Whirlpool RCS2012R User manual

COOKTOP PARTS
1
For Models:RCS2012RS02
(Stainless Steel)
4−06 Litho in U.S.A. (cre) Part No. 8186649
20" ELECTRIC
BUILT−IN
COOKTOP
Illus. Part
No. No. DESCRIPTION
1 LITERATURE PARTS
8286310 Installation
Instructions
8286613 Use & Care Guide
9759133 Safer Cooking Tips
9762761 Safer Cooking Tips
2 8286443 Bracket, Switch
Mounting
3 3192454 Bracket, Mounting
4 Cooktop
8286389LM Stainless Steel
7 Switch Infinite
3191472 Use W/8" Element
(Silver Shaft)
3191471 Use W/6" Element
(Blue Shaft)
8 4456181 Light, Indicator
9 3177991 Screw
10 3196537 Screw
11 Pan, Surface Unit
3195208 6"
3195209 8"
12 Element, Surface
8053265 6"
8053267 8"
14
8286043BL Knob, Control (2)
15 3183956 Seal, Switch
Shaft (2)
16
W10005700 Burner Box
20 4455917 Bracket, Mounting
21 3400093 Screw
26 3195917 Clip, Element

2
OPTIONAL PARTS (NOT INCLUDED)
For Models:RCS2012RS02
(Stainless Steel)
8186649
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242821 Wire, Blue
14 Ga. 150 C
242822 Wire, Brown
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
WIRING HARNESS PARTS
Wiring Harness Parts
8286437 Harness, Wiring
(Main)
W10005710 Bracket, Harness
Cover
W10005730 Conduit Assembly
3400015 Screw
4455805 Grommet, Harness
