INSTALLATION MANUAL
M-SC6 / 8 / 10
- 3000 RPM -
Marine diesel generating set 230V / 50Hz
Digital Diesel Control
WHISPER POWER BV
Kelvinlaan 82
9207 JB Drachten
The Netherlands
Tel.: [phone]
Fax.: [phone]
www.whisperpower.eu
V1. June 2010
Art.nr. 40200361

CONTENTS
2June 2010 / M-SC6/8/10 - 3000RPM / EN
CONTENTS:
1INSTALLATION............................................................................................................................................................... 3
1.1 General .............................................................................................................................................................. 3
1.2 Location.............................................................................................................................................................. 3
1.3 Instructions for optimal sound and vibration insulation ....................................................................................... 3
1.4 Ventilation........................................................................................................................................................... 4
1.5 Connections ....................................................................................................................................................... 4
1.5.1 Fuel supply ........................................................................................................................................ 6
1.5.2 Cooling .............................................................................................................................................. 8
1.5.3 Exhaust system ............................................................................................................................... 10
1.5.4 Digital Diesel Control system (12 Volt) ............................................................................................ 14
1.5.5 AC power system (230 Volt)............................................................................................................ 17
2INSTALLATION SPECIFICATIONS.............................................................................................................................. 19
2.1 Installation table ............................................................................................................................................... 19
2.2 Commission table............................................................................................................................................. 19
2.3 Installation specifications M-SC6, 8 and 10 – 3000RPM.................................................................................. 20
2.4 Specification of the accessories ....................................................................................................................... 20
2.5 Installation materials M-SC6/8/10..................................................................................................................... 21
3DIAGRAMS & DRAWINGS ........................................................................................................................................... 25
3.1 DC wiring diagram............................................................................................................................................ 25
3.2 Wiring codes and colours ................................................................................................................................. 26
3.3 Diagram electronic governor M-SC8 and 10 3000 rpm .................................................................................... 27
3.4 AC wiring diagram 230V / 50Hz ....................................................................................................................... 28
3.5 Remote control panel drawings ........................................................................................................................ 29
3.6 M-SC6/8/10 dimensions ................................................................................................................................... 30

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 3
1 INSTALLATION
1.1 GENERAL
This installation manual is valid for the following models:
Part
number Description
41102005 M-SC6 / 230V 3000rpm
41102006 M-SC6 / 230V 3000rpm - ungrounded
41103005 M-SC8 / 230V 3000rpm
41103006 M-SC8 / 230V 3000rpm - ungrounded
41104005 M-SC10 / 230V 3000rpm
41104006 M-SC10 / 230V 3000rpm - ungrounded
For other models see our website: www.whisperpower.eu.
To ensure reliability and durability of the equipment, it is
very important that the installation is carried out with the
utmost care and attention. To avoid problems, such as
temperature problems, noise levels, vibration, etc. the
instructions set out in this manual must be followed and all
installation work must be carried out professionally.
1.2 LOCATION
Since Whisper generating sets have extremely compact
dimensions, they can be installed in tight locations. Please
consider that even almost maintenance-free machinery
must still remain accessible.
When selecting the location area in which to mount the
generating set, make sure there is sufficient room to carry
out any maintenance work. The unit must be easily
accessible on the service side and on the distribution side
to have access to the V-belt.
Please also note that in spite of the automatic oil pressure
sensor it is still essential that the oil level is checked
regularly.
1.3 INSTRUCTIONS FOR OPTIMAL SOUND
AND VIBRATION INSULATION
Position the generating set as low as possible in the
vessel. As the generating set is already secured to the
base frame by means of flexible engine mountings, the
frame can be mounted directly to the vessel’s main
structure.
Whisper generating sets are standard equipped with a
sound cover. The canopy has been designed to give
effective sound insulation. For optimum sound and
vibration dampening, the following factors should be
considered.
1 Most important is the structure on which the
generator is places to be stiff. Directly below the
rubber mountings the structure should be supported
vertically to the superstructure of the ship.
2 Avoid mounting the generating set in close proximity
to thin walls or floors that may cause resonance.
3 Sound dampening is extremely poor if the generating
set is mounted on a light weight flimsy surface such
as plywood which will only amplify vibrations. If
mounting on a thinner surface cannot be avoided,
this should at least be reinforced with stiffening struts
or ribbing. If possible, holes should be bored or cut
through the surface to help reduce the resonance.
Covering the surrounding walls and floors with a
heavy coating plus foam will certainly improve the
situation.
4 Never connect the base of the generating set directly
to bulkheads or tanks.
Figure 1: Mounting of the Whisper generating set. X = wrong, V = OK

INSTALLATION
4June 2010 / M-SC6/8/10 - 3000RPM / EN
1.4 VENTILATION
The generating set normally draws air from the engine
room. Engine rooms with natural ventilation must have
vent openings of adequate size and location to enable the
generating set to operate without overheating. To allow an
ample supply of air within the temperature limits of the
generating set an opening of at least 100 cm2 is required.
A "sealed" engine compartment must have a good
extraction ventilator to maintain reasonable engine room
temperatures. High temperature of intake air reduces
engine performance and increases engine coolant
temperatures. Air temperatures above 40°C reduce the
engine power by 2% for each 5°C of rise. To minimise
these effects the engine room temperature must not be
more than 15ºC above the outside ambient air
temperature.
Apply a combination of ventilators, blowers and air intake
ducting to meet the temperature limit. The air inlet ducts
should run to the bottom of the engine room to clear fumes
from the bilge and to circulate fresh air. Air outlets should
be at the top of the engine room to remove the hottest air.
An engine room blower should be used as an extraction
ventilator to remove air from the engine room.
In cases where it is impossible to meet the above
mentioned temperature limit by using machine room
ventilation, connections are to be made for an air inlet
directly to the enclosure. With these connections the
generating set can be directly connected to an air duct.
Air inlets should be louvered, where appropriate, to protect
the engine room and to protect the generating set from
water spray. As an extra precaution, the fitting of a cowl
ventilator with a cover box located as high as possible, is
recommended.
1.5 CONNECTIONS
The generating set comes supplied with all supply lines
and output cable (i.e. electric cables, cooling water
connections, exhaust, fuel lines etc.) already connected to
the engine and generator. The supply lines are fed through
the capsule’s front base. The connections are marked as
shown in fig. 2.
All electrical connections, cable types and sizes must
comply with the appropriate national regulations. Supplied
cables are rated for ambient temperatures up to 70°C. If
the cables are required to meet higher temperature
requirements, they must be run through conduits.
ATTENTION!
Before working (installation) on the system
read the section safety instructions

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 5
Fig. 2: Connections M-SC6, 8 and 10.
01 Raw water inlet Ø19mm
02 Fuel out Ø8mm
03 Battery + 25mm2
04 Battery - 25mm2
05 Fuel in Ø8mm
06 Expansion tank Ø8mm
08 Bypass cooling water
out Ø19mm (3/4")
09 Bypass cooling water
in Ø19mm (3/4")
10 Exhaust hose Ø40mm
11 AC power output
12 Remote control
13 Engine air intake

INSTALLATION
6June 2010 / M-SC6/8/10 - 3000RPM / EN
1.5.1 Fuel supply
1 FUEL TANK
Fuel tanks should be made of appropriate material such as
(stainless) steel or plastic. Steel tanks should not be
galvanised or painted inside. Condensation can occur in
metal tanks when temperature changes. Therefore, water
accumulates at the bottom of the tank and provisions
should be made for the drainage of this water.
The tank will need a filling connection, a return connection
and an air ventilation connection which will require
protection against water entry.
Some official regulations do not allow connection points at
the base of the fuel tank; in this instance connections are
to be made at the top of the tank with internal tubing down
to a few cm above the bottom of the tank.
2 FUEL LIFT PUMP
The generating set itself is equipped with a fuel lift pump;
therefore the tank can be installed at a lower level than the
generating set. The maximum suction height is 1 m.
If the pump has to lift the fuel higher than one meter an
external fuel lift pump must be installed. The control board
is already prepared to connect an extra fuel pump.
3 FUEL PIPES
When the tank is above the generating set (figure 3)`we
recommend ending the return line on the top of the tank .
When the return is on the top - in case of a leakage the
return line cannot overflow because of siphoning. One will
only need a fuel cock in the fuel supply line.
When the tank is below the generating set (figure 4) we
recommend ending the return line on the bottom of the
tank (A) below the inlet of the supply line to discharge
under the lowest fuel level. This prevents air getting into
the fuel line. Here also one needs a fuel cock only in the
supply line
Both supply and return fuel pipe lines should be
appropriate material and 8 mm outer diameter tubing. The
quality of the tubing of fuel pipes could be submitted to
local regulations depending on the application of the
vessel.
The fuel pipes can be plumbed to the flexible hoses which
are on the generating set and have a connection to fit to 8
mm pipe. This fuel lines fulfils CE standards and are
according to ISO 7840 A2. It is important to avoid bends in
the pipes, as they could trap air bubbles. The return pipe
should never be connected to the suction pipe. Other
consumers of diesel fuel, such as the propulsion engine
and heaters, have to be connected to separate suction
and return pipes.
4 FUEL FILTERS
A fine fuel filter is installed which requires maintenance.
Whisper Power advises to install an extra fuel filter/ water
fuel separator near the fuel tank.
Before starting your generating set for the first time follow
the fuel system bleeding procedure in the user manual.

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 7
Fig. 3: Fuel supply (fuel tank is above the generating set)
Fig. 4: Fuel supply (fuel tank is below the generating set)
1 Fuel return;
2 Fuel supply;
3 Prefilter / water separator (optional);
5 Fuel tank;
1 Fuel return;
2 Fuel supply;
3 Prefilter / water separator (optional);
4 Extra fuel lift pump (optional);
5 Fuel tank;

INSTALLATION
8June 2010 / M-SC6/8/10 - 3000RPM / EN
1.5.2 Cooling
Intercooling is based on a raw water pump, heat
exchanger and water-injected exhaust. Cooling liquid in
the internal cooling system is cooled in a heatexchanger
by outboard water (raw water or seawater). After the raw
water is warmed up in the heatexchanger it is dumped
overboard by injecting it in the exhaust.
The generating set should have its own sea water (coolant
water) inlet and should not be connected to any other
engine systems. A properly installed cooling system is
critical to keep engine temperatures within an acceptable
range. Ensure that the installation complies to the
following installation instructions.
1 THE INTERNAL COOLING SYSTEM
The internal cooling system should be filled with cooling
liquid. (Refer to the user manual 2.5.12) When the engine
becomes hot the liquid expands and the system is
pressurised. After the pressure becomes too high the
release valve in the filling cap on the manifold opens and
the expanding liquid is pressed into the expansion tank
that is in the delivery. Also the air in the system that is
collected at the top of the manifold is released in this way.
When the liquid cools down there will be under-pressure.
Another valve opens and the liquid is sucked into the
manifold again. This system works only when there is
enough liquid initially. This has to be checked when
commissioning the generator set. By filling up the
expansion tank when necessary there will always be
enough liquid in the system. The hose that is in the
delivery has to be connected to the connection on the side
of the filling cap. This hose is made of heat resistant
plastic and is not sensitive for kinks.
The tank has to be placed close to the generator. When it
is mounted above the top of the manifold the liquid in the
tank will be drained when the cap on the manifold is taken
off. When keel cooling or radiator cooling is applied the
system will not be pressurised. A cap without releasevalve
should be applied. Refer to the special manual for these
applications.
2 RAW WATER SUPPLY
For raw water supply the following installation materials
are required: -a skin fitting - a sea cock - a water strainer -
hoses and clamps. In order to keep the suction resistance
in the line at a minimum, the sea water intake system (i.e.
sea cock, tru-hull fitting, inlet filter, etc.) must have an
inner diameter of at least:
Model Minimum inner diameter
M-SC6 – 3000 rpm 19 mm (3/4")
M-SC8 – 3000 rpm 19 mm (3/4")
M-SC10 – 3000 rpm 19 mm (3/4")
Fig.5: Expansion tank placement
1 Water level 5 Air vent;
2 Water/exhaust separator 6 Water strainer;
3 Seacock 7 Seacock.
4 Waterlock
Fig. 6: Internal cooling system

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 9
The suction hose should be kept as short as possible.
Raw water plumbing should avoid bends as much as
possible.
Restriction of raw water flow, caused by kinked hoses,
undersized pipes or connections, will reduce the engine
cooling capability. This is the main cause for overheating
of an engine.
After running the generating set for the first time, check the
coolant flow rate using a stopwatch and by holding a pail
of a known volume under the wet-exhaust outlet. The flow
rate should be according to the data in the user manual.
3 INSTALLATION OF THROUGH HULL FITTING
It is good practice for yachts to use a hull inlet fitting with
an integrated strainer (water scoop). For propulsion
engines in motorboats the water scoop is often mounted
against the sailing direction to induce more water intake
for cooling.
This should not be done in the case of a
generating set! When sailing at higher
speeds, water will be forced into the inlet and
your generating set will overflow!
Fig. 7 Installing water intake
On motorboats and on sailing boats the water scoop for a
generating set should be fitted with the opening faced
backwards to prevent water being forced in during sailing.
Use a sealant when mounting the skin fitting.
4 WATER STRAINER
Use an appropriate water strainer with connections of the
following dimensions:
Model Inner dimensions
M-SC6 – 3000 rpm 19 mm (3/4")
M-SC8 – 3000 rpm 19 mm (3/4")
M-SC10 – 3000 rpm 19 mm (3/4")
Install the water strainer in a well accessible position,
(refer to fig. 6-6) 5 cm above the waterline.
5 SIPHON BREAKER (AIR VENT)
When the point of water injection is below the waterline,
then -when the engine is stopped -there is a risk that the
cooling water may enter the engine as a result of
siphoning. To avoid this happening, the generating set is
designed to accommodate a siphon breaker (air vent). In
the standard delivery the connections are bypassed. See
figure 8.
Fig. 8: Bypassed siphon breaker connections
Hoses with the following inner diameter should be used:
Model Inner dimensions
M-SC6 – 3000 rpm 19 mm (3/4")
M-SC8 – 3000 rpm 19 mm (3/4")
M-SC10 – 3000 rpm 19 mm (3/4")
If the generating set cannot be mounted such that the
bottom of the generating set is placed above the waterline,
an air vent must be installed. See figure 9.
Extend the water hose of the by-pass 60 cm above
waterline and install an air vent. Ideally, the air vent should
be mounted above the yacht keel center line (i.e. to
minimize the influence of swaying on the water intake).
Fast motorboats will lay deeper when sailing at large
speed and can cause pressure on the waterinlet. This
should be avoided to prevent fleeding the engine.
If the air vent is clogged the water hoses will
not be vented when the generating set has
stopped and water can be forced into the
engine. This leads to immediate engine
problems and eventually severe damage!
SAILING DIRECTION
SAILING DIRECTION
FLOW DIRECTION
FLOW DIRECTION

INSTALLATION
10 June 2010 / M-SC6/8/10 - 3000RPM / EN
DAMAGE CAUSED BY THE INGRESS OF WATER IN
THE ENGINE IS NOT COVERED BY WARRANTEE
Figure 9: Siphon breaker connected
On the valve is a little hose to drain a little water that could
be spilled from the valve. This hose should go down and
may not end under water, because it should ventilate air
into the valve to break the siphoning.
OPEN
Fig 10: Wrong siphon breaker hose routing
Check the air vent at regular intervals. Open, clean and
lubricate the valve as required.
1.5.3 Exhaust system
Water is injected in the exhaust system of the generating
set. In this way the cooling water that has passed the heat
exchanger is mixed with the exhaust gases. Temperature
and volume of the gases are thereby reduced
considerably, so that a rubber exhaust hose can be used
and the level of noise is reduced as well.
OPEN
Fig. 11: Whisper Power siphon breaker
1 STANDARD EXHAUST SYSTEM INSTALLATION
The generating set exhaust system must remain
completely independent and separate from the exhaust
system of any other engine on board. A water lock
prevents the generating set from being flooded by cooling
water and should be installed as close to the generating
set as possible. The lock must be large enough to hold the
entire water volume held in the hose from the top of the
goose neck to the water lock. The water lock must be
installed at the lowest point of the exhaust system (ref. to
fig. 10-1). The exhaust hose must have an inner diameter
of 40 mm (1⅝”) no less, no more. The exhaust system
must be installed so that the back pressure inside the
exhaust does not exceed 0.07 bar (1psi – 70 cm
watercolumn) and total length from the genearot to the top
of the goose neck or or water/separator does not exceed
3m (10 ft.). (Refer to paragraph 5.4.3 of the user manual).
The exhaust hose descends from the capsule to the water
lock. Then the hose rises via the "goose neck" to the
through-hull exhaust outlet, situated minimum 5 cm (2")
above the water line (ref. to fig. 12-5.) The "goose neck"
must be vertical and situated preferable along the ship’s
keel center line. If the generating set is mounted less than
60 cm (24") above the waterline, a "goose neck" must be
installed to prevent the engine from overflowing. It is
recommended to install an extra muffler close to the
through-hull fitting.

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 11
1 Exhaust water lock; 4 Goose neck;
2 Exhaust outlet muffler; 5 Through-hull exhaust outlet Ø 40 mm (1 5/8”);
Fig. 12 3 Exhaust line Ø 40 mm (1 5/8”); 6 Water level.

INSTALLATION
12 June 2010 / M-SC6/8/10 - 3000RPM / EN
1 Water level 3 Seacock
Figure 13 2 Water/exhaust separator 4 Waterlock
Figure 14: Only after the exhaust / water separator the exhaust hose may have a length of over 7.5 meter

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 13
2 "SUPER SILENT" EXHAUST SYSTEM
See figure 11. In order to reduce the noise level of the
generating set to a minimum, an option to reduce the
exhaust noise further (especially exhaust water splashing)
is an exhaust/water separator. The exhaust/water
separator allows the cooling water to be ejected through a
line separate from the exhaust fumes and also functions
as a goose neck to prevent water from flooding the engine.
If the exhaust/water separator is mounted more than 60
cm above the water level an additional goose neck is not
required.
If the through-hull exhaust outlet has to be mounted far
from the generating set (Total length of the exhaust piping
from generator to top of goose neck (water separator) is
more than 3m.), an exhaust/water separator must
definitely be installed. The sea water from the separator
must then run down along the shortest possible path to the
through-hull outlet.
Only after the exhaust/water separator the exhaust hose
may have a length of over 7,5 m if the exhaust hose
diameter is also increased from Ø 40 mm (1 5/8”) to 51 mm
(2”) in order to reduce the back pressure (ref. to figure 12)
However watertraps should be avoided as the fumes still
contains water and this should not accumulate in bents
(refer to figures 15 and 16). An additional outlet exhaust
muffler close to the hull outlet will help further to reduce
noise emission.
Fig.15: Water trap in exhaust system
Figure 16: Water will collect in the hanging bend of the exhaust gas hose and will cause back pressure
OK! WRONG!

INSTALLATION
14 June 2010 / M-SC6/8/10 - 3000RPM / EN
If the generating set and the exhaust system have been
installed correctly, neighbouring boats will not be disturbed
by generating set noise, With the "super silent" exhaust
system, generating set noises are almost inaudible. For
optimal noise reduction, the sea water outlet from the
exhaust/water separator (center outlet on the unit) should
be installed below the water level to eliminate noisy
splashing of the effluent sea water.
The through-hull outlet for the exhaust fumes should not
direct the fumes directly toward the water surface as this
will cause excessive noise (ref. to fig. 17).
Do not direct the outlet directly toward the
water surface.
Figure 17: Outlet direction
1.5.4 Digital Diesel Control system (12 Volt)
1 DIGITAL DIESEL CONTROL SYSTEM
The electrical control system is standard in 12 Volt with
negative earth. Non- earth return is available as an option
for aluminium vessels to prevent corrosion.
All electrical wiring has been prepared on the generating
set to the control panel prior to despatch from the factory.
The engine is controlled by a very advanced
microprocessor based system: Digital Diesel Control.
The “black box” containing the microprocessor is located
on top of the alternator.
A local control panel is on the generating set.
Remote control
A remote control panel also containing a microprocessor is
in the delivery. A 15 m intermediate 8-pole communication
cable is in the standard supply as well (refer to fig. 18). If
necessary an optional longer (up to 30m / 100ft)
intermediate cable can be connected if the standard length
does not suit the required distance. When a longer
distance than 30m / 100ft is required, consult the Whisper
Power service department for advice.
Fig. 18: Remote control cable
OK!
WRONG!

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 15
One can mount the control panel after drilling a hole in the
dashboard using the plastic cover. Refer to the
dimensional drawing in paragraph 3.5. The panel without
the plastic cover fits the Mastervision modular panel
system.
More remote control panels (slave panels) can be put in
parallel by using the modular connectors on the back of
the units. As a slave one can use the same panel offering
all functions again. It is also possible to use an old or new
type slave panel only to start and stop the generator.
Old type remote panels and system panels can be
connected by means of the green connector.
Pay attention to the colour codes as indicated in fig. 19
when fitting cable to the green connector. Some software
versions in old system panels (supplied before May 2004)
could conflict with the software in the DDC and an update
of the software of the system panel could be necessary.
When this is the case consult to the Whisper Power
service department for advice.
When using the factory settings, installation is very simple:
just plug the remote cable into the remote and the
generator is ready to use. Refer to fig. 19.
WIRING COLOURS
RED
GREEN
BROWN
YELLOW
PINK
PURPLE
BLUE
WHITE
GREY/ PI NK
GREY
RED/BLUE
BLACK
MAX. 150 mA
WARNING RELAY
REMOTE CABLE
REMOTE CABLE
2
1
5
4
3
8
7
6
11
10
9
12
SENSE BAT. 2
121110987654321
Whisper Remote Panel
WRP/2
J3
Fig. 19 Remote box terminals
Acoustic alarm or warning lamp
One can connect an external max.150 mA relay to
generate an acoustic warning or applying a warning lamp
etc. Be aware of polarity as some relays has a diode
inside and should be connected plus to plus en minus to
minus as indicated. Refer to fig. 19.
Connection for emergency stop / fire alarm switch
To connect an emergency stop button or to stop the
generator automatically in case of a fire alarm, you can
use the bypass connection between fastons J7 and J18 on
the backside of the local control panel. See fig. 20. To do
so, remove this bypass connection and then replace it by
an emergency switch or a potential free fire alarm switch
with normally closed contacts.
Fig. 20: Connection for emergency stop / fire alarm switch
Automatic start/stop
Whisper Power cannot be held responsible
for damage caused by the unattended
running generator using the auto-
start/stop mode or interval mode.
Using the auto-start/stop (interval) mode
the generator can start unexpectedly.
When working on the electrical system, the
3 Amp fuse must be removed from the
control panel and the battery plus cable
must be removed from the battery.
The Whisper Power Digital Diesel Control system offers
several options for automatic starting and stopping.
Access to this menu and other menus could be blocked.
For blocking and setting up this options refer to the
APPENDIX of the DDC users manual.
Remove bypass
between J7 - J18
Normal operation
Alarm / emergency
local control panel
(rear view)

INSTALLATION
16 June 2010 / M-SC6/8/10 - 3000RPM / EN
One of these options is to monitor a second battery (not
being the starter battery) to start the generator
automatically when the voltage of this battery drops below
a certain setting.
Other names for this second battery are “auxiliary battery”,
“service battery”, ”users battery” or “consumers battery”.
We will refer to this battery as “the second battery”(BAT2).
In some menus the starter battery could be indicated as
“the first battery” (BAT1).
A sense wire to monitor the second battery should be
connected (attention polarity!) to the connector on the
back of the remote panel. Refer to fig. 17. The sense wires
must be connected directly on the second battery before a
main switch and be protected by a 3 Amps fuse.
(Monitoring the generator starter battery does not require
an extra sense connection)
Settings
When one want to apply other settings than the factory
settings refer to the DDC users manual, especially to the
APPENDIX.
2 STARTER BATTERY
For starting, the Whisper generator requires a 12V starter
battery with the following capacity:
Model Minimum capacity
M-SC6 – 3000 rpm 60 Ah
M-SC8 – 3000 rpm 60 Ah
M-SC10 – 3000 rpm 60 Ah
The generating set can be connected with the main engine
battery or have its own battery.
We strongly recommend the use of a separate battery for
the generating set and to keep the wiring system for the
propulsion engine and the domestic DC supply system
completely separate and individually connected to
separate batteries.
Fig. 21 Starter battery
However, the negative of all the batteries on the vessel
should be interconnected (when on earth) to avoid
difference in the voltage level of the earth on different
places causing trouble to electronic devices which might
be in the system.
The above recommendation is not valid for ships having
the starter battery of the propulsion engine or other
auxiliary equipment positive grounded. When this is the
case an expert should be consulted.
A battery switch may be used.
The starter battery is charged by the standard internal
charger in the alternator. An additional battery charger will
help to keep the battery in good condition when the
generating set is not used. A battery charger is not
included in the standard supply. A high efficiency battery
charging unit can be ordered from Whisper Power which is
able to charge both the ship’s main battery and the starter
battery. Also a small charger can be used to charge the
starter battery only, such as the IVO SMART 12/10. A
battery switch and a charger are included in the battery
installation kit, art. no. 50230210 (70Ah).

INSTALLATION
EN / M-SC6/8/10 - 3000RPM / June 2010 17
3 OTHER RECOMMENDATIONS AND WARNINGS
The battery should be secured for seagoing conditions and
the terminals should be insulated. For extra safety the
battery can be enclosed in a wooden, plastic, Fiberglas
etc. (non metal) box. Even when the earth return system is
applied a negative battery cable should be used and the
vessel should not to be used as a conductor.
In the negative battery cable a 250 Amp starter battery
switch could be applied to switch off the battery. The
battery cables are supplied in a standard length of 1.5 m, if
longer cables are required a larger cross sectional area
should be considered to compensate for voltage reduction.
When two batteries are used in series to provide a 24 Volt
supply system, never take off 12 Volt (starting) power from
one of these batteries. This will result in severe damage to
the batteries within a short time.
Disconnect the battery leads if electrical welding is to be
carried out, otherwise damage will be caused to the diodes
of the alternator.
As explosive hydrogen gases are discharged
during charging, the battery should be located
in a well ventilated room. Ensure that the
supplied battery cable connectors are properly
fitted and never remove during or shortly after
charging as sparking can occur, which may
ignite the hydrogen gasses.
1.5.5 AC power system (230 Volt)
Before working (installation) on the system
read the sections on safety in the user
manual.
Be sure that all electrical installations (including all safety
systems) comply with all required regulations of the local
authorities. All electrical safety/shutdown and circuit
breaking systems have to be installed onboard as the
generating set itself cannot be equipped with such
equipment for every possible variation.
The vessel’s power supply system should be suitable and
safe for the AC voltage which is applied and the power
that will be generated. Special attention has to be paid on
dividing the system in branches which are fused
individually.
It is absolutely essential that each and every circuit in the
on-board electrical system is properly installed by a
qualified electrician.
1 FUSE
An output fuse (from the generating set to the system)
should be installed to protect the installed electrical
system. The following maximum output current applies for
each separate phase:
Model Maximum output current
M-SC6 – 3000 rpm 25 Amp
M-SC8 – 3000 rpm 32 Amp
M-SC10 – 3000 rpm 40 Amp
The fuses must be of the slow reacting type. For electrical
motors connected to the system, a motor protection switch
must be installed.

INSTALLATION
18 June 2010 / M-SC6/8/10 - 3000RPM / EN
2 GROUNDING
The AC alternator windings are not grounded.
Measures against earth insulation failures are often
subject to local regulations. The housing of the alternator
and all other metal parts are grounded. For safety reasons
connect the main ships ground to negative point of the
generating set start battery. When an ungrounded return
DC system or positive grounded DC system is applied the
battery negative should not be connected to the main
ships ground.
To make a connection between “neutral” and “ground”
could be necessary as part of a specific insulation failure
protection system.
Small pleasure craft in Europe is submitted to The
Recreational Craft Directive 94/25/EC. The guidelines of
this directive refer to (ISO 13297).
When the installation comply to this standard the “neutral”
and “ground” should be connected on the generating set
by connecting the blue (neutral) wire with the terminal on
which the yellow/green wire is connected.
WARNING
In all situations the transfer switches between
shore, inverter and generator should switch all
connections, the phase line (L) as wel as
neutral (N). Of course this is the case when
using a Masterswitch.
Be aware that insulation protection systems can be
different for different applications and even within the ship
there could be different standards for different spaces. We
did refer to the Recreational Craft Directive that applies to
pleasure craft up to 24 m of length. Sometimes one has to
comply with other standards such as the rules of
certification societies like Lloyds Register of Shipping or
Veritas, regulations for the protection of personal, building
legislation, etc. It is of the greatest importance to have
expert advice on this issue.
For safety reasons connect the main ships ground to
negative point of the generating set start battery. When a
ungrounded DC system or positive grounded DC system is
applied the battery negative should not be connected to
then main ships ground.
3 CABLE
For the power cable we recommend the oil resistant cable
with the following cross sectional area:
Model cross sectional area
M-SC6 – 3000 rpm 3x4 mm² (5m. included)
M-SC8 – 3000 rpm 3x4 mm² (5m. included)
M-SC10 – 3000 rpm 3x10 mm2 (not included)
For very long cables it is recommended to apply cables
with a larger cross section than the mentioned above.
4 TRANSFER SWITCH
A power source selector switch much be installed between
the generating set and the ship’s electrical supply system.
This switch must ensure that all AC consumers can be
switched off at once. This switch should also be installed
to keep the generating set and shore (grid) power systems
separate.
Transfer switches - to switch over from shore to ship or
from generating set to inverter - should be well designed to
switch over all wires including neutral (and not only phases
or line) and there should be provisions with the aid of
timers to prevent relays from chattering.
Whisper Power advises the installation of a Masterswitch
as the power source selector. This works automatically
when the generating set is not running the input remains in
the shore position and as soon as the generating set is
running the Masterswitch switches automatically after 10
seconds delay time over to the generating set position.

INSTALLATION SPECIFICATIONS
EN / M-SC6/8/10 - 3000RPM / June 2010 19
2 INSTALLATION SPECIFICATIONS
2.1 INSTALLATION TABLE
1 Mount the generating set directly, without additional
vibration dampers, on a solid surface.
2 Connect the (sea) water inlet to the strainer.
3 Connect exhaust system.
4 Connect a siphon breaker or ‘air vent’ into the cooling
circuit, if necessary.
5 Connect ‘fuel supply line’ to the water separator/ fuel
filter.
6 Connect ‘fuel return line’ to the fuel tank.
7 Connect remote panel (just plug in).
8 Connect the AC cable from the AC box to the power
source selector or Masterswitch.
9 Connect plus and minus from the 12V starter battery
to the battery cables.
10 Install a Whisper Power battery charger. (optional)
2.2 COMMISSION TABLE
1 Check if a siphon breaker (air vent) is necessary and
has been installed
2 Open the seawater inlet valve and check all water
connections. Check if the strainer is installed above
the seawater level.
3 Check if the exhaust system is properly installed.
Check maximum length of exhaust hose, diameter of
exhaust hose, position of the waterlock, maximum lift.
Also check the minimum required height of 60 cm
(24”) above sea level of the exhaust loop (goose
neck).
4 Open the seawater outlet valve and check all water
connections.
5 Check the AC cables and the grounding.
6 Check if an AC breaker is installed before or after the
power source selector. When there is only a circuit
breaker, use it to disconnect the generating set from
the grid.
7 Check all DC connections, check if the battery switch/
circuit breaker is closed.
8 Open the fuel valve and bleed the fuel system. Check
if there are no air leaks in the fuel supply line, and
check if the lift of the fuel is less than 1 meter (3 ft).
Check if there is no air in the water fuel separator.
9 Check if the air intake in the canopy is not blocked.
10 Check the oil level and color of the oil. Check the
coolant level
11 To bleed the fuel system push the startbutton on the
local control (not on the remote) and hold at least 5
seconds and as long as necessary to bleed the
system.
12 Start the engine by pushing the start button.
13 Check when the generating set is running, the delay
of 5 to 10 seconds in the power source selector
transfer.
14 Check voltage and frequency under ‘no load’
conditions.
15 Check voltage and frequency under ‘full load’
conditions.
16 Check if the battery charger of the generating set is
working (max. 14.5 Volt).
17 Close the sound shield and check the noise level.
18 Stop the generating set and check the engine again
for leakages of oil, fuel or water.
Installation checklist available on our website:
www.whisperpower.eu.
Commissioning form available on our website:
www.whisperpower.eu.

INSTALLATION SPECIFICATIONS
20 June 2010 / M-SC6/8/10 - 3000RPM / EN
2.3 INSTALLATION SPECIFICATIONS M-SC6, 8 AND 10 – 3000RPM
TECHNICAL DATA
M-SC6 M-SC8 M-SC10
Dimensions wxdxh. 69.0 x 52.5 x 58.0 cm 69.0 x 52.5 x 58.0 cm 80.5 x 52.5 x 58.0 cm
Weight including sound shield 200 kg 200 kg 240 kg
Max. operation angle 25° 25° 25°
Remote panel 15 m cable Digital Diesel Control System
Battery capacity min. 12V, 60 Ah 12V, 60 Ah 12V, 60 Ah
Fuel consumption 1,5 – 4 l/hr, load dependent
Lift fuel pump electric driven 12 V DC, max. lift 1 m
Cooling indirect cooling
Cooling pump raw water Whisper Power self priming impeller pump, PTO driven, type M
Minimum water supply 9-15 l/min 9-15 l/min 9-15 l/min
Crank case lube oil capacity 2.4l.+0.5l oil filter, total 2.9l. 2.4l.+0.5l oil filter, total 2.9l. 3.6l.+0.5l oil filter, total 4.1l
Alternator synchronous brushless, maintenance free water cooled
Voltage regulation Capacitor Capacitor capacitor + AVR
Output power at
power factor cos phi = 1
5.2 kW, 230V 50 Hz 6.4 kW, 230V 50Hz 9.4 kW, 230V 50Hz
Battery charger alternator including regulator (40 Amps)
2.4 SPECIFICATION OF THE ACCESSORIES
Water scoop 3/4” = 19 mm
Inlet valve 3/4” in 19 mm out
Water strainer 19 mm in, 19 mm out
Air vent 19 mm
Inlet suction hose 19 mm
Fuel filter/water separator 30 micron
Fuel inlet and return 8 mm
Exhaust hose in/out Ø 40 mm / 1⅝”
Water lock Ø 40 mm / 1⅝”
Water/gas separator Ø 40 mm / 1⅝”
Anti shock mounts art. nr. 50230552
Foundation plate min. 60 kg (only for the M-SC6 and 8)
Battery charger (optional) IVO SMART 12/10; 12V / 10 Amps, 230V/50Hz
