Weston Products 08-5000 User manual

COMMERCIAL
PRODUCTS
ATTENTION
If any components of this unit are broken,
do not operate properly, or for product returns,
please contact Pragotrade at
1-800-814-4895
Outside the U.S. call 440-638-3131.
Fax: [phone]
Exclusively imported by Pragotrade LLC, Strongsville, Ohio
www.pragotrade.com
REV081809
C O M M E R C I A L
WHEATGRASS JUICER
INSTRUCTION MANUAL
Model No. 08-5000

-2-
COMMERCIAL WARRANTY CARD
SEND THIS CARD ALONG WITH A COPY OF YOUR ORIGINAL PURCHASE RECEIPT
Business Name: _________________________________
Contact Name: __________________________________
Address: ______________________________________
City/State/Zip: ___________________________________
Telephone Number: (_________) ___________________
E-Mail Address:___________________________________
OriginalDateof Purchase: _______/_________/__________
Product Model #: __________________________________
Serial # (if applicable): ____________________________
DIAGRAM PART PART
NUMBER DESCRIPTION NUMBER
1 Head 08-5010
2 Juicer Motor N/A
3 Head Locking Screw 08-2005
4 Auger Bushing See Replacement Parts Kit
5 Screen See Replacement Parts Kit
6 Auger 08-5015
7 Rubber Gasket See Replacement Parts Kit
8 Head Aligning Cap 08-5017
9 Waste Valve 08-5018
10 Rubber Feet (4) 08-2007
11 Stomper 08-5020
12 Head Aligning Cap Wrench 08-5021
Not Shown Toggle Switch Rubber Boot 08-5012
13 Replacement Parts Kit 08-5022
Screen (2)
Rubber Gasket (2)
Auger Bushing (2)
A Complete Motor Assembly 08-5028
B Complete Head Assembly 08-5029
COMPONENT LIST
If any parts are missing or damaged, the unit does not operate properly or to
replace worn-out parts call Pragotrade LLC toll free at
1-800-814-4895
Monday thru Friday 8:00am-5:00pm EST.
Outside the U.S. call 440-638-3131
-11-
1
WARRANTY INFORMATION
SAVE THIS WARRANTY INFORMATION FOR YOUR RECORDS!
Pragotrade LLC warrants to the ORIGINAL RETAIL PURCHASER of this product that if operated in accordance
with the printed instruction accompanying it, then for a period of 1 year from the date of purchase, the product shall be
free from defects in material and workmanship.
The Warranty Card, along with a copy of the original receipt, must be received by Pragotrade LLC within 30 days
from purchase date for the warranty to apply. Failure to send the completely lled out Warranty Card, along with a copy
of the original receipt, will void the warranty.
The product must be delivered to or shipped freight prepaid to Pragotrade LLC for warranty services, in either its
original packaging or similar packaging affording an equal degree of protection. Damage due to shipping is not the
responsibility of the company. Pragotrade LLC charges a $35.00 per hour bench charge. NOTE: No repairs will be
started without the authorization of the customer. The return shipping cost to the customer will be added to the repair
invoice.
Pragotrade LLC will repair (or at its discretion, replace) the product free of charge, if in the judgment of the company,
it has been proven to be defective as to seller’s labor and material, within the warranty period.
New or rebuilt replacements for factory defective parts will be supplied for one (1) year from the date of purchase.
Replacement parts are warranted for the remainder of the original warranty period.
For non-warranty repairs, contact Pragotrade’s Customer Service at 1-800-814-4895 M-F 8am-5pm EST (outside of
the United States 440-638-3131) to obtain a Return Authorization Number (RMA Number). Pragotrade will refuse all
returns that do not contain this number. DO NOT RETURN THE UNIT WITHOUT PROPER AUTHORIZATION
FROM PRAGOTRADE LLC.
LIMITATIONS: The warranty is void if the product is used for any purpose other than that for which it is designed.
The product must not have been previously altered, repaired, or serviced by anyone else other than Pragotrade LLC.
If applicable, the serial number must not have been altered or removed. The product must not have been subjected
to accident in transit or while in the customer’s possession, misused, abused, or operated contrary to the instructions
contained in the instruction manual. This includes failure caused by neglect of reasonable and necessary maintenance,
improper line voltage and acts of nature. This warranty is not transferable and applies only to U.S. and Canadian sales.
Except to the extent prohibited by applicable law, no other warranties whether expressed or implied, including
warranty merchantability and tness for a particular purpose, shall apply to this product. Under no circumstances shall
Pragotrade LLC be liable for consequential damages sustained in connection with said product and Pragotrade LLC
neither assumes nor authorizes any representative or other person to assume for it any obligation or liability other than
such as is expressly set forth herein. Any applicable implied warranties are also limited to the one (1) year period of
the limited warranty.
This warranty covers only the product and its specic parts, not the food or other products processed in it.
CUT ALONG THE DOTTED LINE AND SEND THE WARRANTY CARD ALONG WITH A
COPY OF YOUR ORIGINAL PURCHASE RECEIPT TO:
Pragotrade LLC
20365 Progress Drive, Strongsville, OH 44149
2
8
9
5
6
Power
Cord 7
11
13
Juice
Outlet
Feed
Chute
3
4
10
12
Power Switch /
Circuit Breaker
Reset Button
A
B

-3-
-10-
WARNING!
1. Read and understand all information in
this manual before using the Wheatgrass
Juicer.
2. Clean the Wheatgrass Juicer before
using it for the rst time and every time
after use. See the “Cleaning Instructions”
section of this manual.
3. DO NOT use the Wheatgrass Juicer
unless it is fully assembled and all parts
are secured in place. See the “Assembly
Instructions” section of this manual.
4. To avoid serious personal injury,
NEVER reach into the Head. Use the
Stomper to push wheatgrass into the
Head.
5. Stay clear of the juice outlet on the
bottom of the Head. NEVER insert your
ngers into the juice outlet. Serious
personal injury could result.
6. Disconnect the Power Cord from the
electrical outlet before cleaning, assembling
or disassembling the Wheatgrass Juicer.
7. Only operate the Wheatgrass Juicer
on a level, stable surface. Make sure all of
the feet touch the surface.
8. To prevent unintentional starting,
make sure the Power Switch on the Juicer
Motor is set to “OFF” before connecting the
Power Cord to the electrical outlet.
9. DO NOT operate the Wheatgrass
Juicer without wheatgrass in the Head.
Damage to the Head and Auger may
occur.
10. Inspect the Power Cord for damage
before each use. DO NOT use the
Wheatgrass Juicer if the Power Cord
or any other part is damaged. DO NOT
attempt to repair the Wheatgrass Juicer.
Call Pragotrade at the number listed on the
back of this manual for information on unit
repair or replacement.
11. DO NOT use parts or attachments
from other manufacturers on the
Wheatgrass Juicer. Use of unauthorized
parts or attachments may cause personal
injury and/or unit damage and will void the
warranty.
12. DO NOT use the Wheatgrass Juicer
outdoors.
13. Before operating the Wheatgrass
Juicer, tie back long hair, roll up long
sleeves and remove ties, watches and
jewelry.
14. Wait until all parts have stopped
moving before toggling the Wheatgrass
Juicer into “Reverse” or “Forward”.
15. DO NOT run the Wheatgrass Juicer
in “Reverse” for more than 3 seconds at a
time. Damage to the unit may occur.
16. DO NOT use the Wheatgrass Juicer
while under the inuence of drugs or
alcohol.
17. DO NOT operate the Wheatgrass
Juicer if the Juicer Motor is very cold.
The temperature of the Juicer Motor
should be at least 45oF (7oC) before use.
18. The body and Juicer Motor may
become warm during use. This is normal.
DO NOT touch these parts while the
Wheatgrass Juicer is running or until they
cool afterwards.
19. WEAR EYE PROTECTION. Wear
safety glasses while operating the
Wheatgrass Juicer. Everyday eye
glasses are not safety glasses. Approved
safety glasses conform to ANSI-287.1
requirements and will have Z87 printed or
stamped on them.
IMPORTANT SAFETY RULES
SAVE THESE INSTRUCTIONS!
Refer to them often and use them to instruct others.
READ AND FULLY UNDERSTAND ALL INSTRUCTIONS
AND WARNINGS PRIOR TO USING THIS UNIT. YOUR
SAFETY IS MOST IMPORTANT! FAILURE TO COMPLY
WITH PROCEDURES AND SAFEGUARDS MAY RESULT
IN SERIOUS INJURY OR PROPERTY DAMAGE.
REMEMBER: YOUR PERSONAL SAFETY IS YOUR
RESPONSIBILITY!
HELPFUL HINTS
1. If you notice a decrease in juice output, the Screen may be clogged. You will need to
disassemble the Wheatgrass Juicer (see “Cleaning Instructions” section of this manual) and
clean the Screen before continuing.
2. See the “Using the Reverse Function” section of this manual for information on clearing a
jam.
3. Spray the Drive Shaft of the Motor Body with a food-grade silicone spray after every
cleaning.
NEVER operate Wheatgrass Juicer unless it is
fully and properly assembled.
To avoid serious or fatal injury, NEVER reach into any inlet or outlet.
ONLY USE the Stomper to push wheatgrass into the Head.
Read and understand all information in this manual before use.
WARNING!

-4-
GROUNDING
This appliance must be grounded to protect the
operator from electric shock during use. For this
purpose, it is equipped with a three-conductor power
cord and three-prong grounding-type plug (Figure
A). The plug only ts three-hole electric receptacles.
For the plug to t a two-hole receptacle, you will
need a Grounding Plug Adapter with a wire or metal
tab (Figure B). Connect the wire/tab to the electrical
outlet with the cover plate screw. The screw must
be metal. The electrical box must be properly
grounded (Figure C).
EXTENSION CORDS
When using an extension cord with this appliance,
only use a three-wire extension cord with a
three-prong grounding-type plug and three-pole
connector. The extension cord must have an
electrical rating equal to or greater than that of the
appliance. Do not use a damaged extension cord.
Examine the cord before each use and replace it if
necessary. Do not abuse an extension cord. Pull
on the plug, not the cord, to disconnect it. Keep
the extension cord away from hot surfaces and
sharp edges.
GROUNDING INSTRUCTIONS
CIRCUIT BREAKER INSTRUCTIONS
The Wheatgrass Juicer is equipped with a
Circuit Breaker to protect it from damage due
to overload or short circuit. If the Wheatgrass
Juicer should unexpectedly stop running, take
the following steps to get it running again.
1. Turn the Power Switch to the “OFF”
position.
2. Check for possible reasons for the overload,
ie. a jam in the machine or incorrect assembly.
3. Press the Circuit Breaker Reset Button (Figure 1).
4. Turn the Wheatgrass Juicer back on and resume juicing.
5. Resume normal operation.
If the Wheatgrass Juicer still does not run, check the household circuit breaker to see if it
has tripped and/or try connecting the Power Cord to a different electrical outlet. If these steps
don’t work or if the Circuit Breaker repeatedly trips, turn the unit off and disconnect it from the
electrical outlet. DO NOT continue to try running the Wheatgrass Juice or unit damage
may occur. Contact Pragotrade at the number on the back of this manual for information on unit
repair or replacement.
Figure A
3 prong
grounding-
type plug
Figure C
Metal
Grounding
Screw
Cover of
Grounded
Outlet Box
Figure B
Grounding
Plug
Aadaptor
Metal tab or
wire
-9-
ALLOW MOTOR TO
COMPLETELY STOP
BEFORE ENGAGING IN
FORWARD OR REVERSE.
READ & FULLY UNDERSTAND
ALL INSTRUCTIONSAND
WARNINGS PRIORTO
USING THIS UNIT.
Figure 1
Circuit Breaker
Reset Button
NOTICE: DO NOT run the Wheatgrass
Juicer in reverse for more than 3 seconds
at a time. Unit damage may occur.
Use the Reverse Function to improve
ow through the Wheatgrass Juicer when
necessary. Briey engage “Reverse” to help
clear a jam, for example.
1. Turn the Power Switch to the “OFF” position.
2. Wait until the Juicer Motor comes to a
complete stop.
3. Briey hold the Power Switch in the “Reverse” position (Figure 8). DO NOT hold the Power
Switch in “Reverse” for more than about 3 seconds. Unit damage may occur.
4. The Power Switch will automatically return to “OFF” once released from the “Reverse”
position.
If juice ow does not improve after engaging “Reverse” , disassemble, clear the jam and
clean the Screen holes before resuming operation.
USING THE REVERSE FUNCTION
WASTE VALVE SETTINGS
To extract the maximum amount
of juice from wheatgrass, we
recommend you fully close the
Waste Valve (Figure 7). A different
setting may result in more juice,
though. Experiment by adjusting the
Waste Valve in and out. Be careful
not to remove the Waste Valve while
the Wheatgrass Juicer is running.
ALLOW MOTOR TO
COMPLETELY STOP
BEFORE ENGAGING IN
FORWARD OR REVERSE.
READ & FULLY UNDERSTAND
ALL INSTRUCTIONSAND
WARNINGS PRIORTO
USING THIS UNIT.
NEVER operate Wheatgrass Juicer unless it is
fully and properly assembled.
To avoid serious or fatal injury, NEVER reach into any inlet or outlet.
ONLY USE the Stomper to push wheatgrass into the Head.
Read and understand all information in this manual before use.
WARNING!
WARNING! Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
Power
Switch
Figure 8
Figure 7
Waste
Valve

-5--8-
Clean and sanitize the Wheatgrass Juicer as indicated in the “Cleaning Instructions”
section of this manual before using it for the rst time.
DO NOT IMMERSE THE JUICER MOTOR IN WATER OR OTHER LIQUIDS.
PRIOR TO USE
DISASSEMBLY INSTRUCTIONS
1. Turn the Wheatgrass Juicer to the “OFF” Position. Disconnect the Power Cord on the
Juicer Motor from the electric outlet.
2. Loosen the Head Aligning Cap (on the Head) by turning it clockwise. DO NOT REMOVE
the Head Aligning Cap at this time. Use the Head Aligning Cap Wrench if necessary.
3. Loosen the Head Locking Screw on the Juicer Motor until it releases the Head Assembly.
4. Remove the Head Assembly from the Juicer Motor.
5. Unscrew the Head Aligning Cap from the Head by turning it clockwise.
6. Unscrew the Waste Valve from the Head Aligning Cap by turning it clockwise.
7. Remove the Rubber Gasket from the Head Aligning Cap.
8. Remove the Auger and Screen from the Head.
9. Allow the parts to air-dry before reassembling and storing the Wheatgrass Juicer.
10. The Wheatgrass Juicer is NOT dishwasher safe.
WARNING! Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
CLEANING INSTRUCTIONS
JUICER MOTOR
1. Make sure the Power Cord on the Juicer Motor is disconnected from the electric outlet.
2. Clean the Juicer Motor by wiping it with a damp cloth. NEVER immerse the
Juicer Motor in water or other liquid. DO NOT spray the Juicer Motor with water.
3. Dry the Juicer Motor before storing it.
HEAD ASSEMBLY, STOMPER & HEAD ALIGNING CAP WRENCH
1. Fill a sink with hot water. Maintain a water temperature of at least 140oF (60oC) throughout
the washing process.
2. Add a manual dishwashing detergent formulated for commercial use to the water per the
manufacturer’s instructions.
3. Place all parts to be washed in a sink.
4. Thoroughly wash all parts with a sponge or dishcloth. Be sure to fully remove any food
residue from each part.
WARNING! Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
OPERATING INSTRUCTIONS
1. Place a cup under the outlet on
the bottom of the Head to collect juice.
Place a cup or container under the
Waste Valve to collect pulp (Figure 6).
2. Fill the Head with
wheatgrass.
3. Make sure the Power
Switch is in the “OFF”
position. Connect the
Power Cord on the Juicer
Motor to an electrical outlet.
4. Turn the Wheatgrass
Juicer “ON” by pushing
the Power Switch to the
“Forward” position.
5. Use the Stomper to push
wheatgrass into the Head. DO
NOT use your ngers to push
wheatgrass into the Head!
6. Add wheatgrass to the Head as
needed to keep juice owing. Always
be careful. Keep your ngers clear
of the Head Opening.
7. Turn the Wheatgrass Juicer
“OFF” and disconnect the Power
Cord from the electrical outlet when
you are done.
NEVER operate Wheatgrass Juicer unless it is
fully and properly assembled.
To avoid serious or fatal injury, NEVER reach into any inlet or outlet.
ONLY USE the Stomper to push wheatgrass into the Head.
Read and understand all information in this manual before use.
WARNING!
WARNING! Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
Figure 6
Head
Opening
KEEP FINGERS
CLEAR!
Waste
Valve
Juice
Outlet
Power
Switch

-7--6-
Figure 5
Head
Locking
Screw
ASSEMBLY INSTRUCTIONS
1. Slide the Screen (curved side
down) into the slot on the inside bottom
of the Head until it stops. Make sure
both sides of the Screen are within the
slot (Figure 2).
2. Place the Auger Bearing onto the
splined end of the Auger. Insert the the
Auger into the open end
of the Head until it stops.
The splines on the end of
the Auger should protrude
from the opposite end of the
Head (Figure 3).
3. Place the Rubber
Gasket onto the at surface
on the inside of the Head
Aligning Cap below the
threads. The Rubber
Gasket is properly installed
when it lays at on the
surface (Figure 4).
4. Screw the Head Aligning Cap
counterclockwise onto the Head until it
is rmly seated.
5. Screw the Waste Valve
counterclockwise into the tip of the
Head Aligning Cap until it stops.
7. Loosen the Head Locking Screw
on the Juicer Motor until it no longer
protrudes into the receptacle for the
Head Assembly (Figure 4).
8. Install the Head Assembly onto the
Juicer Motor. You will need to align the
cutout on the Head with the pin inside
Figure 2
Figure 3
Slot
WARNING! Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
Head
Screen
Head
Auger
Bearing
Auger
Rubber
Gasket
Head
Aligning
Cap
Waste
Valve
Auger
Splines
Figure 4
CAUTION:
Make sure Screen
is properly seated
in the slot before
operation or unit
damage will occur.
Pin Inside
Receptacle
Cutout
In Head
5. After washing, drain the sink and rell it with warm water.
6. Rinse the parts by submerging them in water. Change the water and repeat, if necessary, to
remove all of the detergent.
7. When done rinsing, drain the sink and rell it with a sanitizing solution of water and chlorine
bleach (use 1 ounce of chlorine bleach per 4 gallons of water). Soak the parts in the solution for
a minimum of 5 minutes.
8. Remove the parts from the sink.
9. Allow the parts to air-dry before reassembling and storing the Wheatgrass Juicer.
NOTE! The Wheatgrass Juicer is NOT dishwasher safe.
the receptacle (Figure 5). Align the
Auger Splines with the keyways
on the drive shaft of the Juicer
Motor. If the parts do not align,
rotate the Auger end (it protrudes
from the Head) a bit and try again.
Wiggling the Head Assembly
during installation may help as well.
IMPORTANT: Tighten the Head
Locking Screw until it rmly holds
the Head Assembly in place.
CAUTION!: DO NOT operate the
Wheatgrass Juicer without the
Head Assembly rmly secured
into place. Personal injury or unit
damage may occur.
NEVER operate Wheatgrass Juicer unless it is
fully and properly assembled.
To avoid serious or fatal injury, NEVER reach into any inlet or outlet.
ONLY USE the Stomper to push wheatgrass into the Head.
Read and understand all information in this manual before use.
WARNING!
