Well CONV-HDMI-VGAST-WL User manual

HDMI to VGA Mini Converter
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
USER MANUAL
Table of Contents
1.0 Introduction.........................................................................01
2.0 Feature.................................................................................01
3.0 Specification.........................................................................02
4.0 Package Content..................................................................02
5.0 Panel Description.................................................................03
6.0 Connection and Operation..................................................03

HDMI to VGA Mini Converter
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
HDMI to VGA Converter
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
1.0 Introduction
The HDMI to VGA converter converts digital HDMI video signal to analog VGA, taking the input
resolution from your device and converting it into an analog signal at the same resolution. The
converter also separates the audio stream from the HDMI signal (HDMILPCM 2-Channel) and
converts it to analog stereo audio that can be used with the VGA display. With support for
resolutions of up to 1080p, the converter is a perfect solution for connecting video cards (desktop
or laptop) or consumer electronics devices such as game consoles or home theater receivers that
offer an HDMI output to a VGAdisplay.
2.0 Feature
* Easy to Use: Installs in seconds, no settings and resolution pass-through converter
* Converter HDMI signal to VGAsignal at the same resolution
*Audio output format: 2 channel LPCM
* Support HDCP 1.2
* Supports 225MHz/2.25Gbps per channel (6.75Gbps all channels) bandwidth for HDMI input
* HDMI resolution:
480p@60Hz, 720p@50/60Hz, 1080p@50/60Hz, 800x600@60 Hz,
1024x768@60 Hz,1920x1080@60Hz
* VGA resolution:
640x480@60Hz, 1280x720@50/60Hz,
1920x1080@50/60Hz. 800x600@60 Hz. 1024x768@60 Hz;
1

HDMI to VGA Mini Converter
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
3.0 Specification
Input Video Signal
HDMI Signal
Output Video Signal
VGA Signal
DTV/HDTV
480p/576p/720p/1080p
Video. Amplifier Bandwidth
2.25Gbps/225MHz
Vertical Frequency Range
60Hz
Progressive Resolutions(60Hz)
480p,576p,720p,1080p
Limited Warranty
1 Year Parts and Labor
Operating Temperature
0℃to 70℃
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10℃to +80℃
Storage Humidity
5% to 90% RH (no condensation)
Power Supply
5V DC
Power Consumption(Max)
5W
Converter Unit Cert
FCC,CE, RoHS
Power Supply Cert
CE,FCC, RoHS
Power Adapter Standard
US, UK, EU, AUS Standard
User Manual
English Version
Note:
1. The converter doesn’t support audio decoding. Please assure the output audio format of the
input device is set to LPCM in case there’s no sound output for the converter.
2. Specification is subject to change without notice.
4.0 Package Content
1) Main Unit x1
2) 5V Power Supply x1
3) User Manual x1
2

HDMI to VGA Mini Converter
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
5.0 Panel Description
6.0 Connection and Operation
3
