Whale SH2201 Assembly Instructions

Thank you for purchasing this Whale® product.
For over 70 years Whale® has led the way in the design and manufacture of water and waste systems including:-
plumbing, faucets, showers, pumps and heating for mobile applications. Today’s range features space and water
heaters for caravans and motorhomes. The company and its products have built a reputation for quality, reliability and
innovation backed up by excellent customer service.
For information on our full product range visit: www.whalepumps.com
CONTENTS
1. Principles of Operation
2. Specification
3. Application
4. Warnings
5. Parts List
6. Instructions for Installation
7. Instructions for Use
8. Maintenance
9. Trouble Shooting
10. Winterising
11. Service Support Details
12. EU Declaration of Conformity
13. Patents and Trademarks
14. Warranty
15. Appendix - Identifying Flue Type
L ST OF MAGES
Fig. 1 Components Drawing
Fig. 2 Installation in Vehicle SH2201/SC2201/SH2202/SC2202
Fig. 3 Installation Under Vehicle SH2211/SC2211
Fig. 4 Dimensions– Internal Side View SH2201/SC2201
Fig. 5 Dimensions– Internal Plan View SH2201/SC2201
Fig. 6 Dimensions– Internal Front View SH2201/SC2201
Fig. 7 Dimensions– Internal Side View SH2202/SC2202
Fig. 8 Dimensions– Internal Plan View SH2202/SC2202
Fig. 9 Dimensions– Internal Front View SH2202/SC2202
Fig. 10 Dimensions– External (Underfloor) Plan View SH2211/SC2211
Fig. 11 Dimensions– External (Underfloor) Side View SH2211/SC2211
Fig. 12 Dimensions– External (Underfloor) Front View SH2211/SC2211
Fig. 13 Flue Locating Diagram
Fig. 14 Attaching Flues
Fig. 15 Space Heater Locating
Fig. 16 Installation and Securing the Space Heater
Fig. 17 Securing the Space Heater (Plan View)
Fig. 18 Attaching Underfloor Space Heater
Fig. 19 Attaching the Flues
Fig. 20 Secure the Flue Brackets
Fig. 21 Connect to as Supply - Internal Installation
Fig. 22 Connect as Supply - External (Underfloor) Installation
Fig. 23 Internal Installation - Connect to Hot Air Duct
Gas Only or Gas & Electric
Space Heater Mk
nternal Models: SH2201, SC2201, SH2202 or SC2202
Underfloor Models: SH2211 or SC2211
1
NSTALLAT ON & USER NSTRUCT ONS
Fig. 24 External (Underfloor) Installation - Connect to Hot Air Duct
Fig. 25 T Fitting Orientation
Fig. 26 Internal Installation - Connect to Cold Air Duct
Fig. 27 External Installation - Connect to Cold Air Duct
Fig. 28 Insert Control Panel
Fig. 29 Secure Control Panel
Fig. 30 Installed Control Panel
Fig. 31 Internal Installation - Connect 12V d.c.
Fig. 32 External (Underfloor) Installation - Connect 12V d.c.
Fig. 33 Mains Electrical Connection
Fig. 34 Mains Connection
Fig. 35 Completed Installation - Internal
Fig. 36 Completed Installation - External
Fig. 37 Whale Control Panel
Fig. 38 Whale Duo Control Panel
Fig. 39 Whale iVan Control Panel
Fig. 40 Reset Button Location
Fig. 41 Flue Type - For Standard Installation C53
Fig. 42 Flue Type - For Vehicle In Motion C13
EN
All work must be carried out by a competent person as defined by
BS7671 PART2.
All Whale gas products must be installed by a Qualified Gas Engineer in
accordance with the installation instructions and BS EN 1949-2011.
Please note if incorrectly installed a risk of electrocution exists.

This Whale® Space Heater Mk II is either a gas or gas & electric blown air Space Heater. Nominal heat output is
2kW on gas. The compact design provides versatility in installation locations and requires minimal maintenance. The
vehicle’s internal temperature is set by a Control Panel which can be manually adjusted to a wide range of
temperature settings or for warm weather ventilation. Key enhancements to the Mk II design are improved insulation,
improved service access and a lighter, more compact design.
Read the following carefully before installation
Model: SH2201 or SC2201 (inside vehicle) Maximum dimensions: Height: 230mm, Width: 157mm, Length: 634mm
SH2211 or SC2211 (underfloor) Maximum dimensions: Height: 121mm, Width: 290mm, Length: 714mm
SH2202 or SC2202 (inside vehicle) Maximum dimensions: Height: 230mm, Width: 157mm, Length: 634mm
Countries of Destination: AT, BE, B , CH, CY, CZ, DE, DK, EE, ES, FI, FR, B, R, HU, HR, IE, IS, IT, LT, LU, LV,
MT, NL, NO, PT, SE, SI, SK, TR
Weight: SH2201 or SC2201 5.7kg
SH2211 or SC2211 5.8kg
SH2202 or SC2202 7.8kg
as: Butane 28-30mbar - CAT I3+ (28-30/37), Butane/Propane 30mbar - CAT I3B/P (30)
Propane 37mbar - CAT I3p (37)
as Consumption (M) 150g/h
Please note: For use in road vehicles (caravans and motorhomes) only.
Classification of Heater: Type: C53 (Fanned) Normal Installation
C13 Vehicle In Motion Installation
Nominal Heat Input: as 2.0kW
Nominal Heat Input: Electric 2.0kW
Battery Supply Electric Supply
Nominal voltage: 12V d.c. Nominal voltage: 230V a.c. 50 Hz
Operating range: 10.0V d.c. min. to 15V d.c. max. Operating range: 500W / 1000W / 2000W. max.
Maximum current d.c. gas operation: 2.5 Amps Maximum current a.c.: 9 Amps
(0.01 Amps on standby)
Dry Storage Temperature: -20°C to 70°C
Hot Air Duct Diameter: 60mm ID
Flue Diameter: 22mm ID
Maximum Exhaust Flue Length: 2m
Minimum Exhaust Flue Length: 1.25m
Maximum Combustion Air Flue Length: 2m
Minimum Combustion Air Flue Length: 1.25m
The Space Heater position must allow access for servicing and there must be a minimum of 25mm distance around
the Space Heater to adjacent walls when mounted inside the vehicle.
For use in road vehicles only i.e. caravans and motorhomes. Not suitable for use in caravan holiday homes i.e.
mobile homes or static caravans.Whale’s policy is one of continuous improvement and we reserve the right to
change specifications without prior notice.
2. SPEC F CAT ON
1. PR NC PLES OF OPERAT ON
2

The Whale® Space Heater has been designed for caravan, motorhome and mobile applications, and is suitable for
typical recreational vehicle use. It is only suitable for use in road vehicles, i.e. caravans and motorhomes, but is not
suitable for caravan holiday homes i.e mobile homes or static caravans. The Whale® Space Heater is designed to be
installed in conjunction with a ducted hot air system and must not be used in conjunction with any other system.
If the Space Heater is to be used in motion, the Vehicle in Motion Kit must be fitted. This is an accessory to the
Whale® Space Heater and must be fitted to allow use in motion. If the Vehicle in Motion Kit is not fitted, you must
not operate the appliance while the vehicle is in motion. Please see Appendix for information on identifying flue type.
For more information on this kit, contact Whale® Support.
This symbol indicates that this appliance is suitable for use in Leisure Accommodation Vehicles.
This symbol indicates that this appliance is not suitable for use in boats.
Observe all warnings.
In the unlikely event of leaks in the gas system, or if there is a smell of gas:
• Extinguish all naked flames
• Switch off all appliances and do not operate any electrical switches
• Turn off all gas appliances
• Open windows and doors for ventilation
• Do not smoke
• Shut off gas connection
Immediately ensure that the system is thoroughly checked by a registered gas engineer at a Whale® Approved
Service Centre or by a member of the Whale Service Engineer Network.
The Space Heater must not be operated in the following situations:
• When refuelling the vehicle or refuelling the vehicle towing the caravan or refuelling any other
appliances.
• When the vehicle in which the Space Heater is installed is in a confined space (such as a garage).
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children must be supervised to ensure that they do not play with the appliance.
A minimum of one of the hot air outlet vents must be permanently open. This hot air vent must be the vent located
the furthest distance from the Space Heater.
Any alteration to the appliance, including flue components, use of non-Whale® spare parts/accessories and
non-observation of the installation and operation instructions will lead to cancellation of the warranty and exclusion of
liability claims and results in it becoming illegal to use the appliance.
Please note: Incorrect installation, misuse or use of non original Whale® parts may invalidate the warranty. It also
becomes illegal to use the appliance if incorrectly installed, and in some countries may make it illegal to use the
vehicle.
When operating the Space Heater using gas, the combustion air inlet flue and exhaust flue must never be
obstructed. They must be checked regularly, and if necessary cleaned by the user (e.g. in winter, snow must be
removed from the combustion outlet and air intake).
Where the open end of the exhaust flue terminates, three sides of the Underfloor Space Heater must be kept open
and not obstructed, and not contain through-floor ventilation openings.
3. APPL CAT ON
3
4. WARN NGS

The Space Heater, its gas supply, and flues for the products of combustion must be inspected in accordance with
national regulations or if these do not exist, the Space Heater manufacturer’s recommendations. Whale advises that
this must be carried out at least annually.
Please note: The Space Heater and Ducts will become hot. Avoid anything directly touching the Space Heater
or Ducts.
The Whale® Space Heater kit contains:
Please note: The Whale® Space Heater requires a separate Flue Kit for installation.
Exhaust Flues are available in lengths of 1.25 metres and 2 metres.
Inlet Flues are available in lengths of 1.25 metres and 2 metres.
5. PARTS L ST
4
SH2201 or
SC2201
SH2211 or
SC2211
SH2202 or
SC2202
Space Heater and 4 screws 1 1
Space Heater and 10 screws 1
Control Panel / Room Thermostat and 4 screws. Not SC models. 1 1
3.5m Control Panel cable (retail only) 1 1
Warranty Registration card 1 1 1
Instruction manual including installation templates 1 1 1
Instruction manual storage pocket, with adhesive fixing strip 1 1
Overheat Stat Insulation
Electric Overheat Thermostat
as Overheat Thermostat
Heat Exchange Case Cover
as Heat Exchange
Heat Exchange askets
Burner askets
Burner
Electrodes Case Lid
as Injector
as Train
Sealing Washer
End Plate asket
End Plate
End Plate
Connector
Olive
Nut
Outer Box
Interface Box
Fan Combustion Air
Motor asket
Air Flow Sensor
Fan Housing
Fan Hot Air
Motor Mounting Plate
Motor
Fan Housing asket
Heat Exchanger Case
PCB
Insulation
Electric Assembly
Element Mounting Plate
Element Cover Plate
Fig. 1 Components Drawing

The Whale® Space Heater can be installed either inside the vehicle, Part Number: SH2201 or SC2201 and SH2202
or SC2202 (as in Fig. 2) or under the floor, Part Number: SH2211 or SC2211 (as in Fig. 3).
Fig. 2 Internal Installation - SH2201, SC2201, SH2202 or SC2202
Fig. 3 External Installation - SH2211 or SC2211
To the Fitter:
Installation and servicing of this appliance must only be carried out by competent persons registered with the as
Safe Register ( B) or the relevant national organisation, in accordance with the relevant regulatory and safety
requirements.
Before installation, you must ensure that the appliance has been supplied in good condition and if damaged do not
install.
A competent person must install the appliance in accordance with the appliance installation instructions. This
appliance is for use with LP (see appliance data plate) and mains electric. Please check that the product is suitable
for the intended application. In particular, the installer must check the compatibility of the data plate information with
the LP supply requirements of the vehicle.
Follow these installation instructions and ensure that all relevant personnel read the points listed below. Also ensure
that these operating instructions are passed on to the end user.
Please note: The appliance must be installed in accordance with any relevant regulations in the country where the
appliance is installed. For this appliance in Europe, the standard is BS EN 1949:2011 “Specification for the
Installation of LP Systems for Habitation Purposes in Leisure Accommodation Vehicles and in Other Road
Vehicles”.
Ventilation must comply with relevant national and/or local requirements.
5
6. NSTRUCT ONS FOR NSTALLAT ON
Exterior Wall
Hot Air Outlet Duct
Vehicle Floor
Interior Wall
Exhaust Flue
Combustion Air Inlet
as Pipe
Space Heater
Space Heater
as Pipe
Combustion Air Inlet
Exhaust Flue
Cold Air Inlet
Hot Air Outlet
Vehicle Floor
Reset Button (Red)

6
D MENS ONS
nternal installation - SH2201 or SC2201
Fig. 4 Internal Installation - Side View - SH2201 / SC2201
Fig. 6 Internal Installation - Front View - SH2201 / SC2201
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Space Heater
as In
270mm
257mm
226mm
Cold Air Inlet
Exhaust Flue Combustion Air Inlet
Cold Air Inlet
Hot Air Outlet
157mm
78mm
46mm
Reset Button
Reset Button (Red)
610mm
634mm
121mm
137mm
141mm
Fig. 5 Internal Installation - Plan View - SH2201 / SC2201

D MENS ONS
nternal installation - SH2202 or SC2202
Fig. 7 Internal Installation - Side View - SH2202 / SC2202
Fig. 8 Internal Installation - Plan View - SH2202 / SC2202
Fig. 9 Internal Installation - Front View - SH2202 / SC2202
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Space Heater
as In
270mm
257mm 226mm
Cold Air Inlet
121mm
134mm
430mm
454mm
Exhaust Flue Combustion Air Inlet
Cold Air Inlet
Hot Air Outlet
157mm
78mm
46mm
Reset Button
7

D MENS ONS
External (underfloor) installation - SH2211 or SC2211
Fig. 10 External (Underfloor) Installation - Plan View - SH2211 / SC2211
Fig. 11 External (Underfloor) Installation - Side View - SH2211 / SC2211
Fig. 12 External (Underfloor) Installation - Front View - SH2211 / SC2211
8
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
as In
531mm
180mm
171mm
76mm
121mm
Exhaust Flue
Combustion Air Inlet
Hot Air Outlet
25mm
65mm
Exhaust Flue
Combustion Air Inlet
Hot Air Outlet
Cold Air Inlet
226mm
261mm
288mm
Reset Button

Step 1 Find Suitable Location For Space Heater nstallation
Consider the following points:
i. For weight distribution in caravans, position the Space Heater as close to the axle as possible. You
must avoid locating the Space Heater at the very rear or very front of the vehicle.
ii. If mounting under the floor, the Space Heater must be positioned within the chassis members and
close to the axle to help protect the appliance.
iii. Please note: The Space Heater, ducts and flues will become hot. Avoid anything directly touching
these.
iv. Ensure that the position of the Space Heater allows access for servicing and that there is a minimum
of 25mm distance around the Space Heater to adjacent walls.
v. The hot air outlet of the Space Heater must be fitted to the hot air ducting system. The Space
Heater must be positioned to minimise the amount of ducting required. Sharp bends in the ducting
must be avoided.
vi. In selecting the position of the Space Heater, ensure that the exhaust flue and combustion air inlet
flue can be installed avoiding all chassis members and gas pipes etc. that are located underneath
the floor. For SH2202 and SH2201, use flue template supplied.
vii. The open end of the exhaust flue must not be fitted at the side of the caravan / motorhome where
an awning may be fitted. It is recommended that the Space Heater is installed on the opposite side of
the caravan / motorhome to avoid routing the exhaust flue to the far side of the caravan/motorhome.
viii. Only Whale® supplied flue components are permitted to be used. The open end of either flue must
not be positioned within 500mm of a refuelling point or fuel tank breather outlet or any ventilator from
the fuel system(s). The exhaust flue must not be fitted within 300mm of a ventilator for the living
space or an opening part of a window. The open end of the exhaust flue must be positioned at least
500mm from the open end of the combustion air intake flue and be pointing in the same direction.
The exhaust flue must be positioned at the side or end of the caravan / motorhome. The exhaust
flue must only be positioned vertically below an opening part of a window if the appliance is fitted
with an automatic shut-off device to prevent operation when the window is open.
Fig. 13 Flue Locating Diagram
ix. The combustion air inlet flue can be terminated underneath the vehicle. The open end of it must be
at least 500mm away from the open end of the exhaust flue, and pointing in the same direction.
Care must be taken to ensure that both flues have a slight downward slope from as close to the
Space Heater as possible to prevent any possibility of water traps. Ensure that neither the exhaust
nor the combustion air inlet flues are terminated in an underfloor box section.
x. The minimum length of the exhaust flue is 1.25 metres, and the maximum length is 2 metres.
The minimum length of the combustion air inlet flue inlet must be 1.25 metres, and the maximum
length is 2 metres.
xi. When operating the Space Heater using gas, the combustion air inlet flue and outlet openings for
the products of combustion (exhaust flue) must never be obstructed. They must be checked
regularly, and if necessary cleaned by the user (e.g. in winter, snow must be removed from the
combustion flue outlet and combustion air inlet flue).
9
Fuel refuelling / breather vent
PLEASE NOTE: Step i to xv
for information on Space
Heater and Flue Locations.
KEY
Prohibited area
for Space Heater flue
Min 500mm

xii. Where the open end of the exhaust flue terminates, three sides of the underfloor space must be
kept open and not obstructed, and must not contain through-floor ventilation openings.
xiii. The Space Heater, its gas supply, ducting and flues must be inspected in accordance with national
regulations or if these do not exist, the Space Heater manufacturer’s recommendations. Whale
advises that this must be carried out at least every year.
xiv. The Space Heater must not be used when the vehicle is in motion (unless a vehicle in motion kit is
fitted - see Appendix).
xv. The user must have access to the reset button, if applicable.
f installing under the floor of the vehicle, please skip Steps 2 and 3.
Step 2 nternal nstallation - Cut Out Holes for Exhaust and Combustion Air Flues
Position the Flue Template on the floor where the Space Heater is to be mounted. Mark the position of the two holes
for the combustion air inlet and exhaust flues, then drill holes with a 51mm (2”) minimum diameter hole saw.
Push on the ends of the flues with the blue adaptor to the pipes on the underside of the Space Heater ensuring that
they are fully pushed on, and secure with the supplied hose clips.
Fig. 14 Attaching the Flues
Step 3 nternal nstallation - Attach Space Heater to The Floor
From inside the vehicle, feed the exhaust and combustion air flues through the holes drilled on the floor.
Locate the Space Heater so that the flues are centralised in the holes. Attach the Space Heater to the floor with 4
screws supplied (No. 8 x ¾”), as shown in Figs. 15 & 16.
Fig. 15 Locating the Space Heater
10
Space Heater
as In
Combustion Air Inlet
Exhaust Outlet
Combustion Air Inlet Flue
Exhaust Flue
Hot Air Outlet
Cold Air Inlet
Hot Air Outlet
as In
Space Heater
Vehicle Floor
Exhaust Flue
Combustion Air Inlet Flue

Fig. 16 Installation and Securing the Space Heater
For internal installation, please proceed to Step 6.
Step 4 Underfloor nstallation - Underfloor Heater Location
For underfloor installation, the floor of the vehicle must be manufactured as per Fig. 18. Wooden batons must be
incorporated in the floor’s construction to secure the screws into.
Locate the Space Heater in position so that the screws will enter the wooden batons, and attach the Space Heater
with the 10 screws (No. 8 x 5⁄8”) provided.
Fig. 17 Securing the Space Heater (Plan View)
Fig. 18 Attaching the Underfloor Space Heater
Vehicle Floor
Cut out in Floor
Space Heater
as In
Vehicle Wall
11
as In
Screw Hole
Vehicle Floor Screw Hole
Hot Air Outlet
Cold Air Inlet
Wooden Batons
built into floor
96mm
Cut out in floor
R51mm x 2

Step 5 Underfloor nstallation Only - Securing The Flues
Push on the ends of the flues with the blue adaptor to the pipes on the side of the Space Heater, ensuring that they
are fully pushed on, and secure with the supplied hose clips (see Fig. 19).
Fig. 19 Attaching the Flues
Step 6 nternal and Underfloor nstallation - Mounting The Flues
When mounting the combustion air inlet and exhaust flue, they must run downwards from the Space Heater to the
open end to allow any condensation to drain out. The open ends must be angled downwards to prevent rain from
entering. Care must be taken to route exhaust flues around chassis members and to avoid gas pipes and wires.
The flues must otherwise be kept as straight as possible.
Please note: The exhaust flue must be positioned at the side or the rear end of the vehicle. The open end of the
combustion air inlet flue must be at least 500mm away from the open end of the exhaust flue and pointing in the
same direction.
The combustion air inlet flue is attached to the underside of the floor with two of the brackets (supplied).
The remaining two brackets (supplied) are used to attach to the exhaust flue. Clip the bracket around the flue and
use the two screws (No.8 x ¾”) to attach each bracket to the floor (as per Fig. 20).
Fig. 20 Securing the Flue Brackets
Step 7 nternal and Underfloor nstallation - Connect to Gas Supply
The appliance must be installed by a competent person in accordance with the installation instructions and comply
with any relevant regulations in the country where the appliance is installed.
The Space Heater is supplied with a compression nut and olive for 8mm (5⁄16”) pipe. The supply pipe must be
checked and must be free from dirt or other particles before connecting to the compression joint on the Space
Heater. The supply pipe must be routed so that the appliance can be removed for servicing.
A gas shut off valve must be located in the vicinity of the Space Heater and all connections must be kept to a
minimum.
12
as In
Space Heater
Flue
Flue
Combustion Air Inlet
Exhaust Outlet
Hose Clip
Hose Clip
Screw Hole
Screw Hole
Bracket
Flue

A as Pressure Test Point must be fitted to the inlet of the appliance.
When the gas line is complete, all joints must be tested for leaks using Leak Detection Solution.
N.B. Never with a naked flame.
The gas pressure must be verified at the pressure test point.
Please note: The operating pressure for the gas supply must be either 28-30mBar Butane or 30mBar-37mBar
Propane.
Fig. 21 Internal Installation - Connect to Gas Supply
Fig. 22 Underfloor Installation - Connect to Gas Supply
Step 8 nternal and Underfloor nstallation - Fitting Hot Air Ducts
To fit the ducting, push it onto the ‘hot air outlet’, where it will be gripped by the nozzle.
Fig. 23 Internal Installation - Connect to Hot Air Duct
If fitting the Space Heater underfloor, fit the air duct into the hot air outlet on the Space Heater as shown in Fig. 24.
Fig. 24 Underfloor Installation - Connect to Hot Air Duct
13
Space Heater
as In
as Pipe
Vehicle Floor
Hot Air Outlet
Cold Air Inlet
as In
as Pipe
Space Heater
Vehicle Floor
Hot Air Outlet
Cold Air Inlet
Ducting
Vehicle Floor
Vehicle Floor
Cold Air Inlet
Hot Air Outlet
Duct

mportant: At least one hot air outlet vent must be permanently open. The hot air duct must not be fed into the
centre branch of a T fitting (see Fig. 25).
Fig. 25a Incorrect Tee Fitting rientation Fig. 25b Correct Tee Fitting rientation
Step 9 nternal and Underfloor nstallation - Fitting Cold Air Supply
The Whale® Space Heater must be adequately supplied with cold air. If the Space Heater is installed in a bed box or
another confined space, vents into the area must be fitted or ducting used to supply the Space Heater with cold air.
If a vent is fitted, it must be no smaller than one designed for use with 60mm ducting. If ducting is fitted, it must
supply air from the living space of the vehicle. To fit the ducting, push it onto the cold air inlet at the Space Heater
where it will be gripped by the nozzle.
Fig. 26 Internal Installation - Connect to Cold Air Duct Fig. 27 Underfloor Installation
Step 10 nstalling Whale® Control Panel
When installing the Whale® Control Panel, find a suitable convenient and accessible position. For good temperature
control, select a position away from draughts and approximately 1.5 metres above the floor. Ensure suitable access
for wiring loom connection and cable. Note that the cable supplied with the retail Space Heater (models: SH2201,
SH2202, SH2211) to connect the Control Panel to the Space Heater is 3.5m long.
The minimum depth behind panel for wiring must be 40mm. If using a Control Panel specific to the manufacturer of
the vehicle, the electrical connections must be made in accordance with Step 11.
14
Tee Fitting
Tee Fitting
Hot Air Outlet Hot Air Outlet
Ducting
Ducting
Ducting
Ducting Ducting Ducting
Hot Air Duct
Cold Air Inlet
Cold Air Duct
Hot Air Duct
Cold Air Duct
Hot Air Outlet
Cold Air Inlet
Vehicle Floor
Hot Air
Hot Air
Hot Air
Hot Air
Hot Air
Hot Air Outlet

Option 1 - nstalling Whale Space Heater Control Panel
Option 2 - nstalling Whale Duo Control Panel
Option 3 - nstalling Whale iVan Control Panel
Option 4 - nstalling Vehicle Manufacturer Control Panel
Option 1 - nstalling Whale Space Heater Control Panel
The Whale Space Heater Control Panel requires a cut out 95mm wide x 42mm high. Feed the wires through the cut
out in the wall and locate into desired position. Secure with 4 screws (No.4 x 3⁄4”) provided, then clip on the surround
frame.
In some instances, it may be necessary to make the wiring connections in Step 9, before securing the Control Panel
to the wall.
Please note: It may be possible to retrofit the Whale® Control Panel into existing frames.
Fig. 28 Insert Control Panel Fig. 29 Secure Control Panel Fig. 30 Installed Control Panel
Option 2 - nstalling Whale Duo Control Panel
The Whale Duo Control Panel requires a cut out 118mm wide x 64mm high. Feed the wires through the cut out in the
wall and locate into desired position. Secure with 2 screws (No.4 x 3⁄4”) provided, then clip on the Surround Frame.
In some instances, it may be necessary to make the wiring connections in Step 9 before securing the Whale Duo
Control Panel to the wall.
Option 3 - nstalling Whale iVan Control Panel
When installing the Whale iVan®Control Panel, find a suitable convenient and accessible position.
For good temperature control, select a central position away from draughts, direct sunlight and approximately 1.5
metres above the floor. Ensure suitable access for connecting to the 12V d.c. supply. The minimum panel cut out
depth for the controller and wiring must be 15mm.
i. Position the supplied cutting template in the chosen location and temporarily secure with low tack adhesive.
Using a suitable 10mm drill bit, drill through the template and the panelling behind, in the four corners
marked on the template. Then cut out the rectangular shape by cutting along the dotted lines. Finally, drill the
4 screw holes with a 2mm drill bit. Discard the remains of the cutting template.
ii. Feed the wires through the newly cut hole, and position the controller so that the screw holes line up with
those that have been drilled. Secure in place with the 4 small screws supplied (No.6 × ⅝” pan head screws).
iii. Connect the positive and negative wires from the back of the controller into the vehicle’s electrical system
through a 1 Amp automotive fuse.
Please Note: The manufacturer cannot be held responsible for claims arising from incorrect installation, unauthorised
modification or misuse of this product.
Reconnect / turn on the power supply. The Control Panel should turn on. You will be asked to set the time.
Cut Out
Mounting
Frame
Surround Frame
15

To Set the Time:
Press and hold the Home Button to enter the ‘Setup and Options’ screen•
Touch ‘Set Clock’•
Adjust the time with the + and - keys, and select to adjust hours or minutes with the left and right arrows. •
Press the ‘Home’ button to return to the ‘Home’ screen.•
Connecting iVan®to the Heaters:
Turn on the Water Heater, Space Heater and Control Panel at the same time by using the master switch in the
vehicle. When the Water Heater, Space Heater and Control Panel are switched on (it is important that they turn on at
the same time), within a few seconds “A Water Heater has been found” and “A Space Heater has been found”
message will appear on the screen. Press OK both times and the Water and Space Heater will be paired to the
Control Panel.
Option 4 - nstalling Vehicle Manufacturer Control Panel
If your vehicle is fitted with an alternative control panel, please refer to your vehicle manufacturer’s handbook or
instructions supplied by the control panel manufacturer.
Step 11 Electrical Connections 12V d.c.
Vehicle Manufacturer nstallation
WARN NG: Always disconnect the appliance from the power supply prior to working on electrical components.
The Space Heater and both the Whale Space Heater Control Panel and the Whale Duo Control Panel come
complete with electrical connectors fitted.
The Whale® Space Heater and Control Panels are designed to be integrated into the caravan’s wiring loom. The
Space Heater is provided with a JST VL series 12 way socket, and the Control Panel with JST VL 6 and 3 way
sockets. 9 wires are required to connect the Space Heater to the Control Panel, and 12V d.c. and 0V d.c. power
supply must be connected to the 12 way socket at the Space Heater.
Please note: Whale recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply. It may be possible to
retrofit the Whale® Control Panel into existing frames.
16

Step 12 Electrical Connections 12V d.c.
Vehicle Manufacturer nstallation - Part Number: SH2211 or SC2211
WARN NG: Always disconnect the appliance from the power supply prior to working on electrical components.
The Space Heater and Control Panel come complete with electrical connectors fitted. The Whale® Space Heater and
Control Panel are designed to be integrated into the caravan’s wiring loom. The Space Heater is provided with a JST
VL series 12 way socket, and the Control Panel with JST VL 6 and 3 way sockets. 9 wires are required to connect
the Space Heater to the Control Panel. The 12V d.c. power supply (red wire) and 0V d.c. power supply (white wire)
are to be connected to the 12 way socket at the Space Heater (as shown in Table 1 and 2). Please note: Whale
recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
Table 1: Connections at Space Heater
Table 2: Connections at Control Panel
Retail nstallation - Part Number: SH2201 or SH2202
The Space Heater and Control Panel come with electrical connectors fitted.
Step 1
Connect the 12 way electrical connector with the unattached red and white leads to the 12 way connector on the
Space Heater.
Step 2
Route the wire to the Control Panel and connect the 6 way electrical connector to the 6 way connector on the Space
Heater.
Step 3
Route the 3 way electrical connector to the 3 way connector at the Control Panel.
Step 4
Secure the wire close to the Control Panel ensuring that there is no strain on the wires at the switches.
Step 5
Connect the free red lead coming from the 12 way connector to a 12V d.c. supply.
Connect the free white lead to the caravan 0V d.c. supply.
Please note: Whale recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
17
Terminal Number Description Wire Colour
1 Switch common Brown
2 0V to Switch panel Black
3 Fan Switch Yellow
4 Electric 1 Switch reen
5 Electric 2 Switch rey
6 Electric 3 Switch Pink
7 Burner Switch Blue
8 Burner LED Orange
9 Lockout LED Violet
10 12V supply Red
11 0V supply White
Connector Terminal
Number Description Wire Colour
6 Way
connector
1Switch common Brown
2Burner Switch Blue
3Fan Switch Yellow
40V to Switch panel Black
5Burner LED Orange
6Lockout LED Violet
3 Way
connector
1Electric 1 Switch reen
2Electric 2 Switch rey
3Electric 3 Switch Pink

Step 13 Electrical Connection 230V
The appliance must be installed in accordance with the installation instructions and comply with any relevant
regulations in the country where the appliance is installed. Electrical installation must be carried out by a suitably
qualified electrician. The electrical supply must be connected to a 13 amp fused spur provided with an all-pole
disconnection and the appliance must be earthed.
Vehicle Manufacturer nstallation
The mains supply cable is supplied with a JST LP series socket (terminal pins are JST slm-61T-2.0) and must be
mounted in a housing with strain relief to prevent accidental disconnection and prevent access to the connector.
Retail nstallation
The Whale® Space Heater comes fitted with a 3 pin plug. The socket must be mounted vertically and away from
potential exposure to water. If installation of an electrical socket is required, this must be carried out by a competent
person. The plug is fitted with a 10 amp fuse.
Fig. 34 Mains Connection
Please note: If the supply cable is damaged, it must be replaced by the caravan/motorhome/cable manufacturer or
a Whale® Approved Service Centre or Technician.
Warning: The appliance must not be supplied through an external switching device, such as a timer or a circuit that
is regularly switched. This is to avoid an inadvertent resetting of the thermal cut out.
N.B. Ensure that the Space Heater is not located immediately below the electrical supply socket.
18
Hot Air Duct
Vehicle Floor
Cold Air Inlet
Cold Air Duct
12 Way Connector
Reset Button
Fig. 33 Mains Electrical Connection
Space Heater Wiring Loom
Protective Cover Protective Cover Lid
Cold Air Inlet
Hot Air Outlet
Space Heater
12 Way Connector
Reset Button
Fig. 31 Internal Installation - Connect 12V d.c. Fig. 32 Underfloor Installation - Connect 12V d.c.
Vehicle
Floor Hot Air Outlet

Completed installation
Fig. 35 Completed Internal Installation Fig. 36 Completed Underfloor Installation
Please note: After completing the installation, a full function check including gas soundness must be carried out to
ensure the appliance has been installed and operates correctly. The gas soundness check must be carried out by an
accredited LP engineer and a test certificate issued.
To the User:
Read the following instructions carefully.
Observe all warnings.
In the unlikely event of leaks in the gas system, or if there is a smell of gas:
- Extinguish all naked flames
- Do not operate any electrical switches
- Turn off all gas appliances
- Open windows and doors for ventilation
- Do not smoke
- Shut off gas connection
Immediately ensure that the system is thoroughly checked by a Whale® Approved Service Centre / Technician.
The Space Heater must not be operated in the following situations:
• When refuelling the vehicle or refuelling the vehicle towing the caravan or refuelling any other
appliances.
• When the vehicle in which the Space Heater is installed is in motion. Please refer to Section 3
(Application) in this document (unless a Vehicle in motion kit is fitted - see Appendix).
• When the vehicle in which the Space Heater is installed is in a confined space (such as a garage).
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Ensure that a minimum of one of the hot air outlet vents is permanently open.
When using gas, the combustion air inlet flue and outlet openings for the products of combustion (exhaust flue) must
never be obstructed. They must be checked regularly and if necessary cleaned by the user (e.g. in winter, snow or
fallen leaves must be removed from the combustion outlet and air intake).
19
7. NSTRUCT ONS FOR USE

OPERAT NG NSTRUCT ONS
For operation of the Space Heater, a 12V d.c. supply must be connected at all times. To operate the Space Heater’s
electric elements, it must also be connected to a suitable 230V a.c. supply. Table 3 outlines which control panel can
be used with which heater. Do not use an incompatible combination.
Table 3: Control Panels
Option 1 - Operating Whale Space Heater Control Panel
Option 2 - Operating Whale Duo Control Panel
Option 3 - Operating Whale iVan Control Panel
Option 4 - Operating Vehicle Manufacturer Control Panel
Table 4: Control Panel Functions
Option 1 - Whale Space Heater Control Panel
Fig. 37 Whale Control Panel
For Fan Only Operation: Turn the selector knob to the ‘fan’ position.
For Gas Operation: Turn the selector knob to the ‘gas on’ (flame) position. There will be a pre-purge pause of
approx. 30 seconds to allow any un-burnt gas to leave the flue. A green LED will light upon successful flame ignition.
If there is air in the gas supply line it may take a few attempts for the gas to ignite. See Section 9 for gas lockout
re-setting. If the ignition is not satisfactory the red LED on the Control Panel will flash, refer to the Trouble Shooting
uide (see Section 9).
20
Symbol Setting Description
OFF OFF Space Heater will be off.
as
Space Heater will operate on gas. There will be a pre-purge time of around
30 seconds before ignition. When the gas is lit, the green LED will be
illuminated. If the Space Heater fails to light for any reason, the red LED will
flash or turn solid red. Refer to Trouble Shooting uide (Section 9).
Electric Low Space Heater will operate at LOW on electric setting.
Electric Medium Space Heater will operate at MEDIUM on electric setting.
Electric High Space Heater will operate at HI H on electric setting.
Fan Space Heater will operate on fan only operation.
*Whale Space Heater Control Panel nly.
Frost Protection Frost Protection will activate.
*Whale Duo Control Panel nly.
reen LED Light
Red LED Light
Selector Knob Temperature Control Knob
SH2201, SC2201, SH2202, SC2202, SC2211 SH2211
Whale Space Heater Control Panel
Whale Duo Control Panel
Whale iVan Control Panel
Vehicle Manufacturer Control Panel
