Whirlpool CEM2940TQ0 User manual

c2009 WHIRLPOOL CORPORATION
COMMERCIAL
ELECTRIC DRYER
MODELS
CEM2940TQ0
CEM2940TQ1
1−09 Litho in U.S.A. (LT.)(bay) Part No. W10119630 Rev. D

BULKHEAD PARTS
2
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630

BULKHEAD PARTS
3
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8563800 Instructions,
Installation
8576820 Label, Wiring
Diagram
W10119630 Repair Parts List
2 3388703 Washer, Support
3 8066086 Drum Hole
Plug
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 696302 Shield, Exhaust
7 3387134 Thermostat,
Internal Bias
8 90296 Clip
9 3977393 Thermal Cut−Off
(Includes
Illus. 15)
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8541818 Box, Heater
15 3977767 Thermostat,
High Limit
221 F (105C)
16 348368 Lint Chute
Assembly
17 3403588 Heater Element
18 279457 Wire Kit
(For Heater
Element Wiring
Harness Repair)
19 3390647 Screw, 8−18 x 1/2
20 489463 Screw, 8−18 x 5/8
21 690997 Ring, Tri
22 3399506 Shaft, L.H.
23 3399507 Shaft, R.H.
24 3397590 Roller, Support (2)
25 348197 Washer,
Support (4)
26 3359452 Nut, 3/8−16 (2)
27 3403410 Bulkhead
28 692526 Ring, Bearing (2)
29
W10219342 Screw, 8−16 x 1/2
30 3406130 Seal, Rear Drum
31 695587 Drum Assembly
32 692490 Baffle, Drum (2)
33 3403636 Baffle, Drum (1)
34 339956 Seal
35 3976434 Bracket, Support
Shaft

TOP AND CONSOLE PARTS
4
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630

TOP AND CONSOLE PARTS
5
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 357213 Nut, Push−In (2)
2 8283378 Cover, Lint Screen
3 297535 Bumper, Lint Lid
4 8316437 Switch, Pushbutton
5 385421 Funnel, Coin
6 3949737 Cap, End (R.H.)
7 98445 Screw, 10−16 x 3/4
8 3402631 End Cap (L.H.)
9
W10127740 Panel, Control
10 349639 Screen, Lint
11 3398113 Bracket, Control
12 3978606 Hinge, L.H.
3978605 Hinge, R.H.
13 688983 Screw, 8−18 x 5/8
14 3387978 Panel, Rear
15 97787 Screw, 11−16 x 3/4
16 8527847 Top
17 94614 Terminal
18 303921 Screw, 8−32 x 3/8
19 8316433 Pushbutton
20 3348109 Lens, Amber (3)
21 3401177 Light Indicator
Assembly
22 693995 Screw, 8−18 x 3/8
23 351297 Plug, Harness
24 357572 Clip, Ground
25 339554 Screw, 8−18 x 5/16
26 3978748 Case, Meter
27 3349065 Bolt,
5/16−24 x 1
28 353424 Connector,
3−Circuit
29 3347825 Plate, Mounting
30 3954807 Kit, Vertical
8−Coin
(Includes
Illus. 48−49−51
53−54−57 & 58)
31 8576512 Harness, Wiring
32 3954761 Adapter Plate
Chute Assembly
(Includes
Illus. 5)
33 3351136 Door, Service
34 689559 Nut, Push In
35 3954812 Cushion, Console
36 690853 Wire, Ground
37
W10045440 Timer
(Includes
4−Pin Cam)
38 Timing Cam
3387974 3−Pin (60 Min)
339855 4−Pin (45−Min)
343777 6−Pin (30−Min)
Also Available
339854 9−Pin (20 Min)
339853 12−Pin (15 Min)
39 339805 Screw,
10−32 x 3/16
40 3401682 Harness, Timer
41 388326 Screw, Console
42 90406 Nut, Cage
43 351296 Receptacle
44 717253 Receptacle (2−Way)
45 717252 Connector, 2−Way
46 3395683 Connector, Housing
47 691707 Receptacle (3−Way)
48 3400086 Screw, 10−32 x 3/8
49 8316532 Installation
Instruction
Coin Kit
50 3394427 Clip, Harness
Following Parts Supplied
On Whirlpool Coin
Equipped Models Only
51 8316526 Security Lock &
Cam Assembly
52 8318517 Bolt, Slide
Mechanism
53 8316520 Slide Mechanism
(Vertical 8−Coin)
Inserts
(Not Shown)
8316264 Blank
8316265 25¢
54 8316525 Money Box W/Lock
55 Key (Money Box)
(When Ordering,
Specify Vendor
and Key Number)
56 Key (Service Door)
(When Ordering,
Specify Vendor
and Key Number)
57 8316523 Extension
58 8316524 Kit, Decal
Coin mechanism parts, may be
ordered from whirlpool or
The vendor(s) listed below
ESD
270 New Jersey Dr.
Fort Washington, PA
19034
1−800−523−1510
@
info esdcoin.com

CABINET PARTS
6
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630

CABINET PARTS
7
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3954895 Bracket, Top Lock
2 354730 Bolt,
5/16−18 x 2 3/4
3 90984 Nut
4 3404162 Clamp, Motor
(W/Shield)
5 8541400 Bracket, Cabinet
6 3403630 Plug, Strike
Hole
7 343641 Screw, 10−16 x 1/2
8 3393008 Screw, 10−16 x 1/2
9 3397659 Terminal Block
10 356674 Cone−Wedge
11 279393 Screw Kit
(For Terminal
Block)
12 3404413 Plug, Hinge
Hole (4)
13 279318 Terminal,
Tinned & Brass (3)
14 697776 Screw, 10−32 x 5/8
(Grounding)
15 3396795 Cover, Block
16 8066217 Hinge, Top (2)
17 3394083 Clip, Front
Panel
18 3396805 Panel, Rear
19 3405184 Handle, Door
20 3402335 Door, Front
21 98234 Clip, Ground (2)
22 3406129 Seal & Bearing
Assembly
23 693995 Screw, Hex
Washer Head
24
W10224853 Front Panel
Assembly
25 3392100 Foot
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
26 3402341 Door, Rear
27 342055 Screw, 8−18 x 1/2
28 8530603 Cabinet
(Includes
Illus. 5)
29 3405514 Hinge & Pin
Assembly (2)
30 3406109 Switch, Door
31 3403431 Strike, Door
32 3405246 Seal, Door
33 690363 Lock, Front
Top (2)
34 685203 Clip, Felt Pad (2)
35 3389441 Catch, Door
36 8066206 Motor Assembly
60 Hz.
37 348780 Base, Motor
38
W10131364 Belt, Drive
39 3400500 Bolt,
5/16−18 x 3/4
40 691366 Idler & Pulley
Assembly
41
W10121316 Clamp, Motor
42 8066184 Pulley, 60 Hz.

OPTIONAL PARTS (NOT INCLUDED)
8
For Model: CEM2940TQ0, CEM2940TQ1
(White) (White)
W10119630
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
