Weber mt CR 8 MDM Operating instructions

CR 8
CR 8 MDM
CR 8 CCD 2.0
0116721; 0116724;
0116729; 0116730;
0116731; 0116732;
0116735; 0116736
Operating and
Maintenance Manual

2
1
2
3
4
56
Attached to the machine is a rating plate. Note down the information given on this plate so that
you can recreate the rating plate should the plate be lost.
1 Description 2 Type
.................................................... ...................................................
3 Serial no. 4 Year of construction
.................................................... ....................................................
5 Weight 6 Rated power kW
.................................................... ...................................................

3
Contents
1. Introduction..................................................................................................................... 4
2. Description...................................................................................................................... 5
3. Technical data................................................................................................................. 6
4. Safety............................................................................................................................... 7
4.1. Information and safety stickers ........................................................................... 12
5. Operation....................................................................................................................... 13
6. Transport....................................................................................................................... 23
7. Storage .......................................................................................................................... 23
8. Maintenance.................................................................................................................. 24
8.1. Maintenance overview .............................................................................................. 25
8.2. Description of the maintenance operations............................................................ 26
8.2.1. Clean the air lter............................................................................................. 26
8.2.2. Check V-belt..................................................................................................... 26
8.2.3. Check the engine oil level ................................................................................ 27
8.2.4. Change the engine oil ...................................................................................... 27
8.2.5. Change the engine oil lter .............................................................................. 28
8.2.6. Check the water separator .............................................................................. 29
8.2.7. Change the fuel lter ....................................................................................... 29
8.2.8. Check the hydraulic oil level ............................................................................ 29
8.2.9. Change the oil in the exciter ............................................................................ 30
8.2.10. Change the fuses........................................................................................... 30
8.2.11. Use a permanent charger .............................................................................. 30
8.3. Operating uids and ll levels ................................................................................. 31

4
This operating and maintenance manual is designed to help
you become familiar with your soil compactor and enable you
to maintain it and use it for its intended purpose.
The safety and maintenance instructions provided in this
manual will help avoid hazards, reduce repair and downtime
costs and will increase the reliability and operational readiness
of your machine. Follow these instructions precisely.
This operating and maintenance manual must always be kept
at the implementation site of the machine and be available to
the machine operator.
Turn to your Weber MT dealer if you require any additional
information.
Found on the last page of this manual is a QR code.
Scan it to acquire the current contact addresses of all
Weber MT branches.
You can obtain information on the assembled Hatz diesel
engine and the associated operating and maintenance
manual as well as the spare parts list, if needed,
at www.hatz-diesel.com
You can obtain the current spare parts list of the machine in
the WeberMT Service App or use the link below:
1. Introduction
https://www.webermt.com/DE/deu/ersatzteillistenspare-partscr-6-cr-9/cr-8/

5
2. Description
The machine The machine is a hand-guided, reversible soil compactor.
The machine is composed of a bottom and a top section.
The bottom section houses the exciter, while the top section
contains the engine and the required controls.
An air-cooled Hatz diesel engine makes the exciter vibrate
via a centrifugal clutch. The generated force is transmitted
between top and bottom section via a V-belt.
The engine is started electronically by a permanently installed
start module.
The engine speed is adjusted between idle speed and
full-throttle speed via a gas lever.
Forward and reverse travel is variably controlled with a handle
via a hydraulic system.

6
3. Technical data
CR 8 CR 8 MDM CR 8 CCD 2.0
Weight
Operating weight CECE [kg] 601 605 605
Dimensions
Overall length [mm] 1830 1830 1830
Overall width / with attachment
plates [mm] 600/700/850 600/700/850 600/700/850
Height with folded guide bar [mm] 1160 1160 1160
Base plate length [base in mm] 450 450 450
Pressure surface [mm] 450x700/450x850 450x700/450x850 450x700/450x850
Drive
Engine manufacturer Hatz Hatz Hatz
Type 1 D 81 1 D 81 1 D 81
Performance at operating speed in
accordance with ISO 3046-1 [kW] 9.4 9.4 9.4
Combustion process 4-stroke diesel 4-stroke diesel 4-stroke diesel
Operating speed [1/min] 2800 2800 2800
Operating speed
[soil-dependent, m/min] 24 24 24
Incline capacity [soil-dependent, %] 35 35 35
Vibration
System Two-shaft vibrator Two-shaft vibrator Two-shaft vibrator
Drive concept Mechanical Mechanical Mechanical
Frequency [Hz] 67.5 67.5 67.5
Centrifugal force [kN] 75 75 75
Noise emissions in accordance
with 2000/14/EC
Sound pressure level
LPA ascertained in accordance
with EN 500, [dB (A)] 94 94 94
Sound power level LWA
ascertained in accordance with
EN ISO 3744 and EN 500, [dB (A)] 109 109 109
Vibration values
Root-mean-square acceleration
value for hand-arm vibration
ascertained in accordance
with EN 500, [m/s²] 1.8 1.8 1.8
In accordance with directive
2006/24/EC, complying with
the vibration values is the owner’s
responsibility

7
4. Safety
General All safety instructions must be read and complied with,
as non-compliance will result in
– danger to life and limb of the user,
– impairments to the machine or other property.
In addition to the operating manual, the accident-prevention
regulations in the country where the appliance is used
must be complied with.
Intended use The machine should only be used in technically faultless
condition, as intended, in a safety-conscious and hazard-
conscious manner, and in compliance with the instructions
in the operating manual.
Malfunctions that may impair safety require that you stop
working with the machine immediately. These types of
damage must be reported and corrected without delay.
The machine is designed exclusively for compacting:
– sand,
– gravel,
– crushed rock,
– low-cohesive mixed material,
– paved surfaces.
The operator’s work position is behind the machine.
The operator must guide the machine safely with both
hands on the handle.
Non-intended use Unless used as intended, the machine involves a risk of
personal injury and property damage. The machine is
expressly not suitable for:
– compacting frozen subsurfaces,
– compacting hard soils that cannot be compacted
further,
– compacting non-bearing material,
– compacting highly cohesive soils,
– compacting (ramming) that exerts point loads on
the base plate,
– crushing and compacting individual rocks.
The responsibility for any damage arising from non-intended
use falls on the owner / operator.
Non-intended use or misuse will void all liability and
warranty claims.
Residual risk There is always an increased risk of accidents in the
immediate danger area around the machine if the operator
fails to notice persons in the vicinity of the machine.
Anyone close to the machine must be made aware of this risk.
The operator must not put the machine into operation unless
everyone in the vicinity of the machine is aware of this risk.

8
Requirements on the operator This soil compactor may only be operated by suitable
operators who are 18 years or older. They must be instructed
on how to operate the machine by the owner or by the owner’s
assigned personnel. The operator must comply with tra󰀩c
regulations.
The machine must not be operated by children.
Personal protective
equipment
Personal protective equipment consisting of
– hard hat,
– hearing protection,
– protective gloves,
– work shoes or boots with toe guard
must be worn during operation and the execution of
maintenance on the machine.
Danger areas The immediate danger area is the direct perimeter around
the machine. This area is o󰀨-limits to third parties.
Spare parts, changes
and conversions
Changes and conversions are prohibited unless made with
original Weber MT spare parts. If the machine is modied
with other accessories without the approval of Weber MT,
the manufacturer will not assume liability for any resulting
personal injury or property damage.
All maintenance and repairs must be carried out with original
Weber MT spare parts. Untested spare parts may a󰀨ect
the reliability and safety of the machine.
Before starting the machine There is danger of material damage if the machine is
started before necessary maintenance or repairs have been
completed. Make sure every time before starting the machine
that all work on the machine has been completed.
To avoid injuries, the machine must not be started unless the
operator wears the required personal protective equipment.
Objects placed on top of the machine may fall or be ung o󰀨
during operation or when the machine is started. Therefore,
remove all loose objects or tools before starting the machine.
If the gas cap is open, fuel may escape and ignite on the
engine when the machine is started or while it is operating.
There is a risk of burns. Therefore, do not start the machine
unless the gas cap is closed.

9
Start-up procedure Do not disperse any sprays or other agents into the air intake
while the machine is starting up. They may lead to overheating
in the combustion chamber and result in damage to the engine.
There is danger of su󰀨ocation if the operator starts up the
machine in closed rooms or in deep and tight trenches.
Operating the machine in closed rooms is prohibited. Provide
for an adequate supply of air before starting the machine.
One start procedure must not last longer than 30 seconds
to avoid damage to the engine. If the engine fails to turn
over after no more than 30 seconds, turn the ignition key
back to the “0” position and eliminate the cause.
If the ignition key fails to spring back to position “1” by itself,
the electric starter and the engine may sustain damage.
Abort the start procedure and shut down the machine.
Identify and rectify the cause before the next start attempt.
During operation Monitor the surroundings to avoid injury to third parties or
material damage.
Suspend operation and shut down the machine if detecting
damage on the machine during operation.
Stop operation and shut down the machine if the light
indicators of the start module do not go out shortly after
startup or come on during operation.
The symbol is lit permanently during operation. It signals
that the engine is running. Refer to the section “Operation”
for the exact meaning of the individual light indicators.
Parking the machine Always park the machine on a level subsurface with su󰀩cient
bearing capacity.
Parked machines presenting an obstacle must be secured
in accordance with statutory regulations, particularly in the
area of public tra󰀩c surfaces.
Engine and exhaust heat up during operation and can cause
burns on contact. Therefore, do not touch these components
during operation or shortly after the machine was switched o󰀨.
Fueling the machine Spilled fuel may ignite and has a negative impact on the
environment. Therefore, wipe up spilled fuel and make sure
the gas cap is rmly tightened after fueling.

10
When coming into contact with fuels, the rubber-bonded metal
bu󰀨ers of the machine may become damaged or ine󰀨ective.
Therefore, wipe spilled fuel carefully o󰀨 the rubber-bonded
metal bu󰀨ers.
Fuel vapors are easily ammable. Do not smoke and
keep away from open re while refueling the machine.
The machine must not be fueled unless the engine is
switched o󰀨.
Cleaning work Use clear water for cleaning. Do not use ammable solvents.
The vapors of the solvents may ignite upon contact with hot
components or other sparks.
Perform cleaning tasks only in rooms that are suitable and
have been approved for that purpose. Residual oil and
lubricants that may have been rinsed o󰀨 have a negative
impact on the environment and must be collected by suitable
means (e.g. oil separator).
Safe handling of combustion
engines
Combustion engines pose a particular risk during operation.
Their exhaust emissions contain carbon monoxide, a colorless
and odorless gas that is extremely hazardous, which, if inhaled
even briey, can cause unconsciousness and death.
Therefore, never inhale the exhaust gas.
Inspection The machine must be inspected in accordance with the corre-
sponding implementation conditions and operating conditions
to ensure its operationally safe status. This inspection should
be performed as needed by an expert – however, no less than
once a year. The ndings of the inspection must be stored in
writing until the time of the next inspection.

11
Safety instructions
and warnings
A variety of safety instructions and warnings are used
throughout this operating manual.
The following explains the meaning of signal words
and symbols.
ATTENTION warns of
the danger of material
damage.
CAUTION warns of the
danger of slight injury.
WARNING warns of
a danger that may lead to
death or serious injury.
DANGER warns of
a danger that will lead to
death or serious injury
unless avoided.
ATTENTION
CAUTION
WARNING
DANGER
The information symbol provides supplemental
information on the operation of the machine and
points to complementary technical information.

12
4.1. Information and safety stickers
Sticker Meaning
1
All threaded unions must
be checked for rm seat
on a regular basis and,
particularly, after initial use.
2The fuel tank may only be
fueled with diesel.
3Turn the gas cap to open
and close it.
4
Use the designated lifting ring
to lift the machine.
Sound power level 109 dB (A),
wear ear protection.
5*
When disconnecting the engine
bracket from the base plate,
make sure not to damage the
sensor cable.
The sensor must be detached
from the base plate.
*Only units equipped with COMPATROL 2.0 compaction control.

13
5. Operation
Preparing the machine
for initial use
Remove all packaging material.
Check all components for visible damage. Do not start
the machine if detecting visible damage. Contact the
responsible dealer.
Check if the shipment of the machine and its components
is complete.
Check the ll level of the operating uids and top o󰀨 if
necessary.
Set up the machine at its place of use.

14
1
2
3
4
5
6
7
8
9
10 11
Operating positions on the machine
Overall view CR 8
1 Base plate with exciter
2 Mounting bracket
3 Gas lever
4 Handle
5 Guide bar
6 Lifting ring
7 Maintenance cover
8 Engine (no image)
9 Key switch
10* Start module
11** Compaction control system Compatrol 2.0
Figure 1
* Only units equipped with COMPATROL 2.0 compaction control.
* Figure shows the start module MS 25 (MDM / Compatrol 2.0).

15
5
1
2
4
3
The start module
MS 15 (CR 8)
1 Operational status indicator
(LED)
2 Oil pressure indicator (LED)
3 Operating hours counter
4 Charge level indicator (LED)
5 Key switch
Figure 2
This indicator signals that the ignition of the machine is
switched on. It comes on as soon as the key switch (5)
is set to position “1”.
This indicator warns of insu󰀩cient oil pressure.
Shut down the machine immediately when this indicator
comes on.
This eld shows the operating hours completed by
the machine.
The counter will show the remaining time until the next
scheduled maintenance for the rst 10 seconds after the
ignition was switched on (key switch (5) in position “1”).
This indicator comes on if the charging current supply to the
starter battery is insu󰀩cient. While operation of the machine
can resume, the cause of the insu󰀩cient charging current
supply must be identied and rectied.
The key switch is used to switch the power supply (ignition)
to the machine on or o󰀨. It also actuates the electric starter of
the engine.
Switch in position “1”
The ignition is switched on.
Switch in position “0”
The ignition is switched o󰀨.
Switch in position “2”
The electric starter is actuated.
ATTENTION
Danger of material damage from running electric starter.
The ignition key must spring back from position “2” to
position “1”. Otherwise:
Shut down the machine immediately.

16
1
2
3
4
5
6
7
8
MS 25 & 35 (CR 8 MDM & CCD)
1 Operational status indicator
(LED)
This indicator signals that the ignition of the machine is
switched on. It comes on as soon as the key switch (5)
is set to position “1”.
2 Oil pressure indicator (LED) This indicator warns of insu󰀩cient oil pressure.
Shut down the machine immediately when this indicator
comes on. The engine is switched o󰀨 automatically.
3 Charge level indicator (LED) This indicator comes on if the charging current supply to the
starter battery is insu󰀩cient. While operation of the machine
can resume, the cause of the insu󰀩cient charging current
supply must be identied and rectied.
4 Operating hours counter This eld shows the operating hours completed by
the machine.
The counter will show the remaining time until the next
scheduled maintenance for the rst 10 seconds after the
ignition was switched on (key switch (5) in position “1”).
5 Temperature indicator (LED) This indicator comes on if the engine is overheating.
Shut down the machine immediately when this indicator
comes on. The engine is shut down automatically 3 minutes
after the indicator comes on.
6 Air lter indicator (LED) This indicator comes on in case of heavy fouling of the air lter.
Shut down the machine immediately when this indicator comes
on. The engine is shut down automatically 10 minutes after
the indicator comes on.
7 Maintenance indicator (LED) This indicator comes on 10 operating hours before the next
scheduled maintenance interval.
Figure 3

17
8 Key switch The key switch is used to switch the power supply (ignition)
to the machine on or o󰀨. It also actuates the electric starter of
the engine.
Switch in position “1”
The ignition is switched on.
Switch in position “0”
The ignition is switched o󰀨.
Switch in position “2”
The electric starter is actuated.
ATTENTION
Danger of material damage from running electric starter.
The ignition key must spring back from position “2” to
position “1”. Otherwise:
Shut down the machine immediately.

18
1 3
2
The COMPATROL compaction control system
1 Operational status indicator
(Green)
This indicator comes on as soon as the proper operating
frequency has been reached and signals that the compaction
control system is operational.
If the indicator ashes constantly, the machine is operating
with the wrong operating frequency.
2 Compaction indicator (Yellow) The LEDs 1 – 7 indicate the achieved level of soil compaction.
The number of lit LEDs increases with the level of compaction.
If no additional LED comes on after another pass over the
same spot, the maximum level of compaction has been
reached.
3 Warning light (Red) The warning light warns of operation on soils that are too hard.
These types of soil cannot be compacted further with the
machine type used and may result in damage to the machine.
Figure 4

19
The attainable maximum may vary with the type and composition of the soil.
On sand, the maximum is commonly reached at a low number of lit LEDs.
Following the compaction of a mix of gravel and crushed rock that
is uniformly graded and contains the proper concentration of water,
the indicator is likely to show six to seven lit LEDs.
It is important to closely monitor the indicator during the last pass.
Places where the number of lit LEDs drops sharply are poorly compacted.
In these places, the soil needs to be compacted again or may even have
to be replaced.
Possible indicator states
Function test of the LEDs A function test of the LEDs is performed when the ignition
is turned on, but the engine has not yet been started.
The operational status indicator (1) and the warning light (3)
light up permanently.
The LEDs of the compaction indicator (2) light up in
succession from left to right and go out in reverse order.
After engine start, before reach-
ing the operating frequency
The warning light (3) signals by lighting up permanently
that the compaction indicator is not operational yet.
The LEDs of the compaction indicator (2) are not yet lit.
The operational status indicator (1) signals by ashing that
the operating frequency has not been reached yet.
Reaching the operating
frequency, operation
Upon reaching the operating frequency, the operational
status indicator (1) lights up permanently, indicating that
the machine is ready for operation.
The warning light (3) goes out.
The compaction indicator (2) starts lighting up, indicating
the achieved level of soil compaction.
Illumination of the warning
light
The warning light warns of operation on soils that are too hard.
If all LEDs of the compaction indicator (2) are lit together with
the warning light (3), the soil to be compacted is too hard.
Stop operation immediately to avoid damage to the machine.

20
1
2
Before starting work
Perform the following tasks before starting to work in order to
prevent failures or excessive wear.
Visual inspections Hydraulic line for leaks
Fuel system for leaks
Rubber bu󰀨ers for crack formation
Other damage
Check and, if necessary,
correct the ll levels
Engine oil
Hydraulic oil
Fuel
Other inspections Check all threaded unions for rm seat
Verify compliance with the maintenance schedule
Figure 5
