Wellcare WE-167FWH User manual

Electric Foot Warmer
Warmth in all directions | Carefully designed
Instruction Manual
WE-167FWH
Elektrischer Fußwärmer
Wärme in alle Richtungen |
Durchdachtes Design
Gebrauchsanleitung
Elektrische Voetenwarmer
Warmte van alle kanten I
Zorgvuldig ontworpen
Gebruiksaanwijzing
Chaue-pieds électrique
Chaleur dans toutes les directions |
Design soigné
Mode d’emploi

2
MODEL: WE-167FWH
GB Electric Foot Warmer
Warmth in all directions |
Carefully designed
Instruction Manual
DE Elektrischer Fußwärmer
Wärme in alle Richtungen |
Durchdachtes Design
Gebrauchsanleitung
NL Elektrische voetenwarmer
Warmte van alle kanten I
Zorgvuldig ontworpen
Gebruiksaanwijzing
FR Chaue-pieds électrique
Chaleur dans toutes les directions |
Design soigné
Mode d’emploi
WELLCARE CO., LTD.
16F, No. 738, Jhong Zheng Rd., Jhong He District, New Taipei City 235, Taiwan
Tel. [phone] Fax. [phone]
www.wellcare-global.com
CONTENT
B809.101-J1024
………………… 03
………………… 1 7
………………… 33
………………… 51

3
Explanation of symbols
GB
Read instructions
Do not dry clean
Do not tumble dry
Do not pierce with needles
Drip-proof! (applicable for the foot warmer)
Do not use when folded or creased
Do not iron
Not to be used by very young children
(0-3 years)
Wash by hand.
Maximum temperature 30°C
The lining can be washed in extra gentle
washing program at 30°C!
Do not bleach

4
Thank you for purchasing the Electric
Foot Warmer of Wellcare.
To enjoy the most comfortable
experience and the greatest satisfaction,
please take a few minutes to read this
instruction carefully before using this
product.
IMPORTANT SAFETY INSTRUCTIONS
RETAIN FOR FUTURE USE
KEEP CAREFULLY IN CASE IT IS NEEDED!
This foot warmer is designed to be used for many
years if it is properly used. Read the instruction
carefully to prevent damage or danger caused
by incorrect use. Keep this instruction manual at
an easy-to-access location so you can refer back
when necessary.
If you let somebody else use this product, please
pass on this instruction manual as well and make
sure the user has read it before using.
GB

5
B
C
1
34
2
A
FOOT
WARMER
REMOVABLE
LINING
56
7
321
GB

6
4D DWF® Technology (please see fig. C)
This electric foot warmer utilizes WELLCARE’s recent and the most
innovative technology – 4D DWF®. While this technology pioneers in the
flexible heating industry, its production process is also the state of the art
Our physical living environment consists of three dimensions, width,
length, and depth; hence, the term “3D”. As Wellcare introduces to you
the 4D DWF® technology, the “temperature” brought to you by dynamic
flow of warmth is the definition of the fourth dimension. 4D DWF®
employs concepts of breathing system which creates full-body heat
circulation for heat to disperse evenly, thoroughly, and quickly. The heat
is generated by heating elements, builds up and gathers around several
hundred uniquely designed circular holes. Through these holes, the heat
flows bi-directionally to create a gentle heat flow and the thermal energy
can flow rapidly to warm up human bodies.
There are many benefits of this innovative technology :
• Better breathability
• Rapid heating
• Higher temperature
• Uniquely designed holes to provide 360° warmth circulation
• Greater heat distributing area
• Eective heat transmission
• Strands of warmth flow retain air moisture
• Warmth kept at a constant temperature
• Energy saving
GB

7
This appliance is not intended for medical use in
hospitals.
• Please read carefully and follow the instructions.
• Examine the appliance frequently for signs of
wear or damage. If there are such signs or if
the appliance has been misused or does not
work, return it to the supplier before switching it
on again.
• Do not use this appliance if there is visible
damage.
• Use the appliance only as described in this
instruction manual.
• Before connecting the foot warmer to your
power supply, please ensure that the supply
voltage stated on the rating plate is compatible
with your mains supply.
• The foot warmer must not be used when folded
or crumpled.
• Do not use the appliance for persons who
cannot move without help, small children,
persons who cannot feel heat, or animals.
Persons who can feel heat to some extent may
only use the appliance with supervision.
• This appliance must not be used by persons
insensitive to heat and other very vulnerable
persons who are unable to react to overheating.
• Do not pierce the foot warmer with needles,
safety pins or other sharp objects.
• Do not tug, twist or make sharp bends to the
GB

8
cables.
• Do not carry or unplug the foot warmer by
pulling its mains cable.
• Do not expose the controller, the connection
box and the mains cable to moisture or liquids.
• Do not use this appliance when wet and only
use it in dry environments.
• Do not operate the foot warmer unsupervised.
• Caution! Never fall asleep while the appliance is
in operation.
• Prolonged use can cause burns to the skin.
• When the appliance will be used for an
extended period (falling asleep), the
temperature setting should be adjusted to the
lowest level (setting 1) for continuous use to
avoid overheating on the same body part, which
may lead to burns to the skin.
• A damaged mains cable cannot be replaced.
If the mains cable is damaged, the whole foot
warmer must be disposed of.
• While the foot warmer is switched on,
- Do not place any large or heavy objects on it
such as suitcases, etc.,
- Do not place any heat sources on it such as
hot water bottles, heating pads or such like.
- Due to the components in the controller will
make it slightly warm, never let the controller
to be covered or placed on the heating pad,
pillows and the like or lie on the electric
mattress heater.
GB

9
• Do not fold the foot warmer when it is hot.
• Children should be supervised to ensure that
they do not play with this appliance.
• Children below the age of three (0~3 years old)
are not allowed to use this appliance because
they are not able to react to overheating.
• This appliance cannot be used by young children
over the age of three (3 ~ 8 years old) unless the
controller has been preset by a parent or
guardian or the child has been instructed and
how to operate the blanket safely.
• This appliance may be used by children over the
age of eight (8), and persons with reduced
physical, sensory or mental capabilities or lack of
experience or knowledge if they have been
supervised or instructed concerning use of the
appliance in a safe way and understand the
hazards involved.
• Cleaning and user maintenance shall not be
made by children without supervision.
• If you have any concerns about health issues,
please consult with your doctor before using the
appliance.
• Do not use the foot warmer on parts of the
body that are swollen, injured or inflamed.
• If you experience any pain or discomfort while
using the unit, stop using it immediately.
• If you use a pacemaker, please consult your
doctor and the manufacturer of the pacemaker
before using this product due to the EMF
GB

10
(electromagnetic fields) emanated from this
electric product may interfere with functions of
your pacemaker under certain circumstances.
• This foot warmer is only designed to warm up
the human body. Do not use it on pets or other
animals.
• When the foot warmer is not in use:
- Set the slide switch on the controller to setting
“0” (OFF)
- The plug should be removed from the wall
socket and the foot warmer should be stored
in a dry place, without additional weight on it.
• When the foot warmer will not be used for a
period of time, we recommend that you store it
in the original packaging.
- Allow it to cool down before the storage.
- Do not crease the foot warmer by placing
items on top of it during storage.
- Store it in a dry place away from any liquids or
sources of heat.
• Do not wear shoes when using the foot warmer
because this will lower your heat-sensitivity and
will make the foot warmer dirty.
GB

11
ITEMS INCLUDED IN THE PACKAGE
1 Foot Warmer
1 Removable Fleece Lining
1 Controller with Cable and Power Plug
1 Instruction Manual
1 Product Catalogue
1 Service Instruction
1 Membership Card
DESCRIPTION OF THE DEVICE AND
CONTROLLER (please see fig.A)
1. Mains cable with plug
2. Controller
3. APS (Active Protection System) with 3-colored
LED display (on both sides)
4. Slide switch for ON, OFF and temperature
settings (1, 2, 3, 4)
5. Removable fleece lining
6. Foot warmer
7. Connection box
ADJUSTABLE FLEECE LINING (please see fig.B)
The snap button design on the fleece lining can
help you to adjust the lining to wrap your feet
higher, cover more area and feel snugger.
PREPARING FOR USE
1. Always make sure the foot warmer (6) is
GB

12
without any folds, creases or ruck-up.
2. Always use the foot warmer (6) with the
removable fleece lining (5) and only use the one
supplied with it.
3. Make sure the controller (2) is not covered by the
sheet, pillow or any objects.
4. Plug the mains cable (1) to the wall socket.
Unplug the appliance from the wall socket when it
is no longer in use.
SWITCHING ON
Before each time you use the foot warmer (6),
please make sure it is not bundled, folded or
creased before it is switched on.
Connect the product only to 230VAC. Switch on
the product by using the hand-operated slide
switch (4) and the light on the APS (3) will be
turned on to ensure the product has been operated
correctly.
Temperature settings :
4 = maximum warmth
2-3 = moderate warmth
1 = minimum warmth
0 = OFF
In order to warm up the foot warmer faster, it is
recommended to initially set the foot warmer at the
highest temperature setting.
GB

13
APS (Active Protection System) – 3-Color LED
This product is equipped with APS (Active
Protection System) (3) technology which detects
errors on the operation or component failures. By
the 3-color LEDs which can be seen from both sides
of the controller (2), APS can help you to operate
the foot warmer easily and safely.
Green – The product has reached the desired
temperature level.
Orange – The product is heating up to reach the
desired temperature level.
Due to the temperature variation in dierent
environments (room, bed, etc.), APS LED may
change between green and orange colors
within seconds which indicates continuous
heating when the product is in use. Under
this circumstance, please note the product is
functioning properly and normally.
Red light – Possible malfunction or overheating,
switch o the appliance immediately.
In the following situations, the red light will come on
to indicate warning:
• When the critical components are damaged:
Please disconnect the mains cable from wall
outlet immediately.
• When the heating wires or other components
are broken and the device cannot work anymore.
The warnings mentioned above cannot cover
all defective situations as the damages on some
GB

14
components will not lead to red light.
TURBO HEATING
The foot warmer is with a turbo heating function for
user to feel warmth within 7-10 minutes after it is
switched on.
TIMER FUNCTION
Now you can enjoy the pleasant warmth especially for
your feet. This foot warmer is equipped with an
automatic switch-o function. After approx. 90 minutes,
T
the foot warmer will be switched o automatically.
In order to put the foot warmer into operation again
you must set the slide switch (4) to setting ‘0’ first.
After about 5 seconds, you can switch on the foot warmer again.
CAUTION
• Do not use the foot warmer when it is folded, creased or drawn
together.
• The electronic components inside the controller may cause the
controller slightly warm when the product is in use. Therefore, the
controller must not be covered or placed on top of any heating
sources when it is in operation.
• You should not gauge the foot warmer’s temperature by hands
because hands are less sensitive to heat than the skin on the rest of
the body parts. The temperature may feel lukewarm by hands but
could be unpleasantly hot to feet.
CLEANING AND CARE
• Before cleaning the foot warmer (6), always unplug the product from
the wall socket first. Otherwise, there is a risk of electric shock.
• To clean the controller (2), use a dry, lint-free cloth.
Do not use any chemical or abrasive cleaning detergents.
• Please note that the foot warmer (6) should not be dry-cleaned,
wrung out, machine-dried, pressed, ironed or bleached.
• The foot warmer (6) can be hand washed at 30°C; small marks on
the foot warmer can be cleaned with a slightly damp cloth or a soft
brush. The connection box (7) must not come into contact with
water or any liquids.
• The removable fleece lining (5) is machine washable. Set washing
GB

15
machine to a gentle washing cycle at 30°C, the fleece lining
should only be washed together with other textiles. Use a mild
washing detergent for delicate fabrics and dose it according to
the manufacturer’s instructions. Always use a laundry bag for better
protection of the fabric.
• For dark color products, always wash separately.
• After washing, reshape the foot warmer (6) and the fleece lining (5)
to its original dimensions while it is still damp, and lay them flat on a
moisture-absorbent towel, mat or clothes horse to dry it.
• Do not use pegs or similar items to attach the foot warmer (6) to the
clothes horse, they may damage the foot warmer.
• Only use the foot warmer (6) and the fleece lining (5) when they are
complete dry.
• Never switch on the foot warmer to dry it.
STORAGE
If the foot warmer will not be used for a long time, we highly
recommend:
• Always let the appliance to cool down first before the storage.
• Store it in the original packaging and put it in a dry place.
• Do not put any object on the top of the appliance.
DISPOSAL
This appliance must not be disposed together with
domestic waste but at a suitable local collection or
recycling point. Please dispose of the appliance in
accordance with Directive on Waste Electrical and
Electronic Equipment (WEEE). If there is any
question, please contact the municipal authority for
more information about disposal in your area.
WARRANTY
Please note Wellcare provides two-year limited warranty for this
product. Wellcare warrants that this product will be free from defects in
materials and workmanship for a period of two years beginning on the
date of purchase.
During the two-year period beginning on the date of purchase, Wellcare
will replace defective products covered under this limited warranty.
Please note a clear copy of the purchase receipt for the product is
required. To request limited warranty service, please return the defective
GB

16
product to the store where you purchased it with the clear copy of
purchase receipt within the limited warranty period. The replacement
product will assume the remaining limited warranty of the original product.
We advise you to call our helpdesk for any problems regarding the
product before returning it to the store where you purchased it.
However, please note that our limited warranty does not cover any
damage due to shipment of the products to you and external causes,
including accident, abuse, misuse, problems with electrical power, usage
not in accordance with product instructions, failure to perform reasonable
maintenance, problems caused by use of parts and components not
supplied by Wellcare, and problems caused by unauthorized repair of
Wellcare’s product. Furthermore, our limited warranty does not cover any
damage due to the defects known to exist by you when you purchase the
product.
This limited warranty gives you specific legal rights, and you may also
have other rights that vary from country to country (or jurisdiction to
jurisdiction). Wellcare’s responsibility for malfunctions and defects in
product is limited to replacement as set forth in this limited warranty
statement. All express and implied warranties for the product,
including but not limited to any implied warranties of an conditions of
merchantability and fitness for a particular purpose, are limited in duration
to the limited warranty period set forth above and no warranties, whether
express or implied, will apply after such period. Wellcare does not accept
liability beyond the remedies set forth in this limited warranty statement
or liability for indirect, incidental or consequential damages.
TECHNICAL DATA
Model : WE-167FWH
Size : 30 (L) x 26 (W) x 21 (H) CM
Voltage : 230V~ 50Hz
Watts : 100W
GB

17
DE
Zeichenerklärung
Lesen Sie die Anweisungen
Nicht chemisch reinigen
Nicht im Trockner trocknen
Nicht mit Nadeln durchbohren
Tropfwasser geschützt! (gilt für den Fußwärmer)
Nicht benutzen, wenn gefaltet oder
zerknittert
Nicht bügeln
Nicht bei jungen Kinder einsetzen
(0-3 Jahre)
Handwäsche.
Höchsttemperatur 30 °C
Das Futter Bezug kann mit einem besonders schonenden
Waschprogramm bei 30 °C gewaschen werden!
Nicht bleichen

18
Vielen Dank für den Kauf des elektrischen
Fußwärmers von Wellcare.
Damit Sie unser Produkt optimal nutzen
können und langfristig Freude daran
haben, lesen Sie sich vor dem ersten
Gebrauch bitte sorgfältig die folgenden
Anweisungen durch.
WICHTIGE SICHERHEITSANWEISUNGEN
BEWAHREN SIE DIESE ANWEISUNGEN
ZWECKS SPÄTERER NUTZUNG AUF
HALTEN SIE DIESE ANWEISUNGEN GRIFFBEREIT !
Die Lebensdauer des Fußwärmers ist bei
ordnungsgemäßer Verwendung für viele Jahre
ausgelegt.
Lesen Sie sich die Anweisungen sorgfältig durch,
um Schäden oder Gefahren durch fehlerhaften
Gebrauch zu vermeiden. Bewahren Sie die
Bedienungsanleitung an einem sicheren und
leicht zugänglichen Ort auf, um später darauf
zurückgreifen zu können.
Wenn Sie das Produkt an andere Personen
weitergeben, legen Sie immer die
Bedienungsanleitung bei und stellen Sie sicher, dass
sie vor Gebrauch des Produktes gelesen wird.
DE

19
DE
B
C
1
34
2
A
FOOT
WARMER
REMOVABLE
LINING
56
7
321

20
Vorstellung der patentierten 4D-DWF®-Technologie (siehe Abb. C)
Der elektrische Fußwärmer verfügt über die neue und innovative 4D
DWF®-Technologie von Wellcare. Die wegweisende Heiztechnologie
wird mit einem für die Branche völlig neuen Produktionsverfahren
hergestellt.
Unsere Umgebung besteht aus drei Dimensionen – Breite, Höhe und
Tiefe – kurz ”3D” genannt. Mit der dynamischen Wärmverteilung der
neuen 4D-DWF®-Technologie bringt Wellcare eine vierte Dimension:
Temperatur. Das atmungsaktive System sorgt für eine schnellere und
gleichmäßigere Hitzeverteilung über die gesamte Fläche. Die spezielle
Oberflächenform sorgt dafür, dass die von Heizelementen erzeugte
Wärme um die zahllosen Perforierungen angestaut wird. Der in beide
Richtungen durch die Löcher fließende Luftstrom erzeugt dann einen
leichten Wärmefluss, der den Körper schneller erwärmt.
Diese neuartige Technologie bietet folgende Vorteile:
• Bessere Atmungsaktivität
• Schnelles Erwärmen
• Höhere Temperaturen
• Einzigartiges Lochdesign für eine vollständige Wärmezirkulation
• Großflächigere Wärmeverteilung
• Wirksame Wärmeübertragung
• Gleichbleibende Luftfeuchtigkeit aufgrund von Wärmefluss
• Konstante Temperatur
• Energiesparend
DE
