Webb WEBV26 User manual

Please read & understand this manual, paying particular attention to the safety instructions, before use.
Operator’s Manual & Parts List
6 July 2016
193867001
26cc Petrol Garden
Blower & Vacuum
WEBV26
WEBV26 193867001 IM.indd 1 06/07/2016 09:07

CONTENTS
SAFETY INSTRUCTIONS
SPECIFICATIONS
COMPONENTS
ASSEMBLY
OPERATION
MAINTENANCE, CLEANING & STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
For Spares or Support of your Webb product, please contact us:
Tel: [phone]
(Mon – Fri 8.30am to 5.00pm)
Email: [email protected]
www.webblawnmowers.co.uk
WEBV26 193867001 IM.indd 2 06/07/2016 09:07

CONTENTS
SAFETY INSTRUCTIONS
SPECIFICATIONS
COMPONENTS
ASSEMBLY
OPERATION
MAINTENANCE, CLEANING & STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
For Spares or Support of your Webb product, please contact us:
Tel: [phone]
(Mon – Fri 8.30am to 5.00pm)
Email: [email protected]
www.webblawnmowers.co.uk
WEBV26 193867001 IM.indd 3 06/07/2016 09:07

STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medicaon that could affect
your ability to use it properly. Do not use this machine when you are red or distracted from the job at hand.
Be aware of what you are doing at all mes. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluered areas invite injuries.
Keep your work area clean with sufficient light. Keep area around the machine clear of obstrucons, stones,
scks, wires and other debris or foreign bodies which could cause damage to the machine.
DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for ghtness before each use, especially those securing guards and drive
mechanisms. Vibraon during use may cause these to loosen.
Replace damaged, missing or failed parts before using.
Warning labels carry important informaon.
Replace any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckes or jewelry (rings, wrist watches), which can be caught in
moving parts.
ALWAYS wear protecve eye and ear wear. Appropriate gloves are also recommended.
Wear protecve hair covering to contain long hair, prevenng it from geng caught in machinery.
DO NOT use whilst barefoot or wearing open toed footwear.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower. Do not allow
children to handle, use, or climb on the lawnmower.
DO NOT OVERREACH
Keep proper foong and balance at all mes, parcularly if using on slopes. The machine should not be used
on steep slopes and always be sure of foong.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, parcularly the engine and rotang cung tool.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately aer use. Keep the machine clean to ensure it operates to its full and safest
performance. When maintaining this machine, only the manufacturer’s original replacement parts should be
used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry locaon. Keep the machine away from children and
others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale
and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its applicaon and
limitaons as well as the specific potenal hazards. Retain these instrucons for future reference. The
operator is responsible for following the warnings & instrucons in this manual and on the product.
Read & understand operator’s manual
before using the machine. Failure to
follow instrucons could result in
death or serious injury.
This graphic and when accompanied by
WARNING or DANGER, calls aenon
to acons which could lead to SERIOUS
INJURY
Always wear eye and ear protecon
WARNING
Never modify a machine in any way.
Incorrect use of a machine can cause
SERIOUS OR FATAL PERSONAL INJURY
Always wear gloves to protect your
hands.
SHARP ROTATING BLADES
It is advisable to wear a face mask to
stop debris from entering your body.
Always TURN OFF THE ENGINE,
ensuring the cung tool has stopped,
before cleaning, removing or adjusng
the machine tubes.
15m
Keep all bystanders & animals at least
15 metres away from the machine
during operaon.
If approached, stop the machine
immediately.
No smoking
Risk of Carbon Monoxide Poisoning.
Ensure working area is correctly
venlated.
Do not use near a flame, or sparks
Fire Risk
Fire and its vapors are extremely
flammable & explosive.
Fire or explosion can cause severe
burns or death.
Moving Parts
Rotang parts can contact or entangle
hands, feet, hair, clothing or
accessories.
Traumac amputaonor severe
laceraon can result
Hot Surface.
Running engines produce heat. Engine
parts, especially the exhaust, become
extremely hot.
Severe thermal burns can occur on
contact
Safety alert symbol. Used to alert you to potenal personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situaon which, if not avoided, will result in serious injury.
WARNING
Indicates a potenally hazardous situaon which, if not avoided, could result in serious injury
CAUTION
Indicates a potenally hazardous situaon which, if not avoided, may result in minoror moderate injury.
CAUTION
Used without the safety alert symbol indicates a potenally hazardous situaon which, if not avoided, may
result in property damage.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 4 06/07/2016 09:07

STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medicaon that could affect
your ability to use it properly. Do not use this machine when you are red or distracted from the job at hand.
Be aware of what you are doing at all mes. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluered areas invite injuries.
Keep your work area clean with sufficient light. Keep area around the machine clear of obstrucons, stones,
scks, wires and other debris or foreign bodies which could cause damage to the machine.
DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for ghtness before each use, especially those securing guards and drive
mechanisms. Vibraon during use may cause these to loosen.
Replace damaged, missing or failed parts before using.
Warning labels carry important informaon.
Replace any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckes or jewelry (rings, wrist watches), which can be caught in
moving parts.
ALWAYS wear protecve eye and ear wear. Appropriate gloves are also recommended.
Wear protecve hair covering to contain long hair, prevenng it from geng caught in machinery.
DO NOT use whilst barefoot or wearing open toed footwear.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower. Do not allow
children to handle, use, or climb on the lawnmower.
DO NOT OVERREACH
Keep proper foong and balance at all mes, parcularly if using on slopes. The machine should not be used
on steep slopes and always be sure of foong.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, parcularly the engine and rotang cung tool.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately aer use. Keep the machine clean to ensure it operates to its full and safest
performance. When maintaining this machine, only the manufacturer’s original replacement parts should be
used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry locaon. Keep the machine away from children and
others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale
and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its applicaon and
limitaons as well as the specific potenal hazards. Retain these instrucons for future reference. The
operator is responsible for following the warnings & instrucons in this manual and on the product.
Read & understand operator’s manual
before using the machine. Failure to
follow instrucons could result in
death or serious injury.
This graphic and when accompanied by
WARNING or DANGER, calls aenon
to acons which could lead to SERIOUS
INJURY
Always wear eye and ear protecon
WARNING
Never modify a machine in any way.
Incorrect use of a machine can cause
SERIOUS OR FATAL PERSONAL INJURY
Always wear gloves to protect your
hands.
SHARP ROTATING BLADES
It is advisable to wear a face mask to
stop debris from entering your body.
Always TURN OFF THE ENGINE,
ensuring the cung tool has stopped,
before cleaning, removing or adjusng
the machine tubes.
15m
Keep all bystanders & animals at least
15 metres away from the machine
during operaon.
If approached, stop the machine
immediately.
No smoking
Risk of Carbon Monoxide Poisoning.
Ensure working area is correctly
venlated.
Do not use near a flame, or sparks
Fire Risk
Fire and its vapors are extremely
flammable & explosive.
Fire or explosion can cause severe
burns or death.
Moving Parts
Rotang parts can contact or entangle
hands, feet, hair, clothing or
accessories.
Traumac amputaonor severe
laceraon can result
Hot Surface.
Running engines produce heat. Engine
parts, especially the exhaust, become
extremely hot.
Severe thermal burns can occur on
contact
Safety alert symbol. Used to alert you to potenal personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situaon which, if not avoided, will result in serious injury.
WARNING
Indicates a potenally hazardous situaon which, if not avoided, could result in serious injury
CAUTION
Indicates a potenally hazardous situaon which, if not avoided, may result in minoror moderate injury.
CAUTION
Used without the safety alert symbol indicates a potenally hazardous situaon which, if not avoided, may
result in property damage.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 5 06/07/2016 09:07

COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collecon Bag
4. Sucon Pipe A
5. Sucon Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/OffSwitch
9. Throle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank
14. Fuel Cap
15. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
15
14
5
SPECIFICATIONS
Model WEBV26
Product Number 193867001
Engine (cc) 25.4
Idle Speed (r/min) 3000+200
Fuel Tank Capacity (Litre) 0.5
Fuel Ra o (Petrol:2 Stroke Mineral Oil)Stro
25:1
Dimensions (mm) L-580, W-355, H-370
Weight (kgs) N.W 4.8 - G.W 7.8
The manufacturer reserves the right to change the product specificn and livery according to con ued
product improvements.
This symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable colle on point for the recycling of electrical and
electronic equipment.
For more detailed informa on about recycling of this product, please contact your local council office, your
household waste disposal service or shop where you purchased the product.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 6 06/07/2016 09:07

COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collecon Bag
4. Sucon Pipe A
5. Sucon Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/OffSwitch
9. Throle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank
14. Fuel Cap
15. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
15
14
5
SPECIFICATIONS
Model WEBV26
Product Number 193867001
Engine (cc) 25.4
Idle Speed (r/min) 3000+200
Fuel Tank Capacity (Litre) 0.5
Fuel Ra o (Petrol:2 Stroke Mineral Oil)Stro
25:1
Dimensions (mm) L-580, W-355, H-370
Weight (kgs) N.W 4.8 - G.W 7.8
The manufacturer reserves the right to change the product specificn and livery according to con ued
product improvements.
This symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable colle on point for the recycling of electrical and
electronic equipment.
For more detailed informa on about recycling of this product, please contact your local council office, your
household waste disposal service or shop where you purchased the product.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 7 06/07/2016 09:07

BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same acon aaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING
EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL
APPROVED DEALER FOR ASSISTANCE
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: [phone] - Mon – Fri 8.30am – 5.00pm (excl. Bank Holidays)
Email: [e-mail]
VACUUM ASSEMBLY
1. Open the fan cover, by loosening the top screw and allowing the fan cover to open.
2. Match Sucon Tube A, with the top & boom locking stubs on the body of the machine.
3. Rotate the tube clockwise to lock into place.
4. Repeat the same acons, aaching Sucon Tube B to Sucon Tube A.
5. Insert the Discharge Tube into the Collecon Bag and secure.
6. Connect the Discharge Tube to the Discharge Outlet of the machine and secure with an M5x10 screw
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 8 06/07/2016 09:07

BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same acon aaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING
EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL
APPROVED DEALER FOR ASSISTANCE
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: [phone] - Mon – Fri 8.30am – 5.00pm (excl. Bank Holidays)
Email: [e-mail]
VACUUM ASSEMBLY
1. Open the fan cover, by loosening the top screw and allowing the fan cover to open.
2. Match Sucon Tube A, with the top & boom locking stubs on the body of the machine.
3. Rotate the tube clockwise to lock into place.
4. Repeat the same acons, aaching Sucon Tube B to Sucon Tube A.
5. Insert the Discharge Tube into the Collecon Bag and secure.
6. Connect the Discharge Tube to the Discharge Outlet of the machine and secure with an M5x10 screw
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 9 06/07/2016 09:07

FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking.
Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine
running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
Use good quality unleaded fuel which contains NO ETHANOL or METHANOL. Use Branded 89 octane or higher
unleaded fuel, known to be of good quality.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essen al carburetor components. This could result in star ng issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use Handy Parts – Sure Start Garden Machinery Fuel Addi ve which is
available in 250ml bo les, for 25 litres of fuel.
Helps makes machines easier to start
Extends shelf life of petrol up to 2 years
Keeps carburetor & engine clean
Reduces emissions & increases fuel economy
Only use 2-stroke air cooled engine oil. DO NOT USE automo ve or marine oil.
It is recommended that you use a Fuel Mixing Bo le, to ensure the correct fuel mixture is used with your
machine. We recommend Handy Parts item HP-120. The fuel mixture should be shaken prior to entering the
machine fuel tank.
Mix only the quan ty you require to complete your specific task.
Unscrew the machine fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80%
capacity. This will allow for fuel tank expansion.
Fasten the fuel cap tly, being careful not to cross-thread. This will also prevent loosening through vibra on
during use.
Wipe away any spillage, with an appropriate material.
If the machine has con nued leaks, the product should not be started. Never use the machine with damaged
igni n cable or spark plug cap, as there is a risk of sparks.
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a maximum
of 4-6 weeks.
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start the engine
and drain the carburetor of any remaining fuel. (See Maintenance for further instru on)
Dispose of any unwanted 2-stroke mixture at an authorised recycling point.
Unleaded
Petrol – litre
Two-Stroke
Mineral Oil - ml
1
40
2
80
3
120
4
160
5
200
OPERATION
DANGER
All model Blowers can throw small stones, metal or small objects as well as material. Do not allow anyone to
enter the operang DANGER ZONE with you. The danger zone is an area 15 metres in radius.
Insist that persons in the RISK ZONE beyond the danger zone wear eye protecon from thrown objects. If
the unit must be used where there are unprotected people, operate at a low throle speed to reduce the
risk of thrown objects.
DANGER ZONE WITHIN 15 METRES - RISK ZONE GREATER THAN 15 METRES
GENERAL USE
WARNING
Prior to usingthe machine, ensure all hardware (bolts, screws & nuts) are securely ghtened.
Operate the trigger with your right hand & hold the Lower Handle with your lehand.
The trigger increases and decreases the power of the engine to the aachment, increasing the
revoluon/reciprocaon of the aachment.
WORKING PLAN
Blow material to a safe collecon point, away from stones and other hard debris, which could damage the
mulching fan within the machine.
Limit the amount of me the product is used connuously to a maximum of 40 minutes per session.
Leave the machine to rest between sessions for between 10-20 minutes.
Total amount of work performed per day with the machine, should be limited to 120 minutes maximum.
Connuous use of the machine can cause “Repeve Stress Injury (RSI)”. If you feel discomfort, redness or
swelling of your hands and fingers or any other body part, consult your doctor.
Check local regulaons for sound level and hours of operaon constraints.
Never transport the machine, whilst the engine is running.
USING THE VACUUM
When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is
not thrown.
When the bag is full, open the zip on the bag and p the contents into a recycling bin or compost heap.
USING THE BLOWER
Always be aware of the strength and direcon of the air stream.
Never direct the blower towards period or animals.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 10 06/07/2016 09:07

FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking.
Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine
running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
Use good quality unleaded fuel which contains NO ETHANOL or METHANOL. Use Branded 89 octane or higher
unleaded fuel, known to be of good quality.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essen al carburetor components. This could result in star ng issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use Handy Parts – Sure Start Garden Machinery Fuel Addi ve which is
available in 250ml bo les, for 25 litres of fuel.
Helps makes machines easier to start
Extends shelf life of petrol up to 2 years
Keeps carburetor & engine clean
Reduces emissions & increases fuel economy
Only use 2-stroke air cooled engine oil. DO NOT USE automo ve or marine oil.
It is recommended that you use a Fuel Mixing Bo le, to ensure the correct fuel mixture is used with your
machine. We recommend Handy Parts item HP-120. The fuel mixture should be shaken prior to entering the
machine fuel tank.
Mix only the quan ty you require to complete your specific task.
Unscrew the machine fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80%
capacity. This will allow for fuel tank expansion.
Fasten the fuel cap tly, being careful not to cross-thread. This will also prevent loosening through vibra on
during use.
Wipe away any spillage, with an appropriate material.
If the machine has con nued leaks, the product should not be started. Never use the machine with damaged
igni n cable or spark plug cap, as there is a risk of sparks.
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a maximum
of 4-6 weeks.
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start the engine
and drain the carburetor of any remaining fuel. (See Maintenance for further instru on)
Dispose of any unwanted 2-stroke mixture at an authorised recycling point.
Unleaded
Petrol – litre
Two-Stroke
Mineral Oil - ml
1
40
2
80
3
120
4
160
5
200
OPERATION
DANGER
All model Blowers can throw small stones, metal or small objects as well as material. Do not allow anyone to
enter the operang DANGER ZONE with you. The danger zone is an area 15 metres in radius.
Insist that persons in the RISK ZONE beyond the danger zone wear eye protecon from thrown objects. If
the unit must be used where there are unprotected people, operate at a low throle speed to reduce the
risk of thrown objects.
DANGER ZONE WITHIN 15 METRES - RISK ZONE GREATER THAN 15 METRES
GENERAL USE
WARNING
Prior to usingthe machine, ensure all hardware (bolts, screws & nuts) are securely ghtened.
Operate the trigger with your right hand & hold the Lower Handle with your lehand.
The trigger increases and decreases the power of the engine to the aachment, increasing the
revoluon/reciprocaon of the aachment.
WORKING PLAN
Blow material to a safe collecon point, away from stones and other hard debris, which could damage the
mulching fan within the machine.
Limit the amount of me the product is used connuously to a maximum of 40 minutes per session.
Leave the machine to rest between sessions for between 10-20 minutes.
Total amount of work performed per day with the machine, should be limited to 120 minutes maximum.
Connuous use of the machine can cause “Repeve Stress Injury (RSI)”. If you feel discomfort, redness or
swelling of your hands and fingers or any other body part, consult your doctor.
Check local regulaons for sound level and hours of operaon constraints.
Never transport the machine, whilst the engine is running.
USING THE VACUUM
When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is
not thrown.
When the bag is full, open the zip on the bag and p the contents into a recycling bin or compost heap.
USING THE BLOWER
Always be aware of the strength and direcon of the air stream.
Never direct the blower towards period or animals.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 11 06/07/2016 09:07

MAINTENANCE, CLEANING & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty.
Keep the machine clean for beer and safer performance.
MAINTENANCE
Before each use, check all nuts & bolts to be sure they are sufficiently ghtened.
We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so could
invalidate your manufacturer’s warranty.
The engine must be switched off, with the spark plug cap removed, before the machine is unassembled, cleaned,
serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper adjustment
may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug aer every 10-15 hours of use.
Remove the Spark Plug cap
Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it an-clockwise.
Clean & adjust the electrode gap to 0.6-0.7mm
If the Spark Plug is visibly damaged or worn, replace immediately (See Specificaon for details)
Install the new/cleaned Spark Plug to finger ghtness, before fully ghtening with the spanner.
CLEANING
Keep your machine clean.
Thoroughly clean the machine at the end of each use, paying parcular aenon to cungs in and around the guard and
cung tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumpon and allow abrasive parcles to
pass in the engine. Remove & clean the air filter regularly to ensure opmum performance.
Remove the air filter cover, by releasing the securingwinged screw from the front of the cover.
Lioffthe cover.
Remove the sponge air filter from the housing.
Tap the filter to remove light surface dust.
Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
The fuel tank is fied with a filter. It is situated at the free end of fuel pipe and can be picked out through the fuel filler
neck, with a piece of hooked wire or similar.
Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause difficulty in
starng the engine or abnormalies in engine performance.
When the filter is dirty, replace the filter.
When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
It is advisable to remove the Sucon & Blower tubes from the machine regularly for cleaning.
Use Soapywater to remove any dirt or grime.
ENGINE STARTING & STOPPING PROCEDURE
STARTING A COLD ENGINE
1. Place the machine onto a flat, firm surface.
2. Keep the machine clearof any surrounding objects
3. Move the stop switch to "START" posion
4. Give a gentle push on the primerpump repeatedly (7-10 mes) unl fuel comes into the primerpump.
5. Pull the Choke Leverup to close the choke
6. Whilst holding the machine down with yourlehand, away from the engine and pull the engine recoil starterrope
vigorously, unl the engine false starts.
(DO NOT LET THE RECOIL STARTER ROPE RETRACT BY ITSELF, FEED THE ROPE BACK INTO THE HOUSING)
7. Push the choke leverdownwards (excessive cranking with choke leverup will cause the engine to flood, making it
difficult to start.)
8. Pull starter handle unl engine starts.
9. Allow engine to warm up for a few minutes before using.
STARTING A WARM ENGINE
1. Move the switch to "START" posion
2. If the fuel tank was run dry on previous operaon, follow steps 3-7 of cold startprocedure.
3. Whilst holding the machine down with yourlehand, away from the engine and pull the engine recoil starterrope
vigorously, unl the engine false starts.
STOPPING THE ENGINE
1. Move the stop switch to the “STOP” posion
Choke Closed
Cold Start
Posion
Choke Open
Warm Start or
Run Posion
CHOKE LEVER
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 12 06/07/2016 09:07

MAINTENANCE, CLEANING & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty.
Keep the machine clean for beer and safer performance.
MAINTENANCE
Before each use, check all nuts & bolts to be sure they are sufficiently ghtened.
We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so could
invalidate your manufacturer’s warranty.
The engine must be switched off, with the spark plug cap removed, before the machine is unassembled, cleaned,
serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper adjustment
may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug aer every 10-15 hours of use.
Remove the Spark Plug cap
Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it an-clockwise.
Clean & adjust the electrode gap to 0.6-0.7mm
If the Spark Plug is visibly damaged or worn, replace immediately (See Specificaon for details)
Install the new/cleaned Spark Plug to finger ghtness, before fully ghtening with the spanner.
CLEANING
Keep your machine clean.
Thoroughly clean the machine at the end of each use, paying parcular aenon to cungs in and around the guard and
cung tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumpon and allow abrasive parcles to
pass in the engine. Remove & clean the air filter regularly to ensure opmum performance.
Remove the air filter cover, by releasing the securingwinged screw from the front of the cover.
Lioffthe cover.
Remove the sponge air filter from the housing.
Tap the filter to remove light surface dust.
Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
The fuel tank is fied with a filter. It is situated at the free end of fuel pipe and can be picked out through the fuel filler
neck, with a piece of hooked wire or similar.
Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause difficulty in
starng the engine or abnormalies in engine performance.
When the filter is dirty, replace the filter.
When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
It is advisable to remove the Sucon & Blower tubes from the machine regularly for cleaning.
Use Soapywater to remove any dirt or grime.
ENGINE STARTING & STOPPING PROCEDURE
STARTING A COLD ENGINE
1. Place the machine onto a flat, firm surface.
2. Keep the machine clearof any surrounding objects
3. Move the stop switch to "START" posion
4. Give a gentle push on the primerpump repeatedly (7-10 mes) unl fuel comes into the primerpump.
5. Pull the Choke Leverup to close the choke
6. Whilst holding the machine down with yourlehand, away from the engine and pull the engine recoil starterrope
vigorously, unl the engine false starts.
(DO NOT LET THE RECOIL STARTER ROPE RETRACT BY ITSELF, FEED THE ROPE BACK INTO THE HOUSING)
7. Push the choke leverdownwards (excessive cranking with choke leverup will cause the engine to flood, making it
difficult to start.)
8. Pull starter handle unl engine starts.
9. Allow engine to warm up for a few minutes before using.
STARTING A WARM ENGINE
1. Move the switch to "START" posion
2. If the fuel tank was run dry on previous operaon, follow steps 3-7 of cold startprocedure.
3. Whilst holding the machine down with yourlehand, away from the engine and pull the engine recoil starterrope
vigorously, unl the engine false starts.
STOPPING THE ENGINE
1. Move the stop switch to the “STOP” posion
Choke Closed
Cold Start
Posion
Choke Open
Warm Start or
Run Posion
CHOKE LEVER
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 13 06/07/2016 09:07

STORAGE
For years of trouble free service, make sure the machine is clean and dry before storing.
Before storing, clean the machine thoroughly as indicated above.
Store indoors or in a safe, locked protected area during severe weather and winter months.
DO NOT STORE in an enclosed area, where fuel vapors can reach an open hot flame.
DO NOT STORE fuel in the machine. Ensure fuel is removed from the fuel tank and carburetor.
If storing for an extended period, inspect, clean and repair the machine if necessary. Remove all fuel from the fuel tank.
Start the engine, this will remove all fuel from the carburetor and fuel lines. Remove the spark plug, pour a small
quanty of 2-stroke oil into the spark plug hole of the cylinder and re-seat spark plug. Store in a clean, dry, dust free
area.
DO NOT STORE fuel for longer than 30 days. Fuel can become stale and cause damage to the engine carburetor, which is
not covered by the machines manufacturer’s warranty.
TROUBLE SHOOTING
Failures such as a difficulty in starng the engine, irregularity in funcons and abnormality in performance can normally be
prevented if careful aenon is paid toall operang instrucons and maintenance procedures.
Should the engine not funcon properly, check the following?
That the fuel system is in good condion and fuel is flowing to the engine.
The ignion system is in good condion and the spark plug, sparks correctly.
Compression ofthe engine is adequate.
FAILURE TO START
Correctly follow the starng procedure, not seng the choke lever or priming the engine can cause the engine to not
start.
Dispose of fuel from the tank, parcularly if over 30 days old.
Ensure that fuel is fresh and clean.
Check fuel filter to ensure it is clean. (Replace filter if necessary).
Make sure air filter elements are clean.
Install a new, properly gapped spark plug.
When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved service dealer
inspect it for you.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 14 06/07/2016 09:07

STORAGE
For years of trouble free service, make sure the machine is clean and dry before storing.
Before storing, clean the machine thoroughly as indicated above.
Store indoors or in a safe, locked protected area during severe weather and winter months.
DO NOT STORE in an enclosed area, where fuel vapors can reach an open hot flame.
DO NOT STORE fuel in the machine. Ensure fuel is removed from the fuel tank and carburetor.
If storing for an extended period, inspect, clean and repair the machine if necessary. Remove all fuel from the fuel tank.
Start the engine, this will remove all fuel from the carburetor and fuel lines. Remove the spark plug, pour a small
quanty of 2-stroke oil into the spark plug hole of the cylinder and re-seat spark plug. Store in a clean, dry, dust free
area.
DO NOT STORE fuel for longer than 30 days. Fuel can become stale and cause damage to the engine carburetor, which is
not covered by the machines manufacturer’s warranty.
TROUBLE SHOOTING
Failures such as a difficulty in starng the engine, irregularity in funcons and abnormality in performance can normally be
prevented if careful aenon is paid toall operang instrucons and maintenance procedures.
Should the engine not funcon properly, check the following?
That the fuel system is in good condion and fuel is flowing to the engine.
The ignion system is in good condion and the spark plug, sparks correctly.
Compression ofthe engine is adequate.
FAILURE TO START
Correctly follow the starng procedure, not seng the choke lever or priming the engine can cause the engine to not
start.
Dispose of fuel from the tank, parcularly if over 30 days old.
Ensure that fuel is fresh and clean.
Check fuel filter to ensure it is clean. (Replace filter if necessary).
Make sure air filter elements are clean.
Install a new, properly gapped spark plug.
When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved service dealer
inspect it for you.
INSTRUCTION MANUAL
WEBV26 193867001 IM.indd 15 06/07/2016 09:07

PARTS LIST - WEBV26 Engine
Item No Webb Part No. Handy Descripon Qty
Item No Webb Part No. Handy Descripon Qty
1 WE03130010013 Spark Plug RCJ6Y 1
24 WE02050030018 Flywheel 1
2 WE03010010061 Bolt M5X20 4
25 WE02070010078 Insulator Gasket 1
3 WE70070130011 Cylinder 1
26 WE02110030031 Insulator 1
4 WE02070010020 Cylinder Gasket 1
27 WE03020020012 Bolt M5X20 2
5 WE02020020003 Piston Ring 2
28 WE02070010061 Carburretor Gasket 1
6 WE02010020006 Piston 1
29 WE02050020045 Carburetor 1
7 WE02020010004 Piston Pin 8X28 1
30 WE70030040038 Choke Lever 1
8 WE02020030017 Snap Ring 2
31 WE70080120007 Air filter Housing 1
9 WE03090020018 Needle Bearing 1
32 WE70030040028 Choke 1
10 WE02020150007 Thrust Washer 2
33 WE03010040008 Bolt ST4×10 1
11 WE02020120026 CrankshaAssembly 1
34 WE02090010011 Air filter Housing 1
12 WE03090010028 Bearing 6001/P5 2
35 WE03020020030 Bolt M5X60 2
13 WE03060010002 Pin B3X10 2
36 WE70030040078 Air Filter Cover 1
14 WE02070010110 Crankcase Gasket 1
37 WE70030180012 Air Filter Screw 1
15 WE03050010014 Rear Crankcase 1
38 WE02070010141 Exhaust Gasket 1
16 WE03100010009 Oil Seal 12X22X7 2
39 WE02050010018 Exhaust 1
17 WE03120030003 Stop Ring 2
40 WE03040020019 Washer 5 2
18 WE02050100015 Starter Pawl 1
41 WE03050010014 Washer 5 3
19 WE02020110088 Starter Pawl Spring 2
42 WE03010010049 Screw M5X50 2
20 WE70030140015 Starter Pawl 2
43 WE03040010007 Washer 4 2
21 WE03070010002 WoodruffKey 1
44 WE02070010048 Spacer 2
22 WE70070050001 Crankcase - Front 1
45 WE02050050141 Stop Wire 1
23 WE03010010045 Bolt M5X30 3
46 WE02050030024 Ignion Coil 1
47 WE03020020013 Screw M4X20 2
PARTS DIAGRAM - WEBV26 Engine
WEBV26 193867001 IM.indd 16 06/07/2016 09:07

PARTS LIST - WEBV26 Engine
Item No Webb Part No. Handy Descripon Qty
Item No Webb Part No. Handy Descripon Qty
1 WE03130010013 Spark Plug RCJ6Y 1
24 WE02050030018 Flywheel 1
2 WE03010010061 Bolt M5X20 4
25 WE02070010078 Insulator Gasket 1
3 WE70070130011 Cylinder 1
26 WE02110030031 Insulator 1
4 WE02070010020 Cylinder Gasket 1
27 WE03020020012 Bolt M5X20 2
5 WE02020020003 Piston Ring 2
28 WE02070010061 Carburretor Gasket 1
6 WE02010020006 Piston 1
29 WE02050020045 Carburetor 1
7 WE02020010004 Piston Pin 8X28 1
30 WE70030040038 Choke Lever 1
8 WE02020030017 Snap Ring 2
31 WE70080120007 Air filter Housing 1
9 WE03090020018 Needle Bearing 1
32 WE70030040028 Choke 1
10 WE02020150007 Thrust Washer 2
33 WE03010040008 Bolt ST4×10 1
11 WE02020120026 CrankshaAssembly 1
34 WE02090010011 Air filter Housing 1
12 WE03090010028 Bearing 6001/P5 2
35 WE03020020030 Bolt M5X60 2
13 WE03060010002 Pin B3X10 2
36 WE70030040078 Air Filter Cover 1
14 WE02070010110 Crankcase Gasket 1
37 WE70030180012 Air Filter Screw 1
15 WE03050010014 Rear Crankcase 1
38 WE02070010141 Exhaust Gasket 1
16 WE03100010009 Oil Seal 12X22X7 2
39 WE02050010018 Exhaust 1
17 WE03120030003 Stop Ring 2
40 WE03040020019 Washer 5 2
18 WE02050100015 Starter Pawl 1
41 WE03050010014 Washer 5 3
19 WE02020110088 Starter Pawl Spring 2
42 WE03010010049 Screw M5X50 2
20 WE70030140015 Starter Pawl 2
43 WE03040010007 Washer 4 2
21 WE03070010002 WoodruffKey 1
44 WE02070010048 Spacer 2
22 WE70070050001 Crankcase - Front 1
45 WE02050050141 Stop Wire 1
23 WE03010010045 Bolt M5X30 3
46 WE02050030024 Ignion Coil 1
47 WE03020020013 Screw M4X20 2
PARTS DIAGRAM - WEBV26 Engine
WEBV26 193867001 IM.indd 17 06/07/2016 09:07

PARTS LIST - WEBV26 Machine
Item No Part No. Descripon Qty
Item No Part No. Descripon Qty
1 WE70050010068 Tube A 1
32 WE03010040017 Screw ST4.2×10 1
2 WE70050010069 Tube B 1
33 WE02050050171 Stop Wire 1
3 WE03010060056 Screw M5×16 3
34 WE51010040002 Engine 1
4 WE03040020020 Washer 5 11
35 WE03040050022 Washer 1
5 WE70030030284 Connect Cover 1
36 WE02060020003 Recoil Pulley 1
6 WE03010060078 Screw M5×10 6
37 WE02060020009 Recoil Spring 1
7 WE70030180100 Safety Cover 1
38 WE'70080100004 Housing 1
8 WE02050050002 Safety Switch 1
39 WE03020020041 Screw M5×30 3
9 WE70030070032 Buon Connector 1
40 WE01050010009 Recoil Rope 1
10 WE03040050017 Washer 6 1
41 WE70030140010 Recoil Handle 1
11 WE70030180012 Fan Cover Screw 1
42 WE70050010070 Curved tube 1
12 WE70030030303 Dan Cover 1
43 WE02050040087 Throle Wire 1
13 WE02020160312 Spring sha1
44 WE02050060050 Collecon Bag 1
14 WE02020110048 Spring 1
45 WE02050060022 Harness 1
15 WE70030010071 Rear Case 1
46 WE01040010003 Return Fuel Pipe(L=70) 1
16 WE03030020002 Nut M8×1 1
47 WE02080030025 Fuel Pipe Rubber Bung 1
17 WE02020070042 Shaer Tooth 1
48 WE01040010014 Inlet Fuel Pipe(L=220) 1
18 WE70030090006 Impellor 1
49 WE02050120002 Fuel Filter 1
19 WE03010010045 Screw M5×30 4
50 WE02110020026 Fuel Cap Assembly 1
20 WE02080020046 LeHandle Rubber Cover 1
51 WE03050010007 Washer 8 1
21 WE70030010055 Front Case 1
52 WE03040050005 Washer 23*8*1 1
22 WE02020160117 Pedestal 4
53 WE70050010066 Tube C 1
23 WE70050030063 Fuel Tank 1
54 WE70050010067 Tube D 1
24 WE'03010040057 Screw M5*20 4
55 WE02050070048 Recoil Rope Guide 1
25 WE70030160093 Lower Handle 1
56 WE02040030020 Bush 1
26 WE02020160398 Throle Lever Sha1
57 WE02080030015 Wire Lead 1
27 WE70030070109 Throle Lever Handle 1
58 WE03110020023 “O” Sealing Washer 25x2 1
28 WE02050050111 Stop Switch 1
59 WE03010060076 Screw M5×30 2
29 WE02050050171 Short Stop Wire 2
60 WE03020020018 Screw M5×10 1
30 WE70030160048 Upper Handl;e 1
61 WE03050010015 Washer 5 4
31 WE02080020046 Right Handle Rubber Cover 1
62 WE'03010040048 Screw NST5x16 11
PARTS DIAGRAM - WEBV26 Machine
WEBV26 193867001 IM.indd 18 06/07/2016 09:07

PARTS LIST - WEBV26 Machine
Item No Part No. Descripon Qty
Item No Part No. Descripon Qty
1 WE70050010068 Tube A 1
32 WE03010040017 Screw ST4.2×10 1
2 WE70050010069 Tube B 1
33 WE02050050171 Stop Wire 1
3 WE03010060056 Screw M5×16 3
34 WE51010040002 Engine 1
4 WE03040020020 Washer 5 11
35 WE03040050022 Washer 1
5 WE70030030284 Connect Cover 1
36 WE02060020003 Recoil Pulley 1
6 WE03010060078 Screw M5×10 6
37 WE02060020009 Recoil Spring 1
7 WE70030180100 Safety Cover 1
38 WE'70080100004 Housing 1
8 WE02050050002 Safety Switch 1
39 WE03020020041 Screw M5×30 3
9 WE70030070032 Buon Connector 1
40 WE01050010009 Recoil Rope 1
10 WE03040050017 Washer 6 1
41 WE70030140010 Recoil Handle 1
11 WE70030180012 Fan Cover Screw 1
42 WE70050010070 Curved tube 1
12 WE70030030303 Dan Cover 1
43 WE02050040087 Throle Wire 1
13 WE02020160312 Spring sha1
44 WE02050060050 Collecon Bag 1
14 WE02020110048 Spring 1
45 WE02050060022 Harness 1
15 WE70030010071 Rear Case 1
46 WE01040010003 Return Fuel Pipe(L=70) 1
16 WE03030020002 Nut M8×1 1
47 WE02080030025 Fuel Pipe Rubber Bung 1
17 WE02020070042 Shaer Tooth 1
48 WE01040010014 Inlet Fuel Pipe(L=220) 1
18 WE70030090006 Impellor 1
49 WE02050120002 Fuel Filter 1
19 WE03010010045 Screw M5×30 4
50 WE02110020026 Fuel Cap Assembly 1
20 WE02080020046 LeHandle Rubber Cover 1
51 WE03050010007 Washer 8 1
21 WE70030010055 Front Case 1
52 WE03040050005 Washer 23*8*1 1
22 WE02020160117 Pedestal 4
53 WE70050010066 Tube C 1
23 WE70050030063 Fuel Tank 1
54 WE70050010067 Tube D 1
24 WE'03010040057 Screw M5*20 4
55 WE02050070048 Recoil Rope Guide 1
25 WE70030160093 Lower Handle 1
56 WE02040030020 Bush 1
26 WE02020160398 Throle Lever Sha1
57 WE02080030015 Wire Lead 1
27 WE70030070109 Throle Lever Handle 1
58 WE03110020023 “O” Sealing Washer 25x2 1
28 WE02050050111 Stop Switch 1
59 WE03010060076 Screw M5×30 2
29 WE02050050171 Short Stop Wire 2
60 WE03020020018 Screw M5×10 1
30 WE70030160048 Upper Handl;e 1
61 WE03050010015 Washer 5 4
31 WE02080020046 Right Handle Rubber Cover 1
62 WE'03010040048 Screw NST5x16 11
PARTS DIAGRAM - WEBV26 Machine
WEBV26 193867001 IM.indd 19 06/07/2016 09:07

EC DECLARATION OF CONFORMITY
We Handy Distribuon Ltd - SN3 5HY (Importer) declare that the product:
Designaon: Petrol Blower & Vacuum
Model(s): WEBV26
Type/Serial No. As per rang label on machine
Complies with the following direcves:
Machinery Direcve as last amended by EC Direcve 2006/42/EC
The conformity assessment procedure followed was in accordance with
EN ISO 12100-2/A1:2009
EN 15503:2009
Blower
Measured Sound Pressure Level: LPA = 95.7dB(A)
Measured Sound Power Level: LWA = 112dB(A)
Vacuum
Measured Sound Pressure Level: LPA = 94.7dB(A)
Measured Sound Power Level: LWA = 111dB(A)
Nofied Body:
TÜV SÜD Product Service GmbH
Addresses:
-10 Huaxia Road(m), Dongng, Wuxi, Jiangsu, 214100 (P.R China)
-Zerfizierselle, Ridlerstraße 65, 80339 München, Germany
Authorised signatory and technical file holder
Date: 10/11/2015
Signature:
Name: Mr Simon Belcher
Posion: Managing Director
Company: Handy Distribuon Ltd
Address:Murdock Rd, Swindon, Wiltshire, SN3 5HY.
