WHITE KNIGHT 427SVNC
Air Vented Dryer - UK
0312 427 15310
SERVICE MANUAL
Wiring Diagram
Exploded Views
Parts List
May 2007
369
394
196
403
353
211
352
386
385
248
370
449
391
235
450
376
362
367
201
366
365
364
363
359
203a 363a
203
199
White Knight Air Vented Dryer - Exploded View 1
White Knight Air Vented Dryer - Exploded View 2
446
112
447
432
101
437
402
427
399
400
413
230
390
395
227
125
142
408
228
393
270
141
444
266
144
White Knight Air Vented Dryer- Exploded View 3
440
441
442
248
454
437
445
446
447a
537a
447
229
445a
456
457
458
459
448
White Knight 427SVNC Air Vented Dryer - Wiring Diagram
Colour Code
A
B
C
D
E
F
G
H
K
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
White
TH(I)
TK
CON
DS
HE
HES
M
MC
TH(E)
CS
TB
TDM
C
TI
MRTL
Thermostat (inlet)
Temperature Limiter
Connecting Link
Door Switch
Heater
Heat Switch
Motor
Mains Cord
Thermostat (exhaust)
Centrifugal Switch
Terminal Block
Tumble Dryer Motor
Capacitor
Timer
Temp Limiter (manual reset)
TI
TB
MC
DS
C
COM
TDM
HE
MRTL
HES
TH(E)
TH(I)
NL34TB TH(E)
60ºC
H
L
TI
M
M
MAX
120
MINS
M
N
10 K
APPROX. CON
TL
TDM
1
1
2
2
C
HES
HE
12
3
MRTL
TH(I)
146ºC
DS
White Knight 427SVNC - Parts List
Item Description Code Expl.View
101 Motor & 8µf Capacitor Assembly 4213 092 25611 2
112 8µf Capacitor 4213 092 08091 2
125 Drive Belt 4213 092 18601 2
141 Mains Cable & Plug 4213 076 35123 2
142 Terminal Block 4213 078 44613 2
144 Earth Tab Assembly 4213 092 41181 2
196 Cabinet Assembly 4213 092 36261 1
199 Ignis Plinth 4213 092 36271 1
201 Door Seal 4213 077 08344 1
203 Continental Full Door Assembly 4213 092 38201 1
203a Continental Door Frame Assembly 4213 092 38211 1
211 Timer 4213 078 54771 1
227 Heating Element 4213 092 05521 2
228 Heat TOC 4213 078 50161 2
229 Thermostat 4213 078 48373 3
230 Thermostat (inlet) 4213 078 56261 2
235 Rocker Switch 4213 078 51061 1
248 Microswitch/Bracket Assembly 4213 092 05251 1
266 Drum Assembly 4213 092 05531 2
270 Drum Shaft/Bearing Kit 4213 092 05591 2
352 Timer Knob Assembly 4213 092 36251 1
353 Control Panel Assembly 4213 092 36291 1
359 Continental Door Hinge Assembly 4213 092 25361 1
362 Window 4213 077 44095 1
363 Continental Door Frame 4213 077 84071 1
363a Continental Door Handle 4213 077 82861 1
364 Latch Pivot 4213 075 13013 1
365 Latch Spring 4213 075 70833 1
366 Door Latch 4213 077 53413 1
367 Switch Strike 4213 077 83571 1
369 Loom Clip 4213 075 70941 1
370 Latch Guide 4213 077 40992 1
376 Front Panel Assembly 4213 092 36301 1
385 Top Cover Bracket 4213 070 14541 1
386 Top Cover Assembly 4213 092 36141 1
390 Gasket 4213 074 50862 2
391 Push Button 4213 077 82741 1
393 Flex Support Clip 4213 077 40982 2
394 Foot 4213 077 39833 1
395 Heater Wires Clip 4213 075 70971 2
399 Heater Support 4213 080 06619 2
400 Heater Plate 4213 080 14551 2
402 Access Panel 4213 080 06555 2
403 Roller Assembly 4213 092 35651 1
413 Back Panel 4213 080 0654B 2
427 Motor Spring Clip 4213 078 45362 2
432 Motor Mount Bracket 4213 080 0675A 2
437 Vent Tube Assembly (short) 0312 002 02000 2 & 3
440 Banjo Assembly 4213 092 17811 3
441 Front Bearing (short) 4213 077 40952 3
442 Front Seal 4213 077 61701 3
444 Lifter 4213 077 41009 2
445 Front Bearing (long) 4213 077 40962 3
445a Bearings & Brush Seal Kit Assy 4213 092 21171 3
0312 427 15310
White Knight 427SVNC - Parts List
446 Fan 4213 077 40896 2 & 3
447 Access Cover Assembly 4213 092 18081 2 & 3
448 Spring Clip (Fan) 4213 075 71162 3
449 Button Switch Spring 4213 075 71151 1
450 Switch Bracket 4213 070 11631 1
454 Filter 4213 092 17821 3
456 Banjo Seal 4213 077 07991 3
457 J' Clip 2513 482 08002 3
458 Banjo Insert No 2 4213 077 53502 3
459 Banjo Insert No 1 4213 077 53492 3
471 U' Type Captive Nut 2513 483 12036 3
537 W' Button Plug 4213 078 26311 3
Loom Assembly 4213 076 41933
INSTRUCTION BOOK - 4213 094 5932C
Not shown on exploded views
0312 427 15310

This manual suits for next models
