WiDMX Wireless DMX 512 User manual

USER’S MANUAL
GB
Wireless DMX 512 TRANSMITTER
DMX
W i
R

DESCRIPTION OF THE PANELS
GB
MAKING A DMX 512 SIGNAL CABLE
GB
1
2
2 3 5
4
Power input 5 Vdc 650 mA (included)
1
SMA antenna connector
5
Standard DMX 512 signal INPUT with a 3/5-pole XLR connector.
4
Red Button for change channel and pairing operation
3
Blue led :
Slow blinking: Transmitter OOKK, no DDMMXX551122signal.
Switched on : Transmitter OOKK, DDMMXX551122signal OOKK..
Wi DMX pro has a DMX 512 input that use standard XLR 5-pin or XLR 3-pin con-
nectors.
For the connection refer to the underlying picture
15
3
42
Common
DMX
-
DMX +
XLR 5-pin
1
3
2
Common
DMX
-
DMX +
XLR 3-pin

Power up Wi D Pen PRO receiver
RECEIVER PAIRING
GB
1
Hold the button until the Wi D Pen Pro led starts blinking r-g-b alternately
2
Remove power supply from WiDMX PRO
3
When the led stops fast blinking, the Wi D Pen Pro receiver is paired
5
Holding the red button, connect power supply and wait until the WiDMX PRO
led starts fast blinking
4
RICEVITORE / RECEIVER
Power input
RGB led
key
XLR Connector 3/5 pole
D PEN
W i

All rights reserved. No parts of this document can be copied, photocopied or reproduced without
the prior written permission of CCOODDEEMMMMUUSSIICCss..rr..ll..
No responibility is taken for possible inaccuracies or mistakes.
CCOODDEEMMMMUUSSIICCss..rr..ll..reserves the right to make any alterations or aesthetics changes of this
product that seem necessary at any time and for whatever reason.
CCOODDEEMMMMUUSSIICCss..rr..ll..takes no responsibility for the use or for the application of this product.
GB
CODEM MUSIC S.r.l. - Via G.Pierini, 13 - 61122 PESARO - ITALY
Tel. [phone] - Fax [phone]
http://www.wi-dmx.com - E-mail: [email protected]
Technical features:
Frequency range: 2,4 GHz - 2,483 GHz (ISM)
Number of channels: 20
Transmitter range: 500 meters/1640 feet open air
Voltage/current: 5 Vdc / 650 mA
Dimensions and weight:
Dimension (W x L x H) / Weight: 65 x 45 x 30 mm / 65 g
TRANSMITTER USE
GB
Always connect the provided power supply
!
In the event of radio problem, press the red button until Wi DMX PRO led do a
fast blinking (a new radio channel is set)
?
0122
!
FCC ID: UP2AWA24S
Canadian Cert No IC: 6797A-AWA24S
