WD RE SAS
Enterprise Hard Drives
WD RE SAS hard drives are engineered to offer data-hungry SAS
storage systems the massive capacity they need without
compromising top-of-the-line performance. Advanced reliability
and data integrity features allow for 24x7 operation in tightly
packed vibration prone multi-drive systems. This
uncompromising combination of high-capacity, peak
performance and best-in-class reliability make WD RE SAS drives
ideal for business critical applications.
INTERFACE
SAS 6 Gb/s
WIDTH/HEIGHT
3.5-inch/1-inch
ROTATIONAL SPEED
7200 RPM
CAPACITIES
1 TB and 2 TB
MODEL NUMBERS
WD2000FYYG
WD1000FYYG
Note: Not all products may be
available in all regions of the
world.
High-capacity
WD RE SAS hard drives are available with
up to 2 TB for capacity-intensive storage
applications.
Peak performance
Ultra-fast 6 Gb/s SAS interface
maximizes transfer rates while dual-stage
actuator technology enables fine-tuned
read/write accuracy.
Enterprise-class reliability
Engineered for 24x7 operation with 1.2
million hours MTBF, these drives have the
highest available reliability ratings on a
high-capacity drive.
Compatibility
An ultra-fast 6 Gb/s SAS interface
enables easy integration into SAS storage
subsystems while delivering twice the
interface speed of traditional 3 Gb/s SAS
nearline hard drives.
Vibration protection
Enhanced Rotary Acceleration Feed
Forward (RAFF™) technology includes
sophisticated electronics to monitor the
drive and correct both linear and
rotational vibration in real time resulting in
improved performance and efficiency in
densely packed multi-drive systems.
NoTouch™ramp load technology
The recording head never touches the
disk media ensuring significantly less
wear to the recording head and media as
well as better drive protection in transit.
Enhanced error correction
Full internal IOEDC/IOECC* data integrity
protection means the drive finds and
corrects potential errors before they ever
surface.
Environmentally conscious
In addition to being ROHS compliant,
these drives also incorporate a halogen
free design.
5-year limited warranty
*Input output error detection code/Input output error correction
code
Product Benefits
Applications
High-capacity data center storage, storage area networks (SAN), network attached storage (NAS), direct attach storage (DAS), networked surveillance systems, and cloud
storage.

WD RE SAS
Western Digital, WD, the WD logo,
and Put Your Life On It are registered
trademarks in the U.S. and other countries;
and RAFF, NoTouch, and FIT Lab are
trademarks of Western Digital
Technologies, Inc. Other marks may be
mentioned herein that belong to other
companies. Product specifications subject
to change without notice.
© 2011 Western Digital Technologies, Inc.
All rights reserved.
Western Digital
3355 Michelson Drive, Suite 100
Irvine, California 92612
U.S.A.
2879-771386-A00 Jan 2011
For service and literature:
http://support.wdc.com
www.westerndigital.com
800.ASK.4WDC North America
800.832.4778 Spanish
+800.6008.6008 Asia Pacific
00800.27549338 Europe
(toll free where available)
+31.880062100 Europe/Middle East/Africa
Specifications12 TB 1 TB
Model number WD2000FYYG WD1000FYYG
Interface SAS 6 Gb/s SAS 6 Gb/s
Formatted capacity 2 TB 1 TB
User sectors per drive 3,907,029,168 1,953,525,168
SCSI command queuing Yes Yes
Form factor 3.5-inch 3.5-inch
RoHS compliant2Yes Yes
Performance
Data transfer rate (max)
Buffer to host
Host to/from drive (sustained)
6 Gb/s
139 MB/s
6 Gb/s
139 MB/s
Cache (MB) 32 32
Rotational speed (RPM) 7200 7200
Average drive ready time (sec) 21 21
Reliability/Data Integrity
Load/unload cycles3600,000 600,000
Non-recoverable read errors per bits read <10 in 1016 <10 in 1016
MTBF (hours)41,200,000 1,200,000
Limited warranty (years)555
Power Management
Average power requirements (W)
Sequential read/write
Random read/write
Idle
12.8
12.7
9.9
12.8
12.7
9.9
Environmental Specifications6
Temperature (°C)
Operating
Non-operating
5 to 55
-40 to 70
5 to 55
-40 to 70
Shock (Gs)
Operating (2 ms, read/write)
Operating (2 ms, read)
Non-operating (2 ms)
30
65
300
30
65
300
Average acoustics (dBA)7
Idle mode
Performance seek mode
29
34
29
34
Physical Dimensions
Height (in./mm, max) 1.028/26.1 1.028/26.1
Length (in./mm, max) 5.787/147 5.787/147
Width (in./mm, ± .01 in.) 4/101.6 4/101.6
Weight (lb./kg, ± 10%) 1.66/0.75 1.66/0.75
1As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576
bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SAS 6 Gb/s transfer rate calculated according to the SAS specification published by the INCITS T10
organization as of the date of this specification sheet. Visit www.t10.org for details.
2WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as mandated by the European Union for electrical and electronic products. The RoHS Directive 2002/95/EC of the
European Parliament, which is effective in the EU beginning July 1, 2006, aims to protect human health and the environment by restricting the use of certain hazardous substances in new equipment, and consists of restrictions on lead, mercury, cadmium, and other substances.
3Controlled unload at ambient condition
4100% workload at 50°C on base casting.
5The term of the limited warranty may vary by region. Visit http://support.wdc.com/warranty for details.
6No non-recoverable errors during operating tests or after non-operating tests.
7Sound power level.
