YACHT LAMP
2 Year Warranty
Yacht Lamp #700, 700BK,700SS
WEEMS & PLATH® YACHT LAMP
INSTRUCTIONS
e Yacht Lamp is constructed of solid cast machined brass. It consists of two main parts: the upper bonnet and the lower
oil reservoir which can be detached from the bonnet by turning counter-clockwise. Each lamp is individually marked with a
unique number.e Yacht Lamp is available in three nishes: solid brass (#700), brass with black bonnet (#700BK), and brass
with stainless steel bonnet (#700SS).
To Add Lamp Fuel To e Oil Reservoir (Font):
e oil reservoir consists of the following parts: retaining ring, wick holder, gasket, and oil font with wire wick adjuster.To gain access
to the oil reservoir,turn the retaining ring counter clockwise and lift out the wick holder and wick.You can now carefully add lamp oil.
Fill ¾ full. Do not overll.
To Light Lamp:
1. After lling, replace the wick holder assuring that the wire adjuster is positioned correctly with the wire touching the wick.
2. With the wick holder sitting ush on the cork washer, rmly screw down the retaining ring.
3. Allow the wick to become saturated with oil. en, catching the wick with the wire adjuster, raise the wick to expose 1/10th
of an inch above the holder.
4. Light the wick and screw the font into the bottom of the lamp.
5. Using the wire wick adjuster, move the wick so the ame is about half an inch high. e ame height and quality of the fuel
will determine the burn time. e lamp will burn up to 30 hours on one lling, depending on the type of fuel used.
Lamp Fuel Recommendation: It is important to use high quality lamp fuel such as our Weems & Plath® Lamp Fuel (#780), which is
pure liquid paran.
We very strongly recommend that you do not use kerosene or other cheap lamp fuels, as they will:
• Burn with excessive odor
• Create smoke and soot
• Burn the wick too quickly
• Present a re hazard
We do recommend using Weems & Plath Lamp Fuel because it is:
• Clean burning, free of odor and carbon build up
• Safe (ash point is over 200° F)
• Long burning (1 oz = 6 hours of use)
CAUTION: Lamp will become hot after being lit for more than 5 minutes. When moving use “S” hook at top of bonnet and
place on heat resistant surface.
To Extinguish Flame:
Pull the wick down slightly with the wire adjuster.
To Replace Wick:
1. Be sure to use the proper ½” wick: our part #770-3.
2. Remove and discard old wick.
3. Trim new wick if necessary, so that the top is straight without dangling strings.read it through the wick holder until 1/10th
of an inch is exposed at top. 06/2017
#700, 700BK, 700SS – 10” BRASS YACHT LAMP
Care Of Lamp:
To maintain a bright nish, we recommend our Sure Shine polish (#633) for an easy and lasting shine. To clean the lamp, unscrew
the resevoir from the bottom of the lamp:
1. Insert the tips of scissors or a pair of needle-nose pliers into both notches of the glass assembly holding ring at the base of
the bonnet.
2. With pliers rotate the ring counter-clockwise until removed.
3. Remove the glass and windscreen assembly.
4. Use a degreasing product, like dishwashing liquid mixed in warm water, to wash and clean all components of the lamp.
5. Reassemble by reversing this procedure.
Product Registration:
In order to provide the best service possible, please register your product online at www.weems-plath.com. Your registration serves
as proof of purchase and activates your warranty.
Part Replacement:
To replace lamp parts including wicks, burners, and chimneys, please contact Customer Support at Weems & Plath and be sure to
note the number of your lamp so that the correct parts can be identied.
See inside page for detailed diagram of available parts.
#754
“S” Hook
214 EASTERN AVE. • ANNAPOLIS, MD 21403 • USA 410-263-6700 • fax 410-268-8713
#782
Wind Screen
#750
Screen Retaining Ring
#791
Glass
#752
Glass Retaining Ring
#793
Wick Holder Retaining Ring
#784
Wick Holder
#794
Oil Reservoir Gasket
#700B
Oil Reservoir (Font)
