USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual be ore using
this equipment. Keep this manual
or uture re erence.
Serial
Number
Decal
Model No. WLEVEX24920
Serial No.
QUESTIONS?
As a manu acturer, we are com-
mitted to providing complete
customer satis action. I you
have questions, or i there are
missing parts, please call:
Or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009
www.iconeurope.com
Visit our website at

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOW TO USE THE CHEST PULSE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HOW TO OPERATE THE EXERCISE CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
WESLO is a registered trademark of ICON Health & Fitness, Inc.

3
1. Read all instructions in this manual be ore
using the exercise cycle. Use the exercise
cycle only as described in this manual.
2. It is the responsibility o the owner to ensure
that all users o the exercise cycle are ade-
quately in ormed o all precautions.
3. Use the exercise cycle indoors on a level sur-
ace. Keep the exercise cycle away rom
moisture and dust. Place a mat under the
exercise cycle to protect the loor.
4. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age o 12 and pets
away rom the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes or oot protection.
7. The exercise cycle should not be used by
persons weighing more than 115 kg (250 lbs.).
8. Always keep your back straight whilst using
the exercise cycle; do not arch your back.
9. I you eel pain or dizziness whilst exercising,
stop immediately and cool down.
10 The pulse sensor is not a medical device.
Various actors, including the user's move-
ment, may a ect the accuracy o heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
11. The exercise cycle is intended or home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
WARNING: Be ore beginning this or any exercise program, consult your physician. This
is especially important or persons over the age o 35 or persons with pre-existing health problems.
Read all instructions be ore using. ICON assumes no responsibility or personal injury or property
damage sustained by or through the use o this product.
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk o serious injury, read the ollowing important precau-
tions be ore using the exercise cycle.

4
Congratulations for selecting the new WESLO®
VECTOR 02 exercise cycle. Cycling is one of the
most effective exercises for increasing cardiovascular
fitness, building endurance, and toning the body. The
VECTOR 02 exercise cycle offers a selection of fea-
tures designed to let you enjoy this healthful exercise
in the convenience and privacy of your home.
For your bene it, read this manual care ully be ore
you use the exercise cycle. If you have questions
after reading this manual, please call our Customer
Service Department at 08457 089 009. To help us
assist you, please note the product model number and
serial number before calling. The model number is
WLEVEX24920. The serial number can be found on a
decal attached to the exercise cycle (see the front
cover of this manual for the location of the decal).
Before reading further, please familiarise yourself with
the parts that are labelled in the drawing below.
Water Bottle Holder*
*No water bottle is included
Resistance Knob
REAR
FRONT
Seat
Adjustment Knob
Adjustment Knob
Pedal/Strap
Console
Seat Knob
Handlebar
Adjustment Handle
Wheel
RIGHT SIDE
BEFORE YOU BEGIN

5
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable spanner , Phillips screw-
driver , and pliers .
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part, from the PART LIST on page 18. The second number refers
to the quantity needed for assembly. Note: Some small parts may have been pre-attached or shipping. I a
part is not in the parts bag, check to see i it has been pre-attached.
3/8” Nylon
Locknut (33)–4
M8 Nylon
Locknut (10)–3 M8 Flat
Washer ( 1)–3
Ground
Screw (27)–1
M x 12mm
Screw (49)–4
3/8” x 114mm Carriage Bolt (30)–4
1. Orient the Front Stabiliser (2) so that the Wheels (23)
are on the side shown. Whilst another person lifts the
front of the Frame (1) slightly, attach the Front
Stabiliser with two 3/8” x 114mm Carriage Bolts (30)
and two 3/8” Nylon Locknuts (33). Make sure that the
Front Stabiliser is turned so the Wheels are not
touching the loor.
2
23
23
33
30
1
1
2. Whilst another person lifts the rear of the Frame (1)
slightly, attach the Rear Stabiliser (6) with two 3/8” x
114mm Carriage Bolts (30) and two 3/8” Nylon
Locknuts (33).
30
6
1
2
33
33

6
3
3
42
1
13
3. Slide the two slots in the Handlebar Clamp (42) onto the
two indicated tabs on the Upright (13). Lift the bottom of
the Handlebar Clamp away from the Upright. Insert the
Handlebar (1 ) between the Handlebar Clamp and the
Upright. Centre the Handlebar and rotate it to the desired
position.
Tighten the Adjustment Handle ( 3) onto the Upright
(13). Note: The adjustment handle works like a spanner.
Turn the Handle counterclockwise, pull it away from the
Upright, turn it clockwise, push it toward the upright,
and then turn it counterclockwise again.
4
4. The Console (16) requires three “AA” batteries; alka-
line batteries are recommended. Insert three batteries
into the Console. Make sure that the batteries are
oriented as shown by the diagram inside the
Console.
16
Batteries
. Hold the Console (16) near the Upright (13). Insert the
console cable and the console wire into the indicated
hole and down through the Upright. Attach the ground
wire to the Upright with the Ground Screw (27).
Insert the excess wire and cable into the Upright.
Attach the Console (16) to the Upright (13) with four
M x 12mm Screws (49). Be care ul to avoid pinch-
ing the wires.
16
Be care ul to
avoid pinching
the wires.
13
49
49
27
Ground
Wire
Console
Wire
Console
Cable
Hole
Tabs

7
7. Attach the Seat (12) to the Seat Bracket ( 0) with three
M8 Nylon Locknuts (10) and three M8 Flat Washers
( 1). Note: The Nylon Locknuts and Flat Washers may
be preattached to the underside of the Seat.
Orient the Seat (12) and the Seat Post ( ) as shown.
Insert the pin on the bottom of the Seat Bracket ( 0)
into the indicated slot on the Seat Post. Tighten the
Seat Knob (36) into the Seat Bracket.
6. Whilst another person holds the Upright (13) in the
position shown, connect the console wire to the Reed
Switch Wire (43). Next, connect the console cable to
the Lower Cable (4 ) in the following way:
• Refer to inset drawing A. Pull up on the metal brack-
et (MB) on the Lower Cable (4 ), and insert the tip of
the console cable (CC) into the wire clip inside of the
metal bracket.
• Refer to inset drawing B. Firmly pull the console
cable (CC) and slide it into the metal bracket on the
Lower Cable (4 ) as shown.
• Refer to inset drawing C. Using pliers, squeeze the
prongs on the upper end of the metal bracket
together.
Carefully push the excess wire and cable down into the
Frame (1), and insert the Upright (13) into the Frame.
Be care ul to avoid pinching the wires and cables.
Next, align one of the adjustment holes in the Upright
with the indicated hole in the Frame. Insert the
Adjustment Knob (9) into the Frame and the Upright,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one o the
adjustment holes in the Upright.
13
Console Wire
9
43
Hole
1
4
6
Console Cable
Adjustment
Holes
7
1
12
1
36
10
10
Pin
Slot
0
Be care ul
to avoid
pinching the
wires.
AB C
4
CC
CC
MB MB
MB
4

8
10. Make sure that all parts are properly tightened be ore you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. Identify the Left Pedal (24), which is marked with an
“L.” Using an adjustable spanner, irmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (21). Tighten the Right Pedal (not shown) clock-
wise into the right arm of the Crank. Important:
Tighten both Pedals as irmly as possible. A ter
using the exercise cycle or one week, retighten the
Pedals. For best per ormance, the Pedals must be
kept tightened.
Adjust the left Pedal Strap (2 ) to the desired position,
and press the end of the Pedal Strap onto the tab on
the Left Pedal (24). Adjust the right Pedal Strap (not
shown) in the same way.
9
8. Turn the indicated Adjustment Knob (9) counterclock-
wise and remove it. Insert the Seat Post ( ) into the
Frame (1). Align one of the adjustment holes in the
Seat Post with the indicated hole in the Frame. Insert
the Adjustment Knob into the Frame and the Seat Post,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one o the
adjustment holes in the Seat Post.
1
Hole
Adjustment
Holes
9
8
24
21
2
Tab

9
HOW TO USE THE CHEST PULSE SENSOR
HOW TO PUT ON THE CHEST PULSE SENSOR
The chest pulse sensor consists of two components:
the chest strap and the sensor unit. Follow the steps
below to put on the chest pulse sensor.
See the inset drawing above. Insert the tab on
one end of the chest strap through one end of the
sensor unit. Press the end of the sensor unit
under the buckle on the chest strap.
Wrap the
chest pulse
sensor
around
your chest.
Attach the
free end of
the chest
strap to the
sensor unit as described above. Adjust the length
of the chest strap, if necessary. The chest pulse
sensor should be under your clothes, against
your skin, and as high under the pectoral mus-
cles or breasts as is comfortable. Make sure that
the logo is right-side-up and facing forward.
Pull the
sensor unit
away from
your body
a few inch-
es and
locate the
two elec-
trode areas on the inner side. Using a saline
solution such as saliva or contact lens solution,
wet both electrode areas. Return the sensor unit
to a position against your chest.
CHEST PULSE SENSOR TROUBLESHOOTING
I the chest pulse sensor does not unction proper-
ly, or i the displayed heart rate is excessively high
or low, try the troubleshooting steps below.
• Make sure that you are wearing the chest pulse sen-
sor as described at the left. If the chest pulse sensor
does not function when positioned as described,
move it slightly lower or higher on your chest.
• Each time you use the chest pulse sensor, use
saline solution such as saliva or contact lens solu-
tion to wet the two electrode areas on the sensor
unit (see the drawing below). If heart rate readings
do not appear until you begin perspiring, re-wet the
electrode areas.
• Make sure that you are within arm’s length of the
console. For the console to display heart rate
readings, the user must be within arm’s length o
the console.
• The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical condi-
tions such as premature ventricular contractions
(pvcs), tachycardia bursts, and arrhythmia.
• The operation of the chest pulse sensor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
magnetic interference may be causing a problem,
try relocating your exercise equipment.
• If the chest pulse sensor still does not function prop-
erly, test the chest pulse sensor in the following way:
Hold the chest
pulse sensor
and place your
thumbs over
the electrode
areas as
shown. Next,
hold the chest
pulse sensor near the console. Whilst holding one
thumb stationary, begin tapping the other thumb
against the electrode area at a rate of about one tap
per second. Check the heart rate reading on the
console.
3
2
1
Chest Strap
Sensor Unit
Tab
Buckle
Electrode Areas
Sensor
Unit
Electrode Areas
Logo

10
•If the chest pulse sensor does not function properly
after you have followed all of the above instructions,
the battery should be replaced in the following way:
Locate the battery
cover on the back of
the sensor unit.
Insert a coin into the
slot in the cover,
turn the cover coun-
terclockwise, and
remove the cover.
Remove the old
battery and insert a
new CR 2032 bat-
tery. Make sure
that the battery is
turned so the writ-
ing is on top.
Replace the battery
cover and turn it
clockwise to close
it.
CHEST PULSE SENSOR CARE
• Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the chest pulse sen-
sor is put on; the chest pulse sensor shuts off when
it is removed and the electrode areas are dried. If
the chest pulse sensor is not dried after each use, it
may remain activated longer than necessary, drain-
ing the battery prematurely.
• Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
or other container that may trap moisture.
• Do not expose the chest pulse sensor to direct
sunlight for extended periods of time. Do not expose
the chest pulse sensor to temperatures above 0° C
(122° F) or below -10° C (14° F).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CR 2032
Battery
