WESTLAB
SUBLIME STEREO
MICROSCOPE,
RECHARGEABLE, LED
USER MANUAL
CODE 663-541 & 664-090
INSTRUCTION
MANUAL
Before Use 1
3.Parameter/Technical Terms 2
4.Troubleshooting 3
*Please read these instructions
carefully before use.
.
1. OPERATION
(1.) As the microscope is a precision instrument, always handle
it with care, avoiding impact or abrupt movement during
transportation.
2. MAINTENANCE
(1.) All glass surfaces must always be kept clean. Fine dust on
the optical surface should be blown off by means of a hand
blower or gently wiped off with a soft lens tissue. Carefully
wipe off oil or fingerprints on the lens surfaces with tissue
moistened with a small amount of 3:7 mixture of alcohol
and ether.
(2.) Do not use organic solution to wipe the surface of the other
components. These parts, especially the plastic parts,
should be cleaned with a neutral detergent.
(3.) Do not take down or assemble it yourself.
(4.) After use, cover the microscope with the dustcover provided,
and keep it in a dry and clean place for preventing rust.
(2.) Do not let the microscope be in sunlight directly. Keep
it in a dry and clean place. Avoid high temperature and acute
shaking. Following environment is required: Indoor
temperature: 0°C~40°C, Max relative humidity: 85%.
(3.) Avoiding impact the definition of the image, do not leave
feculence and fingerprints on the lens surfaces.
(4.) Before using, examine to ensure the power supply voltage
is consistent with the rating voltage.
1
BEFORE USE
WESTLAB
SUBLIME STEREO
MICROSCOPE,
RECHARGEABLE,
LED
USER MANUAL
CODE 663-541 & 664-090
2
3. PARAMETER/TECHNICAL TERMS
4-5 TECHNICAL TERMS
(1) Total magnification=(magnification of objective) X (magnification
of eyepiece)
(2) Field of view=(line field of view of the eyepiece selected)
÷(magnification of the objective selected)
(3) N.A.=n·sinα (max), N.A.is very important parameter which
marks the features of the objective and condenser. The “n”
is the refractive index of the medium (air or immersion oil)
between the cover glass of the objective and the specimen.
The “α” is the half of the aperture angle. The N.A.is bigger,
the resolution of the objective is higher.
(4) Object to primary image distance: the distance between the
object plane to the primary image plane. The conjugate
distance is fixed.
(5) Mechanical tube length: The distance between the objective
shoulder and the ocular shoulder.
WESTLAB
SUBLIME STEREO
MICROSCOPE,
RECHARGEABLE,
LED
USER MANUAL
CODE 663-541 & 664-090
4. TROUBLESHOOTING
Optics
(1)The side of
the field of
view is dark or
not even
The nosepiece is not in the right
position
Turn the nosepiece
into the right position
Clean the lens
Stain or dust has accumulated on the
condenser, objective, eyepieces,
base, lens
Symptom Cause
(2)Stain or
dust is
observed in
the field
of view
Stains have accumulated on the
specimen
Clean the specimen
Clean the lens
Stains have accumulated on the lens
(3)Unclear
No cover glass on the specimen slide Add the cover glass
The cover glass is not standard Use a standard cover
glass with thickness
0.17mm
Remedy
Make it face up
Clean thoroughly
Use immersion oil
Get rid of the air bubble
Use a correct one
Adjust the iris
diaphragm
Clean lens
Adjust the condenser
The specimen faces down
The immersion oil has accumulated
on the dry objective
The immersion oil is not used for oil
objective 100XR
Air bubble in the immersion
Use wrong immersion oil
The aperture is not opened to
correct size
Stains or dust has accumulated on
the lens in the inlet of the head
The condenser is not in the right
position
4)One side of
the field of view
is dark or the
image moves
while focusing
The specimen slide is not fixed Fix with clips
Turn the nosepiece
into the right position
The nosepiece is not in the right
position
(5)The field of
view is not
bright enough
The iris diaphragm is not bigger
enough
Adjust the iris
diaphragm
(6)The image
color is not true
No filter is used Use correct filter
Adjust the condenser
Clean lens
The condenser is not in the right
position
Stain or dust has accumulated on the
condenser, objective, eyepieces,
base lens
3
WESTLAB
SUBLIME STEREO
MICROSCOPE,
RECHARGEABLE,
LED
USER MANUAL
CODE 663-541 & 664-090
ONLINE
www.westlab.com.au
Order online with our easy Express
Order form for fast, secure ordering.
PHONE
1800 358 101
Speak to one of our
friendly, efficient staff
from 8.00am to 5.00pm Monday to
Friday.
EMAIL
sales@westlab.com.au
24 hours, 7 days a week convenience.
FAX
1300 725 903
Order via fax and we will confirm your
order and delivery details at the end
of the day.
ORDERING WITH
WESTLAB IS EASY...
4. TROUBLESHOOTING (CONT)
Optics
Electrics
(1) The image
is not focused
while using
high power
objective
The cover glass faces down Put the cover glass
to face up
Use a standard cover
glass with thickness
0.17mm
The cover glass is not standard
Symptom Cause
(2) The
objective
touches the
cover glass
when turning
the nosepiece
The cover glass faces down Put the cover glass
to face up
Use a standard cover
glass with thickness
0.17mm
The cover glass is not standard
(3) Cannot
move the
slide smoothly
The slide is not fixed correctly Adjust it correctly
Remedy
Tighten it
The movable specimen holder is not
fixed properly
(2)The bulb
burnt out
usually
The voltage is too high Use correct power
supply
(3)The fuse
burnt out
usually
The bulb will burn out soon
The wire doesn’t connect all right
Replace with a new
one
Connect correctly
Replace with a
correct one
Use a wrong bulb
(1)The bulb
does not work
No power supply Check the connection
of the power cable
Tighten it
The bulb is not inserted correctly
Replace it
The bulb burnt out
Replace it
The fuse burnt out
4
