-6- -11-
1. Hold the Chute with the outlet tilted almost
fully downward and the head ring facing the Motor
(gure 1).
2. Place the head ring of the Chute over the round
raised face on the front of the Motor. Position
the tabs on the head ring next to the slots in the
corresponding tabs extending from the round face
(gure 2).
3. Rotate the Plastic Chute counterclockwise
until the tabs t into the slots. The Plastic Chute
should now be rmly held in place. When properly
positioned, the outlet of the Chute should dip
slightly downward.
4. Assemble the round end of the Drive Shaft
with a Metal Washer, Spring, Metal Washer,
Plastic Bushing and the Beveled Rubber
Washer. (gure 3). NOTE: The Beveled
Rubber Washer has two sides, a at side and the
beveled side. The beveled side ts onto the top of
the Plastic Bushing like a cap (gure 3b).
5. Insert the square end of the Drive Shaft into the
corresponding slot in the Auger (gure 4).
6. Insert the Auger/Drive Shaft Assembly into
the Head.
7. Position the Screen over the Auger. Line
up the tabs on the Screen with the notches in the
Head. Hold the Screen in place.
8. Slide the Front Ring Nut over the Screen
assembly and turn clockwise to rmly tighten
(make sure the tabs on the Screen remain aligned
with the notches on the Head). DO NOT over-
tighten the Front Ring Nut to avoid damaging the
Motor during operation.
ASSEMBLY
Figure 2
Chute
Round, raised face on
the front of Motor
Tabs on
Motor
WARNING! Before cleaning, assembling or disassembling the Tomato Strainer,
make sure it is turned off “O” and disconnected from the power source. Test to make
sure there is no power to the Motor by switching the Motor on “-” and off “O”.
Figure 1
Chute
Motor
Head
Ring
Figure 3
Drive Shaft Assembly
Figure 4
Drive Shaft
Assembly
Front
Ring Nut
Screen Auger
Head
LARGE BATCH ITALIAN TOMATO SAUCE
1/2 cup olive oil 3 medium onions, chopped 2 cloves garlic, minced
3 Tbsp brown sugar 1 Tbsp dried oregano 4 tsp salt
2 tsp dried basil 1 tsp black pepper 12 cups fresh tomato puree
• Heat the olive oil in a large pan
• Sauté the onions and garlic until tender, do not overly brown
• Add the rest of the ingredients
• Bring mixture to a boil, reduce heat and simmer partially covered for 2 hours or until
sauce has reduced to desired consistency
• Stir occasionally
• Serve or allow to cool then refrigerate or freeze
• Ingredients like sliced mushrooms, cooked/drained sausage, hamburger,
etc. can be added to taste
VEGETABLE JUICE
8 qt fresh tomatoes 8 stalks celery 1/4 cup parsley
3 small onions, nely chopped 1 lemon, juiced
1 leek, only the white part, nely chopped 1/2 tsp allspice
1 Tbsp Worcestershire sauce 1 Tbsp salt
1 cup carrots, nely chopped black pepper, to taste
1 cup green pepper, nely chopped hot sauce, optional
• Put tomato pieces along with nely chopped: celery (stalk and leaves), onion, leek,
carrot and green pepper along with lemon juice into a large, non-aluminum, pot
• Cook over medium heat for 30 minutes until vegetables are soft
• Once the mixture has cooled, process through the Tomato Strainer using the
Standard Screen
• Season with: salt, allspice, Worcestershire sauce and pepper (add hot sauce now if
desired)
• Serve chilled
QUICK APPLESAUCE
3 Tbsp butter 6 Macintosh apples 1/4 cup sugar
1 tsp cinnamon 1/2 tsp nutmeg 4 tbsp water
• Steam apples in a covered pot for approximately 15 minutes or until soft
• Allow apples to cool, then run through the Tomato Strainer using the
Standard Screen
• Mix the remainder of the ingredients with the apple puree and chill
• For variety, try different apples or mix them with different apples
DELICIOUS AND HEALTHY APPLE CRISP
2-1/2 cups granola 2 Cups “Quick Applesauce”
3-1/2 Tbsp brown sugar 1-1/2 Tbsp butter 1-1/2 tsp cinnamon
whipped cream
• First make 2 cups of Quick Applesauce using the above recipe
• In a buttered baking dish alternate layers of granola with the Quick Applesauce
• End with a layer of granola
• Sprinkle with the cinnamon and brown sugar
• Spread the butter around in small pieces
• Bake in oven at 350°F (176°C) for 20 minutes
• Top off with whipped cream
Figure 3b
Plastic
Bushing
Beveled
Rubber
Washer
