Wecon LEVI430T User manual

The Manual of Embedded Industrial Panel PC
www.we-con.com.cn/en/index.asp
SKYPE ID: besidinggoodmind
http://we-con.en.alibaba.com
http://www.wecon-tech.com
techinical support SKYPE ID:wecon-anne
QQ: 15506172
WECON Technology Co., Ltd.
All coprights reserved by WECON, 2014

Directory
1. Company Introduction.......................................................................................................................................................................3
2. A7 Series Industrial Panel PC ...........................................................................................................................................................4
2.1 The Main Hardware Parameters ...........................................................................................................................................................................4
2.2 Software Configuration.........................................................................................................................................................................................4
2.3 Model and Parameters...........................................................................................................................................................................................6
3. A8 Series Industrial Panel PC...............................................................................................................................................................8
3.1 A8 Series Hardware Features................................................................................................................................................................................8
3.2 A8 Series Software Configuration ........................................................................................................................................................................8
3.2.1 WINCE System Configuration..............................................................................................................................................................8
3.2.2 LINUX System......................................................................................................................................................................................10
3.2.3 ANDROID System................................................................................................................................................................................10
3.2.3 A8 Series Model and Parameters......................................................................................................................................................11
4. Installation Dimension and Physical Maps........................................................................................................................................13
4.1 Installation Dimension Maps..............................................................................................................................................................................13
4.2 Physical Maps.....................................................................................................................................................................................................16
5. Solutions and Applications ................................................................................................................................................................19
5.1 Application Case of Production Line Operation Terminal in Garment Dry-cleaning Plant................................................................................19
5.2 Application Case of Intelligent Dispatching Terminal for Forklift.....................................................................................................................23
5.3 Textile Operating Interface .................................................................................................................................................................................23

1.Company Introduction
WECON Technology Co., Ltd. is formerly named Xiamen WECON Technology Co., Ltd. Since its establishment in 2006, this high-tech
company has been specialized in automation product research, development and sales. LEVI series of industrial man-machine interfaces
and industrial Panel PC products produced by the company have achieved a number of hardware and software intellectual properties,
which are widely used in machinery and equipment, metallurgy, chemical, oil and other industries. Our products are exported to nations
and regions including US and Europe.
While WECON Technology Co., Ltd. has attained significant development in human-machine interface products, its independent
research and development of programmable controller (PLC) products began in 2010 officially came into the market in June 2012. The
emergence of WECON LX series PLC means that the company has again mastered a core technology in the field of automation,
indicating that the product lines of WECON began to expand horizontally.
With complete and regular production procurement channels, a rigorous and scientific quality management system, a simple and efficient
mechanism for innovative research and development, we provide services to users wholeheartedly, as well as automation technologies
and products with better quality, easier application and more reliable technologies.
Since its establishment, the company has gathered a large number of young and vibrant high-tech talents, obtained a lot of core
technologies in automation industry and product development, accumulated valuable experience in serving users, and formed many
effective scientific management systems. All of these are the keys to our success.

2.A7 Series Industrial Panel PC
2.1 The Main Hardware Parameters
The main hardware parameters:
zARM9 2416 400MHZ CPU
zThe whole series adopt TFT true color LCD, with 65536 colors and brightness of up to 250 lumens; supporting 4.3-inch, 7-inch,
10.2-inch and 10.4-inch;
z128MB Built-in Flash
za USB HOST; a USB DEVICE
zDDR2 64MB memory
zSupport RS232/RS485/RS422, multiple serial ports
zSupport CANBUS
zSupport Video Input
zSupport audio output
zUsing the embedded installation
2.2 Software Configuration
WECON LEVI series industrial penal PC can pre-install WINCE system and LINUX system according to users’ needs.
A7 Series WINCE system configuration:
zWINCE 5.0 system
zNET Framework 2.0 (also support NET Framework 3.5)
zIE browser (optional)

zRDP function (Remote Desktop) (optional)
zOPC SERVER (optional)
zWIFI wireless Ethernet (optional)
zSerial Drivers (RS232/RS485/RS422), can support up to 921600 baud rate
zUSB mouse, keyboard, ergonomic devices (e.g. scanner)
zUSB mini printer (South Korea SEWOO brand) (optional)
zFTP SERVER (optional)
zCITRIX client (optional)
zHTTP SERVER (optional)
zMedia Player (optional)
zSupport Chinese & English dynamic switch
zCEPC System built-in configuration tool
zACTIVESYNC dynamic debugging tool
Note: Optional represents that WINCE system kernel-image can be customized according to users’ needs.
A7 Series LINUX System Configuration:
zDon’t support LINUX system yet
A7 Series ANDROID System Configuration
zDon’t support ANDROID system yet

2.3 Model and Parameters
Model/specification LEVI430T LEVI700L LEVI777A LEVI102A LEVI910T
Display and Input
LCD Type TFT LCD
Display Size 4.3 inch 7 inch 7 inch 10.2 inch 10.4 inch
LCD aspect ratio 4:3
Colors 65536 colors
Resolution 480*272 800*480 800*480 800*480 800*600
Backlight Type LED Backlight
Backlight
Brightness 250 lumens (adjustable as per software)
Backlight lamp life 50,000 h
Touch Panel High precision four-line resistance
Mouse Can support USB mouse
Hardware parameters
CPU ARM9 2416 400MHZ
Power supply DC24
Voltage range DC12-28V
Rated power <5w <10w
Operating
temperature -10℃-60℃
Storage
temperature -30℃-70℃
FLASH 128 MB
DDR memory DDRII 64 MB

Interface parameters
COM1 RS232/RS485/RS422 RS232/RS485/RS422
COM2 Nonsupport RS232/RS485
COM3 Nonsupport Nonsupport Extensible,
model is
LEVI777A-E
Extensible,
model is
LEVI102A-E
Extensible,
model is
LEVI910T-E
Ethernet Nonsupport Nonsupport Extensible,
model is
LEVI777A-N
Extensible,
model is
LEVI102A-N
Extensible,
model is
LEVI910T-N
SD card Nonsupport Nonsupport Support Support Support
USB HOST 1 1 1 1 1
USB DEVICE 1 1 1 1 1
WIFI Nonsupport Nonsupport Extensible,
model is
LEVI777A-W
Extensible,
model is
LEVI102A-W
Nonsupport
CANOPEN Nonsupport Nonsupport Extensible,
model is
LEVI777A-C
Extensible,
model is
LEVI102A-C
Nonsupport
Video input Camera supporting USB interface
Apparent parameters
Dimension
W*H*Dmm 138*86*37 212*146*36 212*146*36 272*200*47 299*222*54
Mounting
dimension
W*Hmm
131*79 192*138 192*138 260*179 288*212
Shell ABS engineering plastics (flame-retardant level)

3. A8 Series Industrial Panel PC
3.1 A8 Series Hardware Features
zARM Cortex A8 720Mhz
zTFT true color LCD, with 65536 colors and brightness of up to 250 lumens; supporting 7-inch, 10.2-inch and 10.4-inch (4:3 LCD)
zTI 3359 cpu built-in PowerVR 3D/2D acceleration
zFlash large capacity storage, support 4G EMMC
zDDR3 with up to 256 memory
zSupport Ethernet, ethercat, CAN bus
zSupport 5 serial ports, RS232/RS485/RS422
zSupport CAN bus
zSupport Ethernet
zWireless Ethernet (optional)
zsound card (optional)
zSupport U disk, SD card
3.2 A8 Series Software Configuration
WECON A8 Series Embedded Industrial panel PC can pre-install WINCE system, LINUX system and ANDROID system according to
users’ needs.
3.2.1 WINCE System Configuration
Pre-install WINCE system (all product quotations in our company are free of license fees); the standard system configuration is as

follows:
zWINCE 7.0 system
zSupport. NET Framework3.5
zIE browser (optional)
zRDP function (Remote Desktop) (optional)
zOPC SERVER (optional)
zWIFI wireless Ethernet (optional)
zSerial Driver (RS232/RS485/RS422), can support up to 921600 baud
zUSB mouse, keyboard, ergonomic devices (e.g. scanner)
zUSB mini printer (South Korea SEWOO brand) (optional)
zFTP SERVER (optional)
zCITRIX client (optional)
zHTTP SERVER (optional)
zMedia Player (optional)
zSilverlight for Windows Embedded (optional): the powerful functions of Silverlight provides some tools for developers and UI
designers; the separation between UI and business logic is conductive to iterative processing device and application program UI,
and also does not affect the core development tasks.
zFlash 10.1 (optional): Flash 10.1 integrated in browser supports playing Flash, and can run Flash content full-screen without the
presence of browser UI.
zConnection Manager and Windows Device Stage (optional): Connection Manager provides the basic framework technology for a
variety of network transmission of management devices. By using Windows Device Stage, users can easily transfer media and
content between devices and PC.
zMicrosoft Office and PDF viewer (optional): updated application can render Microsoft Office Word, PowerPoint, Excel and Adobe
PDF content, and also support Microsoft Office 97, 2000, 2003, XP and 2007.
zSupport the dynamic switch between English and Chinese
zCEPC System built-in configuration tool
zACTIVESYNC dynamic debugging tool
Note: Optional represents that WINCE system kernel-image can be customized according to users’ needs.

3.2.2 LINUX System
LINUX system can be installed in advance based on users’ needs; the standard system configuration is as follows:
zOperation system version: Linux-3.2.0 version
zCAN bus
zSound card driver (optional)
zTCP/IP
zProgramming tools such as QT or X11 (optional)
zCHROME browser or FIREFOX (optional)
zSystem desktop
zAvailable for multiple languages (Chinese, English, Japanese, etc.), can be switched online
zJAVA Support Package (optional)
zFTP SERVER/HTTP SERVER (optional)
zBuilt-in standard printer driver
zNetwork printing (optional)
zUSB mouse, keyboard and other ergonomic devices (scanner, etc.)
zGDB dynamic debugging tool
zSSH Remote Terminal Tool
3.2.3 ANDROID System
ANDROID system can be installed in advance based on users’ needs; the standard system configuration is as follows:
zOperation system version: ANDROID 4.2 version
zSound card driver (optional)
zTCP/IP
zCHROME browser (users can install other browsers by themselves)
zSupport multiple languages (Chinese, English, Japanese, etc.), can be switched online

zJAVA Support Package (optional)
zFTP SERVER/HTTP SERVER (optional)
zBuilt-in standard printer driver
zNetwork printing (function)
zADB dynamic debugging tool
zSupport U disk, SD card
zUsers can install other applications on their own
zSupport USB keyboard, mouse, and other ergonomic equipment
Note: Optional represents that ANDROID system kernel-image can be customized according to users’ needs.
3.2.3 A8 Series Model and Parameters
Model/specification LEVI8708 LEVI8108 LEVI8104
Display and Input
LCD Type IPS LCD
Display Size 7 inch 10.2 inch 10.4 inch
LCD aspect ratio 16:9 16:9 4:3
Colors 65536 colors
Resolution 480*272 800*480 800*600
Backlight Type LED backlight
Backlight
Brightness 250 lumens (adjustable as per software)
Backlight lamp life 50,000 h
Touch Panel High precision four-line resistance
Mouse Can support USB mouse
Hardware parameters

CPU CORTEX A8 720MHZ
Power supply DC24
Voltage range DC12-28V
Rated power <5w
Operating
temperature -10℃-60℃
Storage
temperature -30℃-70℃
FLASH 4 GB
DDR memory DDR3 256 MB
Interface parameters
COM1 RS232
COM2 RS485/RS422
COM3 RS232
COM4 RS485
COM5 RS485
Ethernet Standard
configuration Standard configuration Standard configuration
SD card Support Support Support
USB HOST 1 1 1
USB DEVICE 1 1 1
WIFI Optional Optional Optional
CANOPEN Optional Optional
Video input Camera supporting USB interface
Apparent parameters
Dimension
W*H*Dmm 212*146*45 272*200*48 286*222*54

Mounting
dimension
W*Hmm
192*138 260*179 288*212
Shell ABS engineering plastics (flame-retardant level)
4. Installation Dimension and Physical Maps
4.1 Installation Dimension Maps

4.3-inch Installation size
map
7-inch Installation size map
10.2-inch Installation size map

10.4-inch Installation size map

4.2 Physical Maps
10.2-inchphysicalmap 4.3-inchphysicalmap

10.2-inch physical map

10.4-inch physical map

5. Solutions and Applications
The industrial panel PCs preloaded with the WINCE system and the LINUX system, as researched and developed in our company, have
been widely applied due to complete interfaces, good open platform, fast operation, stable and reliable performance. The major
applications include:
Production line management: management and operation terminal for production station is used for number statistics, quality analysis
or performance appraisal, and station training, etc. That is, it requires not only communicating directly with some devices to obtain
production data but also coordinating with information systems in factories to complete data collection and other functions.
Information management: act as plant informatization and display control terminal, with no need to directly control; it improves
production efficiency and resource utilization of plants, reduce production costs effectively, which should be used in conjunction with
information systems.
Device control: industrial panel PC based on the WINCE system or the LINUX system allows users to independently develop
configuration software or purchase third-party configuration software. It can communicate with control devices through configuration
software, such as PLC, DCS, control modules or other control products.
It can be applied in intelligent buildings, new energy automobile industries, etc.
5.1 Application Case of Production Line Operation Terminal in Garment
Dry-cleaning Plant
User needs:
The user is a garment dry cleaning plant. Dry-clean production line includes the following procedures: unpacking, rough wash, sperm
washing, drying, ironing, sorting, and packing. Each process is taken charge by one worker, who scans the bar codes on clothes through
the scanner connected to the operation terminal (industrial panel PC) in the USB port. Based on barcodes, the operation terminal checks
garment information and process requirements from the database. Workers operate in accordance with the process requirements. After

the operation is completed, they perform the scanning procedure again and then enter into the next process.
Users require the system to achieve:
1. The process has a demonstration function so as to train workers to follow the process specification;
2. The responsibility of recourse: users can quickly track the entire operation process as per barcode on the clothes. Users are
responsible for any problem occurred.
3. Performance appraisal: according to staff number, calculate employees’ performance pay.
6. WINCE Configuration Software Tools-CEPC.exe
If users select WINCE system, we provide configuration software CEPC for free. And you can ask our techinical support engineer for the
document of CEPC
