Wibramet PL1 User manual
LINEAR FEEDERS - MANUAL
WIBRAMET Piotr Sokołowski
Ul. Gnieźnieńska 68
75-736 Koszalin
NIP: 669-236-08-63
PAGE 2
1. INTENDED USE
Vibratory linear feeder is intended for
lengthen feeding line of orientated, in bowl
feeders, components. Field of use: automatic
assembly, packing, controlling, machining
stations, transport of loose materials.
The vibratory feeder is an integral part of the
stands.
The device operates in normal ambient
conditions within temperature range from +5
to +35˚C.
2. WARNINGS
2.1 Do not connect the feeder to the power
supply network without proper supplying
controller provided for this purpose.
2.2 Do not pour any liquid on the feeder
during its cleaning.
2.3 Any maintenance and repair operations
should be done only if the power supply plug
is taken out from the power supply network
socket.
2.4 Do not operate the feeder before it is set
on rubber shock absorbers (6) located in the
base.
2.5 Do not used feeders in any explosive
atmosphere.
2.6 Do not use feeder without electromagnet
cover (3).
2.7 The electromagnetic field! People with
fitted cardiac pacemakers have to keep
distance of 0,5 meters from the vibratory
feeder.
3. DESIGN DESCRIPTION
Vibratory linear feeder consist of following
parts:
Feeder is equipped with set of flat springs
(made from steel or plastic) and
electromagnet with regulated gap.
Electronic controllers with step-less feed
speed control are supplied in various versions
depending on individual arrangements made
with the customer.
Feeder is equipped in 4 pieces of absorber.
Feeder need to be mount to device by holes
into bottom of absorber.
4. TECHNICAL DATA
For standard feeder technical parameters see
table no. 1.
Feeder in standard version doesn’t have guide
rail.
5. MOUNTING OF GUIDE RAIL
To mount guide rail use 4 treaded holes in
aluminium support plate (2).
Structure of rail should be light and stiff.
Mass of rail shouldn’t exceed the maximum –
see table 1.
Recommended dimensions of rail behind and
in front of aluminium support plate (2) are
marked in drawing.
It is good to lean the feeder by angle 3 to 4˚ to
outlet.
6. FEEDER STARTING
Feeder is supplied with controller.
To start feeder please insert controller plug
into electrical socket 230V/50Hz.
Press the start button and set transmission
performance by knob.
LINEAR FEEDERS - MANUAL
WIBRAMET Piotr Sokołowski
Ul. Gnieźnieńska 68
75-736 Koszalin
NIP: 669-236-08-63
PAGE 3
7. CONTROLLERS
Supply the feeders only from controllers
intended for cooperation with vibratory
feeders.
Preferred controllers are delivered with the
feeder.
The controllers delivered may possess
extensive functional options described in the
manufacturer’s instructions.
The frequency of supply vibrating feeder must
be adjust to frequency of mechanical
vibrations for each feeder type (see tab.1).
8. MAINTANCE
Linear feeder hasn’t got any lubrication points
and doesn’t’ t require any special maintaining
operations during exploitation.
In the event of occurrence of noise exceeding
70dB (without any elements in the guide rail)
or reduction of speed, please check:
•Size of „S” electromagnet operating
gap (for recommended gap to be
applied in given feeder type –see
Table 1 Technical Data).
•Flat springs (5) fixing.
•Flat springs (5) condition –replace any
broken spring.
•Guide rail fixing.
•Electromagnet cover fixing.
•Is feeder blocked by direct touch with
any other device.
9. STORAGE AND TRANSPORT
Transport the feeder on board any covered
means of transport.
Linear feeder please transport packed in box.
Keep the feeders in closed rooms to protected
them against influence of weather conditions.
Ambient temperature: +5 to +35°C.
10. LIST OF DRAWINGS AND
DOCUMENTS ATTACHED
•Drawing 1 –feeder type PL 1.
•Drawing 2 –feeder type PL 2.
•Drawing 3 –feeder type PL 3.
•Table 1 –standard technical
parameters.
•Table 2 –list of important parts.
•Wiring diagram.
•EC Declaration of Conformity.
11. SERVICE PROVIDED BY
„WIBRAMET Piotr Sokołowski ”
75-736 Koszalin st. Gnieźnieńska 68.
POLAND
Tel./fax. (094) 345- 75- 00
www.wibramet.pl
e-mail:info@wibramet.pl
LINEAR FEEDERS - MANUAL
WIBRAMET Piotr Sokołowski
Ul. Gnieźnieńska 68
75-736 Koszalin
NIP: 669-236-08-63
PAGE 4
TAB.1. STANDARD TECHNICAL PARAMETERS.
Characteristics
Unit
PL 1
PL 2
PL 3
Mass (without guide rail)
kg
2
5
22
Quantity
m/min
0 - 3
0 - 6
0 - 6
Guide rail length
mm
140-200
250 - 500
350 - 800
Optimum guide rail mass
kg
0,2 - 0,7
1,0 - 2,0
2,0 - 8,0
Power supply
V/Hz
230/50
230/50
230/50
Absorbers (46°Sh)
mm
Ø15
Ø15
Ø30
Flat springs
≠ mm
1,5
1,5
3
Mounting to table
-
4 x M4
4 x M4
4 x M8
Mounting of guide rail or hopper
-
4szt. M5
4szt. M5
4szt. M8
Operating gap S
mm
0,3
0,7
0,8
Bolts to regulate operating gap
-
2 pcs M4
2 pcs M5
2 pcs M8
Power max.
VA
12
25
90
Vibrating frequency
1/min
6000
6000
3000
TAB.2. IMPORTANT PARTS LIST.
Drawing pos.
Name
Qty.
1.
Lower support
1
2.
Upper support
1
3.
Cover
2
4.
Electromagnet
1
4.1
Core
1
4.2
Dowel
1
5.
Flat spring
6
6.
Absorber
4
7.
Bolt to regulate
2
8.
Weight
1
PAGE 6
DRAWING 1. LINEAR FEEDER TYPE PL 1.
PAGE 7
DRAWING 2. LINEAR FEEDER TYPE PL 2.
PAGE 8
DRAWING 3. LINEAR FEEDER TYPE PL 3.
