Whale InstantMatch SDS236T Assembly instructions

WITH
Quick Connect Guide
SDS236T
Instant atch Transformer
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 2

Important Information
Please read the following information before setting up a Bluetooth®wireless technology connection
between the Whale Instant atch®transformer and ira®Advance Flex Extra (J09N) shower:
• The electrical wiring must conform to EU wiring regulations BS7671:2008 Part 7 (17th Edition).
• The Bluetooth®function of the Whale Instant atch®transformer will only work with the ira®
Advance Flex Extra (J09N) shower.
• Previous Whale Instant atch®Wireless transformers cannot be connected wirelessly to the Bluetooth®
wireless technology enabled ira Advance Flex Extra Shower (J09N).
• Bluetooth® wireless technology enabled transformers can be easily identified by the blue test button.
• For optimum signal strength, mount the transformer within 5 metres of the shower.
• Locating the transformer outside of a 5 metre radius may cause a communication breakdown between
the transformer and shower, resulting in intermittent or complete failure to operate.
• Be aware that in very rare situations, dense building material, metallic objects such as steel baths and
foil lined plaster board, or electronic devices may interfere with the Bluetooth® wireless technology signal
and result in intermittent failure. In this situation you should relocate the transformer closer to the shower.
• A hardwired connection must be established if a Bluetooth® wireless technology connection cannot be
made between the shower and transformer.
• If any component or cord is damaged, it must be replaced by a qualified person to avoid a hazard.
Set Up
1. Shower settings
• Before beginning the Bluetooth® wireless technology
registration process, please ensure that the “Pump LK2”
switch inside the ira®Advance Flex Extra (J09N) has
been set to the “ON” position, and that the "Pump LK1"
and "Pump LK3" switches remain in
the "OFF" position as per the diagram shown.
• At this stage please ensure that your transformer is
set to be used with Bluetooth® wireless technology:
the flow sensor setting must be set to 7 for “Bluetooth”
and the pipe inlet diameter must be set to 1 for 15mm.
12345678
BEAB
OFF ON
43 DEG C
45 DEG C
RESERVED
6L/MIN
PUMP LK3
PUMP LK2
PUMP LK1
WARNING
Plumbin of the Waste Pipe
Bluetooth®wireless technology
A wireless Bluetooth connection may be used to allow the SDS236T
(755.678) Whale Instant atch®transformer to communicate with the
ira Advance Flex Extra (J09N) shower without the use of a physical
hardwired connection or external flow sensor to activate the pump.
To set up the wireless connection, please follow the process below.
Whale
Transformer
Settings
Blue Jumper - Sensor Position 7
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 3

• Ensure that the electric supply to the shower is turned OFF.
Then turn the dial on the shower to FULL COLD.
3. Shower set up
2. Transformer set up
• Switch the mains electric supply to the transformer
ONand wait to hear the audible beep from the transformer.
The light on the transformer will now flash red to indicate
that a Bluetooth®connection has not yet been established.
• Press and HOLD the blue test button on the transformer
until the light flashes red and green to indicate that the
transformer is now in pairing mode.
NOTE: You now have 120 seconds to pair the transformer
to the shower.
• Switch the mains electric supply to the shower ON, Start/Stop
button will illuminate.
• Within 10 seconds press and HOLD the Start/Stop button on
the shower until the Start/Stop light on the black button goes off.
4. Configuring the shower
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 4

6. Pairing the shower to the Whale
Instant Match®transformer
• Press and release the start/stop button on the shower.
The status light on the shower will now flash blue to indicate
that the shower is in pairing mode.
• The status light on the shower will then flash white and you
will hear an audible beep from the shower to indicate that the
transformer has successfully been paired to the shower.
• The Whale®transformer will flash green only to indicate
that it is paired to the ira®shower.
• Turn the temperature control to full cold and press the
Start/Stop button on the shower. The shower will now
return to normal standby mode.
• You may now follow the “Post Installation Procedure” in
the ira®Advance Flex Extra (J09N) Instruction anual
(page 25) if necessary.
7. Completing the pairing
Plu
5. Slowly turn the dial on the shower to
position 2
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 5

Service work that may need to be carried out on the ira®Advance Flex Extra (J09N) shower
e.g. the renewal of the control PCB board may require the Bluetooth® wireless technology
connection between the shower and Whale Instant atch®transformer to be terminated
and paired again. To unpair the transformer from the shower, please follow these steps.
1. Switch the mains electric supply to the
shower FF
2. Be sure to leave the mains electric
supply to the pump N. The light on
the transformer will flash blue
Plumbin of the Waste Pipe
Bluetooth® wireless technology Unpairing
3. Press and H LD the test button on the transformer
until the light flashes red. The transformer and shower
have now been unpaired
NOTE: To pair the shower to the transformer again, please
follow the Bluetooth® wireless technology set up procedure.
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 6

From Transformer
TERMINAL BLOCK
NL
Brown
CN13
Black
Red
12345678
BEAB
OFF ON
43 DEG C
45 DEG C
RESERVED
6L/MIN
PUMP LK3
PUMP LK2
PUMP LK1
Plumbin of the Waste Pipe
Whale Instant Match®Transformer
Hardwired Connections
Mira®Advance Flex Extra 1.1785.005 (J09N)
Wired Connections to the WHALE INSTANT ATCH®Transformer
Whale Transformer Settings
Blue Jumper - Sensor Position 6
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Connection to ira®Advance Flex Extra J09N Shower
Ensure all LK settings are set to
‘ FF’ for hardwired connection
Flex Extra J09N
Where a Bluetooth®connection cannot be established between the transformer and shower,
a hardwired connection may be used (on compatible showers) to activate the pump.
The hardwired connection allows the transformer and shower to communicate by means
of a physical wired connection, eliminating the need for an external flow sensor.
Compatible showers and their pump connections may be found below.
Plu
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 7

Whale®Transformer Settings
Blue Jumper - Sensor Position 4
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Triton®Safeguard +
mnicare Design,
mnicare Style, T150Z+
Wired Connections to
the Whale Instant
atch®Transformer
Redring®Selectronic WP
(SEL85WP or SEL95WP)
Wired Connections to the Whale
Instant atch®Transformer
Blue Jumper - Sensor Position 4
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Redring Shower
Connections
and Settings
Plumbin of the Waste Pipe
Whale Instant Match®Transformer
Hardwired Connections Cont'd
Triton®Shower
Connections and Settings
Redring®Shower
Connections and Settings
Whale®Transformer Settings
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 8

Whale®Transformer Settings
Blue Jumper - Sensor Position 2
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Whale®Transformer Settings
Blue Jumper - Sensor Position 4
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Sika®Sensor
Gems®Sensor
Please ensure that water flow
through the sensor is in the
direction of the arrow on the sensor.
Please ensure that water flow
through the sensor is in the
direction of the arrow on the sensor.
Plumbin of the Waste Pipe
Whale Instant Match®Transformer
Flow Sensor Connections
There are two versions of Gems®flow sensor:
1000 pulses per litre (ppl) and 2200 ppl.
Blue jumper position 3 = 1000 ppl
Blue jumper position 4 = 2200 ppl (shown below)
An external flow sensor should be used where a shower is not compatible with
a Bluetooth® wireless technology or hardwired connection to activate the pump.
Compatible flow sensors and their connections to the transformer are listed below.
Plu
Sika®Sensor Connection
Gems®Sensor Connection
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 9

When connecting to the Grundfos®Venturi sensor it is important
to connect an earth wire from the Venturi sensor to the signal
earth connection on Whale®transformer (shown below).
Whale®Transformer Settings
Blue Jumper - Sensor Position 5
Grey Jumper - Over run 10 Seconds
Red Jumper - Pipe inlet 15mm
Venturi®sensor
Please ensure that water flow
through the sensor is in the
direction of the arrow on the sensor.
Plumbin of the Waste Pipe
Whale Instant Match®Transformer
Flow Sensor Connections Cont'd
Grundfos®(Venturi) Connection
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 10

Whale®Transformer Settings
Flow Switch
Step 1: Turn Dip switch 2 to the 'ON' position.
Step 2: ove red jumper to pipe size '1' for 15mm inlet pipe.
Step 3: ove the blue jumper to increase or decrease the pump
speed as required, using the table below as a guide.
Step 4: ove the grey jumper to increase or decrease the pump
overrun if necessary.
Whale Instant Match®Transformer
Flow Switch Connections
In a situation where a Bluetooth®wireless technology or hardwired connection with the shower
cannot be established, or a suitable flow sensor has not been fitted, the Whale SDS236T
Instant atch transformer can be used with an AK1568 flow switch to activate the pump.
Electric Shower Settings
Jumper Flow Rate
Position (LP )
1. 4.5 - As shown opposite
2. 5.0
3. 5.5
4. 6.0
5. 6.5
6. 7.0
7. 7.5
• Flow rates are nominal values only.
This will vary depending on pipework.
Dip Switches
Please ensure that water flow
through the sensor is in the direction
of the arrow on the sensor.
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 11

Whale Instant Match®Transformer
Flow Switch Connections Cont'd
©Copyright Whale 2018 - All rights reserved. Reproduction in whole or in part without permission is prohibited. WHALE® and WHALE
INSTANT MATCH® are registered trademarks of Munster Simms Engineering Limited, Bangor, Northern Ireland trading as Whale.
Whale’s policy is one of continuous improvement and we reserve the right to change specications without prior notice. Illustrations are
for guidance purposes only. Neither the accuracy nor completeness of the information contained in this or any product literature is
guaanteed by the Company and may be subject to change at its sole discretion.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Munster
Simms Engineering Ltd (trading as Whale) is under licence. Other trademarks and trade names are those of their respective owners.
MIRA® is a registered trade mark of Kohler Mira Limited.
TRITON® is a registered trade mark of Triton Showers a division of Norcros Group (Holdings).
REDRING® is a registered trade mark of Redring Xpelair Group Limited.
SIKA® is a registered trade mark of Dr. Siebert & Kuhn GMbH & Co. KG
GEMS® is a registered trademark of Gems Sensors & Controls.
GR NDFOS® is a registered trademark owned by Grundfos Management A/S or Grundfos A/S, Denmark.
Blue Jumper - Sensor Position 1
Grey Jumper - Over run 10 seconds
Red jumper - Pipe inlet 15mm
Whale®Transformer Settings
Blue Jumper - Sensor Position 1
Grey Jumper - Over run 30 Seconds
Red Jumper - Pipe inlet 22mm
Note: An additional flow switch is available in the
AK1570 ixer Valve Conversion kit (sold separately).
Step 1: Turn Dip switch 2 to the 'ON' position.
Step 2: ove red jumper to pipe size '2' for 22mm inlet pipe.
Step 3: ove the blue jumper to increase or decrease the pump
speed as required, using the below table as a guide.
Step 4: ove the grey jumper to increase or decrease the pump
overrun if necessary. 30 is the recommended setting for
use on mixer showers.
Mixer Shower Settings
Flow Switch x 2
Jumper Flow Rate
Position (LP )
1. 7.5 - As shown opposite
2. 8.0
3. 8.5
4. 9.0
5. 9.5
6. 10.0
7. 11.0
• Flow rates are nominal values only.
This will vary depending on pipework.
Dip Switches
Please ensure that water flow
through the sensor is in the direction
of the arrow on the sensor.
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 12

0845 0694 253
[e-mail]
www.whalepumps.com
@Whalecare
Whale, 2 Enterprise Road,
Bangor, Co. Down,
BT19 7TA, N.Ireland
Ref. 182.606_v2_0218
BLUETOOTH MINI A5 (2018):Layout 1 27/03/2018 14:57 Pa e 1
