USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual be ore using
this equipment. Keep this manual
or uture re erence.
Serial
Number
Decal
Model No. WLEVEX12920
Serial No.
www.iconeurope.com
Visit our website at
QUESTIONS?
As a manu acturer, we are com-
mitted to providing complete
customer satis action. I you
have questions, or i there are
missing parts, please call:
Or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOW TO OPERATE THE EXERCISE CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
1. Read all instructions in this manual be ore
using the exercise cycle. Use the exercise
cycle only as described in this manual.
2. It is the responsibility o the owner to ensure
that all users o the exercise cycle are ade-
quately in ormed o all precautions.
3. Use the exercise cycle indoors on a level sur-
ace. Keep the exercise cycle away rom
moisture and dust. Place a mat under the
exercise cycle to protect the loor.
4. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age o 12 and pets
away rom the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes or oot protection.
7. The exercise cycle should not be used by
persons weighing more than 115 kg (250 lbs.).
8. Always keep your back straight whilst using
the exercise cycle; do not arch your back.
9. I you eel pain or dizziness whilst exercising,
stop immediately and cool down.
10.The exercise cycle does not have a ree
wheel; the pedals will continue to move until
the lywheel stops.
11. The pulse sensor is not a medical device.
Various actors, including the user's move-
ment, may a ect the accuracy o heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12.The exercise cycle is intended or home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
WARNING: Be ore beginning this or any exercise program, consult your physician. This
is especially important or persons over the age o 35 or persons with pre-existing health problems.
Read all instructions be ore using. ICON assumes no responsibility or personal injury or property
damage sustained by or through the use o this product.
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk o serious injury, read the ollowing important precau-
tions be ore using the exercise cycle.

3
Congratulations for selecting the new WESLO®
PURSUIT 102 exercise cycle. Cycling is one of the
most effective exercises for increasing cardiovascular
fitness, building endurance, and toning the body. The
PURSUIT 102 exercise cycle offers a selection of fea-
tures designed to let you enjoy this healthful exercise
in the convenience and privacy of your home.
For your bene it, read this manual care ully be ore
you use the exercise cycle. If you have questions
after reading this manual, please call our Customer
Service Department at 08457 089 009. To help us
assist you, please note the product model number and
serial number before calling. The model number is
WLEVEX12920. The serial number can be found on a
decal attached to the exercise cycle (see the front
cover of this manual for the location of the decal).
Before reading further, please familiarise yourself with
the parts that are labeled in the drawing below.
Water Bottle Holder*
*No water bottle is included
Resistance Knob
REAR
FRONT
Seat
Adjustment Knob
Adjustment Knob
Pedal/Strap
Console
Pulse Sensor
Handlebar
RIGHT SIDE
BEFORE YOU BEGIN

4
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable spanner , Phillips screw-
driver , and pliers .
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part, from the PART LIST on page 1 . The second number refers
to the quantity needed for assembly. Note: Some small parts may have been pre-attached or shipping. I a
part is not in the parts bag, check to see i it has been pre-attached.
3/8” Nylon
Locknut (33)–
M8 Nylon
Locknut (10)–3
M8 Flat
Washer (51)–3
M8 x 15mm Button
Screw (3 )–3
3/8” x 68mm Carriage Bolt (30)–
Curved
Washer ( 2)–3
Ground
Screw (27)–1
M5 x 12mm
Screw ( 9)–
M8 Split
Washer (55)–3
1. Set the Front Stabiliser (2) in front of the Frame (1),
with the Wheels (23) on the side shown. Whilst another
person lifts the front of the Frame slightly, attach the
Front Stabiliser with two 3/8” x 68mm Carriage Bolts
(30) and two 3/8” Nylon Locknuts (33). Make sure that
the Front Stabiliser is turned so the Wheels are not
touching the loor.
2
23
23
33
30
1
1
2. Whilst another person lifts the rear of the Frame (1)
slightly, attach the Rear Stabiliser (6) with two 3/8” x
68mm Carriage Bolts (30) and two 3/8” Nylon Locknuts
(33).
30
6
1
2
33
33

5
3
9
3
19
5
1
13
Hole
Zip Tie
Adjustment
Holes
36
3. Whilst another person holds the Upright (13) in the
position shown, connect the Upper Wire (36) to the
Reed Switch Wire ( 3). Cut and remove the zip tie
holding the Reed Switch Wire to the Frame (1). Next,
connect the Resistance Cable (19) to the Lower Cable
( 5) in the following way:
• See drawing A. Press the small cylinder on the end
of the Resistance Cable (19) into the hole in the con-
nector on the Lower Cable ( 5). Pull the Resistance
Cable up and slide it into the slot in the top of the
connector.
• See drawing B. Turn the Resistance Cable (19) until
it is aligned with the slot in the connector, and press
the Resistance Cable down into the connector. The
Resistance Cable will lock into place.
Carefully pull the excess Upper Wire (36) out of the
top of the Upright (13), push the excess Cable (19, 5)
down into the Frame (1), and insert the Upright into the
Frame. Be care ul to avoid pinching the Wires and
Cables. Next, align one of the adjustment holes in the
Upright with the indicated hole in the Frame. Insert the
Adjustment Knob (9) into the Frame and the Upright,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one o the
adjustment holes in the Upright.
. The Console (16) requires three 1.5V AA batteries;
alkaline batteries are recommended. Insert three bat-
teries into the battery compartment. Make sure that
the batteries are oriented as shown by the mark-
ings inside the battery compartment.
AB
5
16
19
19
Batteries
Cylinder
Connector
Connector
Slot
Hole
Be care ul to
avoid pinching
the wires and
cables whilst
inserting the
Upright.

6
7. Attach the Seat (12) to the Seat Post (5) with three M8
Flat Washers (51) and three M8 Nylon Locknuts (10).
Note: The Flat Washers and Nylon Locknuts may be
preattached to the underside of the Seat.
6. Whilst another person holds the Handlebar (15) near
the Upright (13), connect the console wire to the Upper
Wire (36). Insert the excess wire down into the Upright.
Attach the Handlebar to the Upright with three M8 x
15mm Button Screws (3 ), three M8 Split Washers
(55) and three Curved Washers ( 2). Be care ul to
avoid pinching the wires.
15
36 3
55
13
2
55
3
3
2
6
Console Wire
7
51
12
51
10
10
5
5. Hold the Console (16) near the Handlebar (15).
Connect the ground wire to the Handlebar with the
Ground Screw (27). Insert the console wire into the
indicated hole in the Handlebar.
Move the Console (16) toward the Handlebar (15), at
the same time inserting the excess ground wire up into
the hole in the underside of the Console. Continue
until all of the excess ground wire is inside of the
Console. Attach the Console to the Handlebar with
four M5 x 12mm Screws ( 9). Be care ul to avoid
pinching the wires.
16
5
Be care ul to
avoid pinching
the wires.
Be care ul
to avoid
pinching the
wires.
15
9
9
27
Ground
Wire
Hole
Console
Wire

7
10. Make sure that all parts are properly tightened be ore you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. Identify the Left Pedal (2 ), which is marked with an
“L.” Using an adjustable spanner, irmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (21). Tighten the Right Pedal (not shown) clock-
wise into the right arm of the Crank. Important:
Tighten both Pedals as irmly as possible. A ter
using the exercise cycle or one week, retighten the
Pedals. For best per ormance, the Pedals must be
kept tightened.
Adjust the left Pedal Strap (25) to the desired position,
and press the end of the Pedal Strap onto the tab on
the Left Pedal (2 ). Adjust the right Pedal Strap (not
shown) in the same way.
9
8. Turn the indicated Adjustment Knob (9) counterclock-
wise and remove it. Insert the Seat Post (5) into the
Frame (1). Align one of the adjustment holes in the
Seat Post with the indicated hole in the Frame. Insert
the Adjustment Knob into the Frame and the Seat Post,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one o the
adjustment holes in the Seat Post. 1
5
Hole
Adjustment
Holes
9
8
2
21
25
Tab

8
HOW TO OPERATE THE EXERCISE CYCLE
HOW TO ADJUST THE SEAT POST
For effective exer-
cise, the seat
should be at the
proper height. As
you pedal, there
should be a slight
bend in your knees
when the pedals
are in the lowest
position. To adjust
the height of the
seat, first turn the
indicated knob
counterclockwise
and remove it. Next, slide the seat post up or down and
align one of the adjustment holes in the seat post with
the indicated hole in the Frame. Insert the knob into the
frame and the seat post, and turn the knob clockwise
until it is tight. Make sure that the knob is inserted
through one o the adjustment holes in the seat
post.
HOW TO ADJUST THE UPRIGHT
The upright can be
adjusted to the
height that is the
most comfortable
for you. To adjust
the upright, first
turn the indicated
knob counterclock-
wise and remove it.
Next, slide the
upright up or down
and align one of the
adjustment holes in
the upright with the
indicated hole in the frame. Insert the knob into the
frame and the upright, and turn the knob clockwise until
it is tight. Make sure that the knob is inserted
through one o the adjustment holes in the
upright.
HOW TO ADJUST THE PEDAL STRAPS
To adjust the pedal
straps, first pull the
ends of the straps
off the tabs on the
pedals. Adjust the
straps to the
desired position,
and press the ends
of the straps back
onto the tabs.
HOW TO ADJUST THE PEDALING RESISTANCE
To increase the
resistance of the
pedals, turn the
resistance knob
clockwise; to
decrease the resis-
tance, turn the knob
counterclockwise.
Important: Stop
turning the knob
when turning
becomes di icult,
or damage may
result.
Strap
Tab
Upright
Knob
Hole
Seat Post
Knob
Hole
Seat
Resistance
Knob

9
FEATURES OF THE CONSOLE
The easy-to-use console features six modes that pro-
vide instant exercise feedback during your workouts.
The modes are described below.
Speed—This mode displays your pedalling
speed, in kilometres per hour or miles per hour.
Time—This mode displays the elapsed time.
Note: If you stop pedalling for a few seconds,
the time mode will pause.
Distance—This mode displays the distance you
have pedalled, in kilometres or miles.
Calorie—This mode displays the approximate
number of calories you have burned.
Heart Rate—This mode displays your heart rate
when you use the pulse sensor.
Scan—This mode displays the speed, time, dis-
tance, calorie, and heart rate modes, for a few
seconds each, in a repeating cycle. Note: The
heart rate mode will be displayed only when the
pulse sensor is being used.
HOW TO OPERATE THE CONSOLE
Make sure there are batteries in the console (see
BATTERY REPLACEMENT on page 11). If there is a
thin sheet of clear plastic on the console, remove it.
Follow the steps below to operate the console.
1. To turn on the power, press the ON/RESET button
or begin pedalling. The entire display will briefly
appear; the console will then be ready for use.
2. Select one of the modes:
Scan mode—
When the power
is turned on, the
scan mode will be
selected automati-
cally. A mode indi-
cator will appear
below the scan
symbol to show
that the scan
mode is selected,
and a second
mode indicator will show which mode is currently
displayed. Note: If you have selected a different
mode, repeatedly press the MODE button to select
the scan mode again.
Speed, time, dis-
tance, or calorie
mode—To select
one of these
modes for continu-
ous display,
repeatedly press
the MODE button.
The mode indica-
tors will show
which mode is selected. Make sure there is not a
mode indicator below the scan symbol.
Note: The console can display speed and dis-
tance in either kilometres or miles. To change
the unit o measurement, press the ON/RESET
button or about ive seconds. The letters km/h or
mph will appear in the display to show which unit of
measurement is selected. When the batteries are
replaced, it may be necessary to reselect the
desired unit of measurement.
Mode Indicators

10
3. Measure your heart rate, if desired.
To measure your
heart rate, stop
pedaling and
place your thumb
on the pulse sen-
sor as shown. Do
not press too
hard, or the cir-
culation in your
thumb will be
restricted and
your pulse will
not be detected.
After a few seconds, the heart-shaped indicator in
the display will flash steadily, two dashes will
appear, and then your heart rate will be shown.
Hold your thumb on the pulse sensor for about 15
seconds for the most accurate reading.
If the displayed heart rate appears to be too high or
too low, or if your heart rate is not displayed, lift
your thumb off the pulse sensor for a few seconds.
Then, place your thumb on the pulse sensor as
described above.
Make sure you are applying the proper amount of
pressure to the pulse sensor. Try the pulse sensor
several times until you become familiar with it.
Remember to sit still whilst measuring your heart
rate.
. To reset the display at any time, press the
ON/RESET button.
5. To turn off the power, simply wait for a few minutes.
The console has an “auto-o ” eature. I the
pedals are not moved and the console buttons
are not pressed or a ew minutes, the power
will turn o automatically to save the batteries.
WARNING: The pulse sensor
is not a medical device. Various actors
may a ect the accuracy o heart rate read-
ings. The pulse sensor is intended only as
an exercise aid in determining heart rate
trends in general.
Pulse Sensor

11
Inspect and tighten all parts of the exercise cycle reg-
ularly. Replace any worn parts immediately.
To clean the exercise cycle, use a damp cloth and a
small amount of mild detergent. Important: To avoid
damage to the console, keep liquids away rom
the console and keep the console out o direct
sunlight.
BATTERY REPLACEMENT
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries. To replace the batteries, refer
to step 5 on page 6 and remove the console from the
handlebar. Next, refer to step on page 5 and insert
three batteries into the console. Reattach the console
to the handlebar, being careful not to pinch the wires.
HOW TO ADJUST THE REED SWITCH
If the console does not display correct feedback, the
reed switch should be adjusted. In order to adjust the
reed switch, the left side shield must be removed.
Turn the Crank (21) to the position shown. Using an
adjustable spanner, turn the Left Pedal (2 ) clockwise
and remove it. Next, remove the five M x 25mm
Screws (52) and the M x 19mm Screw (5 ) from the
Left Side Shield (17). Carefully remove the Left Side
Shield.
Next, locate the Reed Switch ( 3). Turn the Crank
(21) until the Magnet (38) is aligned with the Reed
Switch. Loosen, but do not remove, the M x 12mm
Screw ( 6). Slide the Reed Switch slightly closer to or
away from the Magnet. Retighten the Screw. Turn the
Crank for a moment. Repeat until the console dis-
plays correct feedback. When the Reed Switch is cor-
rectly adjusted, reattach the left side shield and the
left pedal.
PULSE SENSOR TROUBLESHOOTING
Refer to step 3 on page 10.
MAINTENANCE AND TROUBLESHOOTING
52
5
17
21
38
3
6
52
2
21

12
CONDITIONING GUIDELINES
The following guidelines will help you to plan your
exercise program. Remember that proper nutrition
and adequate rest are essential for successful results.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, the key to achieving the
desired results is to exercise with the proper intensity.
The proper intensity level can be found by using your
heart rate as a guide. The chart below shows recom-
mended heart rates for fat burning, maximum fat
burning, and cardiovascular (aerobic) exercise.
To find the proper heart rate for you, first find your age
at the bottom line of the chart (ages are rounded off to
the nearest ten years). Next, find the three numbers
above your age. The three numbers are your “training
zone.” The lowest number is the recommended heart
rate for fat burning; the middle number is the recom-
mended heart rate for maximum fat burning; the high-
est number is the recommended heart rate for aerobic
exercise.
Fat Burning
To burn fat effectively, you must exercise at a relative-
ly low intensity level for a sustained period of time.
During the first few minutes of exercise, your body
uses easily accessible carbohydrate calories for ener-
gy. Only after the first few minutes of exercise does
your body begin to use stored fat calories for energy.
If your goal is to burn fat, adjust the intensity of your
exercise until your heart rate is near the lowest num-
ber in your training zone as you exercise. For maxi-
mum fat burning, adjust the intensity of your exercise
until your heart rate is near the middle number in your
training zone as you exercise.
Aerobic Exercise
If your goal is to strengthen your cardiovascular sys-
tem, your exercise must be “aerobic.” Aerobic exer-
cise is activity that requires large amounts of oxygen
for prolonged periods of time. This increases the
demand on the heart to pump blood to the muscles,
and on the lungs to oxygenate the blood. For aerobic
exercise, adjust the intensity of your exercise until
your heart rate is near the highest number in your
training zone.
WORKOUT GUIDELINES
Each workout should include the following three parts:
A warm-up, consisting of 5 to 10 minutes of stretching
and light exercise. A proper warm-up increases your
body temperature, heart rate, and circulation in prepa-
ration for exercise.
Training zone exercise, consisting of 20 to 30 min-
utes of exercising with your heart rate in your training
zone. Note: During the first few weeks of your exer-
cise program, do not keep your heart rate in your
training zone for longer than 20 minutes.
A cool-down, with 5 to 10 minutes of stretching. This
will increase the flexibility of your muscles and will
help to prevent post-exercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, plan three work-
outs each week, with at least one day of rest between
workouts. After a few months of regular exercise, you
may complete up to five workouts each week, if
desired. Remember, the key to success is make exer-
cise a regular and enjoyable part of your everyday life.
WARNING:
• Be ore beginning this or any exercise pro-
gram, consult your physician. This is espe-
cially important or persons over the age o
35 or persons with pre-existing health
problems.
• The pulse sensor is not a medical device.
Various actors may a ect the accuracy o
heart rate readings. The pulse sensor is
intended only as an exercise aid in deter-
mining heart rate trends in general.

13
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right.
Move slowly as you stretch—never bounce.
1. Toe Touch Stretch
Stand with your knees bent slightly and slowly bend forward from
your hips. Allow your back and shoulders to relax as you reach
down toward your toes as far as possible. Hold for 15 counts,
then relax. Repeat 3 times. Stretches: Hamstrings, back of knees
and back.
2. Hamstring Stretch
Sit with one leg extended. Bring the sole of the opposite foot
toward you and rest it against the inner thigh of your extended
leg. Reach toward your toes as far as possible. Hold for 15
counts, then relax. Repeat 3 times for each leg. Stretches:
Hamstrings, lower back and groin.
3. Cal /Achilles Stretch
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your back
foot flat on the floor. Bend your front leg, lean forward and move
your hips toward the wall. Hold for 15 counts, then relax. Repeat
3 times for each leg. To cause further stretching of the achilles
tendons, bend your back leg as well. Stretches: Calves, achilles
tendons and ankles.
4. Quadriceps Stretch
With one hand against a wall for balance, reach back and grasp
one foot with your other hand. Bring your heel as close to your
buttocks as possible. Hold for 15 counts, then relax. Repeat 3
times for each leg. Stretches: Quadriceps and hip muscles.
5. Inner Thigh Stretch
Sit with the soles of your feet together and your knees outward.
Pull your feet toward your groin area as far as possible. Hold for
15 counts, then relax. Repeat 3 times. Stretches: Quadriceps and
hip muscles.
1
2
3
5

14
1 1 Frame
2 1 Front Stabiliser
3 1 “C” Magnet Bracket
Stabiliser Endcap
5 1 Seat Post
6 1 Rear Stabiliser
7 2 Handlebar Endcap
8 2 Foam Grip
9 2 Adjustment Knob
10 M8 Nylon Locknut
11 2 M6 x 32mm Bolt
12 1 Seat
13 1 Upright
1 2 Frame Bushing
15 1 Handlebar
16 1 Console
17 1 Left Side Shield
18 1 Right Side Shield
19 1 Resistance Control/Cable
20 1 M8 x 5mm Spacer
21 1 Crank/Pulley
22 1 Reed Switch Clamp
23 2 Wheel
2 1 Left Pedal
25 2 Pedal Strap
26 1 Right Pedal
27 1 Ground Screw
28 6 3/8” Jam Nut
29 2 U-bracket
30 3/8” x 68mm Carriage Bolt
31 2 Eyebolt
32 M6 Nylon Locknut
33 3/8” Nylon Locknut
3 M8 x 15mm Button Screw
35 1 M10 Flat Washer
36 1 Upper Wire
37 1 Flywheel
38 1 Magnet
39 1 Flywheel Axle
0 2 Flywheel Bearing
1 1 “C” Magnet
2 3 Curved Washer
3 1 Reed Switch/Wire
1 Crank Bearing Set
5 1 Lower Cable
6 1 M x 12mm Screw
7 1 Return Spring
8 1 Belt
9 M5 x 12mm Screw
50 1 M5 x 20mm Screw
51 M8 Flat Washer
52 5 M x 25mm Screw
53 1 Resistance Knob
5 2 M x 19mm Screw
55 3 M8 Split Washer
# 1 User’s Manual
# 2 Assembly Wrench
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
PART LIST—Model No. WLEVEX12920 R1002A
Key No. Qty. Description Key No. Qty. Description

15
1
2
3
5
1
7
7
8
8
9
10
1011
11
12
13
1
15
16
17
18
21
22
25
2
26
25
9
31
31
32
32
32
32
36
37
38
39
0
0
1
3
6
5
7
53 8
19
23
23
30
30
33
33
33
33
9
50
51 51
52
52
5
5
6
51
10
28
28
28
28
35
29
29
27
20
3
3
3
2
2
3
2
55
55
55
EXPLODED DRAWING—Model No. WLEVEX12920 R1002A

Part No. 186223 R1002A Printed in Taiwan © 2002 ICON Health & Fitness, Inc.
WESLO is a registered trademark of ICON Health & Fitness, Inc.
ORDERING REPLACEMENT PARTS
To order replacement parts, contact the ICON Health & Fitness, Ltd. office, or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
Tel:
Outside the UK: 0 (0 ) 113 387 7133
Fax: 0 (0 ) 113 387 7125
To help us assist you, please be prepared to give the following information:
• the MODEL NUMBER of the product (WLEVEX12920)
• the NAME of the product (WESLO®PURSUIT 102 exercise cycle)
• the SERIAL NUMBER of the product (see the front cover of this manual)
• the KEY NUMBER and DESCRIPTION of the part(s) (see page 1 )
08457 089 009
