Wen 10725 User manual

INSTRUCTION MANUAL
SPECIFICATIONS
MODEL 10725
DIGITAL MICROMETER
WARRANTY STATEMENT
V. 2023.02.23
KNOW YOUR MICROMETER
Measuring Range 0 to 1 in. / 0 to 25 mm
Resolution 0.00005 in. / 0.001 mm
Measuring Force 5 to 10 N
Power CR2032 Lithium Battery
Power Consumption < 20 u A
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 76°F / -20 to 60°C
INSTALLING THE BATTERY
One CR2032 Lithium battery is included with your instrument. Turn the battery cover counterclockwise to open.
Insert the battery with the positive (+) side facing upward. Turn the battery cover clockwise to close.
CLEANING THE MEASURING SURFACES
Wipe clean the anvil and spindle faces with ethyl alcohol prior to use to remove any oil, grease, or debris.
WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this
commitment and our dedication to qualit
y.
LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE
GREA
T LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN
consumer
power tools will be free from defects in material or workmanship during personal use for a period of two (2) years
used
for professional or commercial use. Purchaser has 30 days from the date of purchase to report missing
or
damaged parts.
SELLER’S
SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the extent per-
mitted
by law, any warranty or condition implied by law, shall be the replacement of parts, without charge, which
are
defective
in material or workmanship and which have not been subjected to misuse, alteration, careless
handling,
misrepai
r, abuse, neglect, normal wear and tear,
improper maintenance, or other conditions adversely affecting the
Product
or the component of the Product, whether by accident or intentionally, by persons other than Seller. T
o
make
a claim under this Limited Warranty, you must make sure to keep a copy of your proof of purchase that
clearly
-
dor
of Great Lakes Technologies, LLC. Purchasing through third party vendors, including but not limited to
garage
sales,
pawn shops, resale shops, or any other secondhand merchant, voids the warranty included with this
product.
Contact [email protected] or 1-847-429-9263 with the following information to make arrangements:
your
shipping address, phone number, serial number, required part numbers, and proof of purchase. Damaged
or
defective parts and products may need to be sent to WEN before the replacements can be shipped out.
-
turning
a product for warranty service, the shipping charges must be prepaid by the purchaser. The product
must
be
shipped in its original container (or an equivalent), properly packed to withstand the hazards of shipment.
The
product
must be fully insured with a copy of the proof of purchase enclosed. There must also be a description of
the
will be returned and shipped back to the pur
chaser at no charge for addresses within the contiguous United States.
THIS
LIMITED WARRANTY DOES NOT APPLY TO ITEMS THAT WEAR OUT FROM REGULAR USAGE OVER T
IME,
INCLUDING
BELTS, BRUSHES, BLADES, BATTERIES, ETC. ANY IMPLIED WARRANTIES SHALL BE LIMITED
IN
DUR
ATION TO TWO (2) YEARS FROM DATE OF PURCHASE. SOME STATES IN THE U.S. AND SOME
CANADIAN
PROVINCES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMI-
TAT
ION MAY NOT APPLY TO YOU.
IN
NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING
BUT
NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE OR USE OF THIS PRODUCT
.
SOME ST
ATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITAT
ION
OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPL
Y
TO YOU.
THIS
LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS
WHICH
VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN CANADA AND FROM COUNTRY
TO COUNT
RY.
THIS
LIMITED WARRANTY APPLIES ONLY TO ITEMS SOLD WITHIN THE UNITED STATES OF AMERICA, CANA-
DA
AND THE COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE WITHIN OTHER
COUNTRIES,
CONT
ACT THE WEN CUSTOMER SUPPORT LINE. FOR WARRANTY PARTS OR PRODUCTS REPAIRED
UNDER
W
ARRANTY SHIPPING TO ADDRESSES OUTSIDE OF THE CONTIGUOUS UNITED STATES, ADDITIONAL
SHIPPING
CHARGES MA
Y APPLY.
Thimble
(Fine Adjustment)
LCD Display Ratchet
(Quick Adjustment)
Anvil Spindle Lock
ABS / in / mm
Button
On / Off / Set Button
Spindle

INSTRUCTION MANUAL
GENERAL SAFETY WARNINGS
OPERATION
ON / OFF / SET BUTTON
• Press and Release - Turns the tool ON / OFF
• Press and Hold (4 Seconds) - Resets reading to ZERO
ABS / IN / MM BUTTON
• Press and Release - Switches between absolute
measuring mode and relative measuring mode ("INC")
• Press and Hold (4 Seconds) - mm / in conversion
LCD DISPLAY
TOOL USE AND CARE
1. Avoid exposure to any liquids or excessive humidity.
2. Avoid exposure to electromagnetic fields or high voltages.
3. Avoid exposure to direct sunlight.
4. Use and store the instrument within the recommended temperature ranges.
5. Do not drop or apply excessive force to the instrument.
6. Do not attempt to disassemble the instrument.
7. Do not press the keys with a pointed object.
8. Use a dry soft cloth or cotton swab to clean the instrument. Ethyl alcohol can be used.
9. Do not use solvents (such as acetone or benzene) to clean the instrument.
CALIFORNIA PROP 65 WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities may contain
chemicals, including lead, known to the State of California to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other masonry products.
• Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies depending on how often you do this type of work. To reduce your exposure
to these chemicals, work in a well-ventilated area with approved safety equipment such as dust masks specially
designed to filter out microscopic particles.
INSTRUCTION MANUAL
"INC" Relative Measuring Mode
"in" Inch
"mm" Millimeter
NOTE: When taking measurements, do not touch the measuring faces of the micrometer. The small amount
of oil on your hands can affect the accuracy of your reading.
SPINDLE LOCK
Turn the spindle lock clockwise to lock the instrument. Do not rotate the thimble or ratchet when the lock is
engaged. Turn the spindle lock counterclockwise to unlock the instrument.
RATCHET & THIMBLE
Rotate the ratchet to make quick adjustments the spindle; rotate the thimble to make fine adjustments to the
spindle. When you hear a clicking sound during the rotation of the thimble, that means the spindle and anvil have
exerted adequate pressure on the subject and an accurate reading can be taken.
NOTE: The instrument will automatically turn OFF if it is not used for five minutes to preserve battery power.
Remove the battery if the instrument is not being used for an extended period of time.
OPERATION
WARNING! Follow the safety instructions below for handling and maintaining batteries.
• Do not short circuit batteries.
• Do not keep batteries near fire, sources of heat, or use in direct sunlight.
• Remove batteries from tool when not being used to an extended period of time.
• Never handle leaked batteries. Do not dismantle batteries.
• Recycle used tool and batteries at your local recycling facility.
• Remove the battery if the instrument is not being used for an extended period of time.
BATTERY WARNINGS
After each use, wipe clean the instrument clean with a soft cloth. DO NOT use any type of solvent. DO NOT
immerse the instrument in liquid. Water damage may cause the display to fail. If this happens, wipe off the liquid
and reset the instrument by removing the battery for 30 seconds. Then reinstall the battery and turn the tool ON.
CLEANING
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
[email protected]1-847-429-9263 (M-F 8AM-5PM CST)
PROBLEM POSSIBLE CAUSE SOLUTION
Incorrect measurement 1. Measuring surfaces are dirty
2. Preset data is incorrect
1. Clean the measuring surfaces
2. Reset instrument reading to ZERO
No display on LCD 1. Battery power is low
2. Battery is not properly installed
1. Replace with new CR2032 battery
2. Reinstall the battery, ensuring the (+)
side is facing up
Display is dim or flashing 1. Battery power is low 1. Replace with new CR2032 battery
TROUBLESHOOTING GUIDE
ABS / in / mm
Button
On / Off / Set
Button
