Weslo Pursuit T 169 Bike User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Serial Number
Decal
Model No. WLEVEX1916.0
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
Or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009
www.iconeurope.com
Visit our website at

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
HOW TO OPERATE THE EXERCISE CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
1. Read all instructions in this manual and all
warnings on the exercise cycle before using
the exercise cycle.
2. Use the exercise cycle only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
4. The exercise cycle is intended for home use
only. Do not use the exercise cycle in
acommercial, rental, or institutional setting.
5. Keep the exercise cycle indoors, away from
moisture and dust. Place the exercise cycle
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is enough clearance around the exer-
cise cycle to mount, dismount, and use it.
6. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
7. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
8. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
9. The exercise cycle should not be used by
persons weighing more than 113 kg (250 lbs).
10.The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
11. Always keep your back straight while using
the exercise cycle; do not arch your back.
12.If you feel pain or dizziness at any time while
exercising, stop immediately and cool down.
13.The warning decal shown on page 3 has been
placed on the exercise cycle. If the decal is
missing or illegible, call the telephone num-
ber on the front cover of this manual and
request a free replacement decal. Apply the
decal in the location shown.
WARNING:Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
IMPORTANT PRECAUTIONS
WARNING:To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.

3
Congratulations for selecting the new WESLO®
PURSUIT T 169 exercise cycle. Cycling is one of the
most effective exercises for increasing cardiovascular
fitness, building endurance, and toning the body. The
PURSUIT T 169 exercise cycle offers a selection of
features designed to let you enjoy this healthful exer-
cise in the convenience and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, please see the front cover
ofthis manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number is WLEVEX1916.0. The serial
number can be found on a decal attached to the exer-
cise cycle (see the front cover of this manual for the
location of the decal).
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
REAR
FRONT
Seat
Seat Post Knob
Pedal/Strap
Console
Pulse Sensor
Handlebar
Pivot Handle
RIGHT SIDE
BEFORE YOU BEGIN
Seat Knob

4
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the includ-
ed tools and your own adjustable wrench and Phillips screwdriver .
Use the drawings below to identify the small parts used for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on page 14. The number following the key number is
the quantity needed for assembly. Note: Some small parts may have been preassembled. If a part is not in
the parts bag, check to see if it has been preassembled.
M4 x 15mm Round
Head Screw (58)–2
M8 Split Washer
(42)–7 M8 Nylon Locknut
(10)–4
M8 x 15mm Button
Screw (34)–3
M6 x 15mm Button
Screw (46)–4 M8 x 60mm Button Screw (30)–4
M8 x 60mm Button Screw (33)–2
M5 x 15mm Round
Head Screw (59)–4
1. Insert the Rear Stabilizer (6) into the Frame (1).
Attach the Rear Stabilizer with four M8 x 60mm
Button Screws (30).
6
30
1
2. Orient the Front Stabilizer (2) with the large holes
facing the Frame (1). Attach the Front Stabilizer to
the Frame with two M8 x 73mm Button Screws (33).
1
1
233
2Large
Holes

5
3. Attach the Left and Right Frame Covers (19, 3)
around the Frame (1) with an M4 x 15mm Round
Head Screw (58) and two M5 x 15mm Round Head
Screws (59) as shown.
19
3
59
59
58
1
4. Attach the Seat (12) to the Seat Carriage (29) with
four M8 Split Washers (42) and four M8 Nylon
Locknuts (10). Note: The Split Washers and the
Nylon Locknuts may be pre-attached to the
underside of the Seat.
Remove the Seat Knob (56) from the Seat Post (5).
Place the Seat Carriage (29) on the Seat Post and
insert the Seat Knob through the Seat Post into the
hole in the Seat Carriage. Then, tighten the Seat
Knob. Make sure the Seat Knob is engaged in the
hole in the Seat Carriage.
4
12
5
42
42
10
29
56
10
5. Turn the Seat Post Knob (9) counterclockwise and
remove it from the Frame (1). Next, insert the Seat
Post (5) into the Frame. Adjust the Seat Post to the
desired height and insert the Seat Post Knob
through the indicated hole in the Frame into one of
the adjustment holes in the Seat Post. Then, turn the
Seat Post Knob clockwise until it is tight. Make sure
the Seat Post Knob is firmly engaged in one of
the adjustment holes in the Seat Post.
5
5
1
9
Hole
Adjustment
Holes
3

6
6
6. While another person holds the Upright (13) near
the Frame (1) as shown, connect the Extension
Wire (23) to the Reed Switch Wire (39). Then, push
the wires downward into the Frame (1).
Next, insert the Upright (13) into the Frame (1). Be
careful to avoid pinching the wires. Attach the
Upright with three M8 x 15mm Button Screws (34)
and three M8 Split Washers (42). Be careful to
avoid pinching
the wires and
cables.
34
39
42 34
23
13
1
42
7. The Console (16) requires four AA batteries; alkaline
batteries are recommended. Press the tab on the
battery cover and remove it. Insert four batteries into
the Console as shown. Make sure that the batter-
ies are oriented as shown by the diagram on the
battery cover. Then, reattach the battery cover.
7
16
Batteries
Battery Cover

7
11. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over.Place a mat beneath the exercise cycle to protect the floor.
10.Identify the Left Pedal (24), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (21). Tighten the Right Pedal (not shown)
clockwise into the right arm of the Crank. Important:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten
the Pedals. For best performance, keep the
Pedals tightened.
Adjust the strap on the Left Pedal (24) to the desired
position, and press the end of the strap onto the tab
on the side of the Left Pedal. Adjust the strap on the
Right Pedal (not shown) in the same way.
10
8. Attach the Pivot Bracket (53) to the Upright (13) with
the Pivot Clamp (54) and the Pivot Handle (55).
Note: The Pivot Handle functions like a ratchet. Turn
the Pivot Handle clockwise, pull it away from the
Upright, turn it counterclockwise, push it toward the
Upright, and then turn it clockwise again. Repeat this
process until the Pivot Handle is tight.
While a second person holds the Console (16) near
the Upright (13), insert the console wire through the
Pivot Bracket (53) and connect it to the Extension
Wire (23). Then, insert the excess wire downward
into the Upright.
Attach the Console (16) to the Pivot Bracket (53)
with four M6 x 15mm Button Screws (46). Be care-
ful to avoid pinching the wires.
8
Be careful to
avoid pinching
the wires.
23
46 46
13
24
Strap
21
Console Wire
16
53
54
55
9. Attach the Left and Right Pivot Covers (50, 51)
around the Upright (13) with an M4 x 15mm Round
Head Screw (58) and two M5 x 15mm Round Head
Screws (59).
9
59
51
50
59
58 13

8
HOW TO OPERATE THE EXERCISE CYCLE
HOW TO ADJUST THE SEAT POST
For effective exer-
cise, the seat
should be at the
proper height. As
you pedal, there
should be a slight
bend in your knees
when the pedals
are in the lowest
position. To adjust
the height of the
seat, first turn the
seat post knob
counterclockwise
and remove it.
Next, slide the seat post upward or downward and
align one of the adjustment holes in the seat post with
the indicated hole in the Frame. Insert the seat post
knob into the frame and the seat post, and turn the
seat post knob clockwise until it is tight.Make sure
that the seat post knob is inserted through one of
the adjustment holes in the seat post.
HOW TO ADJUST THE SEAT
To adjust the hori-
zontal position of
the seat, loosen the
seat knob on the
underside of the
seat, slide the seat
forward or backward
to the desired posi-
tion, and then
retighten the seat
knob.
HOW TO ADJUST THE ANGLE OF THE CONSOLE
To adjust the angle
of the console,
loosen the pivot
handle, rotate the
console to the
desired angle, and
then retighten the
pivot handle.
Seat Post
Seat Post Knob
Seat Knob
Hole
Seat
Seat
Pivot
Handle

9
CONSOLE DIAGRAM
FEATURES OF THE CONSOLE
The console offers a selection of features designed to
make your workouts more effective. When you use the
manual mode of the console, you can change the
resistance of the pedals with the touch of a button. As
you pedal, the console will provide continuous exer-
cise feedback. You can even measure your heart rate
using the built-in handgrip pulse sensor.
The console also offers four smart programs that auto-
matically change the resistance of the pedals and
prompt you to vary your pedaling pace while guiding
you through an effective workout.
Before using the console, make sure that batteries are
installed (see assembly step 7 on page 6). If there is a
sheet of clear plastic on the display, remove the plastic.
HOW TOUSE THE MANUAL MODE
Turn on the console.
To turn on the console, press the On/Reset button
or begin pedaling. The entire display will light for a
moment; the console will then be ready for use.
Select the manual mode.
When you turn
on the console,
the manual
mode will be
selected. If you
have selected a
program, rese-
lect the manual
mode by pressing the Smart Programs button
repeatedly until zeros appear in the display.
Change the resistance of the pedals as desired.
As you pedal,
change the resis-
tance of the ped-
als by pressing
the Resistance
increase and
decrease but-
tons. There are
ten resistance levels. Note: After you press the
buttons, it will take a moment for the pedals to
reach the selected resistance level.
Follow your progress with the display.
The console has seven displays that show the fol-
lowing workout information:
Speed—This display shows your pedaling speed,
in miles or kilometers per hour.
Time—This display shows the elapsed time.
Note: When a smart program is selected, the dis-
play shows the time remaining in the program
instead of the elapsed time.
Distance—This display shows the distance you
have pedaled, in miles or kilometers.
Calories—This display shows the approximate
number of calories you have burned.
Fat Calories—This display shows the approximate
number of fat calories you have burned (see Fat
Burning on page 13).
Pulse—This display shows your heart rate when
you use the handgrip pulse sensor.
Scan—When you select this display option, the
upper section of the display will show both time
and distance information, and the lower left section
of the display will show calories and fat calories
information.
4
3
2
1

10
When you turn
the power on,
the scan dis-
play will be
selected auto-
matically. An
indicator will
appear below
the word SCAN
to show that
the scan display is selected.
As you exer-
cise, the upper
section of the
display will
alternately
show the
elapsed time
and the dis-
tance that you have pedaled; the lower left sec-
tion of the display will alternately show the num-
ber of calories you have burned and the number
of fat calories you have burned. The lower right
section of the display will show your pedaling
speed.
In addition, the
pace meter on
the right side of
the display will
provide a visual
representation
of your pedaling
pace. As you
increase or
decrease your
pace, bars will appear or disappear in the pace
meter.
Tocancel the scan mode, press the Display but-
ton. The indicator below the word SCAN will dis-
appear.The upper section of the display will then
show only the elapsed time, and the lower left
section of the display will show only the number
of calories you have burned. If you press the
Display button again, the upper section of the
display will show only the distance pedaled, and
the lower left section of the display will show only
the number of fat calories you have burned. To
select the scan mode again, press the Display
button repeatedly until an indicator appears
below the word SCAN.
Note: The console can display speed and dis-
tance in either miles or kilometers. The letters
“mph” or “km/h” will appear in the display to show
which unit of measurement is selected. To change
the unit of measurement, hold down the On/Reset
button for several seconds until the desired unit of
measurement appears in the display.
To reset the display, press the On/Reset button.
To pause the console, stop pedaling. When the
console is paused, the time will flash in the dis-
play. To continue your workout, simply resume
pedaling.
Measure your heart rate if desired.
Note: If there
are sheets of
clear plastic on
the metal con-
tacts of the
handgrip pulse
sensor,remove
the plastic. To
measure your heart rate, hold the handgrip pulse
sensor,with your palms resting against the metal
contacts. Avoid moving your hands or grip-
ping the contacts tightly.
When your pulse is detected, the heart-shaped
indicator in the display will flash each time your
heart beats and two dashes will appear. After a
moment, your heart rate will be shown in the dis-
play. For the most accurate heart rate reading,
continue to hold the handgrips for about 15 sec-
onds. Note: If you continue to hold the handgrip
pulse sensor,the display will show your heart
rate for up to 30 seconds. The display will then
show your heart rate along with the other modes.
If your heart rate is not shown, make sure that
your hands are positioned as described. Be care-
ful not to move your hand excessively or to
squeeze the metal contacts too tightly. For opti-
mal performance, clean the metal contacts using
asoft cloth; never use alcohol, abrasives, or
chemicals to clean the contacts.
When you are finished exercising, the con-
sole will turn off automatically.
If the pedals do not move for a few seconds, the
time will flash in the display and the console will
pause. If the pedals do not move for a few min-
utes, the console will turn offand the display will
be reset.
6
5
Indicator
Pace Meter
