WESTECH WT-F010-3 Classic User manual

http://www.westechlighting.com Copyright ©2016 WESTECH. All Rights Reserved.
特点和性能
可以太阳能供电，也可以市电充电；
体积小，机构简单，易于安装
高亮度 LED
自主运行时间长
■多档位调节
■USB 输出 5V 500mA
Features and Benefits
Solar Powered Directly and AC Charging
Compact. Portable and durable
High luminance LED
Running long time after fully charged
■Multi file adjustment
■USB output 5V 500mA
应用
室内照明
走廊庭院照明
露营及业务作业
灾难救生照明
Application
Indoor Lighting
Corridor court Lighting
Camping and field operation
Lighting disaster lifesaving
Solar LED Lanterns
Mode: WT-F010-3 Classic
3W Solar Panel
220V Charging Interface

http://www.westechlighting.com Copyright ©2016 WESTECH. All Rights Reserved.
Solar LED Lanterns WT-F010-3 Specifcation
Product Code WT-F010-3
Number of LED Per Lantern SMD2835 24PCS
Ingress Protection IP20
AC Input 220V 50/60Hz
Solar Charging Input DC Jack 9V
USB Output 5V 500mA
Indicator Full Charge Indicator
LED information:
Lamp Brightness 350 lumens for high brightness
20 Lumens for high brightness
Lamp Power 12W
Lifetime of LED LM-80
Color Temperature 5500-6500K
Battery Information:
Battery Type Sealed Maintenance Free (SMF) lead acid battery
Battery Back Up 4V 6AH
AC Charging Time 20-24Hrs
Solar Charging Time 20-24Hrs
Working Time 3-4Hrs with high brightness
≥100Hrs with low brightness
Packing Information(Lamp Only)
：
Unit Dimension 150*150*320
Inner Packing Size 153*153*325
outer Packing Size 635*320*345/ 8Pcs
Gross Weight Per Box 11.6Kg
Solar Panel
Solar LED Panel Type 3W 9.0V .0.25A Polycrystalline Solar Panel
Solar Panel Dimensions 235*140*17mm
Solar Panel connecting cable length 2M
Solar Panel characteristics A stand at the back of solar panel to maintain 30 degree facing to the
Sun.

http://www.westechlighting.com Copyright ©2016 WESTECH. All Rights Reserved.
Solar LED Lanterns WT-F010-3 Specification
Operation Information 1. Please read the instructions and fully charged before Use;
2. Before
plugging in an external battery or power supply, please make sure if the
power supply is correct;
3.
During the use process, when the LED lamp brightness get dimmed and batteries
become fully discharged state, in order to protect the battery，please stop using
and charge it in time at this time. Shouldn't charge after the LED lamp is completely
no light, because easily lead to excessive discharge battery failure extremely;
4. Must use more than 8 hours every three months;
5. Make the lamp off when not in use
6. When the temperature is below 0 degrees or above 40 degrees, use and charging
efficiency will be reduced;
7. Do not go near water or rain;
Maintenance 1. solar panel surface clean
2. The solar panel surface cannot be scratched and damaged.
Scrap products 1.
In order to reduce pollution of the environment, please do not throw the battery,
battery to a designated disposal agency or the designated bins.
