White Rodgers 3L09 User manual

To prevent electrical shock and/or equipment
damage, disconnect electric power to system at
main fuse or circuit breaker box until installation
is complete.
Label all wires prior to disconnection when ser-
vicingcontrols.Wiringerrorscancauseimproper
and dangerous operation.
Following installation or replacement, follow
appliancemanufacturers’recommendedinstal-
lation/service instructions to insure proper op-
eration.
PART NO. 37-6133A
9949
Printed in U.S.A.
DESCRIPTION
This series of limit controls has a normally closed SPST
switch that opens on temperature rise to limit the maxi-
mum allowable temperature in forced air heating sys-
PRECAUTIONS
THIS CONTROL MUST BE INSTALLED BY A QUALI-
FIED INSTALLER.
All wiring must conform to local and national electrical
codes and ordinances.
This control is a precision instrument, and should be
handled carefully. Rough handling or distorting compo-
nents could cause the control to malfunction.
Thiscontrolhasbeenaccuratelycalibratedatthefactory.
Anyattempttore-calibratethiscontrolwillvoidtheWhite-
Rodgers warranty.
Do not use on circuits exceeding specified volt-
ages. Higher voltages will damage control and
could cause shock or fire hazard.
If in doubt about whether your wiring is millivolt,
low or line voltage, have it inspected by a quali-
fied heating and air conditioning contractor or a
licensed electrician.
CAUTION
!
tems.Asmallbimetalsensingelementislocatedintheair
stream for quick response. These controls have a fixed
temperature setting and fixed differential.
WARNING
!
SPECIFICATIONS
ELECTRICAL RATING:
Resistive: 15 amps @ 120 VAC
13 amps @ 240 VAC
9.3 amps @ 277 VAC
Inductive: 5.8 FLA, 34.8 LRA @ 120 VAC
2.9 FLA, 13.0 LRA @ 240 VAC
Pilot Duty: 278 VA
Temperature Setting:
Fixed setting stamped on control
WHITE-RODGERS DIVISION
EMERSON ELECTRIC CO.
9797 REAVIS ROAD
ST. LOUIS, MISSOURI 63123-5398
3L09
Limit Controls
WHITE-RODGERS
INSTALLATION INSTRUCTIONS
Operator: Save these instructions for future use!
FAILURETOREADANDFOLLOWALLINSTRUCTIONSCAREFULLYBEFORE
INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL
INJURY AND/OR PROPERTY DAMAGE.
This control must be mounted in the air stream of the
appliance. Follow the original equipment manufacturers’
recommendations for proper location and wiring.
Wiring
All wiring must conform to local and national
electrical codes and ordinances.
INSTALLATION
