Assembly and Owner’s Manual
OnBoard®Auxiliary Podium
©Wenger Corporation 2009 Printed in USA 07/09 Part #210A475-01
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: [phone] • International (call collect): [phone] • www.wengercorp.com
Note: Please read and understand the OnBoard Auxiliary Podium Owner’s Manual before using the
Auxiliary Podium.
Note: Remove Auxiliary Podium assembly parts from the shipping container. Refer to the
illustrations on the following pages. If you need additional information about your Auxiliary
Podium, write or telephone Wenger Corporation at the number below.
CONTENTS
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
USER INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2
SAFETY PRECAUTIONS
Throughout this manual you will find CAUTIONS and WARNINGS which are defined as follows:
• WARNING; failure to follow the instruction may result in serious injury or death.
• CAUTION; failure to follow the instruction may result in serious injury or damage to property.
Note: Failure to comply with precautions in this section can result in serious injury.
OPERATION
•When using the Auxiliary Podium in performance position, always park the Podium on a level
surface.
•The Auxiliary Podium must be used with the boundary rail at all times when in performance position.
•Auxiliary Podium maximum total load capacity is 300 lbs.
•The Auxiliary Podium is only intended to hold one person when in performance position.
•All four legs must be in contact with the floor or ground at all times.
•Avoid ramps steeper than a one-foot rise or drop in a 12-foot horizontal distance.
•When transporting the Auxiliary Podium in a vehicle it must be braced with tie-downs, chains or
cargo straps designed specifically for that purpose so podium will not move.
•Blankets or other padding material may be required to avoid damage to the podium and accessories
from vibration and impact during transport.
Keep hands clear of all
pinch points.
!CAUTION
•Clean the Auxiliary Podium with a mild detergent and warm water. Avoid using harsh or
abrasive cleaning products.
•Immediately replace any wheels that do not turn freely.
•Periodically check and tighten the fasteners.
•Grease zerks and bushings if required.
MAINTENANCE

3
WARRANTY
The Auxiliary Podium is guaranteed free of defects in materials and workmanship for five full years.
Our guarantee assures you of either a full refund or repair or replacement of the defective materials
or workmanship without charge, at the discretion of our Customer Service Department.
Just call a Customer Service Representative at 1-800-887-7145 and state the reason you are
dissatisfied. If a product return is necessary, your representative will issue a return authorization.
This is your sole remedy for breach of this warranty.
Should you have a question or problem with any Wenger product, don’t hesitate to call, even if the
product is past warranty. It’s important to us that all our customers be satisfied.
This is the sole warranty made by Wenger. Wenger disclaims all other warranties, including the
warranties of merchantability and fitness for a particular purpose, as well as all liability for incidental,
consequential, special, and indirect damage. Wenger liability for direct damages shall be limited to the
amount you paid for the product involved. Wenger reserves the right to make product changes without
obligation to incorporate such changes into products previously sold.
Some states do not allow the exclusion or limitation of damages or warranties, so the above may not
apply to you. This warranty gives you specific legal rights. You may also have other rights which vary
from state to state.
IMPORTANT USER INFORMATION
GENERAL
Copyright©2009 by Wenger Corporation
All rights reserved. No part of the contents of this manual may be reproduced, copied, or transmitted in
any form or by any means including graphic, electronic, or mechanical methods or photocopying,
recording, or information storage and retrieval systems without the written permission of the publisher,
unless it is for the purchaser's personal use.
Printed and bound in the United States of America.
The information in this manual is subject to change without notice and does not represent a commitment
on the part of Wenger Corporation. Wenger Corporation does not assume any responsibility for any
errors that may appear in this manual.
In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for
direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this
manual.
The information in this document is not intended to cover all possible conditions and situations that might
occur. The end user must exercise caution and common sense when assembling or installing Wenger
Corporation products. If any questions or problems arise, call Wenger Corporation at 1-800-733-0393.
MANUFACTURER
The OnBoard®Auxiliary Podium is manufactured by:
Wenger Corporation
555 Park Drive
Owatonna, MN 55060
1-507-455-4100 • 1-800-733-0393
www.wengercorp.com
INTENDED USE
•This product is intended for limited outdoor use — it must not be exposed to prolonged outside
weather conditions.

4
PARTS LIST
Item # Qty Description
1 1 AUXILIARY PODIUM
2 1 BOUNDARY RAIL
1
2

5
OPERATION
MOVING THE AUXILIARY PODIUM
1. If the Auxiliary Podium is transported in a vehicle, it
must be braced or strapped to the vehicle so that it
cannot move. Bracing must use tie-downs or straps
specifically designed to prevent the Auxiliary Podium
from moving in the vehicle.
2 If the Podium needs to be stored tipped on it’s long
edge, make sure the storage pins are in place to
prevent the Podium from unfolding.
SET UP THE AUXILIARY PODIUM IN PERFORMANCE POSITION
1. With the Auxiliary Podium (#1) in the stored
position, insert the Boundary Rail (#2) in the
cut-out slots on the deck.
2. Place the Auxiliary Podium on it’s side.
Note: The side with the snapper pins
in the corner brackets must be
facing up.
3. Remove snapper pins from the corner
brackets.
!CAUTION
Tow Handle
2
1
Snapper Pins

6
OPERATION (CONTINUED)
1
2
4. Unfold the Podium upright and ladder frames out aligning the holes in the corner brackets.
5. Secure the Podium upright and ladder frames in place using the snapper pins.
6. Tighten the knobs on the underside corners of the deck to secure the Boundary Rail.
7. Lift the Podium up into the performance position.
Snapper Pins
Tightening
Knobs
Ladder
Upright
Tightening
Knob
Snapper Pin

7
OPERATION (CONTINUED)
RETURN THE AUXILIARY PODIUM TO STORED POSITION
1. Place the Auxiliary Podium on it’s side.
Note: The side with the snapper pins in the corner brackets must be facing up.
2. Remove snapper pins from the corner brackets.
3. Fold the ladder frame inward against the deck bottom.
4. Align the hole on the ladder frame with the hole in the corner bracket. Insert the snapper pin to
secure the ladder frame to the Podium deck.
5. Repeat steps 4 and 5 on the upright frame.
6. Loosen the tightening knobs securing the Boundary Rail and remove rail.
7. Place Podium onto it’s wheels.
2
1
Snapper Pins
Tightening
Knobs
Ladder
Upright
Tightening
Knob
Snapper Pin

8
REPLACEMENT PART LIST
Item # Description Item # Description
1 DECK ASSEMBLY 11 SNAPPER PIN
2 BOUNDARY RAIL 12 NYLON LANYARD
3 UPRIGHT FRAME 13 CARRIAGE BOLT, 3/8 - 16 X 1
4 LADDER FRAME 14 LOCK NUT, 3/8 - 16
5 CORNER BRACKET, RH 15 TUBE PLUG, 1 X 2
6 TUBE PLUG, 1" SQUARE 16 CAPSCREW, 1/2-13 X 4 1/2
7 ANTI-SLIP TAPE 17 LOCK NUT, 1/2 - 13
8 6" WHEEL 18 FLAT WASHER
9 LOCK NUT, 5/16 - 18 19 CORNER BRACKET, LH
10 SHOULDER BOLT, 5/16 - 18 X 3/8
910
12
11
15
13 14
19
1
2
5
6
3
4
16 17 18
8
7
