subsequent connections should be automatic. If not,
for BeHear headsets, a short press on the headset's
Power button should re-establish the connection.
4. When pairing is complete (after 5-30 seconds) will
be illuminated on the HearLink PLUS front display
panel.
The is illuminated to indicate that the Low Latency
APTX-LL Bluetooth CODEC is being used.
Successful connection of the headset is indicated by
the illuminated on the HearLink PLUS front display
panel.
TX
LL
A
Bluetooth headset
1. Place HearLink PLUS into pairing mode with a short
press on its button. When in pairing mode the
indicator light will flash quickly.
2. Place your Bluetooth headset in “pairing” mode. Refer to
the headset’s technical documentation for pairing
instructions.
3. Place the Bluetooth headset close to the HearLink
PLUS device.
TX
First Time Connection
4

For BeHear headsets only:
To toggle between two connected audio sources
(e.g., HearLink PLUS and a smartphone),
simultaneously short press the headset's volume
up and volume down buttons.
Press volume down button to decrease the
volume.
Press volume up button to increase the volume.
Short press the multifunction button to toggle
Play/Pause audio.
Manage audio play using the headset’s controls.
2. Bluetooth Headset Remote Control
Press to decrease the volume. A tone is played
when minimum volume is reached.
Press to increase the volume. A tone is played
when maximum volume is reached.
Short press to toggle audio Play/Pause.
1. HearLink PLUS Manual Control
Audio Playback
4
HearLink Plus-QS-EN-Ver02
Connect the HearLink PLUS TX port to the TV via the
optical or 3.5mm audio cable, and the RX port to a
speaker or other peripheral audio equipment using the
same type of cable as the TX port connection.
To passthrough HearLink PLUS set
its Mode switch to Bypass position,
indicated by . To restore
connection with the headset set
the Mode switch to TX.
TX
AUX
OPT
Wired Speaker
Remove the sticker to expose the RX ports.
1. If you do not hear audio:
§Ensure that the ‘audio out’ port of your TV (or other
media device) connected to the HearLink PLUS is
active. For some devices you need to enable the
audio output. Refer to your device’s user manual.
§Toggle the Play/Pause button on the headset or
b button on the HearLink PLUS.
2. Use the HearLink PLUS Bypass mode to maintain the
existing interfaces between your TV and peripheral
audio equipment.
Helpful Information
5
