Whirlwind RoughRider User manual

Watch the Assembly Video
at
www.whirlwindwheelchair.org/roughrider-support

10mm
19mm
(3/4”)
13mm
(1/2”)
19mm
(3/4”)
13mm
(1/2”)
19mm
(3/4”)
1 Parts and Tools
45 - 55 PSI
Wheels
2
19mm 19mm
Select Axle Position

1 2 3 4 5
13mm
Brakes
5
13mm 13mm
Footrests
4
19mm
19mm
Casters
3

13mm
Backrest
6
Mid
3
High
2

Pre-Assembled
Low
4

Backrest Cover
7
Seat Extension
8
10mm

Calf Strap
9
10Cushion Note: Pressure sores can occur at any point
of contact between the rider and the
wheelchair, including but not limited to
backrest, seat or cushion surface,
edge of seat, calf strap, and footrests.
If riders do not have complete sensation, or if they
cannot communicate effectively, riders should have a
competent person evaluate the risk of pressure sores.
Riders should monitor themselves carefully,
or be monitored by an assistant,
to minimize the risk of pressure sores.
Whirlwind recommends professional fitting and
rider training from an experienced wheelchair user.

• Tires are inflated equally to 45-55 psi.
•Rear wheels are positioned in the desired hole, and are the same position
on both left and right sides.
• Rear wheel axle bolts are tightened firmly and wheels spin freely.
• The casters spin and rotate freely.
•Footrests are at the desired height and set while the cushion is in place.
Footrests are at the same height on left and right side (unless rider has
asymmetrical leg length) and the calf (or heel) strap is adjusted comfort-
ably. Footrests must be high enough to not interfere with the casters as
they swivel.
• Brakes lock and unlock easily, and keep the rear wheel from moving
when locked.
•Backrest tubes are at the desired height and are the same height on left
and right side.
• Backrest straps are not twisted or tangled, and they do not prevent the
wheelchair from opening fully.
• Backrest straps are adjusted to promote the comfort and posture of the
rider, and do not create high pressure areas on any part of the back.
• Backrest cover is installed with the tabs secured below the backrest
straps.
• The seat depth is set according to the rider’s preference (with or without
extension).
• The wheelchair with rider rolls straight on a level floor. (Not rolling
straight may indicate a problem with assembly.)
• A seat cushion appropriate to the rider's risk of pressure sores is on the
chair and correctly fitted to the rider.
www.whirlwindwheelchair.org/roughrider-support
Assembly Checklist
Revision: Jan 8-2013
2
Wheels
5
Brakes
4
Footrests
6
Backrest
7
Backrest Cover
8
Seat Extension
3
Casters
10
Cushion
