Wicked Warnings LIN-8 Installation instructions

WIRE
RED: Positive
BLACK: Negative
BLUE: Pattern Select to Negative
YELLOW: Synchronized Function
White: Steady Burn to Positive (Optional)
*Maximum of 8 pcs LIN-8 Series can be
synchronized within P1 to P48
OPERATION
Apply BLUE TO BLACK wire:
●Less than 1 sec. for next pattern.
●Between 1-3 sec. for previous pattern.
●Between 3-5 sec. for Factory Default.
● More than 5 sec for last pattern.
Wicked Warnings LIN-8
Installation and Operation Instructions
IMPORTANT: Please read all of the following instructions before installing your new LIN-8. WARNING: Failure to install or use this product
according to manufacturer’s recommendations may result in property damage, serious injury, and/or death to those you seek to protect!
TROUBLESHOOTING
The LIN-8 series has been factory tested and approved. If
the functions of device fail, please check the following:
1. After connecting with the power supply, be sure that
the power source end is joined in correct way. And
then, make sure that there is no short circuited
power occurring.
2. Ensure Power switch is turned to "ON" position.
3. Press the Pattern Switch to be sure the “OFF” pattern
is not selected. If the blue wire touches black wire
over 5 seconds, it would switch to OFF pattern. It
would be lighted up again when using blue wire
touches black wire less than 1 second.
4. To synchronize 2 lights together, first set both lights
on the same pattern. 2nd connect the YELLOW wires
together for the lights you want synchronized (max
8) and they will either flash simultaneously or
alternating depending on the phase of pattern you
chose.
www.wickedwarnings.com ● [email protected] ● [phone]
INCLUDED ITEMS
Inspect the contents to be certain that the following
items are included: Light Head (1), Screw (2), Mounting
Gasket (1), Option: Universal Mounting
SEE PATTERNS, MOUNTING DIAGRAM,
AND SAFETY INFORMATION ON THE
NEXT PAGE
SPECIFICATION
●Input Voltage: 10 – 30VDC
●Work Current: 1.0A max@DC12V, 0.6A
max@DC24V
●Waterproof: IP67
●Recommended Operation Environment:
Ambient Temperature: -30 to 50℃, Relative
Humidity: 10 to 85% , non-condensing.

Wicked Warnings LIN-8
Installation and Operation Instructions
PATTERNS & SAFETY
PATTERN TABLE
P1 Single 75FPM Ph1 Color 1
P2 Single 75FPM Ph2 Color 1
P3 Single 75FPM Ph1 Color 2
P4 Single 75FPM Ph2 Color 2
P5 Single 75FPM Ph1 Color 1 Alternately Color 2
P6 Single 75FPM Ph2 Color 1 Alternately Color 2
P7 Single 120FPM Ph1 Color 1
P8 Single 120FPM Ph2 Color 1
P9 Single 120FPM Ph1 Color 2
P10 Single 120FPM Ph2 Color 2
P11 Single 120FPM Ph1 Color 1 Alternately Color 2
P12 Single 120FPM Ph2 Color 1 Alternately Color 2
P13 Double 75FPM Ph1 Color 1
P14 Double 75FPM Ph2 Color 1
P15 Double 75FPM Ph1 Color 2
P16 Double 75FPM Ph2 Color 2
P17 Double 75FPM Ph1 Color 1 Alternately Color 2
P18 Double 75FPM Ph2 Color 1 Alternately Color 2
P19 Double 120FPM Ph1 Color 1
P20 Double 120FPM Ph2 Color 1
P21 Double 120FPM Ph1 Color 2
P22 Double 120FPM Ph2 Color 2
P23 Double 120FPM Ph1 Color 1 Alternately Color 2
P24 Double 120FPM Ph2 Color 1 Alternately Color 2
P25 Triple 75FPM Ph1 Color 1
P26 Triple 75FPM Ph2 Color 1
P27 Triple 75FPM Ph1 Color 2
P28 Triple 75FPM Ph2 Color 2
P29 Triple 75FPM Ph1 Color 1 Alternately Color 2
P30 Triple 75FPM Ph2 Color 1 Alternately Color 2
P31 Triple 150FPM Ph1 Color 1
P32 Triple 150FPM Ph2 Color 1
P33 Triple 150FPM Ph1 Color 2
P34 Triple 150FPM Ph2 Color 2
P35 Triple 150FPM Ph1 Color 1 Alternately Color 2
P36 Triple 150FPM Ph2 Color 1 Alternately Color 2
P37 Quad 75FPM Ph1 Color 1
SAFETY INSTRUCTIONS
*Do not stare directly into these lights.
*DO NOT install this product or route any wires in the Air Bag Deployment Zone.
Refer to vehicle Owner’s Manual for deployment zones.
*The installer must be sure that no vehicle components or other vital parts could be
damaged by the drilling process during installation.. Install grommets into all wire
passage holes.
*Inspect and operate this product regularly to confirm proper operation.
*For this product to operate at optimum efficiency, a good electrical connection to
chassis ground must be made. The recommended procedure requires the product
ground wire to be connected directly to the NEGATIVE (-) battery post.
If this product uses a remote device to activate or control this product, make sure
that this control is located in an area that allows for safe operation.
*FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD
RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO
YOU AND YOUR PASSENGERS.
www.wickedwarnings.com ● [email protected] ● [phone]
P38 Quad 75FPM Ph2 Color 1
P39 Quad 75FPM Ph1 Color 2
P40 Quad 75FPM Ph2 Color 2
P41 Quad 75FPM Ph1 Color 1 Alternately Color 2
P42 Quad 75FPM Ph2 Color 1 Alternately Color 2
P43 Quad 150FPM Ph1 Color 1
P44 Quad 150FPM Ph2 Color 1
P45 Quad 150FPM Ph1 Color 2
P46 Quad 150FPM Ph2 Color 2
P47 Quad 150FPM Ph1 Color 1 Alternately Color 2
P48 Quad 150FPM Ph2 Color 1 Alternately Color 2
P49 Steady burn - Color 1
P50 Steady burn - Color 2
