Weber LEGACY Family Easel U-9601 User manual

Rev June 08 RPI
Martin/F. Weber Co. • 4444 Lawton Avenue, Detroit, MI 48208 USA
Tel:[phone] • Fax:[phone] • E-mail:[email protected]
www.MartinUniversalDesign.com • www.weberart.com
Made in China
U-9601
ASSEMBLY INSTRUCTIONS

If you have any problems with assembling this easel, please call: [phone]
or e-mail us at [email protected]. Thank You.
U-9601 • LEGACY FAMILY EASEL
ASSEMBLY INSTRUCTIONS
MAKE SURE CARTON CONTAINS THE FOLLOWING PARTS
WOOD PARTS
Quantity ....... Description ID#
1 ea. ........ Chalkboard Surface [A]
1 ea. ........ White Drawing Surface [B]
2 ea. ........ Upper Legs with Hinges [C]
2 ea. ........ Lower Legs with Channel [D]
1 ea. ........ Materials Tray [E]
1 ea. ....... Cross Supports [F]
1 ea. ........ Paper Roll Holder [G]
HARDWARE PARTS
Quantity ........ Description ID#
4 ea. ............. 2-3/8” Bolts [H]
NO TOOLS NEEDED
Page 2
Rev June 08 RPI
Chalkboard Surface [A] White Drawing Surface [B]
Upper Legs with Hinges [C]
Lower Legs with channel [D]
Paper Roll Holder [G]
Materials Tray [E]
Cross Supports [F]
For recommended assembly lay all wood parts on flat carpeted surface.
Martin/F. Weber Co. • 4444 Lawton Avenue, Detroit, MI 48208 USA
Tel:[phone] • Fax:[phone] • E-mail:[email protected]
www.MartinUniversalDesign.com • www.weberart.com
Made in China
8 ea. ............Wooden Knobs (attached to 1-5/8” Bolts) [M]
4 ea. ............. 2” Bolts [I]
[ I ]
[H]
8 ea. .............. Wing Nuts [J]
[J]
8 ea. .............. Washers [K]
[K]
8 ea. ............1-5/8” Bolts (attached to wooden knobs) [L]
[L]
[M]

STEP 1. Assembling Legs.
Take each Upper Leg [C] (make sure
hinges are positioned on top) along with
each Lower leg [D].
Insert a 2” Bolt [ I ] through inside of upper
leg and through lower hole and then
through channel of lower leg part [D].
See FIG 1.
Secure with washer [K] and wing nut [J]
provided. See FIG 1B zoom. Repeat on all
3 remaining legs. Note: Channel in lower
portion of leg is for height adjustment
of easel.
Pg. 3
C
STEP 2. Assembed Legs.
You should now have two Assembled Legs as shown
below in FIG 2.
FIG 1
FIG 1B
FIG 2
STEP 3. Attaching the Chalkboard Surface [A].
Begin by laying the assembled legs down onto a flat
carpeted surface. Insert a 1-5/8” bolt [ L ] through each
of the two holes at the top of the upper legs See FIG 3
and two 1-5/8” bolts [L] in the lower holes of the upper
legs. See FIG 3B. Insert from the inside of the leg going
through the hole and out the front of the leg. Continue by
laying the chalkboard [A] surface over the 4 bolts & by
lining up the holes in the surface. NOTE: The green side
of the chalkboard surface should be facing outward.
FIG 3
FIG 3B
STEP 4. Attaching the Chalkboard Surface, con’td.
After the chalkboard is placed over the [4] bolts [ L ] &
[L], continue by adding one of the cross supports [F] to
the top section of the chalkboard. See FIG 4. After the
cross support is in place. Secure by using one wooden
knob [M] for each of the 4 bolts on the chalkboard
surface. NOTE: No washer is needed. See FIG 4B.
FIG 4
A
FIG 4B
F
A
A
M
L
C
D
D
CC
DDDD
C C
L
LL
CI
F
Rev June 08 RPI

Pg. 4
STEP 5. Attaching the Surfaces
The images below show how the wooden knobs [M] on
all four bolts should look after proper assembly.
See FIG 5.
REPEAT STEPS 3 - 5 for the White Drawing Surface.
Please Note the White Drawing surface is the shiny
white side. This side would face the outside of the easel.
FIG 5
C
A
STEP 7. Attaching Material Tray [E], con’td.
The images below show a zoom of the correct location
of the holes that are used for the assembly of the
materials tray. See FIG 7.
STEP 6. Attaching Material Tray [E]
NOTE: 2 People needed for this step.
Move the legs in to make the easel narrower to allow
the material tray [E] to slide down over the easel into the
proper position. As one person holds the tray, the other
can line up the holes in the sides of the upper portion
of the legs. Insert one 2-3/8” [H] bolt through each hole
and secure with washer [K] and wing-nut [J]. Repeat on
other side of easel. See FIG 6.
FIG 6
E
D
STEP 8. Add Paper Roll Holder [G] & Paper
Slide paper roll over wood roll holder [G] and then insert
ends of paper roll holder into slots found on upper
portion of easel legs. See FIG 8.
Note: Insert paper edge down between cross support
and dry-erase surface to hold paper in position during
use of paper.
A
C
D
M
M
This image is the upper portion of
the surface.
This image is the lower
portion of the surface.
FIG 7
C
E
Attach
washer [K]
and wing-nut
[J] here. C
G
F
Martin/F. Weber Co. • 4444 Lawton Avenue, Detroit, MI 48208 USA
Tel:[phone] • Fax:[phone] • E-mail:[email protected]
www.MartinUniversalDesign.com • www.weberart.com
Made in China
C
FIG 8
HH
H
H
K
J
Rev June 08 RPI
