Wen 3705 User manual

1

2

3
Table of Contents
SECTION PAGE
Specifications………………………………………………………………… 4
Rules for safe operation……………………………………………………… 5
General instructions for all power tools……………………………………… 6
Extension cords………………………………………………………………. 12
Grounding instructions……………………………………………………….. 13
Unpacking……………………………………………………………………. 14
Assembly……………………………………………………………………... 15
To mount table saw on a work bench………………………………… 15
To assemble the leg stand……………………………………………. 15
To mount the leg stand on table saw base……………………………. 16
To install the handwheel……………………………………………… 16
To assemble the blade guard…………………………………………. 16
Operating instructions………………………………………………………… 17
Table saw adjustments………………………………………………... 17
Blade depth and angle adjustments…………………………………... 17
45º and 90º positive stop adjustment…………………………………. 18
Aligning and adjusting the rip fence…………………………………. 18
Adjusting table insert…………………………………………………. 19
Miter gauge operation and adjustment……………………………….. 19
Adjusting blade parallel to miter gauge slots………………………… 19
Installing/Replacing saw blade………………………………………. 20
Workpiece and work area set up……………………………………… 21
Operating……………………………………………………………… 21
Avoiding kickback…………………………………………………….. 22
Making a cross-cut…………………………………………………….. 22
Making a rip-cut……………………………………………………….. 23
Making a bevel rip-cut………………………………………………… 24
Maintenance and servicing…………………………………………………….. 25
Exploded view and parts list…………………………………………………… 26
Warranty statement…………………………………………………………….. 29

4
Specifications
10” Table Saw with Stand Item#: 3705
Motor: 120V, 60Hz, 15A
Motor speed: 4800rpm (no load)
Blade: 10” carbide tipped
Arbor size: 5/8” dia.
Depth of cut at 90º: 3”
Depth of cut at 45º: 2-3/8”
Bevel angle range: Left, 90º-45º
Table dimensions: 16”x26”
Weight: 39 lbs
Package contents:
Table Saw, Stand Set, Blade Guard, Rip Fence, Miter Gauge, Push Stick and Blade Wrench

5
Rules for safe operation
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols, and the explanations with them, deserve your careful attention and understanding. The
safety warnings do not by themselves eliminate any danger. The instructions or warnings they
give are not substitutes for proper accident prevention measures.
Symbol Meaning
Safety Alert Symbol:
Indicated danger, warning, or caution, may be used in conjunction with other symbols
or pictographs. Always follow the safety precautions to reduce the risk of fire, electric
shock and personal injury.
NOTE: advising you of information or instructions is vital to the operation or maintenance of
the equipment.
Important
Servicing requires extreme care and knowledge and should be performed only by a qualified
service technician. For service, we suggest you return the tool to WEN PRODUCTS a division
of Great Lakes Technologies, LLC. for repair . When servicing, use only identical WEN®
replacement parts.
WARNING - Do not attempt to operate this tool until you have read thoroughly and
understand completely all instructions, safety rules, etc…contained in this manual.
Failure to comply can result in accidents involving fire, electric shock, or serious
personal injury. Save this operator’s manual and review frequently for continuing safe
operation and instructing others who may use this tool.
Safe operation of this power tool requires that you read and understand this operator’s manual
and all labels affixed to the tool. Safety is a combination of common sense, staying alert, and
knowing how your tool works.

6
General instructions for all power tools
READ ALL INSTRUCTIONS!!!
•Know your power tool. Read the operator’s manual carefully. Learn the application and
limitations as well as specific potential hazards related to this tool.
•Keep guards in place and in working order. Never operate the tool with any guard or cover
removed. Make sure all guards are operating properly before each use.
•Remove adjusting keys & wrenches. Form a habit of checking to see keys and adjusting
wrenches are removed from tool before turning it on .
•Keep work area clean. Cluttered work areas and work benches invite accidents.
•Do not use in dangerous environments. Do not use power tools near gasoline or other
flammable liquids, in damp or wet locations or expose them to rain. Keep work area well
lighted.
•Keep children and visitors away. All visitors should wear ANSI-Z87.1 approved safety
glasses and be kept a safe distance from work area.
•Make workshop childproof with padlocks, master switches, or by removing starter keys.
•Don’t force the tool. It will do the job better and safer at the rate for which it was designed.
•Use the right tool. Do not force the tool or attachment to do a job for which it was not
designed.
•Wear proper apparel. Do not wear loose clothing, neckties, or jewelry that can get caught in
the tool’s moving parts and cause personal injury. Non-slip footwear is recommended when
working outdoors. Wear protective hair covering to contain long hair.
•Always wear ANSI-Z87.1 approved safety glasses with side shields. Everyday eyeglasses
have only impact-resistant lenses; they are not safety glasses.
•Do not overreach. Keep proper footing and balance at all times.
•Maintain tools with care. Keep tools sharp and clean for best and safest performance.
Follow instructions for lubricating and changing accessories.
•Disconnect all tools. When not in use, before servicing, or when changing attachments,
blades, bits, cutters, etc¡-, all tools should be disconnected from power source.
•Reduce the risk of unintentional starting. Be sure switch is off when plugging in.

7
General instructions for all power tools (continued)
•Use recommended accessories. Consult the operator’s manual for recommended accessories.
The use of improper accessories may cause risk of injury.
•Never stand on tool. Serious injury could occur if the tool is tipped or if the blade is
unintentionally contacted.
•Direction of feed. Feed work into a blade or cutter against the direction or rotation of the
blade or cutter only.
•Never leave tool running unattended. Turn power off. Don’t leave tool until it comes to a
complete stop.
•Check damaged parts. Before further use of the tool, a guard or other part that is damaged
should be carefully checked to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts, binding or moving parts, breakage
of parts, mounting and any other condition that may affect its operation. A guard or other
part that is damaged must be properly repaired or replaced by an authorized service center
to avoid risk of personal injury.
•Protect your hearing. Wear hearing protection during extended periods of operation.
•Keep tools dry, clean, and free from oil and grease. Always use a clean cloth when cleaning.
Never use brake fluids, gasoline, petroleum-based products, or any solvents to clean tool.
•PROTECT YOUR LUNGS. Wear a face or dust mask if the operation is dusty.
WARNING - Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to cause cancer, birth defects
or other reproductive harm. Some examples of these chemicals are:
•Lead from lead-based paints
•Crystalline silica from bricks and cement and other masonry products
•Arsenic and chromium from chemically treated lumber. Your risk from
These exposures varies, depending on how often you do this type of work. To re-duce your
exposure to these chemicals, work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed to filter out microscopic
particles.
•Guard against electrical shock by preventing body contacting with grounded surfaces. For
example: pipes, radiators, ranges, refrigerator enclosures.
•Inspect tool cords and extension cords periodically and, if damaged, have repaired by a
qualified service technician. Stay constantly aware of cord location and keep it away from
the rotating wheel.

8
General instructions for all power tools (continued)
•Never use in an explosive atmosphere. Normal sparking of the motor could ignite fumes.
•Use only outdoor extension cords with approved ground connection that is intended for use
outdoors and so marked.
•Avoid awkward operations and hand positions where a sudden slip could cause your hand
to move into the blade. Always make sure you have good balance.
•Allow the motor to come up to full speed before starting a cut to avoid binding or stalling.
•Do not use tool if switch does not turn it on and off. Have defective switches replaced by an
authorized service center.
•Replacement parts. All repairs, whether electrical or mechanical, should be made by a
qualified service technician at an authorized service center.
WARNING - when servicing use only identical WEN® replacement parts. Use of any
other part may create a hazard or cause product damage.
•Keep hands away from cutting area. Do not hand hold pieces so small that your fingers go
under the blade guard. Do not reach underneath work or in blade cutting path with your
hands and fingers for any reason.
•Before making a cut, be sure all adjustments are secure.
•Always support large work pieces while cutting to minimize risk of blade pinching and
kickback. Saw may slip, walk or slide while cutting large or heavy boards.
•Do not remove jammed cutoff pieces until blade has stopped.
•Never start the tool when the blade is in contact with the work piece.
•Never touch blade or other moving parts during use.
•Before changing the setup, removing covers, guards or blades, unplug the saw and remove
the switch key.
•Always turn off saw before disconnecting it to avoid accidental starting when reconnecting
to a power source.
WARNING – Do not operate this tool while under the influence of drugs, alcohol or
any medication that may impair your judgment or control.

9
General instructions for all power tools (continued)
•Stay alert and exercise control. Watch what you are doing and use common sense. DO NOT
operate tool when you are tired. DO NOT RUSH!
•Make sure work area has ample lighting to see the work and that no obstructions will
interfere with safe operation before performing any work by using your saw.
•Save these instructions. Refer to them frequently and use them to instruct other users. If you
loan someone this tool, loan them these instructions also.
•Use the proper extension cord. Make sure your extension cord is in good condition. When
using an extension cord, be sure to use one heavy enough to carry the current your product
will draw. An undersized cord will cause a drop in line voltage resulting in loss of power
and overheating. A wire gauge size (A .W .G.) of at least 16 is recommended for an
extension cord 25 feet or less in length. If in doubt, use the next heavier gauge. The smaller
the gauge number is, the heavier the cord is.
•Don’t abuse cord. Never carry tool by the cord or yank it to disconnect from receptacle.
Keep cord from heat, oil, and sharp edges.

10
Specific safety rules for table saw
For Your Own Safety Read Instruction Manual before Operating Saw
1. Wear eye protection.
2. Use saw-blade guard and spreader for every operation for which it can be used, including all
through sawing.
3. Keep hands out of the line of saw blade.
4. Use a push-stick when required.
5. Know how to reduce risk of kickback.
6. Do not perform any operation freehand.
7. Never reach around or over saw blade.
8. Make sure the work piece is supported at all times while sawing.
9. To properly understand all safety warnings, be familiar with the following safety terms and
equipment:
Featherboard - A block with “fingers” that hold the work piece against the fence while
sawing.
Through-sawing - A cut made from one side of a board to the opposite side, without
stopping.
Ripcut or Ripping - A cut made parallel to (along with) the grain of the wood.
Crosscut or Crosscutting - A cut made perpendicular (at a 90º angle) to the grain of the
wood.
Push-stick – A narrow strip of wood or other soft material with a notch cut into one end
and which is used to push short pieces of material through saws. It provides a safe distance
between the hands and the cutting tool. Must be narrower than the cut width to prevent contact
with the blade.
Freehand - Feeding a work piece through the saw without using a fence or guided support
to guide it. NOT A SAFE METHOD.
Kerf - The gap made by the saw in the work piece.
Kickback - A sudden reaction to a pinched, bound, or misaligned blade, causing an
uncontrolled work piece to lift up and out of the saw toward the operator.
Spreader - A metal plate that follows the saw blade to keep the kerf (gap) from closing on
the saw blade. Spreaders, except riving knives, must be aligned to the blade after blade
adjustment to prevent binding.
Riving Knife - A spreader mounted on the same mechanism as the blade. Generally more
effective than simple spreaders
10. As noted previously, Kickback is a sudden reaction to a pinched, bound, or misaligned
blade, causing an un-controlled work piece to lift up and out of the saw toward the operator.
Kickback is usually a result of tool misuse and can be limited or avoided by following the
precautions below:
•Fence must be completely parallel to the saw blade.
•Work piece must be free from flaws (such as loose knots) and from foreign objects
(such as nails and screws).
•Support large work pieces along their entire length. Large work pieces tend to bend,
grabbing the blade.
•Do not use a dull, damaged, or pitch-covered blade.

11
Specific safety rules for table saw (continued)
•Do not use fence as a guide when crosscutting.
•Do not ripcut a twisted or warped work piece, or work piece without straight edge to
guide along fence.
•Maintain control of the work piece. Do not allow the work piece to rest against the
moving blade without holding onto it.
•If the blade binds or a cut is interrupted, turn off the power switch and hold the work
piece still until the blade stops. Correct the cause of blade binding before proceeding.
•Before continuing an unfinished cut, center the blade in the pre-cut kerf and check that
the saw teeth are not engaged into the work piece before turning on the saw.
•Push the wood stock past the blade prior to release.
11. Check guards for proper operation with saw disconnected from power before each use. Do
not disable any guard. Do not operate saw if any movable guard does not move freely and
close instantly. Make sure any movable guard does not touch the blade in all angles, depths
of cut, and positions.
12. Keep the guard in place while through-sawing. Verify that the spreader lines up with the
blade to prevent binding.
13. When servicing use only identical replacement parts.
14. Only use safety equipment that has been approved by an appropriate standards agency.
Unapproved safety equipment may not provide adequate protection. Eye protection must be
ANSI-approved and breathing protection must be NIOSH-approved for the specific hazards
in the work area.
15. Avoid unintentional starting. Prepare to begin work before turning on the tool.
16. People with pacemakers should consult their physician(s) before use. Electromagnetic
fields in close proximity to heart pacemaker could cause pacemaker interference or
pacemaker failure. In addition, people with pacemakers should:
•Avoid operating alone.
•Do not use with power switch locked on.
•Properly maintain and inspect to avoid electrical shock.
•Any power cord must be properly grounded. Ground Fault Circuit Interrupter (GFCI)
should also be implemented - it prevents sustained electrical shock.
17. The warnings, precautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this product,
but must be supplied by the operator.

12
Extension cords
In the event of a malfunction or breakdown, grounding provides a path of least resistance for
electric current and reduces the risk of electrical shock. Tools equipped with an electrical cord
having an equipment-grounding conductor must be plugged into a matching outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
Do not modify the plug provided in any way. If the plug does not fit the outlet, have the proper
outlet installed by a qualified electrician.
The use of any extension cord will cause some loss of power. To keep this to a minimum and to
prevent overheating and motor burned-out; use the table below to determine the minimum wire
size (A .W .G.) of extension cord.
Use only three (3) wire extension cords that have three (3) prong grounding plugs, and three (3)
pole receptacles that accept the tool’s plug.
Minimum Gauge for Extension Cords (AWG)
(When using 120 V only)
Ampere Rating
Total Length of Cord in feet
More Than
Not More Than
25
50
100
150
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Recommended

13
Grounding instructions
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of
least resistance for electric current and reduces the risk of electric shock. This tool is equipped
with an electric cord that has an equipment grounding conductor and a grounding plug. The
plug MUST be plugged into a matching outlet that is properly installed and grounded in
accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the outlet, have the proper outlet
installed by an electrician.
IMPROPER CONNECTION of the equipment grounding conductor can result in electric shock.
The conductor with the green insulation (with or without yellow stripes) is the equipment
grounding conductor. If repair or replacement of the electric cord or plug is necessary, DO
NOT connect the equipment grounding conductor to a live terminal.
CHECK with a licensed electrician or service personnel if you do not completely understand
the grounding instructions, or if you are not sure if the tool is properly grounded.
USE ONLY THREE-WIRE EXTENSION CORDS that have 3-pronged plugs and outlets that
accept the tool's plug as shown in Fig. A. Repair or replace a damaged or worn cord
immediately.
CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are
not sure if it is, have a licensed electrician check the outlet.

14
Unpacking
WARNING - to prevent accidental starting that could cause possible serious personal
injury; assemble all parts to your saw before connecting it to power supply. Saw
should never be connected to power supply when you are assembling parts, making
adjustments, installing or removing blades, or when not in use.
WARNING - if any parts are missing, do not operate this tool until the missing parts
are replaced. Failure to do so could result in possible serious personal injury.
Do not discard the packing materials until you have carefully inspected the saw, identified all
parts, and satisfactorily operated your new saw.
NOTE: if any parts are damaged or missing, do not attempt to plug in the power cord and turn
the switch on until the damaged or missing parts are obtained and are installed correctly.

15
Assembly
WARNING! Prior to performing any assembly procedures, make sure the 10” table saw is
disconnected from its electrical power source.
To mount table saw on a workbench:
1. NOTE: If the Table Saw is mounted onto a workbench instead of the Leg Assembly, the
workbench surface must have an opening for sawdust to fall through. This opening must be
as large as the opening in the bottom of the Table Saw Base. A minimum height of 36" from
the top of the Base to the floor is recommended.
2. With assistance, set the Table Saw in a desired location on the workbench.
NOTE: Make sure the workbench provides a flat, level, sturdy surface capable of
supporting the weight of the Table Saw, tool accessories, and workpieces.
3. Use the four 5/16" mounting holes located at the bottom of the Base as a template, and mark
the two points at which four holes will be drilled through the workbench. Then, temporarily
set the Table Saw aside.
4. With a drill and a 5/16” drill bit (not provided), drill four mounting holes downward
through the top of the workbench.
5. Align the four mounting holes at the Base of the Table Saw with the four previously drilled
holes in the workbench. Then secure the Table Saw to the workbench, using four 5/16”
bolts of appropriate length, two lock washers, and two nuts (not provided).
To assemble the leg stand:
1. NOTE: Temporarily finger tighten all
hardware mentioned in this section until the
Leg Stand is fully assembled.
2. Attach one Long Brace to the lower
mounting holes in two Legs, using two
Carriage Bolts, two Washers, and two Hex
Nuts for each Long Brace. Repeat the
assembly procedure for the remaining one
Long Brace and two Legs.
3. Attach one Short Brace to the lower
mounting holes in two Legs, using two
Carriage Bolts, two Washers, and two Hex
Nuts for each Short Leg Brace. Repeat the
assembly procedure for the remaining one Short Brace and two Legs.
4. Attach one Side Brace to the upper mounting holes in two Legs, using one Carriage Bolt,
one Washer, and one Hex Nut for each Side Brace. Repeat the assembly procedure for the
remaining one Side Brace and two Legs.
5. Attach one End Brace to the upper mounting holes in two Legs, using one Carriage Bolt,
one Washer, and one Hex Nut for each End Brace. Repeat the assembly procedure for the
remaining one End Brace and two Legs.

16
Assembly (continued)
6. Move the Leg Assembly to the desired floor surface working location. Then, firmly tighten
all hardware, using an appropriate size wrench (not provided).
To mount the leg stand on table saw base:
1. With assistance, place the Table Saw upside down on a flat, level, smooth surface (i.e.,
cardboard) on the floor. Then, place the Leg Assembly upside down on the Base of the
Table Saw.
2. Align the two mounting holes on the each of the two End Braces with the two mounting
holes on each end of the Base. Secure the End Braces to the Base, using four Hex Head
Bolts and four Hex Nuts.
3. With assistance, stand the 10" Table saw upright.
To install the handwheel
1. Remove the Bolt (27) from the Screw Rod (54).
2. Place the Handwheel onto the Screw Rod. Fasten into place by using the Bolt.
To assemble the blade guard
1. Unplug the Saw and remove the Safety Key (18) from the switch (17).
2. Position the Blade (96) 90º to the table and lock in place.
3. Position the recessed end of the Splitter Bracket (119) against the end of the Pivot Plate
(117) and fasten in place using the Spring Washer (3), Mat Washer (4) and Bolt (116).
Please note: Do not fully tighten the Bolt at this time.
4. Remove the Wing Nut (121), Flat Washer (50) and Spring Washer (3) from Splitter Bracket.
5. Position the Splitter (131) against the Splitter Bracket. Make sure the tabs on the Splitter
Bracket are INSIDE the slot of the Splitter.
6. Replace the Wing Nut (121), Flat Washer (50) and Spring Washer (3).
7. Make sure there is at least a 1/8” gap between the bottom edge of the Splitter and the top
surface of the Table (109) and that the tabs are on the INSIDE slot of the Splitter.
8. Use a framing square (not included) to make sure the Saw Blade and Splitter assembly are
square. If not square, loosen the Splitter Bracket and adjust until the Splitter is properly
aligned with the Saw Blade. Then tighten all screws and bolts.

17
Operating instructions
Read the general instructions and safety rules section at the beginning of this manual
before set up or use of this product.
Table saw adjustments
To prevent serious injury from accidental operation:
Turn the Power Switch of the tool to its “OFF” position, remove Safety key, and
unplug the tool from its electrical outlet before performing any inspection,
maintenance, or cleaning procedures.
WARNING! Check the Blade Guard assembly before and after every use.
Blade depth and angle adjustments
The Blade (96) depth should be set so that outer points of the Blade are 1/8” to ¼” higher than
the workpiece while the lowest points are below the workpiece.
To raise the Blade, turn the Handwheel (29) counterclockwise.
To lower the Blade, turn the Handwheel clockwise.
To adjust the Blade’s angle, loosen the Bevel Lock Knob (62) and then turn the Handwheel
until the Blade reaches the desired angle. Then tighten the Bevel Lock Knob. See below.
When the Blade is tilted to the left as far as it will go, the Blade should be at a 45º angle to the
Saw Table and the Bevel Indicator on the Ruler (13) should point to 45º.

18
Operating instructions (continued)
When the Blade is tilted to the right as far as it will go, the Blade should be at a 90ºangle to the
Saw Table and the Bevel Indicator on the Ruler should point to 0º.
Please note: When the Blade is at 90º to the Table Saw, the Blade should be square with the
Saw Table.
WARNING! The Bevel Lock Knob must be tightened during all cutting operations.
45º and 90º positive stop adjustment
The Table Saw is equipped with positive stops for rapid and accurate positioning of the Blade
at 45ºand 90ºto the table.
Before making ANY adjustments, make sure the Table Saw is unplugged and the Safety Key is
removed.
To adjust the positive stop at 90º, loosen the Bevel Lock Knob and move as far to the left as
possible. Then tighten the Knob.
Place a level or square (not included) on the Table (109) with one end blade to make sure Blade
is at 90º. If not, loosen the Bolt (110) a few turns and tilt Blade until at the correct angle.
Tighten the Bevel Lock Knob and then tighten the Bolt (110).
To adjust the positive stop at 45º, loosen the Bevel Lock Knob and move as far to the right as
possible. Then tighten the Knob.
Place a level or square on the Table with one end blade to make sure Blade is at 45º. If not,
loosen the Bolt (111) a few turns and tilt Blade until at the correct angle.
Tighten the Bevel Lock Knob and then tighten the Bolt (111).
Aligning and adjusting the rip fence (146)
WARNING! A misaligned Fence can cause kickbacks and jams. To reduce risk of injury,
always maintain proper Fence alignment. The Rip Fence must be parallel with the Blade and
Table grooves.
Lift up the Fence Handle (26) and move the Fence along the gauge slot until sliding it to the
desired location.
Verify that Fence is parallel, and then push down on the Handle to lock the Fence in place.
A Draw Pole locks the Fence in place. To adjust the Draw Pole, loosen the Bolt that connects
the Draw Pole to the Fence.

19
Operating instructions (continued)
WARNING! The Fence must be properly aligned to the gauge slot to prevent kickback during
ripping.
To check for proper alignment, position the Fence next to the gauge slot and clamp Fence to the
Table by pushing down on Fence Handle. Once locked, the edge of the Fence should be
parallel to the gauge slot.
Adjusting table insert (112)
Lower the Blade by turning the Handwheel clockwise.
Loosen the two Table Insert Bolts (12).
Adjust the Table Insert and retighten, making sure to not overtighten. Doing so can cause the
Table Insert to bow or bend.
If the Table Insert is slightly above the Table, tighten the two Table Insert Bolts until the Table
Insert is flush with or slightly below the Table surface.
Miter gauge (100) operation and adjustment
When straight cross-cutting (the Blade is set at 90ºto the Table) the Miter Gauge can be used in
either table slot.
When bevel cross-cutting (the Blade is tilted away) only use the Miter Gauge in the right table
slot where the Blade is titled away from the Miter Gauge and your hands.
To operate the Miter Gauge, loosen the Miter Gauge Lock Knob (101) and move the Gauge to
the desired angle, then tighten Knob.
Adjusting blade parallel to miter gauge slots
WARNING! Make sure to unplug Table Saw before making any adjustments to Blade.
To prevent kickback and ensure accurate cuts when cutting, the Blade’s angle in relation to the
Miter Gauge should be regularly checked. If any adjustments are needed:
Remove the Blade Guard (113).
Raise the Blade to its highest position and adjust to Blade so that it is 90ºto the Table.
Mark a Blade tooth at the front of the Table Saw with a marker.

20
Operating instructions (continued)
Using a square or ruler (not included), place the square against the Miter Gauge slot and adjust
the flat edge of the square until it touches the marked tooth.
Rotate the Blade and check the same marked tooth at the rear of the Table Saw.
If the front and rear measurements are not identical, have a qualified service technician repair
the Table Saw.
Installing/Replacing saw blade
WARNING! Make sure to unplug Table Saw before making any installing or replacing Blade.
WARNING! Use only a 10” diameter saw blade rated at 4800 RPM and with a 5/8” arbor hole.
1. Remove the Blade Guard, raise the Saw Blade to its maximum height and remove the Table
Insert.
2. Use the Wrench (145) to keep the Saw arbor from rotating while using the Pin Wrench (147)
to remove the Arbor Nut. Turn the nut counterclockwise to remove. Then remove the Outer
Flange (97) and the Blade.
3. Place a new 10” Blade onto the Arbor Shaft (94), making sure the teeth point DOWN at the
front of the Table Saw.
WARNING! The teeth MUST point down toward the front of the Table Saw for proper
operation. See Figure 2 below. Incorrect blade installation can damage the Saw Blade, Table
Saw and/or workpiece.
4. Place the Outer Flange onto the Arbor Shaft. Be sure the hollow side of the Flange is
against the Blade and that all pieces are sung against the arbor housing.
5. Thread the Arbor Nut back onto the Arbor. Tighten with the Wrench (145), turning the nut
clockwise and holding the Arbor steady with the Pin Wrench.
6. Rotate the Blade to make sure it turns freely. Then lower the Blade.
7. Replace the Table Insert and retighten the Table Insert screw.
WARNING! Do not overtighten the Arbor Nut. Doing so can cause the Table to bow or bend,
leading to serious injury.
