WILDTOP WT11488 User manual

1 of 10
WILDTOP TRUCK CAPS
INSTALLATION INSTRUCTIONS

2 of 10
IN THE BOX
PART NO: // PART DESCRIPTION:
// PART DESCRIPTION: Window Option
WT11488
PART NO: WT11488T J p Gladiator 2020 - Pr s nt, Wildtop Truck Cap - No Trail Rail V rsion
- Ensure that appropriate Personal Protective Equipment is used.
- During the accessory fitment, ensure all American automotive and dealership
safety practices are followed.
- Always refer to the vehicles workshop manual when removing components.
SAFETY NOTES
GLOSSARY
B
A
x28
CDEFGHI
x32 x32 x24 x32 x8 x6 x4 x8
K
J
x4
L
x1
x8
HARDWARE
TOOLS REQUIRED
Any vehicle accessories which are not properly tted, can be dangerous. Please read these instructions carefully prior to
tting and comply with the instructions at all times. If in any doubt, please contact us e: [email protected]
[
[
1.4 inch
0.9 inch
2.2 inch
2.4 inch
Hex Key Spanner
Ø 3mm
Drill Bit
Phillips Head
Drill Bit
17mm x2
Marker
6mm
4mm
3mm
Tape
Measure
!
!
Two people
required
Check Caution is
advised
!
!
This way
up
Repeat/Mirror
for both sides
14mm
Clean Wiping
Cloth
Drill
5.9 inch

3 of 10
A x12 C x12B x126mm
17mm
A x8 C x8 B x8
6mm
17mm
OVERVIEW
A
A
BC
BC
B
C
A

4 of 10
A x8 C x8 B x8
6mm
17mm
OVERVIEW
A
BC
All press studs
face inwards

5 of 10
12 inch
12 inch
x8
Marker
Phillips
Drill Bit
Tape
Measure F x8
3mmDrill
x8
x43mmDrill
OVERVIEW
Equal Space
Equal Space
Equal Space
F
F

6 of 10
J x8 E x8
4mm D x8 E x8
14mm
!
!
3mm
OVERVIEW
D x16 E x16
14mm 3mm
OVERVIEW
DE
JE
DE
x6

7 of 10
220
lbs
H
I
I
K
B
C
H x4 I x8 B x4 C x4 K x4 17mm 17mm
G
G x6
G
G
G
GG
x3
Refer to next page on how to attach front of cap to front edge of
truck bed.
�Ensure the canvas roof's seam lines match the frame's top
edges, especially the front and back edges, since the roof is cut to
the same length as the frame. Avoid overhang. This helps position
the ladder rack holes correctly. Adjust the cap as needed and
secure it with the hook-and-loop velcro strips on the frame legs.
!
!

8 of 10
TAILGATE
Cloth L
HOW TO ATTACH THE FRONT OF CAP TO TRUCK BED
Clean any dust or dirt from top
front edge of truck bed with
clean cloth and then wipe
down with surface cleaning
wipe. Let the surface dry. Then
apply Velcro strip with even
rm pressure.Allow to cure for
24 hours for full bond strength.

9 of 10
INSTRUCTIONS FOR USE
�The load must be evenly distributed over the area of the Ladder Rack system, and
the center of gravity of the load kept as low as possible. Loads which overhang the
ends of the carrier system must conform to any relevant laws or by-laws in your area,
and shall be adequately secured.
�Loads must be adequately secured using suitable straps or similar tightening and
locking devices. The security of the load and roof load carrier shall be checked after
loading and regularly throughout the ourney. Elastic straps must not be used. The
user is warned to maintain and to use straps in working order.
�It is recommended that items which may produce signicant lifting forces
(surfboard, sailboard, etc) are not carried side-by-side, but in such a way that lifting
force is minimized, securing them independently to the front and rear of the vehicle
using straps or other methods which are capable of withstanding the lifting forces.
Elastic straps must not be used. Where specialized accessories are available to carry
or secure loads, it is recommended that they are used.
�The handling characteristics of a vehicle (in particular crosswind sensitivity,
handling on bends and braking) change when a carrier system is tted and especially
if that system is loaded. Driving techniques should be altered to allow for these
changes, speed reduced, especially on bends, and braking distances made greater.
Load carrying Requirements and recommendations
�Ensure the truck cap is completely closed before driving.
�Regularly check the tightness of the fasteners.
�Load must be evenly distributed on Ladder Racks and adequately secured.
�Do NOT exceed 220 lbs Dynamic and 770 lbs Static weight limit on Ladder Racks.
Happy with how your truck cap turned out?
Please send us a photo to: [e-mail]
Safety
Send us a photo of your Wildtop Truc Cap!

10 of 10
MAINTENANCE & CARE INSTRUCTIONS
ZIPPERS
Thank you for choosing a Wildtop truck cap for your vehicle! Our caps are built to last,
providing you with the durability and functionality you need. However, to ensure the
longevity of your truck cap, it is crucial that you follow these maintenance and care
instructions carefully.
One key aspect of your truck cap maintenance involves the zippers. Dust or dirt may
accumulate in the zipper teeth over time, especially if you are frequently in dusty or
sandy environments. If such accumulation occurs, please avoid forcing the zipper open
or closed, as it may cause damage. Instead, it is recommended that you wash the
zipper teeth gently to remove any lodged debris. If the debris is stubborn, use a gentle
brush. Dry zippers after.
CANVAS
The premium canvas of your truck cap also requires special care to maintain its
physical performance and aesthetic lustre. In particular, the waterproof performance
of the canvas can be improved through proper conditioning. To condition the canvas,
start by tting the cap to your truck. Then thoroughly wet the canvas with a garden
hose, making sure to cover both the inside and the outside. Allow the cap to fully dry,
preferably in the sun. Repeat 2 or 3 more times. This allows the fabric to settle after
transport and packaging.
The following key points will help maximise the durability and life of your canvas:
�To remove dirt, brush the fabric with a soft bristle brush. An occasional hosing may
remove dust and some ingrained dirt.
�Never scrub the canvas fabric.
�Do not expose to petrol or oil.
�Immediately remove deposits of organic matter (such as soil, grass, bird droppings).
�Remove any mildew, as it appears, rst by brushing, then by treating with diluted
chlorine bleach (typically 1 part household grade bleach to 4 parts water to achieve 1%
available chlorine). Allow to dry in the sun, then hose well to remove any residue.
�Do not use strong bleach such as ‘pool chlorine’.
�Do not use soaps, detergents, solvents, or other liquid cleaners.
By following these instructions, you can extend the life of your soft truck cap, maintain
its aesthetic appeal, and enhance its functional performance. We want your
experience with our product to be nothing short of exceptional, and your care in
maintaining your truck cap is a signicant part of that. Thank you for your cooperation
and enjoy your Wildtop truck cap!
