26cc Petrol Garden Blower
& Vacuum
WEBV26
193867003

17 Jan 2019
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
Instruction Manual
CONTENTS
SAFETY INSTRUCTIONS
SPECIFICATIONS
COMPONENTS
ASSEMBLY
OPERATION
MAINTENANCE, CLEANING & STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY

Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
Instruction Manual
CONTENTS
SAFETY INSTRUCTIONS
SPECIFICATIONS
COMPONENTS
ASSEMBLY
OPERATION
MAINTENANCE, CLEANING & STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY

Instruction Manual
STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect
your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand.
Be aware of what you are doing at all times. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluttered areas invite injuries.
Keep your work area clean with sufficient light. Keep area around the machine clear of obstructions, stones,
sticks, wires and other debris or foreign bodies which could cause damage to the machine.
DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and drive
mechanisms. Vibration during use may cause these to loosen. Replace damaged, missing or failed parts before
using. Warning labels carry important information. Replace any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckties or jewelry (rings, wrist watches), which can be caught in
moving parts.
ALWAYS wear protective eye and ear wear. Appropriate gardening gloves are also recommended.
Wear protective hair covering to contain long hair, preventing it from getting caught in machinery.
DO NOT use whilst barefoot or wearing open toed footwear. Non-slip heavy duty footwear recommended.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower.Do not allow
children to handle, use, or climb on the machine. If approached, turn off machine immediately.
DO NOT OVERREACH
Keep proper footing and balance at all times, particularly if using on slopes. The machine should not be used
on steep slopes and always be sure of footing.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, particularly the engine and rotating cutting tool.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full and safest
performance. When maintaining this machine, only the manufacturer’s original replacement parts should be
used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry location. Keep the machine away from children and
others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale
and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its application and
limitations as well as the specific potential hazards. Retain these instructions for future reference. The
operator is responsible for following the warnings & instructions in this manual and on the product.
Read & understand operator’s
manual before using the
machine. Failure to follow
instructions could result in death
or serious injury.
This graphic and when
accompanied by WARNING or
DANGER, calls attention to
actions which could lead to
SERIOUS INJURY
Always wear eye and ear
protection
WARNING
Never modify a machine in any
way.
Incorrect use of a machine can
cause SERIOUS OR FATAL
PERSONAL INJURY
Always wear gloves to protect
your hands.
SHARP ROTATING BLADES
It is advisable to wear a face
mask to stop debris from
entering your body.
Always TURN OFF THE ENGINE,
ensuring the cutting tool has
stopped, before cleaning,
removing or adjusting the
machine tubes.
15m
Keep all bystanders & animals at
least 15 metres away from the
machine during operation.
If approached, stop the machine
immediately.
No smoking
Risk of Carbon Monoxide
Poisoning.
Ensure working area is correctly
ventilated.
Do not use near a flame, or
sparks
Fire Risk
Fire and its vapors are extremely
flammable & explosive.
Fire or explosion can cause
severe burns or death.
Moving Parts
Rotating parts can contact or
entangle hands, feet, hair,
clothing or accessories.
Traumatic amputation or severe
laceration can result.
Hot Surface.
Running engines produce heat.
Engine parts, especially the
exhaust, become extremely hot.
Severe thermal burns can occur
on contact.
Safety alert symbol. Used to alert you to potential personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in serious injury
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION
Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.

Instruction Manual
STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect
your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand.
Be aware of what you are doing at all times. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluttered areas invite injuries.
Keep your work area clean with sufficient light. Keep area around the machine clear of obstructions, stones,
sticks, wires and other debris or foreign bodies which could cause damage to the machine.
DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and drive
mechanisms. Vibration during use may cause these to loosen. Replace damaged, missing or failed parts before
using. Warning labels carry important information. Replace any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckties or jewelry (rings, wrist watches), which can be caught in
moving parts.
ALWAYS wear protective eye and ear wear. Appropriate gardening gloves are also recommended.
Wear protective hair covering to contain long hair, preventing it from getting caught in machinery.
DO NOT use whilst barefoot or wearing open toed footwear. Non-slip heavy duty footwear recommended.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower.Do not allow
children to handle, use, or climb on the machine. If approached, turn off machine immediately.
DO NOT OVERREACH
Keep proper footing and balance at all times, particularly if using on slopes. The machine should not be used
on steep slopes and always be sure of footing.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, particularly the engine and rotating cutting tool.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full and safest
performance. When maintaining this machine, only the manufacturer’s original replacement parts should be
used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry location. Keep the machine away from children and
others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale
and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its application and
limitations as well as the specific potential hazards. Retain these instructions for future reference. The
operator is responsible for following the warnings & instructions in this manual and on the product.
Read & understand operator’s
manual before using the
machine. Failure to follow
instructions could result in death
or serious injury.
This graphic and when
accompanied by WARNING or
DANGER, calls attention to
actions which could lead to
SERIOUS INJURY
Always wear eye and ear
protection
WARNING
Never modify a machine in any
way.
Incorrect use of a machine can
cause SERIOUS OR FATAL
PERSONAL INJURY
Always wear gloves to protect
your hands.
SHARP ROTATING BLADES
It is advisable to wear a face
mask to stop debris from
entering your body.
Always TURN OFF THE ENGINE,
ensuring the cutting tool has
stopped, before cleaning,
removing or adjusting the
machine tubes.
15m
Keep all bystanders & animals at
least 15 metres away from the
machine during operation.
If approached, stop the machine
immediately.
No smoking
Risk of Carbon Monoxide
Poisoning.
Ensure working area is correctly
ventilated.
Do not use near a flame, or
sparks
Fire Risk
Fire and its vapors are extremely
flammable & explosive.
Fire or explosion can cause
severe burns or death.
Moving Parts
Rotating parts can contact or
entangle hands, feet, hair,
clothing or accessories.
Traumatic amputation or severe
laceration can result.
Hot Surface.
Running engines produce heat.
Engine parts, especially the
exhaust, become extremely hot.
Severe thermal burns can occur
on contact.
Safety alert symbol. Used to alert you to potential personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in serious injury
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION
Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.

Instruction Manual
SPECIFICATIONS
Model WEBV26
Product Number 193867003
Engine (cc) 26
Idle Speed (r/min) 3000+200
Fuel Tank Capacity (Litre) 0.5
Fuel Ratio (Unleaded Petrol:2 Stroke
Synthetic or Semi Synthetic Oil) 40:1
Weight (kgs) N.W 4.8 - G.W 7.05
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collection Bag
4. Suction Pipe A
5. Suction Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/Off Switch
9. Throttle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank Cap
14. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
14
5

Instruction Manual
SPECIFICATIONS
Model
WEBV26
Product Number
193867003
Engine (cc)
26
Idle Speed (r/min)
3000+200
Fuel Tank Capacity (Litre)
0.5
Fuel Ratio (Unleaded Petrol:2 Stroke
Synthetic or Semi Synthetic Oil)
40:1
Weight (kgs)
N.W 4.8 - G.W 7.05
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collection Bag
4. Suction Pipe A
5. Suction Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/Off Switch
9. Throttle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank Cap
14. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
14
5
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: [phone]
Email: customerser[email protected]
Hours: Monday to Friday 8.30am –5.30pm (excl. Bank Holidays)
VACUUM ASSEMBLY
1. Open the fan cover, by loosening the top screw and allowing the fan cover to open.
2. Match Suction Tube A, with the top & bottom locking stubs on the body of the machine.
3. Rotate the tube clockwise to lock into place.
4. Repeat the same actions, attaching Suction Tube B to Suction Tube A.
5. Insert the Discharge Tube into the Collection Bag and secure.
6. Connect the Discharge Tube to the Discharge Outlet of the machine and secure with an M5x10 screw
BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same action attaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING
EXCESSIVE VIBRATION OF THE SHREDDING FAN
INDICATES IT HAS BEEN DAMAGED. CONSULT
YOUR LOCAL APPROVED DEALER FOR ASSISTANCE

Instruction Manual
FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking.
Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine
running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
FUEL MIXTURE
THE MACHINE SHOULD USE A 40:1 UNLEADED PETROL TO TWO STROKE SYNTHETIC OR SEMI SYNTHETIC OIL
MIXTURE RATIO. USE GOOD QUALITY UNLEADED FUEL ONLY WITH AN OCTANE OF 89 OR ABOVE.
Operating the engine with insufficient oil within your fuel mixture, can have catastrophic consequences. Any
failure caused by insufficient oil, will not be covered by the manufacturer’s warranty.
40:1 FUEL MIXTURE RATIO
Unleaded Petrol
(litre)
Two Stroke Synthetic or
Semi-Synthetic Oil
(ml)
1
25
2
50
3
75
4
100
5
125
The mixture should be shaken prior to entering the machine fuel tank.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essential carburettor components. This could result in starting issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use SURE-START FUEL ADDITIVE (HP-199) from Handy Parts. A fuel
additive added to your fuel at the time of mixture, will help make your machine easier to start, extend the
shelf life of your fuel mixture for up to two years, keeps the carburettor & engine clean, plus reduces emissions
and increases fuel economy. A 250ml bottle of SURE-START FUEL ADDITIVE will treat 25 litres of fuel mix
Only use 2-stroke air cooled engine oil. DO NOT USE automotive or marine oil.
It is recommended that you use a Fuel Mixing Bottle, to ensure the correct fuel mixture is used with your
machine. We recommend HANDY PARTS –FUEL MIXING BOTTLE (HP-120).
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a
maximum of 4-6 weeks if not mixed with a fuel additive. If the machine is not going to be used for a long
period, drain the mixture from the fuel tank, start the engine and drain the carburetor of any remaining fuel.
(See Maintenance for further instruction). Dispose of any unwanted 2-stroke mixture at an authorised
recycling point.
FUELING THE MACHINE
Place the machine onto a solid flat surface, ensuring the engine is not running.
Unscrew the fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80% capacity. This
will allow the fuel tank to expand. Fasten the fuel cap tightly, being careful not to cross-thread. This will also
prevent loosening through vibration during use. Wipe away any spillage, with an appropriate material.
If the machine has continued leaks, the product should not be started. Never use the machine with damaged
ignition cable or spark plug cap, as there is a risk of sparks.
OPERATION
DANGER
DANGER ZONE - WITHIN 15 METRES OF USER
RISK ZONE - GREATER THAN 15 METRES OF USER
All model Blowers can throw small stones, metal or small objects as well as material. Do not allow anyone to
enter the operating DANGER ZONE with you. The danger zone is an area 15 metres in radius.
Insist that persons in the RISK ZONE beyond the danger zone wear eye protection from thrown objects. If
the unit must be used where there are unprotected people, operate at a low throttle speed to reduce the
risk of thrown objects. Turn the machine off, if approached by any bystander, child or animal.
GENERAL USE
WARNING
Prior to using the machine, ensure all hardware (bolts, screws & nuts) are securely tightened.
•Operate the trigger with your right hand & hold the Lower Handle with your left hand.
•The trigger increases and decreases the power of the engine to the attachment, increasing the
revolution/reciprocation of the shredder fan.
WORKING PLAN
•Blow material to a safe collection point, away from stones and other hard debris, which could damage the
shredding fan within the machine.
•Limit the amount of time the product is used continuously to a maximum of 40 minutes per session.
•Leave the machine to rest between sessions for between 10-20 minutes.
•Total amount of work performed per day with the machine, should be limited to 120 minutes maximum.
•Continuous use of the machine can cause “Repetitive Stress Injury (RSI)”. If you feel discomfort, redness or
swelling of your hands and fingers or any other body part, consult your doctor.
•Check local regulations for sound level and hours of operation constraints.
•Never transport the machine, whilst the engine is running.
USING THE VACUUM
•When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is
not thrown.
•When the bag is full, open the zip on the bag and tip the contents into a recycling bin or compost heap.
USING THE BLOWER
•Always be aware of the strength and direction of the air stream.
•Never direct the blower towards period or animals.

Instruction Manual
FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking.
Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine
running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
FUEL MIXTURE
THE MACHINE SHOULD USE A 40:1 UNLEADED PETROL TO TWO STROKE SYNTHETIC OR SEMI SYNTHETIC OIL
MIXTURE RATIO. USE GOOD QUALITY UNLEADED FUEL ONLY WITH AN OCTANE OF 89 OR ABOVE.
Operating the engine with insufficient oil within your fuel mixture, can have catastrophic consequences. Any
failure caused by insufficient oil, will not be covered by the manufacturer’s warranty.
40:1 FUEL MIXTURE RATIO
Unleaded Petrol
(litre)
Two Stroke Synthetic or
Semi-Synthetic Oil
(ml)
1
25
2
50
3
75
4
100
5
125
The mixture should be shaken prior to entering the machine fuel tank.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essential carburettor components. This could result in starting issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use SURE-START FUEL ADDITIVE (HP-199) from Handy Parts. A fuel
additive added to your fuel at the time of mixture, will help make your machine easier to start, extend the
shelf life of your fuel mixture for up to two years, keeps the carburettor & engine clean, plus reduces emissions
and increases fuel economy. A 250ml bottle of SURE-START FUEL ADDITIVE will treat 25 litres of fuel mix
Only use 2-stroke air cooled engine oil. DO NOT USE automotive or marine oil.
It is recommended that you use a Fuel Mixing Bottle, to ensure the correct fuel mixture is used with your
machine. We recommend HANDY PARTS –FUEL MIXING BOTTLE (HP-120).
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a
maximum of 4-6 weeks if not mixed with a fuel additive. If the machine is not going to be used for a long
period, drain the mixture from the fuel tank, start the engine and drain the carburetor of any remaining fuel.
(See Maintenance for further instruction). Dispose of any unwanted 2-stroke mixture at an authorised
recycling point.
FUELING THE MACHINE
Place the machine onto a solid flat surface, ensuring the engine is not running.
Unscrew the fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80% capacity. This
will allow the fuel tank to expand. Fasten the fuel cap tightly, being careful not to cross-thread. This will also
prevent loosening through vibration during use. Wipe away any spillage, with an appropriate material.
If the machine has continued leaks, the product should not be started. Never use the machine with damaged
ignition cable or spark plug cap, as there is a risk of sparks.
OPERATION
DANGER
DANGER ZONE - WITHIN 15 METRES OF USER
RISK ZONE - GREATER THAN 15 METRES OF USER
All model Blowers can throw small stones, metal or small objects as well as material. Do not allow anyone to
enter the operating DANGER ZONE with you. The danger zone is an area 15 metres in radius.
Insist that persons in the RISK ZONE beyond the danger zone wear eye protection from thrown objects. If
the unit must be used where there are unprotected people, operate at a low throttle speed to reduce the
risk of thrown objects. Turn the machine off, if approached by any bystander, child or animal.
GENERAL USE
WARNING
Prior to using the machine, ensure all hardware (bolts, screws & nuts) are securely tightened.
•Operate the trigger with your right hand & hold the Lower Handle with your left hand.
•The trigger increases and decreases the power of the engine to the attachment, increasing the
revolution/reciprocation of the shredder fan.
WORKING PLAN
•Blow material to a safe collection point, away from stones and other hard debris, which could damage the
shredding fan within the machine.
•Limit the amount of time the product is used continuously to a maximum of 40 minutes per session.
•Leave the machine to rest between sessions for between 10-20 minutes.
•Total amount of work performed per day with the machine, should be limited to 120 minutes maximum.
•Continuous use of the machine can cause “Repetitive Stress Injury (RSI)”. If you feel discomfort, redness or
swelling of your hands and fingers or any other body part, consult your doctor.
•Check local regulations for sound level and hours of operation constraints.
•Never transport the machine, whilst the engine is running.
USING THE VACUUM
•When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is
not thrown.
•When the bag is full, open the zip on the bag and tip the contents into a recycling bin or compost heap.
USING THE BLOWER
•Always be aware of the strength and direction of the air stream.
•Never direct the blower towards period or animals.

Instruction Manual
MAINTENANCE, CLEANING & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty.
Keep the machine clean for better and safer performance.
MAINTENANCE
•Before each use, check all nuts & bolts to be sure they are sufficiently tightened.
•We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so
could invalidate your manufacturer’s warranty.
•The engine must be switched off, with the spark plug cap removed, before the machine is unassembled,
cleaned, serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper
adjustment may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug after every 10-15 hours of use.
•Remove the Spark Plug cap
•Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it anti-clockwise.
•Clean & adjust the electrode gap to 0.6-0.7mm
•If the Spark Plug is visibly damaged or worn, replace immediately (See Specification for details)
•Install the new/cleaned Spark Plug to finger tightness, before fully tightening with the spanner.
CLEANING
Keep your machine clean.
Thoroughly clean the machine at the end of each use, paying particular attention to cuttings in and around
the guard and cutting tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumption and allow abrasive
particles to pass in the engine. Remove & clean the air filter regularly to ensure optimum performance.
•Remove the air filter cover, by releasing the securing winged screw from the front of the cover.
•Lift off the cover.
•Remove the sponge air filter from the housing.
•Tap the filter to remove light surface dust.
•Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
•The fuel tank is fitted with a filter. It is situated at the free end of fuel pipe and can be picked out through
the fuel filler neck, with a piece of hooked wire or similar.
•Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause
difficulty in starting the engine or abnormalities in engine performance.
•When the filter is dirty, replace the filter.
•When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
•It is advisable to remove the Suction & Blower tubes from the machine regularly for cleaning.
•Use Soapy water to remove any dirt or grime.
ENGINE STARTING & STOPPING PROCEDURE
STARTING A COLD ENGINE
1. Place the machine onto a flat, firm surface.
2. Keep the machine clear of any surrounding objects
3. Move the stop switch to "START" position
4. Give a gentle push on the primer pump repeatedly (7-10 times) until fuel comes into the primer pump.
5. Pull the Choke Lever up to close the choke
6. Whilst holding the machine down with your left hand, away from the engine and pull the engine recoil
starter rope vigorously, until the engine false starts.
(DO NOT LET THE RECOIL STARTER ROPE RETRACT BY ITSELF, FEED THE ROPE BACK INTO THE HOUSING)
7. Push the choke lever downwards (excessive cranking with choke lever up will cause the engine to flood,
making it difficult to start.)
8. Pull starter handle until engine starts.
IMPORTANT
When the engine starts, for maximum performance and operating life, allow the engine to warm before use.
9. Run the engine at idle speed until operating temperature is reached (2 to 3 minutes).
10. As the engine warms, open the choke gradually by slowly pushing the choke control into the fully open
position.
11. The engine should now be ready to use.
STARTING A WARM ENGINE
1. Move the switch to "START" position
2. If the fuel tank was run dry on previous operation, follow steps 3-7 of cold start procedure.
3. Whilst holding the machine down with your left hand, away from the engine and pull the engine recoil
starter rope vigorously, until the engine starts.
IF THE ENGINE DOES NOT START
1. Repeat the appropriate starting procedures for “hot” or “cold” engine. If the engine still will not start,
follow the “Starting a Flooded Engine” procedure (below).
STARTING A FLOODED ENGINE
1. Disconnect the spark plug cap & lead, and use the spark plug spanner to remove the plug in an anti-
clockwise direction.
2. If the spark plug is fouled or is soaked with fuel, clean or replace the plug as required.
STOPPING THE ENGINE
1. Move the stop switch to the “STOP” position
CHOKE LEVER
PRIMER BULB
Choke Closed
Cold Start
Position
Choke Open
Warm Start or
Run Position

Instruction Manual
MAINTENANCE, CLEANING & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty.
Keep the machine clean for better and safer performance.
MAINTENANCE
•Before each use, check all nuts & bolts to be sure they are sufficiently tightened.
•We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so
could invalidate your manufacturer’s warranty.
•The engine must be switched off, with the spark plug cap removed, before the machine is unassembled,
cleaned, serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper
adjustment may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug after every 10-15 hours of use.
•Remove the Spark Plug cap
•Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it anti-clockwise.
•Clean & adjust the electrode gap to 0.6-0.7mm
•If the Spark Plug is visibly damaged or worn, replace immediately (See Specification for details)
•Install the new/cleaned Spark Plug to finger tightness, before fully tightening with the spanner.
CLEANING
Keep your machine clean.
Thoroughly clean the machine at the end of each use, paying particular attention to cuttings in and around
the guard and cutting tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumption and allow abrasive
particles to pass in the engine. Remove & clean the air filter regularly to ensure optimum performance.
•Remove the air filter cover, by releasing the securing winged screw from the front of the cover.
•Lift off the cover.
•Remove the sponge air filter from the housing.
•Tap the filter to remove light surface dust.
•Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
•The fuel tank is fitted with a filter. It is situated at the free end of fuel pipe and can be picked out through
the fuel filler neck, with a piece of hooked wire or similar.
•Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause
difficulty in starting the engine or abnormalities in engine performance.
•When the filter is dirty, replace the filter.
•When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
•It is advisable to remove the Suction & Blower tubes from the machine regularly for cleaning.
•Use Soapy water to remove any dirt or grime.
ENGINE STARTING & STOPPING PROCEDURE
STARTING A COLD ENGINE
1. Place the machine onto a flat, firm surface.
2. Keep the machine clear of any surrounding objects
3. Move the stop switch to "START" position
4. Give a gentle push on the primer pump repeatedly (7-10 times) until fuel comes into the primer pump.
5. Pull the Choke Lever up to close the choke
6. Whilst holding the machine down with your left hand, away from the engine and pull the engine recoil
starter rope vigorously, until the engine false starts.
(DO NOT LET THE RECOIL STARTER ROPE RETRACT BY ITSELF, FEED THE ROPE BACK INTO THE HOUSING)
7. Push the choke lever downwards (excessive cranking with choke lever up will cause the engine to flood,
making it difficult to start.)
8. Pull starter handle until engine starts.
IMPORTANT
When the engine starts, for maximum performance and operating life, allow the engine to warm before use.
9. Run the engine at idle speed until operating temperature is reached (2 to 3 minutes).
10. As the engine warms, open the choke gradually by slowly pushing the choke control into the fully open
position.
11. The engine should now be ready to use.
STARTING A WARM ENGINE
1. Move the switch to "START" position
2. If the fuel tank was run dry on previous operation, follow steps 3-7 of cold start procedure.
3. Whilst holding the machine down with your left hand, away from the engine and pull the engine recoil
starter rope vigorously, until the engine starts.
IF THE ENGINE DOES NOT START
1. Repeat the appropriate starting procedures for “hot” or “cold” engine. If the engine still will not start,
follow the “Starting a Flooded Engine” procedure (below).
STARTING A FLOODED ENGINE
1. Disconnect the spark plug cap & lead, and use the spark plug spanner to remove the plug in an anti-
clockwise direction.
2. If the spark plug is fouled or is soaked with fuel, clean or replace the plug as required.
STOPPING THE ENGINE
1. Move the stop switch to the “STOP” position
CHOKE LEVER
PRIMER BULB
Choke Closed
Cold Start
Position
Choke Open
Warm Start or
Run Position

Instruction Manual
STORAGE
•For years of trouble free service, make sure the machine is clean and dry beforestoring.
•Before storing, clean the machine thoroughly as indicated above.
•Store indoors or in a safe, locked protected area during severe weather and winter months.
•DO NOT STORE in an enclosed area, where fuel vapors can reach an open hot flame.
•DO NOT STORE fuel in the machine. Ensure fuel is removed from the fuel tank and carburetor.
•If storing for an extended period, inspect, clean and repair the machine if necessary. Remove all fuel from
the fuel tank. Start the engine, this will remove all fuel from the carburetor and fuel lines. Remove the
spark plug, pour a small quantity of 2-stroke oil into the spark plug hole of the cylinder and re-seat spark
plug. Store in a clean, dry, dust free area.
DO NOT STORE FUEL FOR LONGER THAN 30 DAYS. FUEL CAN BECOME STALE AND CAUSE DAMAGE TO THE
ENGINE CARBURETOR, WHICH IS NOT COVERED BY THE MACHINES MANUFACTURER’S WARRANTY.
TROUBLE SHOOTING
•Failures such as a difficulty in starting the engine, irregularity in functions and abnormality in performance
can normally be prevented if careful attention is paid to all operating instructions and maintenance
procedures.
•Should the engine not function properly, check the following?
•That the fuel system is in good condition and fuel is flowing to the engine.
•The ignition system is in good condition and the spark plug, sparks correctly.
•Compression of the engine is adequate.
FAILURE TO START
•Correctly follow the starting procedure, not setting the choke lever or priming the engine can cause the
engine to not start.
•Dispose of fuel from the tank, particularly if over 30 days old.
•Ensure that fuel is fresh and clean.
•Check fuel filter to ensure it is clean. (Replace filter if necessary).
•Make sure air filter elements are clean.
•Install a new, properly gapped spark plug.
•When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved
service dealer inspect it for you.

Notes
Instruction Manual
STORAGE
•For years of trouble free service, make sure the machine is clean and dry beforestoring.
•Before storing, clean the machine thoroughly as indicated above.
•Store indoors or in a safe, locked protected area during severe weather and winter months.
•DO NOT STORE in an enclosed area, where fuel vapors can reach an open hot flame.
•DO NOT STORE fuel in the machine. Ensure fuel is removed from the fuel tank and carburetor.
•If storing for an extended period, inspect, clean and repair the machine if necessary. Remove all fuel from
the fuel tank. Start the engine, this will remove all fuel from the carburetor and fuel lines. Remove the
spark plug, pour a small quantity of 2-stroke oil into the spark plug hole of the cylinder and re-seat spark
plug. Store in a clean, dry, dust free area.
DO NOT STORE FUEL FOR LONGER THAN 30 DAYS. FUEL CAN BECOME STALE AND CAUSE DAMAGE TO THE
ENGINE CARBURETOR, WHICH IS NOT COVERED BY THE MACHINES MANUFACTURER’S WARRANTY.
TROUBLE SHOOTING
•Failures such as a difficulty in starting the engine, irregularity in functions and abnormality in performance
can normally be prevented if careful attention is paid to all operating instructions and maintenance
procedures.
•Should the engine not function properly, check the following?
•That the fuel system is in good condition and fuel is flowing to the engine.
•The ignition system is in good condition and the spark plug, sparks correctly.
•Compression of the engine is adequate.
FAILURE TO START
•Correctly follow the starting procedure, not setting the choke lever or priming the engine can cause the
engine to not start.
•Dispose of fuel from the tank, particularly if over 30 days old.
•Ensure that fuel is fresh and clean.
•Check fuel filter to ensure it is clean. (Replace filter if necessary).
•Make sure air filter elements are clean.
•Install a new, properly gapped spark plug.
•When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved
service dealer inspect it for you.

PARTS DIAGRAM - WEBV26 ENGINE (193867003)
PARTS LIST - WEBV26 ENGINE (193867003)
Item
Part No
Description
Qty
Item
Part No
Description
Qty
1
WE03130010013
Champion Spark
Plug RCJ6Y
1
23
WE03010010069
Bolt M5x30
3
2
WE03010010062
Bolt M5x20
4
24
WE02050030260
Flywheel
1
3
WE70070130011
Cylinder
1
25
WE02070010082
Insulating
Gasket
1
4
WE02070010020
Cylinder Gasket
1
26
WE02110030036
Insulator
1
5
WE02020020003
Piston Ring
2
27
WE03020020012
Bolt M5x20
2
6
WE02010020006
Piston
1
28
WE02070010071
Carburettor
Gasket
1
7
WE02020010004
Piston Pin 8x28
1
29
WE02050020296
Carburettor
1
8
WE02020030017
Snap Ring
2
30
WE70030040039
Choke Lever
1
9
WE03090020018
Needle Bearing
1
31
WE70030040059
Air Filter
Housing
1
10
WE02020150007
Thrust Washer
2
32
WE70030040028
Choke
1
11
WE02020120026
Crankshaft
Assembly
1
33
WE03010040023
Bolt ST4x10
1
12
WE03090010028
Bearing 6001/P5
2
34
WE02090010011
Air Filter
1
13
WE02070010048
Spacer
2
35
WE03020020031
Bolt M5x60
2
14
WE02070010111
Crankcase Gasket
1
36
WE70030040078
Air Filter Cover
1
15
WE70070050109
Rear Crankcase
1
37
WE70030180012
Cover Knob
1
16
WE03100010010
Oil Seal 12x22x7
2
38
WE02070010141
Exhaust Gasket
1
17
WE02050050141
Stop Ring
1
39
WE02050010018
Exhaust
1
18
WE02050100015
Starter Pawl
1
40
WE03040020020
Washer 5A
4
19
WE02050030024
Ignition Coil
1
41
WE03050010015
Washer 5B
4
20
WE03020020054
Screw M4x20
2
42
WE03010010050
Screw M5x50
2
21
WE03070010001
Woodruff Key
3*3.7*12
1
43
WE03040010008
Washer 4
2
22
WE70070050108
Front Crankcase
1

PARTS DIAGRAM - WEBV26 ENGINE (193867003)
PARTS LIST - WEBV26 ENGINE (193867003)
Item Part No Description Qty Item Part No Description Qty
1 WE03130010013
Champion Spark
Plug RCJ6Y
1 23 WE03010010069 Bolt M5x30 3
2
WE03010010062 Bolt M5x20 4
24
WE02050030260 Flywheel 1
3 WE70070130011 Cylinder 1 25 WE02070010082
Insulating
Gasket
1
4
WE02070010020
Cylinder Gasket
1
26
WE02110030036
Insulator
1
5
WE02020020003 Piston Ring 2
27
WE03020020012 Bolt M5x20 2
6 WE02010020006 Piston 1 28 WE02070010071
Carburettor
Gasket
1
7
WE02020010004
Piston Pin 8x28
1
29
WE02050020296
Carburettor
1
8
WE02020030017 Snap Ring 2
30
WE70030040039 Choke Lever 1
9 WE03090020018 Needle Bearing 1 31 WE70030040059
Air Filter
Housing
1
10
WE02020150007
Thrust Washer
2
32
WE70030040028
Choke
1
11 WE02020120026
Crankshaft
Assembly
1 33 WE03010040023 Bolt ST4x10 1
12 WE03090010028 Bearing 6001/P5 2 34 WE02090010011 Air Filter 1
13
WE02070010048
Spacer
2
35
WE03020020031
Bolt M5x60
2
14 WE02070010111 Crankcase Gasket 1 36 WE70030040078 Air Filter Cover 1
15
WE70070050109
Rear Crankcase
1
37
WE70030180012
Cover Knob
1
16 WE03100010010 Oil Seal 12x22x7 2 38 WE02070010141 Exhaust Gasket 1
17
WE02050050141
Stop Ring
1
39
WE02050010018
Exhaust
1
18 WE02050100015 Starter Pawl 1 40 WE03040020020 Washer 5A 4
19
WE02050030024
Ignition Coil
1
41
WE03050010015
Washer 5B
4
20 WE03020020054 Screw M4x20 2 42 WE03010010050 Screw M5x50 2
21 WE03070010001
Woodruff Key
3*3.7*12
1 43 WE03040010008 Washer 4 2
22
WE70070050108 Front Crankcase 1

PARTS DIAGRAM - WEBV26 MACHINE (193867003)
PARTS LIST - WEBV26 MACHINE (193867003)
Item
Part No.
Description
Qty
Item
Part No.
Description
Qty
1
WE70050010068
Tube A
1
30
WE70030160048
Upper Handle
1
2
WE70050010069
Tube B
1
31
WE03010040068
Screw ST4.2x12
1
3
WE03010040048
Screw M5x16
11
32
WE03010040025
Screw ST4.2x13
1
4
WE03020020028
Screw M5x16
3
33
WE02050050141
Stop Wire
1
5
WE70030030284
Connect Cover
1
34
WE51010040002
Engine
1
6
WE03010060078
Screw M5x10
3
35
WE03110020023
Seal 2.5x2
1
7
WE70030180100
Safety Cover
1
36
WE70030031189
Recoil Casing
1
8
WE02050050002
Safety Switch
1
37
WE70030160229
Throttle Lock
1
9
WE70030070032
Button
Connector
1
38
WE03040050074
Washer
1
10
WE03040050017
Washer 6
1
39
WE70030160230
Throttle Lock
Joint
1
11
WE70030180015
Screw
1
40
WE03020020018
Screw M5x10
3
12
WE70030031188
Fan Cover
1
41
WE03020020041
Screw M5x30
5
13
WE02020160312
Spring Shaft
1
42
WE70050010070
Curved Tube
1
14
WE02020110048
Spring
1
43
WE02050040087
Throttle Wire
1
15
WE70030010071
Rear Case
1
44
WE02050060050
Collection Bag
1
16
WE03030020002
Nut M8x1
1
45
WE02050060022
Harness
1
17
WE02020070042
Shatter Tooth
1
46
WE02120010045
Fuel Return Pipe
(L=70)
1
18
WE70030090019
Impellor
1
47
WE02080030025
Fuel Pipe
Rubber Bung
1
19
WE03010010069
Screw M5x30
4
48
WE02120010044
Fuel Inlet Pipe
(L=220)
1
20
WE02080020046
Left Hand
Rubber Cover
2
49
WE02050120002
Fuel Filter
1
21
WE70030010550
Body
1
50
WE02110020026
Fuel Cap
Assembly
1
22
WE02020160117
Pedestal
4
51
WE03050010007
Washer 8
1
23
WE70050030063
Fuel Tank
1
52
WE03040050005
Washer 23*8*1
1
24
WE03010040057
Screw M5x20
2
53
WE70050010066
Tube C
1
25
WE70030160093
Lower Handle
1
54
WE70050010188
Tube D
1
26
WE02020160398
Throttle Lever
Shaft
1
55
WE02050070129
Recoil Assembly
1
27
WE70030070716
Throttle Lever
Handle
1
56
WE02040030020
Bush
1
28
WE02050050344
Stop Switch
1
57
WE02080030015
Wire Lead
1
29
WE02050050171
Short Stop Wire
2

PARTS DIAGRAM - WEBV26 MACHINE (193867003)
PARTS LIST - WEBV26 MACHINE (193867003)
Item
Part No.
Description
Qty
Item
Part No.
Description
Qty
1
WE70050010068
Tube A
1
30
WE70030160048
Upper Handle
1
2
WE70050010069
Tube B
1
31
WE03010040068
Screw ST4.2x12
1
3
WE03010040048
Screw M5x16
11
32
WE03010040025
Screw ST4.2x13
1
4
WE03020020028
Screw M5x16
3
33
WE02050050141
Stop Wire
1
5
WE70030030284
Connect Cover
1
34
WE51010040002
Engine
1
6
WE03010060078
Screw M5x10
3
35
WE03110020023
Seal 2.5x2
1
7
WE70030180100
Safety Cover
1
36
WE70030031189
Recoil Casing
1
8
WE02050050002
Safety Switch
1
37
WE70030160229
Throttle Lock
1
9 WE70030070032
Button
Connector
1 38 WE03040050074 Washer 1
10 WE03040050017 Washer 6 1 39 WE70030160230
Throttle Lock
Joint
1
11
WE70030180015
Screw
1
40
WE03020020018
Screw M5x10
3
12
WE70030031188
Fan Cover
1
41
WE03020020041
Screw M5x30
5
13
WE02020160312
Spring Shaft
1
42
WE70050010070
Curved Tube
1
14
WE02020110048
Spring
1
43
WE02050040087
Throttle Wire
1
15
WE70030010071
Rear Case
1
44
WE02050060050
Collection Bag
1
16
WE03030020002
Nut M8x1
1
45
WE02050060022
Harness
1
17 WE02020070042 Shatter Tooth 1 46 WE02120010045
Fuel Return Pipe
(L=70)
1
18 WE70030090019 Impellor 1 47 WE02080030025
Fuel Pipe
Rubber Bung
1
19 WE03010010069 Screw M5x30 4 48 WE02120010044
Fuel Inlet Pipe
(L=220)
1
20 WE02080020046
Left Hand
Rubber Cover
2 49 WE02050120002 Fuel Filter 1
21 WE70030010550 Body 1 50 WE02110020026
Fuel Cap
Assembly
1
22
WE02020160117
Pedestal
4
51
WE03050010007
Washer 8
1
23
WE70050030063
Fuel Tank
1
52
WE03040050005
Washer 23*8*1
1
24
WE03010040057
Screw M5x20
2
53
WE70050010066
Tube C
1
25
WE70030160093
Lower Handle
1
54
WE70050010188
Tube D
1
26 WE02020160398
Throttle Lever
Shaft
1 55 WE02050070129 Recoil Assembly 1
27 WE70030070716
Throttle Lever
Handle
1 56 WE02040030020 Bush 1
28
WE02050050344
Stop Switch
1
57
WE02080030015
Wire Lead
1
29
WE02050050171
Short Stop Wire
2

EC DECLARATION OF CONFORMITY
We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product:
Designation: 26cc Petrol Blower & Vacuum
Model(s): WEBV26
Product No. 193867003
Type/Serial No. As per rating label on machine
Complies with the following directives:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
Noise Emission of Outdoor Equipment Directive 2000/14/EC
The conformity assessment procedure followed was in accordance with
EN ISO 12100-2/A1:2009
EN 15503:2009/A1:2013
EN ISO 14982:2009
Guaranteed Sound Power Level: LWA = 112dB(A)
Vibration Level: ah (Max) 16.1m/s² - Uncertainty K=3dB(A)
Notified Body:
TÜV SÜD Product Service GmbH
Addresses:
Zertifizierselle, Ridlerstraße 65, 80339 München, Germany
Authorised signatory and technical file holder
Date: 17/01/2019
Signature:
Name: Mr Simon Belcher
Position: Managing Director
Company: Handy Distribution Ltd
Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY.
Instruction Manual

Notes
EC DECLARATION OF CONFORMITY
We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product:
Designation: 26cc Petrol Blower & Vacuum
Model(s): WEBV26
Product No. 193867003
Type/Serial No. As per rating label on machine
Complies with the following directives:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
Noise Emission of Outdoor Equipment Directive 2000/14/EC
The conformity assessment procedure followed was in accordance with
EN ISO 12100-2/A1:2009
EN 15503:2009/A1:2013
EN ISO 14982:2009
Guaranteed Sound Power Level: LWA = 112dB(A)
Vibration Level: ah (Max) 16.1m/s² - Uncertainty K=3dB(A)
Notified Body:
TÜV SÜD Product Service GmbH
Addresses:
Zertifizierselle, Ridlerstraße 65, 80339 München, Germany
Authorised signatory and technical file holder
Date: 17/01/2019
Signature:
Name: Mr Simon Belcher
Position: Managing Director
Company: Handy Distribution Ltd
Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY.
Instruction Manual

Notes
Instruction Manual
