Wen 2309 User manual

Model # 2309
VARIABLE SPEED
CORDLESS ROTARY TOOL
bit.ly/WENvideo
Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
[email protected]
WENPRODUCTS.COM
(M-F 8AM-5PM CST)

TABLE OF CONTENTS
2
3
4
5
6
8
9
11
12
13
14
Safety Information
Electrical Information
Know Your Rotary Tool
Assembly and Adjustments
Operation
Exploded View and Parts List
PRODUCT SPECIFICATIONS
Model Number:
Rated Voltage:
Battery Model Number:
Battery Pack Capacity:
Charger Model Number:
Charger Specs:
No Load Speed Range:
Max Disc Diameter:
Max Collet Capacity:
Weight of Tool w/ Battery:
2309
9.6V DC
2309B
1 Ah NiMH
2309C
120V, 60 Hz, 0.5A
5,000 to 25,000 RPM
1 in.
1/8 inch
1 pound
2
Maintenance
Product Specifications
General Safety Rules
Rotary Tool Safety
Warranty

GENERAL SAFETY RULES
You know the drill. The purpose of the following safety symbols is to attract your attention to possible dangers.
We don’t want any of our beloved WEN customers accidentally injuring themselves. The safety symbols and the
explanations with them deserve your careful attention and understanding. The safety warnings do not by them-
selves eliminate any danger. These instructions and warnings are not substitutes for proper accident prevention
measures.
Safety Alert Symbol: Indicates danger, warning, or caution. This may be used in conjunction with
other symbols. Always follow the safety precautions to reduce the risk of fire, electric shock and
personal injury.
NOTE: Advising you of information or instructions is vital to the operation and maintenance of the equipment.
IMPORTANT:
Servicing requires extreme care and knowledge and should be performed only by a qualified service technician.
WARNING - Do not attempt to operate this tool until you have thoroughly read and understood
all instructions, safety rules, etc…contained in this manual. Failure to comply can result in accidents
involving fire, electric shock, or serious personal injury. Save this operator’s manual and review fre-
quently for continuing safe operation and instructing others who may use this tool.
Safe operation of this power tool requires that you read and understand this operator’s manual and all labels af-
fixed to the tool. Safety is a combination of staying alert, knowing how your tool works, and not doing dumb stuff.
3

4
GENERAL SAFETY RULES
Safety is a combination of common sense, staying alert, knowing how your item works, and not doing dumb stuff on
purpose. SAVE THESE SAFETY INSTRUCTIONS.
WARNING: To avoid mistakes and serious injury, do not plug the battery of your tool until the fol-
lowing steps have been read and understood.
1. READ and become familiar with this entire instruction manual. LEARN the tool’s applications, limitations, and
possible hazards.
2. AVOID DANGEROUS CONDITIONS. Do not use power tools in wet or damp areas or expose them to rain.
Keep work areas well lit.
3. DO NOT use power tools in the presence of flammable liquids or gases.
4. ALWAYS keep your work area clean, uncluttered, and well lit. DO NOT work on floor surfaces that are slippery
with sawdust or wax.
5. KEEP BYSTANDERS AT A SAFE DISTANCE from the work area, especially when the tool is operating.
NEVER allow children or pets near the tool.
6. DO NOT FORCE THE TOOL to do a job for which it was not designed.
7. DRESS FOR SAFETY. Do not wear loose clothing, gloves, neckties, or jewelry (rings, watches, etc.) when op-
erating the tool. Inappropriate clothing and items can get caught in moving parts and draw you in. ALWAYS wear
non-slip footwear and tie back long hair.
8. WEAR A FACE MASK OR DUST MASK to fight the dust produced during operation.
WARNING: Dust generated from certain materials can be hazardous to your health. Always oper-
ate the tool in a well-ventilated area and provide for proper dust removal. Use dust collection systems
whenever possible.
9. ALWAYS remove the power cord plug from the electrical outlet when making adjustments, changing parts,
cleaning, or working on the tool.
10. KEEP GUARDS IN PLACE AND IN WORKING ORDER.
11. AVOID ACCIDENTAL START-UPS.
12. REMOVE ADJUSTMENT TOOLS. Always make sure all adjustment tools are removed from the drill before
turning it on.
13. NEVER LEAVE A RUNNING TOOL UNATTENDED. Turn the power switch to OFF. Do not leave the
tool until it has come to a complete stop.
14. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is accidentally hit. DO NOT store
anything above or near the tool.

5
15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot-
wear. Keep the floor clear of oil, scrap, and other debris.
16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean and in good working order. Follow instruc-
tions for lubricating and changing accessories.
17. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts, jamming, breakage, improper
mounting, or any other conditions that may affect the tool’s operation. Any part that is damaged should be properly
repaired or replaced before use.
18. MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches and ALWAYS remove start-
er keys.
19. DO NOT operate the tool if you are under the influence of drugs, alcohol, or medication that may affect your
ability to properly use the tool.
20. USE SAFETY GOGGLES AT ALL TIMES that comply with ANSI Z87.1. Normal safety glasses only have
impact resistant lenses and are not designed for safety. Wear a face or dust mask when working in a dusty environ-
ment. Use ear protection such as plugs or muffs during extended periods of operation.
GENERAL SAFETY RULES
SAFETY RULES FOR BATTERIES
1. Ensure the switch trigger is in the off position before inserting the battery back.
2. Only recharge the battery with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create undesirable risks such as fire or death when used with another battery pack.
3. Only use the tool with the battery specified by the manufacturer.
4. Avoid storing the battery pack in a container with other metal objects such as nails, coins, clips, keys, screws, or
other small metal objects that could potentially connect one terminal to the other. Always protect the battery termi-
nals when the battery pack is not being used. Connecting the terminals together may cause burns or fire.
5. Under abusive conditions, liquid may be ejected from the battery. Avoid contact with this liquid like you would a
fire or an ex-lover. If contact accidentally occurs, flush the contact area with water. If the liquid contacts your eyes,
flush with water for 10 minutes and then seek medical help. Liquid ejected from the battery may cause irritation or
burns.
6. Battery tools do not need to be plugged into an electrical outlet, therefore they are always ready to operate. Be-
ware of the possible hazards when not using your battery tool or when changing accessories. Following this rule will
reduce the risk of electric shock, fire or personal injury.
7. Before using the battery charger, read all cautionary markings on the battery, the battery charger and the product
using the battery.
8. Do not expose the battery pack or the charger to damp environments such as water or rain.
9. Do not operate the charger with a damaged cord or plug.

6
10. Do not operate the charger or the battery if it has received a sharp blow, either from being dropped or damaged.
Take it to a qualified service technician before attempting to use.
11. Do not disassemble the charger or the battery pack. Take these to a qualified service technician when service or
repairs are required. Incorrect assembly may result in electric shock or fire.
12. Do not charge the battery pack when the temperature is below 50 degrees F (10 degrees C) or above 104 degrees
F (40 degrees C). Store the tool and battery pack in a location where temperatures will not exceed 122 degrees F (50
degrees C). This will help prevent serious damage to the battery cells.
13. Place the charger on a flat non-flammable surface and away from flammable materials when re-charging the
battery packs.
14. To reduce the risk of electric shock, unplug the charger from the outlet before attempting any maintenance or
cleaning.
15. If operating time has become excessively shorter, stop operating immediately. It may result in overheating, burn-
ing, or even an explosion.
16. Do not attempt to use a step-up transformer, an engine generator or a DC power receptacle.
17. Do not short the battery pack. Do not touch the terminals with any conductive material. Avoid storing the bat-
tery pack in a container with other metal objects such as nails, coins, etc. Always protect the battery terminals when
the battery pack is not in use.
18. Do not charge the battery pack inside a box or container of any kind. The battery must be placed in a well-
ventilated area during charging.
19. Do not allow anything to cover or clog the charging vents.
20. Do not incinerate the battery pack, even if you think it might be cool. The battery pack can explode in a fire and
pose a threat to anyone in the immediate area, which in my opinion isn’t cool at all.
21. Disconnect the charger from the power source when not in use. This will reduce the risk of electric shock or
damage to the charger if metal pieces should fall into the opening. It also will help prevent damage to the charger
during a power surge.
22. Make sure the trigger switch isn’t pressed before plugging in the battery.
23. The battery should be charged completely the first time of use.
SAFETY RULES FOR BATTERIES

7
CHARGER
Protect the battery charger and its cord from damage. Keep the charger and its cord away from heat, oil and sharp
edges. Electrical plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs
with grounded appliances. Unmodified plugs and matching outlets will reduce the risk of electric shock.
Keep the battery charger, battery pack(s) and the cordless tool out of the reach of children. Do not use the sup-
plied battery charger to charge other cordless tools. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature before inserting it into the charger to recharge.
Do not overcharge batteries. Do not exceed the maximum charging times. These charging times only apply to dis-
charged batteries. Frequent insertion of a charged or partially charged battery pack will result in overcharging and
cell damage. Do not leave battery in the charger for days on end. Never use or charge a battery if you suspect that
it has been more than 12 months since the last time they were charged. There is a high probability that the battery
pack has already suffered dangerous damage (exhaustive discharge). Do not use battery that have been exposed to
heat during the charging process, as the battery cells may have suffered dangerous damage. Do not use battery that
have suffered curvature or deformation during the charging process or those that exhibit other atypical symptoms
(gassing, hissing, cracking, etc.)
SAFETY RULES FOR CHARGERS
1. CHECK THE WORKPIECE for any cracks, bumps, nails or obstructions before commencing operation.
2. NEVER press in the locking pin when the rotary tool is running.
3. DO NOT cut any workpiece larger than the rotary tool’s capacity. Always maintain a firm grip on the rotary tool.
4. SECURE THE WORKPIECE whenever possible to prevent wobble, damage to the workpiece, and personal
injury.
5. ALWAYS USE safety goggles, a dust mask and hearing protection when using the rotary tool.
6. BEFORE TURNING ON THE ROTARY TOOL, ensure that it is completely clear of the workpiece.
7. NEVER touch any moving parts by hand.
8. CHECK THE POSITION of all electrical wiring and plumbing equipment when drilling into walls, floors or
ceilings.
9. DO NOT remove the attachment from the tool until it has completely stopped rotating.
10. DO NOT touch the attachment after operation, as it may be very hot. Allow time for the attachment to cool
before removing it.
11. DO NOT operate the tool in wet or damp conditions. Doing so significantly increases the risk of electrical shock
and other hazards.
12. DO NOT USE the tool if the ON/OFF switch is faulty, the plug or cable is damaged, or the tool produces
sparks, smoke, or unpleasant odors.
ROTARY TOOL SAFETY

CHECK with a licensed electrician or service personnel if you do not completely understand the grounding instruc-
tions or whether the tool is properly grounded.
CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are not sure, have a li-
censed electrician check the outlet.
WARNING: This tool is for indoor use only. Do not expose to rain or use in damp locations.
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy
enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage resulting
in loss of power and overheating. The table below shows the correct size to be used according to cord length and
nameplate ampere rating. When in doubt, use a heavier cord. The smaller the gauge number, the heavier the cord.
Make sure your extension cord is properly wired and in good condition. Always replace a damaged extension cord
or have it repaired by a qualified person before using it.
Protect your extension cords from sharp objects, excessive heat and damp/wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be protected
with a 15 A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in the OFF
position and the electric current is rated the same as the current stamped on the motor nameplate. Running at a
lower voltage will damage the motor.
WARNING: This tool must be grounded while in use to protect the operator from electric shock.
8
ELECTRICAL INFORMATION
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance
for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an
equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching outlet that is
properly installed and grounded in accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the outlet, have the proper outlet installed by a
licensed electrician.
IMPROPER CONNECTION of the equipment grounding conductor can result in electric shock. The conduc-
tor with the green insulation (with or without yellow stripes) is the equipment grounding conductor. If repair or
replacement of the electric cord or plug is necessary, DO NOT connect the equipment grounding conductor to a
live terminal.
AMPERAGE REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
0.5 A 18 gauge 16 gauge 16 gauge 14 gauge

9

CORDLESS ROTARY TOOL
1 - Rotational speed control
2 - Battery-operated LED
3 - Battery pack release button
3a - Battery pack
4 - Metal stirrup hanger
4a - Wrist strap
5 - ON/OFF switch
6 - Clamping nut
7 - Spigot nut
8 - Spindle lock
BATTERY CHARGER (A)
9 - Charging cradle
10 - Mains adapter
11 - LED
ACCESSORIES (B)
12 - 6 HSS drills ( Ø0.8mm, Ø 1mm, Ø1.2mm, Ø1.4mm, Ø1.6mm,
Ø2.0mm)
13 - 2 Mandrels for mounting tools
14 - 3 Polishing wheels
15 - 4 Grinding wheels
16 - 1 Metal brush
17 - 16 Cutting wheels
18 - 5 Collets (Ø 1.0mm, Ø1.5mm, Ø 2.0mm, Ø 2.4mm, Ø 3.2mm)
19 - 2 Plastic brushes
20 - 3 Engraving bits
21 - 2 Milling bits
22 - 5 Grinding bits
23 - Bit-changing spanner wrench

KNOW YOUR ROTARY TOOL

10
OPERATION
CHARGING THE BATTERY PACK
A battery pack that has been unused for a while or a pack that has never been charged before must be charged
completely before using. The battery pack requires roughly 3 to 5 complete charging and draining cycles before it
can reach its full potential.
CAUTION: Always unplug the charger from the wall before inserting or removing the battery from the charger.
INSERTING AND REMOVING THE BATTERY PACK
Make sure that the rotary tool is in the OFF position before plugging in the battery pack. Pressing the tabs (#3) on
either side of the battery pack will allow it to disengage and be removed from the rotary tool’s body. Make sure
the rotary tool is in the OFF position before unplugging the battery pack.
READING THE STATUS OF THE BATTERY PACK
The status or residual power is indicated as follows by the battery shaped readout (#2) found on the back of the
rotary tool.
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium-level charge
RED = weak charge
INSERTING OR REPLACING A TOOL OR COLLET
1. Press the spindle lock button (#8) and hold it down.
2. Rotate the clamping nut (#6) until the lock engages.
3. Loosen the clamping nut (#6) using the bit-changing spanner wrench (#23) and remove it from the tool. Once it
has been removed, you may release the spindle lock.
4. Insert the tool of your choice through the center of the clamping nut (#6) before inserting it into the collet that
matches the bit’s diameter.
5. Press the spindle lock again. Insert the collet into the end of the rotary tool. Hold it in place by tightening the
clamping nut using the bit-changing spanner wrench.
NOTE: Use the screwdriver end of the bit-changing spanner wrench to adjust the mandrels (#13).
ADJUST THE SPEED OF THE ROT ARY TOOL
Numbers on the rotational speed wheel (#1)are used to indicate the direction in which one should spin the adjust-
ment wheel to achieve the desired RPM. To increase speed, turn the wheel right, in the direction of the MAX
sign. To decrease speed, spin the wheel left toward the 1 sign.
Difficult workpieces and jobs (drilling, engraving glass, cutting metal, etc.) generally are performed more efficiently
at higher RPMS. Other projects, such as thermoplastics, or delicate polishing require slow rotary speeds. As a
general rule, larger attachments should be used at a lower speed. DO NOT use attachments larger than 1”, as they
may fly apart, causing injury.
SUGGESTED SPEED MATERIALS
1 to 3 Plastics and Low-Melting Point Materials
4 to 5 Stone and ceramics
5 Softwood and metals
6 to 7 Hardwood
Max Steel

11
OPERATION
BIT SELECTION
FUNCTION ACCESSORY APPLICATION
Drilling HSS Drill (#12) Drilling wood (Fig. C)
Milling Milling Bits (#21) Various tasks such as hollowing out, gouging, shap-
ing, slotting or grooving
Engraving Engraving bits (#20) Markings (Fig. D)
Derusting Metal Brush (#16) Derusting (see Fig. E)
Polishing Polishing Wheel (#14) Working on various metals and plastics, in particu-
lar noble metals like gold or silver (Fig. F)
Cleaning Plastic Brush (#19) Cleaning complex plastic housings or the area
around a door lock
Grinding Grinding Wheels (#15) or
Grinding Bits (#22)
Grinding of stone or precise tasks on hard materi-
als such as ceramics or alloy steel (Fig. G)
Cutting Cutting Discs (#17) Cutting metal and plastic (see Fig. H)

SUGGESTED SPEED MATERIALS
1 to 3 Plastics and Low-Melting Point Materials
4 to 5 Stone and ceramics
5 Softwood and metals
6 to 7 Hardwood
Max Steel


WARNING: Remove the plug from the socket before carrying out any adjustments, service or mainte-
nance.
1. NEVER use water or other liquids to clean the electrical portions of the tool.
2. ALWAYS clean the tool and bits after use.
3. ENSURE that the ventilation slots are not blocked to prevent overheating.
4. REMOVE AND DISPOSE of damaged attachments.
5. CHECK that the locking jaw is correctly aligned before use.
12
MAINTENANCE
EXPLODED VIEW AND PARTS LIST
No. Part Number Description Qty
1 2309-001 Locking Sleeve 1
2 2309-002 Collet Nut 1
3 2309-003 Collet 1
4 2309-004 Driver Shaft 1
5 2309-005 Right Housing 1
6 2309-006 Limited Plate 1
7 2309-007 Shaft Lock Spring 1
8 2309-008 Shaft Lock Button 1
9 2309-009 Bearing 1
10 2309-010 Sleeve 1
11 2309-011 Hex Screw 1
12 2309-012 Rubber Buffer 2
13 2309-013 Motor 1
14 2309-014 Push Plate 1
15 2309-015 Spring 1
16 2309-016 Left Housing 1
17 2309-017 Circuit Board 1
18 2309-018 Indicator Cover 1
19 2309-019 Power Switch 1
20 2309-020 Push Button 1
21 2309-021 Screw M3X12 5
22 2309-022 Battery Cover 1
23 Battery 1
24 End Cover 1
25 Back Moving Spring 2
26 Release Tab 2
27 Hanger 1
28 Screw M3X12 1
N/A 2309-023 Bit Accessory Kit 1
N/A 2309C Charger 1
2309B

13
EXPLODED VIEW AND PARTS LIST

WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with
this commitment and our dedication to quality.
LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE
GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con-
sumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of
purchase. Ninety days for all WEN products, if the tool is used for professional use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to
the extent permitted by law, any warranty or condition implied by law, shall be the repair or replacement of parts,
without charge, which are defective in material or workmanship and which have not been misused, carelessly
handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a claim under this
Limited Warranty, you must make sure to keep a copy of your proof of purchase that clearly defines the Date of
Purchase (month and year) and the Place of Purchase. Place of purchase must be a direct vendor of Great Lakes
Technologies, LLC. Third party vendors such as garage sales, pawn shops, resale shops, or any other secondhand
merchant void the warranty included with this product. Contact [email protected] or 1-800-232-
1195 to make arrangements for repairs and transportation.
When returning a product for warranty service, the shipping charges must be prepaid by the purchaser. The prod-
uct must be shipped in its original container (or an equivalent), properly packed to withstand the hazards of ship-
ment. The product must be fully insured with a copy of the warranty card and/or the proof of purchase enclosed.
There must also be a description of the problem in order to help our repairs department diagnose and fix the
issue. Repairs will be made and the product will be returned and shipped back to the purchaser at no charge.
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY ITEMS THAT WEAR OUT FROM
REGULAR USAGE OVER TIME INCLUDING BELTS, BRUSHES, BLADES, ETC.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO TWO (2) YEARS FROM
DATE OF PURCHASE. SOME STATES IN THE U.S., SOME CANADIAN PROVINCES DO NOT AL-
LOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITA-
TION MAY NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAM-
AGES (INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM
THE SALE OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CANADIAN
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CON-
SEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO
YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE
IN CANADA AND FROM COUNTRY TO COUNTRY.
THIS LIMITED WARRANTY APPLIES ONLY TO PORTABLE ELECTRIC TOOLS, BENCH POW-
ER TOOLS, OUTDOOR POWER EQUIPMENT AND PNEUMATIC TOOLS SOLD WITHIN THE
UNITED STATES OF AMERICA, CANADA AND THE COMMONWEALTH OF PUERTO RICO. FOR
WARRANTY COVERAGE WITHIN OTHER COUNTRIES, CONTACT THE WEN CUSTOMER SUP-
PORT LINE.
LIMITED ONE YEAR WARRANTY
14
