Wen 23114 User manual

3065544
VARIABLE SPEED
ROTARY TOOL
WITH CASE AND FLEX SHAFT
Model # 23114
Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
[email protected]
WENPRODUCTS.COM
(M-F 8AM-5PM CST)
bit.ly/wenvideo
For replacement parts visit
WENPRODUCTS.COM
Please refer to wenproducts.com for the most up-to-date instruction manual.

TABLE OF CONTENTS
2
3
4
6
7
8
9
12
14
15
16
17
PRODUCT SPECIFICATIONS
Model Number:
Motor:
Speed:
Collet Size:
Product Dimensions:
Product Weight:
23114
120V, 60 Hz, 1.4A
8,000 - 35,000 RPM
1/8 in. (3.2 mm)
3/32 in. (2.4 mm)
1/16 in. (1.6 mm)
9-7/8 x 2-1/3 x 2-1/5
1.4 lbs
Product Specifications
Safety Introduction
General Safety Rules
Electrical Information
Rotary Tool Safety Rules
Know Your Rotary Tool
Know Your Accessories
Assembly & Adjustments
Operation
Maintenance
Exploded View & Parts List
Warranty Statement
Compatible Rotary Tool Accessories Kits:
150-Piece (Model 230151A), 282-Piece (Model 230282A),
320-Piece (Model 230321A), 327-Piece (Model 230327A)
Your rotary tool is also compatible with the WEN 2305-KC
Keyless Rotary Tool Chuck, available at wenproducts.com.
2

SAFETY INTRODUCTION
Thanks for purchasing the WEN Rotary Tool. We know you are excited to put your tool to work, but first,
please take a moment to read through the manual. This manual provides information regarding potential
safety concerns, as well as helpful assembly and operating instructions. Safe operation of this tool requires that
you read and understand this operator’s manual and all labels affixed to the tool.
SAFETY ALERT SYMBOL: Indicates danger, warning, or caution. The safety symbols and the
explanations with them deserve your careful attention and understanding. Always follow the safety
precautions to reduce the risk of fire, electric shock and personal injury. However, please note that
these instructions and warnings are not substitutes for proper accident prevention measures.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may
occur. WEN reserves the right to change this product and specifications at any time without prior notice.
Keep this manual available to all users during the entire life of the tool and review it fre-
quently to maximize safety for both yourself and others.
3

Safety is a combination of common sense, staying alert and knowing how your item works.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc-
tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not
plug in your tool until the following steps have been read and understood.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents. Do not work on floor surfaces that
are slippery with sawdust or wax. Keep the ground clear of tripping hazards.
2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or fumes.
3. Keep bystanders at a safe distance from the work area. Never allow children or pets near the tool.
ELECTRICAL SAFETY
1. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock. Do not touch the power plug with wet hands.
2. Power tool plugs must match the outlet. Never modify the plug in any way. Modified plugs with non-matching
outlets will increase the risk of electric shock.
3. Check all power supplies periodically. Do not use defective cords. Damaged or entangled cords increase the
risk of electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts.
WARNING: Dust generated from certain materials can be hazardous to your health. Always operate
the tool in a well-ventilated area and wear a dust mask. Use dust collection systems when processing
wood and plastics. Dust extractors or dust bags must not be connected when processing metals.
PERSONAL SAFETY
1. Stay alert. Watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
2. Do not wear loose clothing, gloves, neckties, or jewelry (rings, watches, etc.) when operating the tool. Inap-
propriate clothing and items can get caught in moving parts and draw you in. Always wear non-slip footwear and
tie back long hair.
3. Use personal protective equipment. Always wear safety goggles at all times that comply with ANSI Z87.1. Use
ear protection such as plugs or muffs during extended periods of operation. Wear work gloves to protect your
hands. Wear a face mask or dust mask to fight the dust.
4. Keep proper footing and balance at all times and do not overreach when operating the power tool.
GENERAL SAFETY RULES
4

POWER TOOL USE AND CARE
1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to
a power source or carrying the tool.
2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper
mounting, or any other conditions that may affect the tool’s operation. Do not use the power tool if the switch
does not turn ON/OFF. Any part that is damaged should be properly repaired or replaced before use.
3. Do not force the tool to do a job for which it was not designed. Always use the correct tool/accessory for the
job and follow instructions to prevent a hazardous situation.
4. Never stand on the tool. Serious injury could occur if the tool is tipped over or if parts of the tool are unin-
tentionally contacted.
5. Remove adjustment tools. Always make sure all adjustment tools or wrenches are removed from the tool
before turning on the power tool.
6. Keep guards in place and in working order before operating the tool. All protection and safety devices must
be in place after completing repair and maintenance procedures.
7. Never leave a running tool unattended. Do not leave the tool until it has come to a complete stop.
POWER TOOL MAINTENANCE
1. Always disconnect the power cord plug from the electrical outlet when making adjustments, changing parts,
or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
2. Maintain power tools properly. Safely store power tools out of the reach of children. Always keep tools clean
and in good working order. Follow instructions for lubricating and changing accessories.
SERVICING
Use only identical replacement parts. Use of any other part can cause personal injury and damage to the tool.
Only have your power tool serviced by a qualified repair person.
CALIFORNIA PROPOSITION 65 WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities may contain
chemicals, including lead, known to the State of California to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling.
Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other masonry products.
• Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies depending on how often you do this type of work. To reduce your ex-
posure to these chemicals, work in a well-ventilated area with approved safety equipment such as dust masks
specially designed to filter out microscopic particles.
GENERAL SAFETY RULES
5

DOUBLE INSULATION
Double insulation is a concept in safety in electric power tools, where two systems of insulation
are provided. This eliminates the need for the usual three-wire grounded power cord. All exposed
metal parts are isolated from the internal metal motor components with protecting insulation.
Double insulated tools do not need to be grounded.
WARNING: The double insulated system is intended to protect the user from electric shock re-
sulting from a break in the tool’s internal insulation. Observe all normal safety precautions to avoid
electrical shock.
1. REPLACEMENT PARTS
When servicing use only identical replacement parts.
NOTE: Servicing of a product with double insulation requires extreme care and knowledge of the system and
should be performed only by a qualified service technician. For service, we suggest bringing the product to you
nearest authorized service center for repair. Always use original factory replacement parts when servicing.
2. POLARIZED PLUGS
To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
3. SERVICE AND REPAIR. To avoid danger, electrical appliances must only be repaired by qualified service
technician using original replacement parts; otherwise this may result in considerable damage to the user.
WARNING: To avoid electrocution, do not use in wet or damp areas or expose to rain.
GUIDELINES FOR USING EXTENSION CORDS
When using an extension cord, be sure to use one heavy enough to carry the current your product will draw.
An undersized cord will cause a drop in line voltage resulting in loss of power and overheating. The table below
shows the correct size to be used according to cord length and nameplate ampere rating. When in doubt, use a
heavier cord. The smaller the gauge number, the heavier the cord.
ELECTRICAL INFORMATION
Make sure your extension cord is properly wired and in good condition. Always replace a damaged extension
cord or have it repaired by a qualified person before using it. Protect your extension cords from sharp objects,
excessive heat and damp/wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be pro-
tected with a 15A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is
in the OFF position and the electric current is rated the same as the current stamped on the motor nameplate.
Running at a lower voltage will damage the motor.
AMPERAGE REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
1.4A 18 gauge 18 gauge 16 gauge 14 gauge
6

ROTARY TOOL SAFETY RULES
WARNING: Read and understand all warnings, cautions and operating instructions before using
this equipment. Failure to follow all instructions listed below may result in personal injury and tool
damage.
WORK ENVIRONMENT
• Do not operate the tool in wet or damp conditions; doing so significantly increases the risk of electrical
shock.
• Do not operate the tool in the presence of flammable liquids or gases.
TOOL INSPECTION
• Before operation, check the tool for any damage or missing parts. Do not use the tool if any part is missing
or damaged. Do not use the tool if the power switch is faulty, the plug or cable is damaged, or the tool pro-
duces sparks, smoke, or unpleasant odors (you may smell brushes burning for a few minutes as the tool breaks
in during the first use, that is okay).
• Make sure all adjustments are correct and all connections are tight.
ACCESSORIES INSPECTION
• The accessory must have a rated speed higher than or equal to 35,000 RPM (the maximum tool operating
speed of your rotary tool), otherwise there is a risk of injury.
• The spindle size of the accessory must properly fit the tool’s collet in order to be mounted securely.
• Before operation, inspect the accessories for any chips, cracks or excess wear. Do not use damaged acces-
sories.
WORKPIECE INSPECTION
• Check the workpiece for any cracks, bumps, nails or obstructions before commencing operation.
• Do not cut any workpiece that exceeds the rotary tool or the rotary tool bit’s operation capacity.
• Check the position of all electrical wiring and plumbing equipment when drilling into walls, floors or ceil-
ings.
SECURING THE WORKPIECE
Use clamps to secure the workpiece whenever possible to prevent wobble, damage to the workpiece, and per-
sonal injury.
PERSONAL SAFETY
• Always use ANSI Z87.1-approved safety goggles, a dust mask and hearing protection during operation.
• Always maintain a firm grip on the rotary tool by the insulated gripping surfaces only.
SETTING THE SPEED
Set the suitable speed for your operation, workpiece and accessory. Use slow speeds for some plastics and pre-
cious metals to prevent damaging the material. Use slow speeds (15,000 RPM or less) for all brushing applica-
tions using wire wheels and polishing operations using felt polishing accessories. Use higher speeds for drilling,
carving, cutting, routing, shaping, cutting dadoes or rabbets in wood, metal and glass.
USING THE FLEX SHAFT
• Never cross the flex shaft over itself during operation.
• Do not bend the flex shaft near its connection to the rotary tool.
• Do not operate the flex shaft with a sharp bend. The recommended minimum radius for the flex shaft is 5
inches. Bending the shaft farther than this can generate excessive heat and damage the flex shaft.
• Lubricate the flex shaft inner coil every couple of hours of operation to prevent overheating.
7

KNOW YOUR ROTARY TOOL
Carefully unpack the tool from the packaging. Check all components and compare against the graph below. If
any part is damaged or missing, please contact our customer service at [phone], M-F 8-5 CST or email
us at [email protected].
Carbon Brush Cover (one on each side)
Spindle Lock Button
Collet Nut
Rotational Direction
Variable Speed Dial
ON/OFF Switch
Hanger
Ventilation Slots
Locking
Collar
ROTARY TOOL SAFETY RULES
(Continued)
TURNING ON THE TOOL
Before turning on the rotary tool, ensure that it is completely clear of the workpiece. Let the tool reach full
speed before making contact with the workpiece.
DURING OPERATION
• Do not apply excessive pressure to the tool or attempt to make an excessive depth of cut. Overstressing the
tool may cause kickback and damage the tool and accessories.
• Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory.
• Never touch any moving parts of the tool by hand.
• Never press in the spindle lock button when the rotary tool is running.
TURNING OFF THE TOOL.
Clear the tool from the workpiece before switching off the tool. Wait for the rotary bit to come to a complete
stop before setting the tool down.
MAKING ADJUSTMENTS
• Always turn off the machine and disconnect from the power source before making adjustments or changing
attachments. Do not remove the attachment from the tool until it has completely stopped rotating.
• Do not touch the accessory attachment immediately after operation, as it may be very hot. Allow time for
the accessory to cool and calm down before removing it.
8

No. Description Qty.
12 Wrench 1
13 Grinding Bits (1/8”) 5
14 Drill Bits (1/8”, 3/32”, and 1/16”) 3
15 Sanding Drum Mandrel 2
16 HSS Cutter (1/8”) 1
17 Drywall Cutting Bit 1
18 Drill Guide Collar 1
19 LED Light Collar 1
20 Shield Collar 1
21 Flex Shaft 1
22 L-Shaped Tool 1
No. Description Qty.
1 Collet (1/8”, 3/32”, and 1/16”) 3
2 Sanding Bands 12
3 Felt Polishing Wheel 4
4 Sanding Disc 40
5 Cut-Off Wheel 36
6 Dressing Stone 1
7 Screw Mandrel (1/8”) 1
8 Small Screw Mandrel (1/8”) 1
9 Wire Brush (1/8”) 2
10 Wool Polishing Bit (1/8”) 1
11 Diamond Bits (1/8”) 7
KNOW YOUR ACCESSORIES
7.
14.
8. 9. 10. 11.
13.
18. 19. 20. 21. 22.
15.
3.2.1.
16. 17.
12.
4. 5. 6.
9
INCLUDED ACCESSORIES:

No. Accessory Explanation & Applications
1
Collet
(Ø1/8", Ø3/32",
Ø1/16")
For holding a rotary tool bit in place. Your tool comes with Ø1/8", Ø3/32",
Ø1/16" sized collets. Always use the correct collet size that matches the shank
diameter of the rotary tool bit.
2Sanding Band
(Big & Small)
Slides over the top of the sanding drum mandrel to sand and smooth around
surfaces and inside curves. Replace the sanding bands when the grits are
worn down. Do not use at speeds higher than 15,000 RPM.
Attach to No. 15 Sanding Drum Mandrel.
3 Felt Polishing Wheel
Screws onto the top of the screw mandrel to clean, polish and buff metal,
wood and plastics to a smooth and bright finish. Do not use at speeds higher
than 15,000 RPM.
Attach to No. 7 Screw Mandrel.
4 Sanding Disc Disc-shaped sandpaper used for material removal and resurfacing.
Attach to No. 8 Small Screw Mandrel.
5 Resin Cut-off Wheel
Thin disc used for slicing and cutting screws, sheet metal, thin wood and
plastics. Only cut along the wheel's edge; do not use for sanding or cutting
curves. Attach to No. 8 Small Screw Mandrel.
6 Dressing Stone A solid block made of hard abrasive. Breathes new life back into old or worn
grinding wheel and grinding stone bits.
7Screw Mandrel
(Ø1/8") A mandrel with a screw head for attaching felt polishing accessories.
8Small Screw Mandrel
(Ø1/8")
A mandrel with a threaded head, rubber rings and slotted tip for attaching
wheel accessories.
9 Wire Brush (Ø1/8")
For general cleaning and polishing purposes.
Do not use at speeds higher than 15,000 RPM. Can be used with polishing
compound for more efficient cleaning or polishing.
CAUTION: Excessive pressure can damage the wires. Operate with light
pressure and let the tips of the wire brush do the work.
10 Felt Polishing Bit
(Ø1/8”) Use for polishing and buffing jewelry, soft metal, wood and plastics.
11 Diamond Coated Bit
(Ø1/8")
Bits of various shape to efficiently cut and engrave in wood, plastics, and soft
metals such as aluminum, copper, and brass.
12 Wrench
Use the front of the wrench for loosening the collet nut to change collets.
Use the back of the wrench for adjusting the screws on the sanding drum and
small screw mandrel, and for opening the carbon brush covers.
Refer to the chart below for explanations and recommended applications for your rotary tool accessory bits.
KNOW YOUR ACCESSORIES
10

KNOW YOUR ACCESSORIES
No. Accessory Explanation & Applications
13 Grinding Stone Bit
(Ø1/8")
Bits of various shapes used for grinding and abrasive operations. Great for
removing flash from metal castings, deburring metal after cutting, smoothing
welded joints, grinding off rivets and removing rust.
Can be sharpened with No. 6 Dressing Stone.
14
Drill Bit
(Ø1/8", Ø3/32",
Ø1/16")
Drill into materials such as metal, hardwood, and plastics. Make sure to use
the correct size collet for your drill bit.
15 Sanding Drum Man-
drel (Ø1/8")
A mandrel with a cylinder-shaped rubber tip for attaching sanding bands.
Can be expanded or retracted using the back of No. 12 Wrench.
16 HSS Cutter Bit
(Ø1/8")
Use for edge cutting, carving and creating slots and holes in plastics, wood
and metals.
17 Drywall Cutting Bit
Use the front of the wrench for loosening the collet nut to change collets.
Use the back of the wrench for adjusting the screws on the sanding drum and
small screw mandrel, and for opening the carbon brush covers.
18 Drill Guide Collar Attach to your rotary tool to hold it vertical and steady during drilling opera-
tions.
19 LED Light Collar Attach to your rotary tool to improve visibility in dimly lit areas.
20 Shield Collar Attach to your rotary tool to improve safety by protecting user from debris
and sparks caused by various applications such as grinding, polishing, etc.
21 Flex Shaft
Flexible shaft that connects to the rotary tool to increase versatility and
control. Follow the instructions and warnings for proper operation and
maintenance of the flex shaft to reduce the risk of tool damage and personal
injuries.
22 L-Shaped Tool Use to lock the spindle of the flex shaft when changing bits on the flex shaft.
Compatible Rotary Tool Accessories Kits: 150-Piece (Model 230151A), 282-Piece (Model 230282A),
320-Piece (Model 230321A), 327-Piece (Model 230327A).
Your rotary tool is compatible with the WEN 2305-KC Keyless Rotary Tool Chuck (not included), available
for purchase at wenproducts.com. The keyless chuck will allow you to quickly and easily change accessories
without changing collets.
11

WARNING: Check to make sure that all accessories are assembled correctly and securely on the ro-
tary tool. Do not use if any accessory or part is loose or damaged.
INSTALLING SANDING BANDS (Fig. 2)
Loosen the screw on the top of the sanding drum using the end of
the included wrench to contract the width of the drum. Slide the
sanding band onto the sanding drum. Fully tighten the screw to
expand the width of the sanding drum to hold the sanding band
in place. Make sure the sanding drum is sufficiently expanded to
secure the band during use. If sanding band is loose on the drum,
it may fly off during operation and cause injuries.
INSTALLING FELT POLISHING ACCESSORIES (Fig. 3)
Thread the felt polishing accessory straight down onto the tip of
the screw mandrel. The accessory must be threaded all the way
down to touch the collar of the screw mandrel.
INSTALLING WHEEL/DISC ACCESSORIES (Fig. 1)
Loosen and remove the screw at the top of the small screw man-
drel. Remove the top red ring from the screw and slide the wheel
or sanding disc above the bottom red ring (ensure the abrasive
side of the disc is facing up for sanding disc). Slide the top red
ring above the wheel/disc, so that there is one red ring on each
side of the wheel. Reattach the screw onto the mandrel to secure
the wheel/disc in place.
INSTALLING ROTARY TOOL BITS (Fig. 4)
1. Switch off and unplug the tool before making any adjustments.
2. Hold down the spindle lock button (Fig. 4 - 1) and rotate the
collet nut (Fig. 4 - 2) until the spindle lock engages.
3. Using the included wrench, loosen and remove the collet nut
by turning it counterclockwise. Release the spindle lock button.
4. An 1/8" collet is pre-installed inside the tool. Three collet sizes
are included with your rotary tool as accessories: 1/8", 3/32" and
1/16".
Select the suitable collet to match the spindle diameter of your
desired rotary tool bit. Thread the selected collet onto the spin-
WARNING: To avoid injury from accidental startups, always ensure that the tool is switched OFF and
unplugged from the power supply before making adjustments or changing accessories.
dle and screw the collet nut back on, but do not tighten all the way.
5. Fully insert the rotary bit into the spindle hole through the collet nut and collet. Press down the spindle lock
button and fully tighten the collet nut using the included wrench. Pull on the rotary tool bit to check that it is
firmly secured inside the tool.
Fig. 4
Fig. 1
Small Screw Mandrel
Screw Mandrel
Sanding Disc or
Cut-Off Wheel
Felt Polishing
Wheel/Tip
Sanding Drum
Mandrel
Sanding Band
Fig. 2
Fig. 3
ASSEMBLY & ADJUSTMENTS
1
2
12

ASSEMBLY AND ADJUSTMENTS
ATTACHING THE FLEX SHAFT (Fig. 5 - 14)
FOR VIDEO INSTRUCTIONS ON ATTACHING THE FLEX SHAFT, VISIT: http://bit.ly/wenflexshaft
Fig. 5
Fig. 7
Fig. 10
Fig. 12
Fig. 6
Fig. 8
Metal Ring Collet Nut
Fig. 11
Fig. 13
Fig. 14
IMPORTANT: Follow the rules below when using your flex shaft to
prevent overheating and causing personal injuries.
•Lubricate your flex shaft regularly to prevent overheating (see
"Lubricating the Flex Shaft" on page 16).
• Do not bend the flex shaft near its connection to the rotary tool.
Keep it straight.
1. Unscrew and remove the locking collar from the end
of the rotary tool (Fig. 5).
2. Use the 1/8" collet for attaching the flex shaft. Press
down on the spindle lock button (Fig. 6) to unscrew the
collet nut and check the collet size. Replace the collet
nut.
3. Take the flex shaft from your tool kit and pull the in-
ner core out about 2 to 3 inches (Fig. 7).
4. Insert the inner core of the flex shaft into the spindle
hole through collet nut and collet (Fig. 8). Make sure
that the golden metal ring is pressed tightly against the
collet nut (Fig. 9). Press down on the spindle lock but-
ton, and fully tighten the collet nut with the included
wrench.
5. Now that the inner core is secured to the collet nut,
slide down the silver flex shaft adapter and screw it onto
the rotary tool by turning it clockwise (Fig. 10).
6. Once secured, take L-shaped tool and insert it into
the spindle hole on the side of the flex shaft to prevent
the flex shaft spindle from rotating. (Fig. 11).
7. Unscrew the flex shaft collet nut and check the size of
the collet against your rotary bit. Use the correct size of
collet for your desired rotary tool bit (Fig. 12).
8. Install the collet and collet nut, and fully insert the
rotary bit into the center hole through the collet. Lock
the spindle with the L-shaped tool and use the included
wrench to fully tighten the collet nut and ensure that the
bit is properly secured to the flex shaft (Fig. 15).
Fig. 9
13
• Never cross the flex shaft over itself during operation. Do not operate the flex shaft with a sharp bend. The
recommended minimum radius for the flex shaft is 5 inches (Fig. 14). Bending the shaft farther than this can
generate excessive heat and damage the flex shaft.

Fig. 15
1
WARNING: Read and thoroughly understand all instructions and safety information before operat-
ing this rotary tool. Failure to do so may cause serious injury.
OPERATION
OPERATING THE ROTARY TOOL
As with all power equipment, a rotary tool can be dangerous if it is not assembled or used properly. Do not
operate this power tool if you have doubts or questions regarding operation safety. Call our customer service
department at 1-800-232-1195 M-F 8-5 CST to address your questions or concerns.
WARNING: Always wear ANSI Z87.1-approved safety glasses, safety gloves and suitable work cloth-
ing. Do not wear jewelry, neckties or other loose clothing which could get caught in moving parts. Hold
the tool away from your face and body in case parts and chips fly out unexpectedly during operation.
WARNING: Do not start or operate this tool in the presence of flammable liquids or gases. Sparks
generated by the rotary tool could ignite these flammable materials.
1. Inspect the tool for any damage before use. Immediately discard any accessories with bent shafts or any other
damage. Make sure that the ventilation slots on the tool are not obstructed, otherwise the motor may overheat.
2. The power switch is located on the underside of the handle. To switch on the tool, flip it to I (the ON posi-
tion). To switch off the tool, flip the switch to O (the OFF position). Be certain the tool is in the OFF position
when not in use and during all maintenance activities.
3. Set the suitable speed for your operation. Turn on the tool and let the motor reach full speed. Slowly lower
the accessory bit onto the workpiece and guide the tool with light, even pressure.
NOTE: Do not exert excessive pressure on your tool as it may damage your workpiece and the accessory bit.
Let the tool do the work. For better results, make several progressive passes until the desired cutting depth or
finish is achieved.
4. Lift the tool away from the workpiece and turn OFF the switch. Wait for the tool to come to a complete stop
before setting it down. Do not touch the rotary accessory or workpiece immediately after operation as they can
be very hot. Follow the instructions on the next page for properly maintaining your tool and accessories.
ADJUSTING THE SPEED OF THE ROTARY TOOL (Fig. 15)
The variable speed adjustment wheel on the top of the rotary tool is used to set
the desired rotation speed. The speed for your rotary tool ranges from 8,000
to 35,000 RPM. To increase the speed, turn the wheel forward to a higher
number. To decrease speed, turn the wheel backwards to a lower number.
Set the suitable speed for your operation, workpiece and accessories:
• Use slow speeds for plastics, ceramics, precious metals and low-melting point materials to prevent damag-
ing the material. All brushing applications and delicate polishing require slow rotary speeds lower than 15,000
RPM.
• Use higher speeds when working on wood, metal and glass. Drilling, carving, cutting, routing, shaping or rab-
bets are generally performed more efficiently at faster rotary speeds.
As a general rule, larger attachments should be used at a lower speed. The best way to determine the suitable
speed is to test on a scrap piece of similar material, observe the results and adjust the speed accordingly.
14

WARNING: Always switch OFF and disconnect the rotary tool from the power supply before car-
rying out any adjustments, service or maintenance.
IMPORTANT: Servicing of the tool requires extreme care and knowledge and should be performed only by
a qualified service technician.
CLEANING AND INSPECTION
1. After each use, clean the tool and accessories using a clean cloth or a soft brush. NEVER use water or other
liquids to clean the electrical portions of the tool.
2. Keep the ventilation openings free from dust and debris to prevent the motor from overheating.
3. Check the tool and accessories for any damage. Remove and dispose of damaged accessories.
LUBRICATING THE FLEX SHAFT
The flex shaft’s inner coil rotates at high speed during operation, generating friction and heat. It is important to
lubricate the inner coil of your flex shaft after several hours of operation to prevent it from overheating.
To lubricate the flex shaft, pull the inner coil out from the flex shaft. Apply an even coat of multi-purpose grease
onto the entire surface of the inner coil. Insert the inner coil back into the flex shaft.
CARBON BRUSHES INSPECTION AND REPLACEMENT (Fig. 16 & 17)
MAINTENANCE
Carbon Brush
Length
To maintain efficiency of the motor, inspect the two carbon brushes
routinely. The wear on the carbon brushes depends on how fre-
quently and how heavily the tool is used. Replace the brushes when
the brush length gets down to 1/8 of an inch or when the tool stops
working.
NOTE: Replacement carbon brushes (Model 23114-010) can be
purchased from wenproducts.com. Only genuine WEN replace-
ment brushes designed specifically for your tool should be used.
1. The carbon brush caps are located on the top and bottom of the
rotary tool (Fig. 16). To access the brushes, unscrew and remove the
two brush caps using the end of the wrench included with your tool
kit.
2. Take out and inspect the carbon brushes (Fig. 17). If the brushes
are worn to under 1/8 inch in length, replace them with new carbon
brushes and reinstall the brush caps. Both carbon brushes should
be replaced at the same time. Fully tighten both brush caps with the
wrench.
Fig. 16
Fig. 17
NOTE: Keep carbon brushes clean and ensure that they slide freely in the brush holders.
PRODUCT DISPOSAL
Used power tools contain recyclable materials and should not be disposed with household waste. Please take
this product to your local recycling facility for responsible disposal and to minimize its environmental impact.
1
15

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty
1 23114-001 Collet Nut 1
2 23114-002 Collet 1
3 23114-003 Nose Cap 1
4 23114-004 Spindle Lock Button 1
5 23114-005 Ø 8 Base 1
6 23114-006 Bearing 1
7 23114-007 Fan 1
8 23114-008 Rotor 1
9 23114-009 Left Body 1
10 23114-010 Carbon Brush 2
11 23114-011 Screw 6
No. Part No. Description Qty
12 23114-012 Variable Speed Dial 1
13 23114-013 Stator 1
14 23114-014 Variable Speed Board 1
15 23114-015 Switch 1
16 23114-016 Hanger 1
17 23114-017 Cord Sleeve 1
18 23114-018 Plug 1
19 23114-019 Cord 1
20 23114-020 Right Body 1
21 23114-021 Flex Shaft 1
22 23114-022 Carrying Case 1
16

17
WEN Products is committed to building tools that are dependable for years. Our warranties are consistent
with this commitment and our dedication to quality.
LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE.:
GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN
consumer power tools will be free from defects in material or workmanship for a period of one (1) year from
date of purchase. Ninety days for all WEN products, if the tool is used for professional use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and,
to the extent permitted by law, any warranty or condition implied by law, shall be the repair or replacement
of parts, without charge, which are defective in material or workmanship and which have not been misused,
carelessly handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a
claim under this Limited Warranty, you must make sure to keep a copy of your proof of purchase that clearly
defines the Date of Purchase (month and year) and the Place of Purchase. Place of purchase must be a di-
rect vendor of Great Lakes Technologies, LLC. Third party vendors such as garage sales, pawn shops, resale
shops, or any other secondhand merchant void the warranty included with this product. Contact techsup-
[email protected] or 1-800-232-1195 to make arrangements for repairs and transportation.
When returning a product for warranty service, the shipping charges must be prepaid by the purchaser. The
product must be shipped in its original container (or an equivalent), properly packed to withstand the hazards
of shipment. The product must be fully insured with a copy of the warranty card and/or the proof of purchase
enclosed. There must also be a description of the problem in order to help our repairs department diagnose
and fix the issue. Repairs will be made and the product will be returned and shipped back to the purchaser at
no charge.
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY ITEMS THAT WEAR OUT
FROM REGULAR USAGE OVER TIME INCLUDING BELTS, BRUSHES, BLADES, ETC.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR FROM
DATE OF PURCHASE. SOME STATES IN THE U.S., SOME CANADIAN PROVINCES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES (INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING
FROM THE SALE OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CA-
NADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO
PROVINCE IN CANADA AND FROM COUNTRY TO COUNTRY.
THIS LIMITED WARRANTY APPLIES ONLY TO PORTABLE ELECTRIC TOOLS, BENCH POW-
ER TOOLS, OUTDOOR POWER EQUIPMENT AND PNEUMATIC TOOLS SOLD WITHIN THE
UNITED STATES OF AMERICA, CANADA AND THE COMMONWEALTH OF PUERTO RICO.
FOR WARRANTY COVERAGE WITHIN OTHER COUNTRIES, CONTACT THE WEN CUSTOM-
ER SUPPORT LINE.
LIMITED ONE YEAR WARRANTY

THANKS FOR
REMEMBERING
