Whale SH2202 Assembly Instructions

Thank you for purchasing this Whale® product.
For over 60 years Whale® has led the way in the design and manufacturer of freshwater and waste systems
including:- plumbing, faucets, showers and pumps for low voltage applications. The company and its products have
built a reputation for quality, reliability and innovation backed up by excellent customer service.
For information on our full product range visit: www.whalepumps.com
CONTENTS
1. Principles of Operation
2. Specification
3. Application
4. Warnings
5. Parts List
6. Instructions for Installation
7. Instructions for Use
8. Maintenance
9. Trouble Shooting
10. Winterising
11. Service Support Details
12. EU Declaration of Conformity
13. Patents and Trademarks
14. Warranty
15. Appendix A - Identifying Flue Type
LIST OF IMAGES
Fig. 1 Components Drawing
Fig. 2 Installation in Vehicle
Fig. 3 Installation Under Vehicle
Fig. 4 Dimensions – Plan View Inside Vehicle
Fig. 5 Dimensions – Side View Inside Vehicle
Fig. 6 Dimensions – Front View Inside Vehicle
Fig. 7 Dimensions – Plan View Under Vehicle
Fig. 8 Dimensions – Side View Under Vehicle
Fig. 9 Dimensions – Front View Under Vehicle
Fig. 10 Flue Locating Diagram
Fig. 11 Attaching Flues - Inside Vehicle
Fig. 12 Heater Locating
Fig. 13 Installation and Securing of Space Heater
Fig. 14 Floor Construction and Cut Out
Fig. 15 Attaching Underfloor Space Heater
Fig. 16 Attaching Flues - Under Vehicle
Fig. 17 Secure Flue Brackets
Fig. 18 Connect to Gas Supply to Inside Space Heater
Fig. 19 Connect Gas Supply to Underfloor Space Heater
Fig. 20 Connect Hot Air Duct to Inside Space Heater
Fig. 21 Connect Hot Air Duct to Underfloor Space Heater
Fig. 22 T Fitting Orientation
Fig. 23 Connect Cold Air Duct to Inside Space Heater
Fig. 24 Connect Cold Air Duct to Underfloor Space Heater
Fig. 25 Insert Control Panel
Fig. 26 Secure Control Panel
Fig. 27 Installed Control Panel
Fig. 28 Connect 12V d.c. Connector - Inside Space Heater
Fig. 29 Connect 12V d.c. to Interface Plate - Underfloor Space Heater
Gas and Electric Space Heater Mk II SH2202 / SH2212B
1
INSTALLATION & USER INSTRUCTIONS

Fig. 30 Typical Manufacturer Mains Electrical Connection
Fig. 31 Typical Retail Mains Electrical Connection
Fig. 32 Completed Installation - Inside
Fig. 33 Completed Installation - Underfloor
Fig. 34 Whale Space Heater Control Panel
Fig. 35 Whale Duo Control Panel
Fig. 36 Flue Type - for Vehicle in Motion
Fig. 37 Flue Type - for Standard Installation
The Whale® Space Heater Mk II is a gas and electric blown air space heater. Nominal heat output is 2kW on gas
and 2kW on mains electric. When on electric mode, heat output is adjustable to low, medium and high settings with
an automatically adjusting fan speed for quiet operation and low current draw. The compact design provides
versatility in installation locations and needs minimal maintenance. The vehicle internal temperature is set by a room
controller which can be manually adjusted to a wide range of temperature settings or to warm weather ventilation.
Key enhancements to the Mk II design are improved insulation, improved service access and lighter, more compact
design.
Read the following carefully before installation
Model:
SH2202 (Internal) Maximum dimensions: Height: 230mm, Width: 157mm, Length: 634mm
SH2212B (Underfloor) Maximum dimensions: Height: 121mm, Width: 290mm, Length: 714mm
Countries of Destination: AT, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GB, GR, HU, HR, IE, IS, IT, LT, LU, LV,
MT, NL, NO, PT, SE, SI, SK, TR
Weight:
Inside Vehicle Installation 7.8kg
Underfloor Installation 8.4kg
Gas: Butane 28-30mbar - CAT I3+ (28-30/37)
Butane/Propane 30mbar - CAT I3B/P (30)
Propane 37mbar - CAT I3p (37)
Gas Consumption (M) 150g/h
Classification of Heater: Type: C53 (Fanned) Normal Installation
C13 Vehicle In Motion Installation
Nominal Heat Input: Gas 2.0kW
Nominal Heat Input Electric 2.0kW.
Mains Electric:
Nominal voltage: 230V a.c. 50Hz
Power options: 500W / 1000W / 2000W
Maximum current a.c.: 9 Amps
Battery Supply
Nominal voltage: 12V d.c.
Operating range: 10.0V d.c. min. to 15V d.c. max.
Maximum current d.c. gas operation: 1.7 Amps (0.01Amps on standby)
Maximum current d.c. electric operation: 2.2 Amps (0.01Amps on standby)
Dry Storage Temperature: -20°C to 70°C
Hot Air Duct Diameter: 60mm ID
2. SPECIFICATION
1. PRINCIPLES OF OPERATION
2

Flue Diameter: 22mm ID
Maximum Exhaust Flue Length: 2m
Minimum Exhaust Flue Length: 0.75m
Maximum Combustion Air Flue Length: 2m
Minimum Combustion Air Flue Length: 0.75m
Ensure that the installation location allows access for servicing the Space Heater and that there is a minimum of
25mm distance around the Space Heater to adjacent walls when mounted inside the vehicle.
Whale’s policy is one of continuous improvement and we reserve the right to change specifications without prior
notice.
The Whale® Space Heater has been designed for caravan, motorhome and mobile applications, and is suitable for
typical recreational vehicle use. The Whale® Space Heater is only suitable for use in road vehicles, i.e. caravans and
motorhomes. It is not suitable for caravan holiday homes i.e. mobile homes or static caravans. The Whale® Space
Heater is designed to be installed in conjunction with a Ducted Hot Air System. If the Space Heater is to be used in
motion, the Vehicle in Motion Kit must be fitted. This is an accessory to the Whale® Space Heater and must be
fitted to allow use in motion. If the Vehicle in Motion Kit is not fitted, you must not operate the appliance while the
vehicle is in motion. Please see Appendix A for information on identifying flue type. For more information on this kit,
contact Whale® Support.
This symbol indicates that this appliance is suitable for use in Leisure Accommodation Vehicles.
This symbol indicates that this appliance is not suitable for use in Boats.
Observe all warnings.
In the unlikely event of leaks in the gas system, or if there is a smell of gas:
• Extinguish all naked flames
• Switch off all appliances and do not operate any electrical switches
• Turn off all gas appliances
• Open windows and doors for ventilation
• Do not smoke
• Shut off gas connection
Ensure that the system is thoroughly checked by a registered gas engineer at a Whale® Approved Service Centre or
by a member of the Whale Service Engineer Network.
The Space Heater must not be operated in the following situations:
• When refuelling the vehicle or refuelling the vehicle towing the caravan or refuelling any other
appliances.
• When the vehicle in which the Space Heater is installed is in motion; unless the Vehicle in Motion
Flue Kit is installed (please see Appendix A for information on identifying Flue Type).
• When the vehicle in which the Space Heater is installed is in a confined space, (such as a garage).
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children must be supervised to ensure that they do not
play with the appliance.
3. APPLICATION
4. WARNINGS
3

Ensure that a minimum of one hot air outlet vents are permanently open. This hot air vent must be located furthest
from the Space Heater.
Any alteration to the appliance, including flue components, use of non-Whale® spare parts/accessories and
non-observation of the installation and operation instructions may lead to cancellation of the warranty and exclusion
of liability claims and results in it becoming illegal to use the appliance.
Please note: Incorrect installation, misuse or use of non original Whale® parts may invalidate the warranty. It also
becomes illegal to use the appliance if incorrectly installed, and can also make it illegal to use the vehicle.
When operating the Space Heater using gas, the combustion air inlet flue and outlet flue for the products of
combustion (exhaust flue) must never be obstructed. They must be checked regularly, and if necessary cleaned by
the user (e.g. in winter, snow must be removed from the combustion outlet and air intake).
Where the open end of the exhaust flue terminates, three sides of the underfloor space must be kept open and not
obstructed, and must not contain through floor ventilation openings.
The Space Heater, its gas supply and flues for the products of combustion are to be inspected in accordance with
national regulations or if these do not exist, the Space Heater manufacturer’s recommendations. Whale advises that
this must be carried out at least annually.
Please note: The Space Heater and ducts will become hot. Please avoid anything directly touching the Space
Heater or ducts.
The Whale® Space Heater kit contains:
Please note that the Whale® Space Heater requires a separate Flue Kit for installation.
Exhaust Flues are available in lengths of 0.75 metres, 1.25 metres and 2 metres.
Combustion Air Inlet Flues are available in lengths of 0.75 metres, 1.25 metres and 2 metres.
A kit is also available specifically to allow the Space Heater to be used while the vehicle is in motion. For a full list of
flue kits available please contact Whale® Support.
5. PARTS LIST
4
SH2202 SH2212B
Space Heater and 4 screws 1
Space Heater and 10 screws 1
Control Panel / Room Thermostat and 4 screws 1
3.5m Control Panel Cable (retail only) 1
Warranty Registration Card 1 1
Instruction Manual Including Installation Templates 1 1
Instruction Manual Storage Pocket with Adhesive Fixing Strip 1

Fig. 1 Components Drawing
5
Overheat Stat Insulation
Electric Overheat Thermostat
Gas Overheat Thermostat
Heat Exchange Case Cover
Gas Heat Exchange
Heat Exchange Gaskets
Burner Gaskets
Burner
Electrodes Case Lid
Gas Injector
Gas Train
Sealing Washer
End Plate Gasket
End Plate
End Plate
Connector
Olive
Nut
Outer Box
Interface Box
Fan Combustion Air
Motor Gasket
Air Flow Sensor
Fan Housing
Fan Hot Air
Motor Mounting Plate
Motor
Fan Housing Gasket
Heat Exchange Case
PCB
Insulation
Electric Assembly
Element Mounting Plate
Element Cover Plate

The Whale® Space Heater can be installed either inside the vehicle (Part Number: SH2202) as in Fig. 2 or under the
floor (Part Number: SH2212B) as in Fig. 3, depending on which model has been purchased.
Fig. 2 Internal Installation
Fig. 3 Underfloor Installation
To the Fitter:
Installation and servicing of this appliance must only be carried out by competent persons registered with the Gas
Safe Register (GB) or the relevant national organisation, in accordance with the relevant regulatory and safety
requirements.
Before installation, you must ensure the appliance has been supplied in good condition and if damaged do not
install.
A competent person must install the appliance in accordance with the appliance installation instructions. This
appliance is for use with LPG (see appliance data plate) and mains electricity (230V a.c.). Check that the product is
suitable for the intended application. In particular the installer must check the compatibility of the data plate
information with the LPG supply requirements of the vehicle. Follow these installation instructions and ensure all
relevant personnel read the points listed below. Ensure that these operating instructions are passed on to the end
user.
Please note: The appliance must be installed in accordance with any relevant regulations in the country where the
appliance is installed. For this appliance in Europe, the standard is BS EN 1949:2011 “Specification for the
Installation of LPG Systems For Habitation Purposes In Leisure Accommodation Vehicles And In Other Road
Vehicles”.
Ventilation must comply with relevant national and/or local requirements.
6
6. INSTRUCTIONS FOR INSTALLATION
Exterior Wall
Hot Air Outlet Duct
Vehicle Floor
Interior Wall
Exhaust Flue
Combustion Air Inlet
Gas Pipe
Space Heater
Space Heater
Gas Pipe
Combustion Air Inlet
Exhaust Flue
Cold Air Inlet
Hot Air Outlet
Vehicle Floor
Cold Air Inlet Duct

DIMENSIONS
Internal Installation
Fig. 4 Internal Installation - Plan View
Fig. 5 Internal Installation - Side View
Fig. 6 Internal Installation - Front View
7
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Space Heater
Gas In
270mm
257mm
270mm
Cold Air Inlet
121mm
137mm
141mm
610mm
634mm
Exhaust Flue Combustion Air Inlet
Cold Air Inlet
Hot Air Outlet
157mm
78mm
46mm

Underfloor Installation
Fig. 7 Underfloor Installation - Plan View
Fig. 8 Underfloor Installation - Side View
Fig. 9 Underfloor Installation - Front View
8
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Gas In
714mm
161mm
171mm
76mm
121mm
Exhaust Flue
Combustion Air Inlet
Gas In
Hot Air Outlet
25mm
65mm
Exhaust Flue
Combustion Air Inlet
Hot Air Outlet
Cold Air Inlet
228mm
281mm
288mm

Step 1 Find Suitable Location For Space Heater Installation
Consider the following points:
i. For weight distribution in caravans, aim to position the Space Heater as near to the axle as possible.
You must avoid (where possible) locating at the very rear and preferably avoid the very front.
ii. If mounting under the floor, the Space Heater must be positioned within the chassis members and
close to the axle to help protect the appliance.
iii. Please note: The Space Heater, ducts and flues will become hot. Please avoid anything directly
touching these.
iv. Ensure the position allows access for servicing the Space Heater and that there is a minimum of
25mm distance around the Space Heater to adjacent walls.
v. The hot air outlet of the Space Heater must be fitted to the hot air ducting system. The Space Heater
must be positioned to minimise the amount of ducting required and sharp bends in the ducting must
be avoided.
vi. In selecting the position of the Space Heater, ensure that the exhaust flue and combustion air inlet
flues can be installed avoiding all chassis members and gas pipes etc. that are located underneath
the floor. Remove the flue template from the back of the instruction manual and use this to find a
suitable location.
vii. The open end of the exhaust flue must not be fitted at the side of the caravan / motorhome where
an awning may be fitted. The Space Heater must be installed on the opposite side of the caravan
/ motorhome to avoid routing the exhaust flue to the far side of the caravan / motorhome.
viii. Only Whale® supplied flue components are permitted to be used. The open end of either flue must
not be positioned within 300mm of a refuelling point or fuel tank breather outlet or any ventilator from
the fuel system(s). The exhaust flue must not be fitted within 300mm of a ventilator for the living
space or an opening part of a window. The open end of the exhaust flue must be positioned at least
500mm from the open end of the combustion air flue and be pointing in the same direction. The
exhaust flue must be positioned at the side or end of the caravan / motorhome. The exhaust flue
may only be positioned vertically below an opening part of a window if the appliance is fitted with an
automatic shut-off device, to prevent operation when the window is open.
Fig. 10 Flue Locating Diagram
ix. The combustion air inlet flue can be terminated underneath the vehicle. The open end of it must be
at least 500mm away from the open end of the exhaust flue, and pointing in the same direction. Take
care to ensure that both flues have a slight downward slope from as close to the Space Heater as
possible to prevent any possibility of water traps. Ensure that neither the exhaust nor the combustion
air inlet flues are terminated in an underfloor box section.
x. The minimum length of the exhaust flue is 0.75 metres, and maximum length 2 metres. The minimum
length of the combustion air inlet flue inlet must be 0.75 metres, and maximum length 2 metres.
xi. When operating the Space Heater using gas, the combustion air inlet flue and outlet openings for the
products of combustion (exhaust flue) must never be obstructed. They must be checked regularly,
and if necessary cleaned by the user (e.g. in winter, snow must be removed from the combustion
outlet flue and combustion flue intake).
9
Fuel refuelling / breather vent
PLEASE NOTE: Points i to
xiv for information on Space
Heater and Flue Locations.
KEY
Prohibited area
for Space Heater flue

xii. Where the open end of the exhaust flue terminates, three sides of the underfloor space must be
kept open and not obstructed, and not contain through-floor ventilation openings.
xiii. The Space Heater, its gas supply, ducting and flues must be inspected in accordance with national
regulations or if these do not exist, the manufacturer’s recommendations. Whale advises that this
must be carried out at least once every year.
xiv. The Space Heater must not be used when the vehicle is in motion unless the Vehicle in Motion
Flues and Bracket are fitted. The Vehicle in Motion Kit is not standard and is available separately.
Please refer to the Vehicle in Motion Kit instruction for further fitting considerations or contact
Whale® Support for more information.
If installing under the floor of the vehicle, please skip Steps 2 and 3.
Step 2 Internal Installation - Cut Out Holes for Exhaust and Combustion Air Flues
Position the template on the floor where the Space Heater is to be mounted. Mark the position of the two holes for
the combustion air inlet and exhaust flues, then drill holes with a 51mm (2”) minimum diameter hole saw.
Fig. 11 Attaching Flues
Push on the ends of the flues with the blue adaptor to the pipes on the underside of the Space Heater ensuring they
are fully pushed on, and secure with supplied hose clips.
Step 3 Internal Installation - Attach Space Heater to The Floor
From inside the vehicle, feed the exhaust and combustion air flues through the holes drilled on the floor. Locate the
Space Heater so that the flues are centralised in the holes. Attach the Space Heater to floor with 4 screws supplied
(No. 8 x ¾”), as per Figs. 12 & 13.
Fig. 12 Locating the Space Heater
10
Space Heater
Gas In
Combustion Air Inlet
Exhaust Flue Outlet
Combustion Air Inlet Flue
Exhaust Flue
Hot Air Outlet
Cold Air Inlet
Hot Air Outlet
Gas In
Space Heater
Vehicle Floor
Exhaust Flue
Combustion Air Inlet Flue

Fig. 13 Securing the Space Heater
For Internal Installation, Please Proceed to Step 6
Step 4 Underfloor Installation - Underfloor Heater Location
For underfloor installation, the floor of the vehicle must be manufactured as per Fig. 14. Wooden batons must be
incorporated in the floors construction to secure the screws into.
Locate the Space Heater in the correct position so that the screws will enter the batons, and attach with 10 screws
(No. 8 x 5⁄8”) provided. Ensure that the mains cable is fed through the rectangular cut out and is not trapped between
the outer cover box and the floor.
Fig. 14 Securing the Space Heater (Plan View)
Fig. 15 Attaching the Underfloor Space Heater
11
Gas In
Screw Hole
Vehicle Floor Screw Hole
Hot Air Outlet
Cold Air Inlet
Batons built
into floor
96mm
Cut out in floor
R51mm x 2
Vehicle Floor
Cut out in Floor
Space Heater
Gas In
Vehicle Wall

Step 5 Underfloor Installation Only - Securing The Flues
Push on the ends of the flues with the blue adaptor to the pipes on the underside of the Space Heater ensuring they
are fully pushed on, and secure with supplied hose clips.
Fig. 16 Attaching the Flues
Step 6 Internal and Underfloor Installation - Mounting The Flues
When mounting the combustion inlet flue and exhaust flue, they must run downwards from the Space Heater to their
open end to allow any condensation to drain out. The open ends must be angled downwards to prevent rain from
entering. Care must be taken to route exhaust flues around chassis members, avoiding gas pipes and wires.
The flues must otherwise be kept as straight as possible.
Please note: The exhaust flue must be positioned at the side or the rear end of the vehicle. The open end of the
combustion air flue must be at least 500mm away from the open end of the exhaust flue and pointing in the same
direction.
The combustion air inlet flue is attached to the underside of the floor with two of the brackets supplied. The remaining
brackets supplied with the flue kit are used to attach the exhaust flue. Clip the bracket around the flue and use two
screws (No.8 x ¾”) to attach each bracket to the floor as per Fig.17.
Fig. 17 Securing the Flue Brackets
Step 7 Internal and Underfloor Installation - Connect to Gas Supply
The appliance must be installed by a competent person in accordance with the installation instructions and comply
with any relevant regulations in the country where the appliance is installed.
The Space Heater is supplied with a compression nut and olive for 8mm (5⁄16”) pipe. The supply pipe must be
checked and be free from dirt or other particles before connection to the compression joint on the Space Heater. The
supply pipe must be routed so that the appliance can be removed for servicing.
A gas shut-off valve must be located in the vicinity of the Space Heater and all connections must be kept to a
minimum.
A Gas Pressure Test Point must be fitted to the inlet of the appliance.
When the gas line is complete, all joints must be tested for leaks using Leak Detection Solution.
N.B. Never with a naked flame.
12
Gas In
Space Heater
Flue
Flue
Combustion Air Inlet
Exhaust Outlet
Hose Clip
Hose Clip
Screw Hole
Screw Hole
Bracket
Flue

The gas pressure must be verified at the pressure test point.
Please note: The operating pressure for the gas supply must be either 28-30mBar Butane or 30mBar-37mbar
Propane.
Fig. 18 Internal Installation - Connect to Gas Supply
Fig. 19 Underfloor Installation - Connect to Gas Supply
Step 8 Internal and Underfloor Installation - Fitting Hot Air Ducts
To fit the ducting, push it onto the ‘outlet’ nozzle, where it will be gripped by the nozzle.
Fig. 20 Internal Installation - Connect to Hot Air Duct
If fitting the Underfloor Space Heater, fit the air duct into the hot air outlet nozzle as shown.
Fig. 21 Underfloor Installation - Connect to Hot Air Duct
13
Space Heater
Gas In
Gas Pipe
Vehicle Floor
Hot Air Outlet
Cold Air Inlet
Gas In
Gas Pipe
Space Heater
Vehicle Floor
Hot Air Outlet
Cold Air Inlet
Ducting
Vehicle Floor
Cold Air Inlet
Hot Air Outlet
Duct Vehicle Floor

14
Important: At least one hot air outlet vent must be permanently open. This vent must be located the furthest
distance from the Space Heater. The hot air duct must not be fed into the centre branch of a T fitting see Fig. 22b.
Fig. 22a Correct Tee Fitting Orientation Fig. 22b Incorrect Tee Fitting Orientation
Step 9 Internal and Underfloor Installation - Fitting Cold Air Supply
The Whale® Space Heater must be adequately supplied with cold air. If the Space Heater is installed in a bed box or
another confined space; vents into the area must be fitted or ducting used to supply the Space Heater with cold air. If
a vent is fitted, it must be no smaller than one designed for use with 60mm ducting. If ducting is fitted it must supply
air from the living space of the vehicle. To fit the ducting, push it onto the cold air inlet, where it will be gripped by the
nozzle.
Fig. 23 Internal Installation - Connect to Cold Air Duct Fig. 24 Underfloor Installation
Step 10 Mounting of Control Panel
When mounting the Whale® Control Panel, find a suitable convenient and accessible position. For good temperature
control, select a position away from draughts and approximately 1.5m above the floor. Ensure suitable access for
wiring loom connection and cable. Note: The cable supplied with the retail Space Heater to connect the Control
Panel to the Space Heater is 3.5m long. The minimum depth behind panel for wiring must be 40mm. If using a
Control Panel specific to the manufacturer of the vehicle the electrical connections must be made in accordance with
Step 11.
Option 1 - Mounting of Whale Space Heater Control Panel
The Whale Space Heater Control Panel requires a cut out 95mm wide x 42mm high. Feed the wires through the cut
out in the wall and locate into desired position. Secure with 4 screws (No.4 x 3⁄4”) provided, then clip on the surround
frame.
In some instances, it may be necessary to make the wiring connections in Step 11 before securing the Control Panel
to the wall.
Please note: It may be possible to retrofit the Whale® Control Panel into existing frames.
Tee Fitting
Hot Air Outlet
Ducting
Ducting Ducting
Hot Air Outlet
Hot Air Duct
Space Heater
Cold Air Inlet
Cold Air Duct
Vehicle Floor
Hot Air Duct
Cold Air Duct
Hot Air Outlet
Cold Air Inlet
Vehicle Floor
Hot Air
Hot Air
Hot Air
T Fitting
Hot Air Outlet
Ducting
Ducting
Ducting
Hot Air
Hot Air

Fig. 25 Insert Control Panel Fig. 26 Secure Control Panel Fig. 27 Installed Control Panel
Option 2 - Mounting of Whale Duo Control Panel
The Whale Duo Control Panel requires a cut out 118mm wide x 64mm high. Feed the wires through the cut out in the
wall and locate into desired position. Secure with 2 screws (No.4 x 3⁄4”) provided, then clip on the Surround Frame.
In some instances, it may be necessary to make the wiring connections in Step 11 before securing the Whale Duo
Control Panel to the wall.
Step 11 Electrical Connections 12V d.c.
Vehicle Manufacturer Installation - SH2212B
WARNING: Always disconnect the appliance from the power supply prior to working on electrical components.
The Space Heater and both the Whale Space Heater Control Panel and the Whale Duo Control Panel come
complete with electrical connectors fitted.
The Whale® Space Heater and Control Panels are designed to be integrated into the caravan’s wiring loom. The
Space Heater is provided with a JST VL series 12 way socket, and the Control Panel with JST VL 6 and 3 way
sockets. 9 wires are required to connect the Space Heater to the Control Panel, and 12V d.c. and 0V d.c. power
supply must be connected to the 12 way socket at the Space Heater.
Please note: Whale recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
Table 1: Connections at Space Heater
Table 2: Connections at Control Panel
15
Terminal Number Description Wire Colour
1Switch common Brown
20V to Switch panel Black
3Fan Switch Yellow
4Electric 1 Switch Green
5Electric 2 Switch Grey
6Electric 3 Switch Pink
7Burner Switch Blue
8Burner LED Orange
9Lockout LED Violet
10 12V supply Red
11 0V supply White
Connector Terminal
Number Description Wire Colour
6 Way
connector
1Switch common Brown
2Burner Switch Blue
3Fan Switch Yellow
40V to Switch panel Black
5Burner LED Orange
6Lockout LED Violet
3 Way
connector
1Electric 1 Switch Green
2Electric 1 Switch Grey
3Electric 1 Switch Pink
Cut Out
Mounting Frame
Surround Frame

Retail Installation - Part Number SH2202
The Space Heater and Control Panels come complete with electrical connectors fitted.
Step i
Connect the 12 way electrical connector with the unattached red and white leads to the 12 way connector on the
Space Heater.
Step ii
Route the wire to the Control Panel and connect the 6 way electrical connector to the 6 way connector.
Step iii
Route the 3 way electrical connector to the 3 way connector at the Control Panel.
Step iv
Secure the wire close to the Control Panel ensuring that there is no strain on the wires at the switches.
Step v
Connect the free red lead coming from the 12 way connector to a 12V d.c. supply, then connect the free white lead to
the caravan 0V d.c. supply.
Please note: Whale recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
Fig. 28 Internal Installation - Connect 12V d.c. Fig. 29 Underfloor Installation - Connect 12V d.c.
Step 12 Electrical Connection 230V
The appliance must be installed in accordance with the installation instructions and comply with any relevant
regulations in the country where the appliance is installed. Electrical installation must be carried out by a suitably
qualified electrician. The electrical supply must be connected to a 13 amp fused spur provided with an all-pole
disconnection and the appliance must be earthed.
Vehicle Manufacturer Installation - Part Number: SH2212B
The mains supply cable is supplied with a JST LP series socket (terminal pins are JST slm-61T-2.0) and must be
mounted in a housing with strain relief to prevent accidental disconnection and prevent access to the connector.
16
Fig. 30 Mains Electrical Connection
Space Heater Wiring Loom
Protective Cover Protective Cover Lid
Hot Air Duct
Hot Air Outlet
Cold Air Inlet
Hot Air Outlet
Space Heater
Vehicle Floor
12 Way Connector
Vehicle Floor
Cold Air Inlet
Cold Air Duct
12 Way Connector

Retail Installation - SH2202
The Whale® Space Heater comes fitted with a 3 pin plug. The socket must be mounted vertically and away from
potential exposure to water. If installation of an electrical socket is required, this must be carried out by a competent
person. The plug is fitted with a 10 amp fuse.
Fig. 31 Mains Connection
Please note: If the supply cable is damaged, it must be replaced by the caravan/motorhome/cable manufacturer or
a Whale® Approved Service Centre or Technician.
Warning: The appliance must not be supplied through an external switching device, such as a timer or a circuit that
is regularly switched. This is to avoid an inadvertent resetting of the thermal cut out.
N.B. Ensure that the Space Heater is not located immediately below the electrical supply socket.
Completed installation
Fig. 32 Completed Internal Installation Fig. 33 Completed Underfloor Installation
Please note: After completing the installation, carry out a full function check including gas soundness to ensure the
appliance has been installed and operates correctly. The gas soundness check must be carried out by an accredited
LPG gas engineer and a test certificate issued.
To the User:
Read the following instructions carefully.
Observe all warnings.
In the unlikely event of leaks in the gas system, or if there is a smell of gas:
- Extinguish all naked flames
- Do not operate any electrical switches
- Turn off all gas appliances
- Open windows and doors for ventilation
- Do not smoke
- Shut off gas connection
Ensure that the system is thoroughly checked by a Whale® Approved Service Centre or Whale Service Engineer.
17
7. INSTRUCTIONS FOR USE

The Space Heater must not be operated in the following situations:
• When refuelling the vehicle, refuelling the vehicle towing the caravan or refuelling any other
appliances.
• When the vehicle in which the Space Heater is installed is in motion, unless the Vehicle in
Motion Flue Kit is installed (please see Appendix A for information on identifying Flue Type).
• When the vehicle in which the Space Heater is installed is in a confined space, (such as a garage).
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children must be supervised to ensure that they do not
play with the appliance.
Ensure that a minimum of one hot air outlet vents is permanently open.
When using gas to operate the Space Heater, the combustion air flue and outlet openings for the products of
combustion (exhaust flue) must never be obstructed. They must be checked regularly and if necessary cleaned by
the user (e.g. snow or fallen leaves must be removed from the combustion outlet and air intake).
Where the open end of the exhaust flue terminates, three sides of the underfloor space must be kept open and not
obstructed, and must not contain through-floor ventilation openings.
The Space Heater, its gas supply and flues for the products of combustion must be inspected in accordance with
national regulations or if these do not exist, the Space Heater manufacturer’s recommendations. Whale advises that
this must be carried out at least annually.
The Whale® Space Heater must be checked periodically by a Whale® Approved Service Centre / Technician, or
competent person, at least annually. This must be completed according to the practice in the country where it is
used and according to the Whale® instructions. Whale recommends annual testing of gas soundness and
combustion by an accredited LPG gas engineer. The appliance contains ESD sensitive components and therefore
must only be opened by a Whale® Approved Service Centre / Technician (contact Whale® Support).
When using non Whale operating switches provided by the installer or vehicle manufacturer, they are responsible for
providing user instructions and identification of symbols on the control panel.
The inlet vents of the Space Heater must never be blocked and at least one hot air outlet vent must be permanently
open.
OPERATING INSTRUCTIONS
For operation of the Space Heater, a 12V d.c. supply must be connected at all times. To operate the Space Heater’s
electric elements, it must also be connected to a suitable 230V a.c. supply.
Option 1 - Whale Space Heater Control Panel
Fig. 34 Control Panel
For Fan Only Operation: Turn the selector knob to the ‘fan’ position.
For Gas Operation: Turn the selector knob to the ‘gas on’ (flame) position. There will be a pre-purge pause of
approx. 30 seconds to allow any un-burnt gas to leave the flue. A green LED will light upon successful flame ignition.
If there is air in the gas supply line it may take a few attempts for the gas to ignite. See Section 9 for gas lockout
re-setting. If the ignition is not satisfactory the red LED on the Control Panel will flash, refer to the Trouble Shooting
Guide (see Section 9).
18
Green LED Light
Red LED Light
Selector Knob Temperature Control Knob

For Electric Operation: The Space Heater is equipped with 3 power settings 500W / 1000W / 2000W. Turn the
selector knob to low power setting for 500W.
Turn the selector knob to medium power setting for 1000W.
Turn the selector knob to high power setting for 2000W.
When operating on low and medium electric power settings, the blown air fan runs at a reduced speed to minimise
noise and current draw.
Note: The electric elements will still operate if the appliance is in gas ignition lock-out.
The appliance cannot be operated with both gas and electric.
Switching Appliance Off: Turn the selector knob to the ‘Off’ position (O).
Note: The fan will continue to run for 3 minutes to allow the Space Heater to cool down.
Adjusting The Temperature: Turn the temperature control knob clockwise to increase and anti-clockwise to reduce
the room temperature. The Space Heater will automatically turn itself on and off to maintain the desired ambient
temperature.
Note: The Control Panel incorporates a low temperature / frost protection setting. This can be activated by turning
the temperature control knob fully anti-clockwise.
Option 2 - Whale Duo Control Panel
Fig. 35 Whale Duo Control Panel
For Gas Operation - Space Heater: Press the Space Heater Function key until the ‘gas’ icon is illuminated. There
will be a pre-purge pause of approx. 30 seconds to allow any un-burnt gas to leave the flue. A green LED will light
upon successful flame ignition. If there is air in the gas supply line it may take a few attempts for the gas to ignite.
See Section 9 for gas lockout re-setting. If the ignition is not satisfactory the Space Heater Diagnostic LED on the
Control Panel will light. If the Diagnostic LED is lit please refer to the Trouble Shooting Guide (see Section 9).
For Electric Operation - Space Heater: The Space Heater is equipped with 3 power settings 500W/1000W/2000W.
For 500W Press the Space Heater Function key until the ‘low power setting’ icon is illuminated.
For 1000W Press the Space Heater Function key until the ‘medium power setting’ icon is illuminated.
For 2000W Press the Space Heater Function key until the ‘high power setting’ icon is illuminated.
When operating on low and medium electric power settings, the blown air fan runs at a reduced speed to minimise
noise and current draw.
Note: The electric elements will still operate if the appliance is in gas ignition lock-out.
The appliance cannot be operated with both gas and electric.
Switching Appliance Off: Press the Space Heater Function key until ‘Off’ is illuminated.
Note: The fan will continue to run for 3 minutes to allow the Space Heater to cool down.
WATER HEATING
HEATING
Control Panel by
Temperature Control
Space Heater Function
Diagnostic LED - Space Heater
Gas Light - Space Heater
Gas Light - Water Heater
Water Heater Function
Diagnostic LED - Water Heater
19

Adjusting The Temperature: Use the temperature control buttons to adjust the temperature. Press ‘ + ’ to increase
the temperature. Press ‘ - ’ to decrease the temperature. The Space Heater will automatically turn itself on and off to
maintain the desired ambient temperature.
Note: The Control Panel incorporates a low temperature / frost protection setting. This can be activated by pressing
‘ - ’ until the frost icon is illuminated.
Table 3: Control Panel Functions
If the Space Heater has not been used for some time, dust may have settled inside the Space Heater and the
ducting. Run the Space Heater on the “Fan only” setting (if available) until it clears. The outside of the appliance
should not normally require cleaning. If it does, isolate the electrical supplies and wipe down with a soft, damp cloth
only. Do not use abrasive cleaners. Allow to fully dry before reconnecting the electrical supplies.
The Whale® Space Heater must be checked periodically by a Whale® Approved Service Centre / Technician, or
competent person, at least annually. This must be completed according to the practice in the country where it is used
and according to the Whale® instructions. Whale recommends annual testing of gas soundness and combustion by
an accredited LPG gas engineer. The appliance contains ESD sensitive components and therefore must only be
opened by a Whale® Approved Service Centre / Technician (contact Whale® Support).
The Space Heater is equipped with an electronic diagnostic system which will detect fault conditions ranging from
poor gas or d.c. supply to internal Space Heater malfunctions. In the unlikely event of a failure, the red LED on the
Control Panel will light.
Option 1 - Whale Space Heater Control Panel
In the unlikely event of a failure, the red LED on the Control Panel will flash a number of times, pause, and repeat
until switched off. Count the number of flashes and refer to the table on page 21.
Gas Lockouts
Gas lockouts must be cleared by turning the selector knob from “gas on” (flame) position to “off” position then back
to the “gas on” position. The complete sequence of switch movements must be completed within 2.5 seconds for a
lockout to be successfully cleared. If there is air in the gas line, e.g. after a gas bottle change, the Space Heater may
require several attempts before it lights. Lockouts can also be cleared by switching to the ‘fan only’ position and then
back to ‘on’ within this 2.5 second period.
20
9. TROUBLE SHOOTING
8. MAINTENANCE
Symbol Setting Description
OFF Space Heater will be off.
Gas
Space Heater will operate on gas. There will be a pre-purge time of
around 30 seconds before ignition. When the gas is lit, the green LED will
be illuminated. If the Space Heater fails to light for any reason, the red
LED will flash. Refer to Trouble Shooting Guide (Section 9).
Electric Low Space Heater will operate at LOW on electric setting.
Electric Medium Space Heater will operate at MEDIUM on electric setting.
Electric High Space Heater will operate at HIGH on electric setting.
Fan Space Heater will operate on Fan Only Operation.
*Whale Space Heater Control Panel Only.
Frost Protection Frost Protection will activate.
*Whale Duo Control Panel Only.
