Western Digital WDG2NC10000 - My Book World Edition II User manual

External Desktop
My Book
Premium Edition™II
Quick Install Guide
™

My Book Premium Edition II | 1
EN
Before Getting Started
Kit Contents
•MyBook
™Premium Edition™II triple interface dual-drive storage system with RAID
• FireWire®800 cable
• FireWire 400 cable
• USB 2.0 certified cable
• AC adapter with power cord
• Installation and software CD
• Quick Install Guide
Compatibility
Note: Compatibility may vary depending on user’s hardware configuration and
operating system.
About Your Drive
My Book Premium Edition II is preformatted for Windows (NTFS) and is
pre-configured for RAID 0 (Striped) mode for maximum capacity and accelerated
performance. This product also supports RAID 1 (Mirrored) mode for data protection.
For more information on this product including instructions on changing the RAID
configuration or drive format, refer to the user manual included on the CD.
Note: For instructions on repartitioning and reformatting the drive to HFS+
(Journaled) prior to installation, see knowledge base answer ID 287 at
support.wdc.com.
Windows ®Macintosh ®
• Available USB or FireWire port • Available USB or FireWire port
• Windows 2000/XP •Mac
®OS X 10.3 or later
Important: For highest performance and reliability, it is recommended that you
install the latest updates and service pack (SP). For Windows, go to the Start
menu and select Windows Update. For Mac, go to the Apple menu and select
Software Update.
Kit Contents
My Book Premium Edition II
Installation and software CD
Quick Install Guide
FireWire 800 Cable
AC Power Adapter
FireWire 400 Cable
USB Cable

My Book Premium Edition II | 2
Installing the Drive
Windows
1. Turn on your computer.
2. Insert the software CD into the CD-ROM drive.
3. The CD autoruns and drive utilities are installed automatically. If a security alert is displayed during this
installation, click Accept or Continue.
Note: If AutoPlay is disabled on your computer, you must run the CD manually.
4. A menu displays a list of options including software, documentation, and a registration link. Click My Book
RAID Manager to install this utility.
5. When finished, click any other selection of your choice; otherwise, click Quit to close the menu.
6. Connect the unit’s power cord and interface cable (USB, FireWire 800, or FireWire 400) as shown, after
which the unit mounts to the system.
My Book is now ready for use. For further information including product features, utilities, RAID configuration,
drive replacement, and troubleshooting, refer to the user manual provided on the CD.
Important: You must first install the drive utilities on the included CD before connecting the unit.

My Book Premium Edition II | 3
Macintosh
1. Turn on your computer.
2. Insert the software CD into the CD-ROM drive.
3. Double-click the CD-ROM drive icon, the My Book drive icon, then the Mac folder, which contains the
software for this device.
4. Double-click My Book RAID Manager to install this program into the Applications folder.
5. WD Button Manager Software disk image contains the installer required to enable the capacity gauge and
Safe Shutdown™. Double-click this icon to install the program into the Applications folder.
6. If you want to install the backup software now, double-click the WD Backup™ icon in the Mac folder and
follow the instructions as prompted.
7. Connect the unit’s power cord and interface cable (USB, FireWire 800, or FireWire 400) as shown, after
which the unit mounts to the system.
My Book is now ready for use. For further information on this product including drive features, utilities, RAID
configuration, drive replacement, and troubleshooting, refer to the user manual provided on the CD.
Regulatory Compliance
FCC Class B Information
This device has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This unit generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. Any changes or
modifications not expressly approved by WD could void the user’s authority to operate this equipment.
The following booklet, prepared by the Federal Communications Commission, may be helpful: How to Identify and Resolve Radio/TV
Interference Problems. This booklet is Stock No. 004-000-00345-4 available from the US Government Printing Office, Washington, DC
20402.
CSA Notice
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This Class B digital apparatus complies with Canadian ICES-003.
Underwriters Laboratories Inc.
Approved for US and Canada. CAN/CSA-C22.2 No. 60950-1, UL 60950-1. Information Technology Equipment - Safety - Part 1: General
Requirements (File E101559).
CE Compliance For Europe
Verified to comply with EN55022 for RF Emissions and EN50082-1 for Generic Immunity, as applicable.

My Book Premium Edition II | 4
Warranty Information
Obtaining Service
WD values your business and always attempts to provide you the very best of service. If this Product requires maintenance, either contact
the dealer from whom you originally purchased the Product or visit our product support Web site at support.wdc.com for information on
how to obtain service or a Return Material Authorization (RMA). If it is determined that the Product may be defective, you will be given an
RMA number and instructions for Product return. An unauthorized return (i.e., one for which an RMA number has not been issued) will be
returned to you at your expense. Authorized returns must be shipped in an approved shipping container, prepaid and insured, to the
address provided on your return paperwork. Your original box and packaging materials should be kept for storing or shipping your WD
product. To conclusively establish the period of warranty, check the warranty expiration (serial number required) via support.wdc.com. WD
shall have no liability for lost data regardless of the cause, recovery of lost data, or data contained in any Product placed in its possession.
Limited Warranty
WD warrants that the Product, in the course of its normal use, will be free from defects in material and workmanship for a period of one (1)
year, unless otherwise required by law, and will conform to WD’s specification therefor. This limited warranty period shall commence on the
purchase date appearing on your purchase receipt. WD shall have no liability for any Product returned if WD determines that the Product
was stolen from WD or that the asserted defect a) is not present, b) cannot reasonably be rectified because of damage occurring before
WD receives the Product, or c) is attributable to misuse, improper installation, alteration (including removing or obliterating labels and
opening or removing external enclosures, unless the product is on the list of limited user-serviceable products and the specific alteration is
within the scope of the applicable instructions, as found at support.wdc.com), accident or mishandling while in the possession of someone
other than WD. Subject to the limitations specified above, your sole and exclusive warranty shall be, during the period of warranty specified
above and at WD’s option, the repair or replacement of the Product. The foregoing warranty of WD shall extend to repaired or replaced
Products for the balance of the applicable period of the original warranty or ninety (90) days from the date of shipment of a repaired or
replaced Product, whichever is longer.
The foregoing limited warranty is WD’s sole warranty and is applicable only to products sold as new. The remedies provided herein are in
lieu of a) any and all other remedies and warranties, whether expressed, implied or statutory, including but not limited to, any implied
warranty of merchantability or fitness for a particular purpose, and b) any and all obligations and liabilities of WD for damages including, but
not limited to accidental, consequential, or special damages, or any financial loss, lost profits or expenses, or lost data arising out of or in
connection with the purchase, use, or performance of the Product, even if WD has been advised of the possibility of such damages. In the
United States, some states do not allow exclusion or limitations of incidental or consequential damages, so the limitations above may not
apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Technical Support Services
If you need additional information or help during installation or normal use of this product, visit our product
support Web site at support.wdc.com and search our knowledge base.
support.wdc.com
www.westerndigital.com
800.ASK.4WDC North America
949.672.7199 Spanish
+800.6008.6008 Asia Pacific
+31.20.4467651 Europe/Middle East/Africa
Western Digital
20511 Lake Forest Drive
Lake Forest, California 92630
U.S.A.
Western Digital, WD, and the WD logo are registered trademarks; and My Book, Premium Edition, WD Backup, and Safe Shutdown are trademarks of Western Digital Technologies, Inc.
Other marks may be mentioned herein that belong to other companies. Specifications subject to change without notice.
© 2006 Western Digital Technologies, Inc. All rights reserved.
2079-701078-101 Nov 2006
