Wilo DrainLift WS 40/50 Basic User manual

Pioneering for You
·
Wilo-DrainLift WS 40/50 Basic
6087354 • Ed.2020-07/05
de Einbau- und Betriebsanleitung
en Installation and operating instructions
fr Notice de montage et de mise en service
it Istruzioni di montaggio, uso e manutenzione

Fig.2.1: DrainLift WS 40E Basic
Fig.2.2: DrainLift WS 40D Basic
800
Ø570 240
600
650
300
785
770
1000 1042
Ø50
120
Ø50/G 2
100/75
120
120
370 75
220
Ø1030
Ø63
Ø75
Ø570
1000
350
120
Ø63
Ø75
355
765
800
Ø50
120
770
1000
1042
350
125 360 50
300
Ø1280
Ø50/G 2Ø50/G 2
100/75

en
36 WILO SE 05
Table of contents
1 General information ............................................................................................................................................................... 38
1.1 About these instructions ............................................................................................................................................................................... 38
1.2 Copyright ......................................................................................................................................................................................................... 38
1.3 Subject to change........................................................................................................................................................................................... 38
1.4 Exclusion from warranty and liability...........................................................................................................................................................38
2 Safety....................................................................................................................................................................................... 38
2.1 Identification of safety instructions............................................................................................................................................................. 38
2.2 Personnel qualifications................................................................................................................................................................................. 39
2.3 Electrical work .................................................................................................................................................................................................40
2.4 Monitoring devices ......................................................................................................................................................................................... 40
2.5 Explosive atmosphere in the collection reservoir ...................................................................................................................................... 40
2.6 Transport.......................................................................................................................................................................................................... 40
2.7 Installing/dismantling..................................................................................................................................................................................... 41
2.8 During operation............................................................................................................................................................................................. 41
2.9 Maintenance tasks.......................................................................................................................................................................................... 41
2.10 Operator responsibilities................................................................................................................................................................................ 41
3 Application/use....................................................................................................................................................................... 41
3.1 Intended use.................................................................................................................................................................................................... 41
3.2 Improper use.................................................................................................................................................................................................... 42
4 Product description................................................................................................................................................................ 42
4.1 Construction.................................................................................................................................................................................................... 43
4.2 Mode of operation .......................................................................................................................................................................................... 43
4.3 Type key...........................................................................................................................................................................................................44
4.4 Scope of delivery............................................................................................................................................................................................. 44
4.5 Accessories ...................................................................................................................................................................................................... 44
5 Transportation and storage................................................................................................................................................... 44
5.1 Delivery............................................................................................................................................................................................................. 44
5.2 Transport.......................................................................................................................................................................................................... 45
5.3 Storage .............................................................................................................................................................................................................46
6 Installation and electrical connection .................................................................................................................................. 46
6.1 Personnel qualifications................................................................................................................................................................................. 46
6.2 Installation types............................................................................................................................................................................................. 46
6.3 Operator responsibilities................................................................................................................................................................................ 46
6.4 Installation ....................................................................................................................................................................................................... 47
6.5 Electrical connection......................................................................................................................................................................................60
7 Commissioning........................................................................................................................................................................ 60
7.1 Personnel qualifications................................................................................................................................................................................. 60
7.2 Operator responsibilities................................................................................................................................................................................ 60
7.3 Operation ......................................................................................................................................................................................................... 61
7.4 Test run ............................................................................................................................................................................................................ 61
7.5 Operation ......................................................................................................................................................................................................... 61
7.6 During operation............................................................................................................................................................................................. 62
8 Shut-down/dismantling......................................................................................................................................................... 62
8.1 Personnel qualifications................................................................................................................................................................................. 62
8.2 Operator responsibilities................................................................................................................................................................................ 62
8.3 Shut-down....................................................................................................................................................................................................... 62
8.4 Clean and disinfect ......................................................................................................................................................................................... 63
8.5 Pump removal.................................................................................................................................................................................................. 63
9 Maintenance and repair.......................................................................................................................................................... 64
10 Spare parts............................................................................................................................................................................... 64
11 Faults, causes and remedies .................................................................................................................................................. 64

en General information
38 WILO SE 05
1 General information
1.1 About these instructions These instructions form part of the product. Adherence to these instructions is a re-
quirement for the intended use and correct operation of the product:
ƒCarefully read the instructions prior to any activities on and with the product.
ƒKeep the instructions in an accessible place at all times.
ƒObserve all product specifications and labels on the device.
The language of the original operating instructions is German. Versions of these in-
structions in any other language are translations of the original operating instructions.
1.2 Copyright Copyright remains with Wilo. Do not:
ƒReproduce any content.
ƒDistribute any content.
ƒUse any content for competition purposes without authorisation.
Wilo shall reserve the right to change the listed data without notice and shall not be li-
able for technical inaccuracies and/or omissions.
1.3 Subject to change Wilo shall reserve the rights to make technical changes to the product and individual
components. The illustrations used may differ from the original and are intended as a
sample representation of the device.
1.4 Exclusion from warranty and liab-
ility Wilo shall specifically not assume any warranty or liability in the following cases:
ƒInadequate configuration due to inadequate or incorrect instructions by the operator
or the client
ƒNon-compliance with these instructions
ƒImproper use
ƒIncorrect storage or transport
ƒIncorrect installation or dismantling
ƒInsufficient maintenance
ƒUnauthorised repairs
ƒInadequate construction site
ƒChemical, electrical or electrochemical influences
ƒWear
2 Safety This chapter contains basic information for the individual phases of the life cycle. Fail-
ure to observe this information carries the following risks:
ƒInjury to persons from electrical, mechanical and bacteriological factors as well as
electromagnetic fields
ƒEnvironmental damage from discharge of hazardous substances
ƒProperty damage
ƒFailure of important functions of the product
Failure to observe the information contained herein will result in the loss of claims for
damages.
The instructions and safety instructions in the other chapters must also be ob-
served!
2.1 Identification of safety instruc-
tions These installation and operating instructions set out safety instructions for preventing
personal injury and damage to property. These safety instructions are shown differ-
ently:
ƒSafety instructions relating to personal injury start with a signal word, are preceded
by a corresponding symbol and are shaded in grey.
DANGER
Type and source of the danger!
Consequences of the danger and instructions for avoidance.
ƒSafety instructions relating to property damage start with a signal word and are dis-
played without a symbol.

en Safety
40 WILO SE 05
ƒGround installation (underground): trained specialist in underground and pipeline
construction
Excavate and prepare the pit, backfill the pit, buoyancy safeguards, connection of
plastic pipes.
ƒMaintenance work: Skilled person (trained specialist in plant technology for sanitary
facilities)
Hazards caused by sewage, basic knowledge of lifting units, requirements EN12056
ƒLifting work: trained specialist for the operation of lifting devices
Lifting equipment, lifting gear, attachment points
ƒPersonnel have been instructed on locally applicable regulations governing accident
prevention.
ƒPersonnel have read and understood the installation and operating instructions.
2.3 Electrical work ƒElectrical work must be carried out by a qualified electrician.
ƒDisconnect device from the mains and secure it against being switched on again
without authorisation.
ƒObserve applicable local regulations when connecting to the mains power supply.
ƒComply with the requirements of the local energy supply company.
ƒTrain personnel on how to make electrical connections.
ƒTrain personnel on the options for switching off the device.
ƒObserve the technical information in these installation and operating instructions as
well as on the rating plate.
ƒEarth the device.
ƒArrange switchgears so as to be overflow-proof.
ƒReplace defective connection cables. Contact customer service.
2.4 Monitoring devices The following monitoring devices must be provided on-site:
Circuit breaker
The size and switching characteristics of the circuit breakers must conform to the rated
current of the connected product. Observe local regulations.
Residual-current device (RCD)
ƒInstall a residual-current device (RCD) in accordance with the regulations of the local
energy supply company.
ƒIf people can come into contact with the device and conductive fluids, install a re-
sidual-current device (RCD).
2.5 Explosive atmosphere in the col-
lection reservoir Sewage containing faeces can lead to gas accumulations in the tank. These gas accu-
mulations can escape into the operating space and create an explosive atmosphere as a
result of incorrect installation or maintenance work. This atmosphere can ignite and
lead to an explosion. In order to prevent an explosive atmosphere, observe the follow-
ing points:
ƒTank must be undamaged (no cracks, leaks, porous material)! Take any defective
lifting units out of operation.
ƒEnsure all connections for the inlet, pressure pipe and aeration and venting are
sealed tightly and in accordance with regulations!
ƒGuide the aeration and venting line over the roof.
ƒWhen opening the tank (e.g. during maintenance work), ensure appropriate ex-
change of air!
2.6 Transport ƒWear the following protective equipment:
–Safety footwear
–Hard hat
ƒLocally applicable laws and regulations on work safety and accident prevention must
be complied with.
ƒDemarcate and cordon off the working area.
ƒKeep unauthorised persons away from the working area.
ƒRemove loose components from the product.
ƒOnly use legally prescribed and approved lifting and hoisting gear.
ƒSelect the lifting gear based on the prevailing conditions (weather, attachment
point, load, etc.).
ƒAlways attach the lifting gear to the attachment points.
ƒEnsure that the lifting gear is securely attached.
ƒEnsure that the hoisting gear is stable.

Application/use en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 41
ƒObserve the swivel range.
ƒEnsure a second person is present to coordinate the procedure if required (e.g. if the
operator’s field of vision is blocked).
ƒStanding under suspended loads is not permitted. Do not move suspended loads
over workplaces where people are present.
2.7 Installing/dismantling ƒWear the following protective equipment:
–Safety footwear
–Safety gloves for protection against cuts
ƒLocally applicable laws and regulations on work safety and accident prevention must
be complied with.
ƒDisconnect device from the mains and secure it against being switched on again
without authorisation.
ƒClose the inlet and pressure pipe.
ƒEnsure enclosed spaces have sufficient ventilation.
ƒWhen working in enclosed spaces, a second person must be present for safety reas-
ons.
ƒToxic or asphyxiating gases may build up in enclosed spaces or buildings. Observe
protective measures in accordance with work regulations, e.g. carry a gas detector
with you.
ƒClean the device thoroughly.
WARNING!Risk of fire if inappropriate clothing is worn and highly flammable
cleaning agents are used!
Static charging may occur when cleaning plastic parts. There is a risk of fire! Only
wear anti-static clothing and do not use highly flammable cleaning agents.
2.8 During operation ƒOpen all gate valves in the inlet and pressure pipe!
ƒThe maximum inflow must be lower than the maximum output of the system.
ƒDo not open the inspection openings!
ƒEnsure aeration and venting!
2.9 Maintenance tasks ƒWear the following protective equipment:
–Sealed safety goggles
–Safety gloves for protection against cuts
–Safety footwear
ƒDisconnect installed products from the mains and secure against unauthorised re-
start.
ƒClose the inlet and pressure pipe.
ƒCarry out maintenance work according to the instructions of the installed products.
ƒOnly carry out maintenance tasks described in these installation and operating in-
structions.
ƒOnly original parts of the manufacturer may be used. The use of any non-original
parts releases the manufacturer from any liability.
ƒCollect any leakage of fluid and operating fluid immediately and dispose of it ac-
cording to the locally applicable guidelines.
2.10 Operator responsibilities ƒProvide installation and operating instructions in a language which the personnel can
understand.
ƒMake sure that the personnel have received the required training for the specified
work.
ƒProvide protective equipment. Ensure that the protective equipment is worn by per-
sonnel.
ƒEnsure that safety and information signs mounted on the device are always legible.
ƒTrain the personnel on how the system operates.
ƒEliminate any risk from electrical current.
ƒDemarcate and cordon off the working area.
Observe the following points when handling the device:
ƒUse is not permitted for persons under the age of 16.
ƒPersons under the age of 18 must be supervised by a technician!
ƒUse is not permitted for persons with limited physical, sensory or mental capacities!
3 Application/use
3.1 Intended use Pumping of sewage:
ƒIn cases where sewage cannot be led to the sewer system via a natural fall.

en Application/use
42 WILO SE 05
ƒFor the backflow resistant drainage in cases where the discharge point is below the
backflow level.
ƒAs a lifting unit within buildings (above ground installation).
ƒAs a pump chamber outside buildings (concealed floor installation).
NOTICE!Install grease traps upstream of the pump chamber if pumping greasy
sewage!
Pumping station
Sewage in acc. with DINEN12050-1 Sewage in acc. with EN12050-1 Sewage in acc. with EN12050-2
WS 40E Basic with Rexa MINI3... - - •
WS 40D Basic with Rexa MINI3... - - •
WS 50E Basic with Rexa MINI3... - • •
WS 50E Basic with Rexa UNI... - • •
WS 50D Basic with Rexa MINI3... - • •
WS 50D Basic with Rexa UNI... - • •
CAUTION
Overpressure in the tank!
If there is overpressure in the tank, it can burst. Observe the following points to pre-
vent overpressure:
• The maximum positive suction head is 5m (16.5 ft)
• The maximum inlet volume flow must be less than the maximum flow rate at the
duty point!
3.2 Improper use
DANGER
Explosion due to use of explosive fluids!
Use of highly flammable and explosive fluids (gasoline, kerosene, etc.) in their pure
form is prohibited. There is a risk of fatal injury due to explosion! The lifting unit is
not designed for these fluids.
Do not use the following fluids:
ƒSewage from drainage objects that are located above the backflow level and can be
drained by natural fall.
ƒDebris, ash, rubbish, glass, sand, plaster, cement, lime, mortar, fibrous materials, tex-
tiles, paper towels, wet-wipes (e.g. fleece cloths, moist toilet paper wipes), nappies,
cardboard, coarse paper, synthetic resins, tar, kitchen waste, grease, oil
ƒSlaughterhouse waste, disposal of slaughtered animals and animal waste (liquid ma-
nure etc.)
ƒToxic, aggressive and corrosive fluids, such as heavy metals, biocides, pesticides,
acids, bases, salts, swimming-pool water
ƒCleaning agents, disinfectants, dishwashing or laundry detergents in excess
amounts, and such that have a disproportionately high degree of foam formation
ƒDrinking water
Intended use also includes compliance with this manual. Any other use is regarded as
non-compliant with intended use.

Product description en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 43
4 Product description
4.1 Construction
1
2
2
3
4
5
6
Fig.1: Structure
1 Chamber cover
2 Pressure pipe connection
3 Pump chamber
4 Drain pipe/diaphragm hand pump connection
5 Venting line connection
6 Cable pipe connection
Chamber
Pump chamber with optimised geometry for deposit-free operation. Chamber compo-
nent with ribbing for high inherent stability and buoyancy safety. The inlets are freely
configurable. Two lifting eyes are integrated for attaching the lifting equipment. The
chamber cover can be walked on and can be loaded with max. 200kg. For the building
installation, the pump chamber is equipped with a floor fixation.
Pipework
ƒDischarge pipe with threaded connection on the pump side
ƒShut-off ball valve
ƒNon-return ball valve
Level control
Depending on the type, the level is controlled via the float switch of the pump, a separ-
ate float switch or a level sensor. If the level is controlled with a separate float switch or
level sensor, it is controlled via switchgear.
4.1.1 Technical data ƒVessel volume: 255l/67US.liq.gal. (WS...E)/400l/105US.liq.gal. (WS...D)
ƒMaximum pressure in the pressure pipe: 1.5bar (22psi)
ƒPressure connection: G 2/50mm (WS 40), G 2½ /63mm (WS 50)
ƒInlet connection: DN 100/150/200
ƒAeration and ventilation connection: 75mm (3in)
ƒCable pipe for ground installation: 63mm (2.5in)
ƒThreaded cable glands for building installation:
- WS...E: 1x M25 + 2x M16
- WS...D: 2x M16 + 2x M25
ƒFluid temperature: 3 ... 40°C (37... 104°F)
ƒMax. ambient temperature: 3 ... 40°C (37... 104°F)
ƒMax. ground water level: 500mm
4.1.2 Dimensions Refer to the dimension drawing for the dimensions:
Fig.2: Dimension drawings
1 DrainLift WS 40E
2 DrainLift WS 40D
3 DrainLift WS 50E
4 DrainLift WS 50D
When the pump chamber extension is installed, the dimensions change as follows:
DrainLift WS...E DrainLift WS...D
Pump chamber extension height 300mm (12in) 300mm (12in)
Pump chamber total height 1342mm (53in) 1342mm (53in)
Max. vessel volume 325l (86US.liq.gal) 470l (124US.liq.gal)
Max. ground water level 1000mm (39in) 500mm (19.5in)
4.1.3 Materials ƒPump chamber: PE
ƒPipework: 1.4404 (AISI 316L)
ƒStopcock: PVC
ƒNon-return valve: Grey cast iron
4.2 Mode of operation The sewage produced is channelled into the pump chamber via the inlet, where it col-
lects. When the water level reaches the switch-on level, the pump is switched on. The
collected sewage is pumped into the on-site pressure pipe via the discharge pipe. When

en Transportation and storage
44 WILO SE 05
the switch-off level is reached, the pump is immediately deactivated. When switchgear
is used for the control, the pump is deactivated after the set follow-up time.
Pump chambers with two pumps operate according to the base load and peak load
principle. The pumps are switched on depending on the fill level. Pump cycling is carried
out after every pumping procedure. If one pump malfunctions, the other pump is auto-
matically used.
4.3 Type key Example: DrainLift WS 40E Basic/Rexa...
DrainLift Product family
WS Pump chamber
40 Size
EChamber design:
ƒE = Single-pump system
ƒD = Double-pump system
Basic Pump chamber with pump and level control
Rexa... Installed pump
4.4 Scope of delivery Pumping station
DrainLift WS 40E Basic (1~230V) DrainLift WS 40E Basic (3~ 400V) DrainLift WS 40D Basic DrainLift WS 50E Basic DrainLift WS 50D Basic
Pump chamber with pipework, shut-off
ball valve and non-return ball valve
•••••
Chamber cover with gasket •••••
Pump with float switch and plug • − − • −
Pump − • • − •
Switchgear with float switch and plug − • − − −
Switchgear with level sensor and plug − − • − •
Hose section 50mm (2in) for drain con-
nection, incl. 2 hose clips
•••••
Inlet set with hole saw 124mm (5in)and
gasket DN 100
•••••
Fixation material •••••
Installation and operating instructions •••••
Key
• = Included in the scope of delivery, − = not included in the scope of delivery
4.5 Accessories ƒPump chamber extension
ƒClamp bolting
ƒGate valve
ƒInlet set (gasket and hole saw)
ƒDiaphragm hand pump
ƒAlarm switchgear
ƒFlash light
ƒHorn
5 Transportation and storage
5.1 Delivery After receiving the shipment, this must be checked immediately for defects (damage,
completeness). Defects must be noted on the freight documentation! Furthermore, de-
fects must be notified to the transport company or the manufacturer immediately on
the day of receipt of shipment. Subsequently notified defects can no longer be asser-
ted.

Transportation and storage en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 45
5.2 Transport
DANGER
Risk of fatal injury if the load is incorrectly secured!
Faulty or incorrect load securing can lead to life-threatening situations! Secure the
load in accordance with local regulations. Check the load is secure before transport!
WARNING
Standing under suspended loads!
Never allow anyone to stand under suspended loads! Danger of (serious) injuries
caused by falling parts. Loads may not be carried over work places where people are
present!
WARNING
Head and foot injuries due to a lack of protective equipment!
Danger of (serious) injuries during work. Wear the following protective equipment:
• Safety shoes
• Safety helmet must be worn if lifting equipment are used!
NOTICE
Use only properly functioning lifting equipment!
Use only properly functioning lifting equipment to lift and lower the pump chamber.
Ensure that the pump chamber does not become jammed during lifting and lower-
ing. Do not exceed the maximum bearing capacity of the lifting equipment! Check
that lifting equipment is functioning properly before use!
To avoid damage during transport, please observe the following points:
ƒAlways transport the pump chamber on a pallet.
ƒAlways set down the pump chamber vertically on the pallet.
ƒSecure the pump chamber against slipping. When lashing, make sure that the plastic
parts do not deform.
ƒClose any openings, ensuring they are sealed watertight.
ƒRemove loose accessories from the pump chamber and pack them separately.
ƒTo avoid damage to the pipework and pipe adaptors, always keep the pump chamber
vertical during transport.
NOTICE!Thoroughly clean used pump chambers before shipping and disinfect them
if necessary.
The following points must also be observed during attachment:
Fig.3: Attachment points
ƒAdhere to the applicable national safety regulations.
ƒUse legally specified and approved lifting gear.
ƒSelect the lifting gear based on the existing conditions (weather, attachment point,
load, etc.).
ƒOnly attach the lifting gear to the attachment point. Fix with a shackle.
ƒUse lifting equipment with sufficient bearing capacity.
ƒThe stability of the lifting equipment must be ensured during operation.
ƒWhen using lifting equipment, a second person must be present to coordinate the
procedure if required (e.g. if the operator’s field of vision is blocked).

en Installation and electrical connection
46 WILO SE 05
5.3 Storage
DANGER
Risk of fatal injury from fluids hazardous to health!
Disinfect the pump chamber after draining and before removal! Observe the spe-
cifications of the work regulations! Make sure that the personnel have received and
read the work regulations!
Newly supplied pump chambers can be stored for one year. For longer storage periods,
contact customer service.
When storing the pump, please note the following points:
ƒDrain the pump chamber completely.
ƒPlace the pump chamber on a firm surface. Check the stability.
ƒSecure the pump chamber against falling over and slipping!
ƒMax. storage temperature: -15 ... 60°C (5 ... 140°F). Max. humidity: 90%, non-con-
densing.
We recommend frost-proof storage. Ambient temperature: 5 ... 25°C (41 ... 77°F),
relative humidity: 40 ... 50%.
ƒClose all openings, ensuring they are sealed watertight.
ƒDo not store the pump chamber in spaces where welding work is carried out. The
resulting gases or radiation can corrode the plastic parts.
ƒProtect the pump chamber from direct exposure to sunlight. Extreme heat can cause
the plastic parts to deform!
If pumps or signal transmitters are installed, please also observe the following points:
ƒSeal the ends of the connection cables against water ingress.
ƒCoil up connection cables and attach in the pump chamber.
ƒObserve information on the max. storage temperature of the pumps and signal
transmitters.
ƒStore the switchgear according to the manufacturer's instructions.
6 Installation and electrical con-
nection
6.1 Personnel qualifications ƒInstallation/dismantling work: trained specialist in plant technology for sanitary fa-
cilities
Fixation and buoyancy safeguards, connection of plastic pipes
ƒGround installation (underground): trained specialist in underground and pipeline
construction
Excavate and prepare the pit, backfill the pit, buoyancy safeguards, connection of
plastic pipes.
ƒLifting work: trained specialist for the operation of lifting devices
Lifting equipment, lifting gear, attachment points
ƒElectrical work: qualified electrician
Person with appropriate technical training, knowledge and experience who can
identify and prevent electrical hazards.
ƒPersonnel have been instructed on locally applicable regulations governing accident
prevention.
ƒPersonnel have read and understood the installation and operating instructions.
6.2 Installation types ƒInstallation in buildings
ƒGround installation outside buildings
6.3 Operator responsibilities ƒObserve locally applicable accident prevention and safety regulations.
ƒObserve all regulations for working with heavy loads and under suspended loads.
ƒProvide protective equipment. Ensure that the protective equipment is worn by per-
sonnel.
ƒObserve local sewage technology regulations for the operation of sewage systems.
ƒStructural components and foundations must be of sufficient stability in order to al-
low the device to be fixed in a secure and functional manner. The operator is re-
sponsible for the provision and suitability of the structural component/foundation!
ƒDemarcate the working area.
ƒKeep unauthorised persons away from the working area.
ƒEnsure free access to the installation location.

Installation and electrical connection en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 47
ƒHorizontal and flat installation surface!
ƒCarry out the installation work according to locally applicable regulations.
ƒIf the weather conditions (e.g. ice formation, strong wind) mean it is no longer pos-
sible to work safely, stop work.
ƒCheck that the available consulting documents (installation plans, installation loca-
tion, inflow conditions) are complete and accurate.
ƒLay and prepare the pipes according to the consulting documents.
ƒMains connection is overflow-proof.
6.4 Installation
DANGER
Danger due to fluids hazardous to health during installation!
Ensure that the installation site is clean and disinfected during installation. If contact
with fluids that are hazardous to health is possible, observe the following points:
• Wear protective equipment:
⇒ sealed safety goggles
⇒ mouth protection
⇒ protective gloves
• Wipe up drips immediately.
• Observe the specifications of the work regulations! The operator must make
sure that personnel have received and read the work regulations!
DANGER
Risk of fatal injury due to dangerous lone working practices!
Work in chambers and narrow rooms as well as work involving risk of falling are dan-
gerous work. Such work may not be carried out autonomously! A second person
must be present for safety reasons.
WARNING
Hand and foot injuries due to lack of protective equipment!
Danger of (serious) injuries during work. Wear the following protective equipment:
• Safety gloves for protection against cuts
• Safety shoes
• Safety helmet must be worn if lifting equipment are used!
WARNING
Standing under suspended loads!
Never allow anyone to stand under suspended loads! Danger of (serious) injuries
caused by falling parts. Loads may not be carried over work places where people are
present!
NOTICE
Use only properly functioning lifting equipment!
Use only properly functioning lifting equipment to lift and lower the pump chamber.
Ensure that the pump chamber does not become jammed during lifting and lower-
ing. Do not exceed the maximum bearing capacity of the lifting equipment! Check
that lifting equipment is functioning properly before use!

en Installation and electrical connection
48 WILO SE 05
Building installation
NOTICE
Installation of the pump chamber inside buildings
Observe EN12056 and local regulations during installation!
ƒPrepare the installation site:
–Clean, free of coarse solids
–Dry
–Frost-free
–Well lit
ƒEnsure operating space has sufficient ventilation.
ƒEnsure a clearance area of min. 60cm (2ft) around the unit.
ƒIn the event of an accident: Provide pump sump in the operating space, min. dimen-
sions: 500x500x500mm (20x20x20in). Select pump accordingly. Ensure that
manual drainage is possible.
ƒAll connection cables must be laid properly. The connection cables must not pose
any risk (i.e. tripping, damage during operation). Check whether the cable cross-sec-
tion and the cable length are sufficient for the selected installation type.
ƒThe mounted switchgear is not overflow-proof. Install the switchgear at an ad-
equate height. Ensure good operation!
Ground installation
CAUTION
Beware of high ground water levels!
Elevated ground water can cause the pump chamber to float up. Observe informa-
tion on the maximum permissible ground water level!
CAUTION
Beware of frost!
Frost can cause malfunctions and damage. Pay attention to local frost depths. If the
unit or pressure outlet are in the freezing zone, take the unit out of operation during
freezing periods.
NOTICE
Installation of the pump chamber outside buildings
Observe EN1610 and local regulations during ground installation!
ƒPrepare the installation site:
–Clean, free of coarse solids
–Dry
–Frost-free
ƒTake immediate countermeasures if there is a build-up of toxic or asphyxiating
gases!
ƒWork must always be carried out by two persons.
ƒInstall lifting equipment: even surface, clean, firm base. Warehouse and installation
location must be easily accessible.
ƒAttach the chain or wire rope to the attachment points with a shackle. Only use lift-
ing gear that has been technically approved.
ƒDo not stay within the swivel range of the hoisting gear.
ƒProvide threading strip for the installation of the connection cables.
ƒThe mounted switchgear is not overflow-proof. Install the switchgear at an ad-
equate height. Ensure good operation!
6.4.1 Note on fixation material The lifting unit can be installed on various constructions (concrete, steel, etc.). Select
the fixation material which is suitable for the relevant construction. For correct installa-
tion, observe the following instructions for the fixation material:

Installation and electrical connection en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 49
ƒAvoid tearing or chipping of the construction surface, observe the minimum edge
distances.
ƒEnsure tight and secure installation, adhere to the prescribed borehole depth.
ƒDrilling dust impairs holding strength, always blow out or vacuum out the bore-
hole.
ƒOnly use components (e.g. screws, anchors, mortar cartridges) which are in perfect
condition.
6.4.2 Note on pipework The pipework is subjected to different pressures during operation. Pressure peaks can
also occur (e.g. when closing the swing check valve) which may be several times higher
than the pump pressure, depending on the operating conditions. These different pres-
sures put a strain on the piping and the pipe adaptors. In order to ensure safe and fault-
less operation, the piping and pipe adaptors must be checked based on the following
parameters and designed according to the requirements:
ƒPipes are self-supporting.
No tensile or compressive forces may act on the lifting unit.
ƒPressure resistance of pipework and pipe adaptors
ƒTensile strength of the pipe adaptors (= longitudinal force fit connection)
ƒConnect the pipes free of stress and vibrations.
ƒProvide a gate valve in the inlet and the pressure pipe on-site!
6.4.3 Work steps The pump chamber is installed in the following steps:
Building installation
ƒPreparatory tasks.
ƒInstall the pump chamber.
ƒConnect the pressure pipe.
ƒConnect the inlet.
ƒConnect the aeration and venting.
ƒConnect the emergency drain.
ƒCheck the pump is properly fitted.
ƒInstall the level control device.
ƒLay the connection cable.
ƒFit the chamber cover.
ƒFinal tasks.
Ground installation
ƒPreparatory tasks.
ƒInstall the pump chamber.
ƒConnect the pressure pipe.
ƒConnect the inlet.
ƒConnect the aeration and venting.
ƒConnect the cable pipe.
ƒFit the pump chamber extension.
ƒBackfill the pit.
ƒCheck the pump is properly fitted.
ƒInstall the level control device.
ƒLay the connection cable.
ƒFit the chamber cover.
ƒFinal tasks.

en Installation and electrical connection
50 WILO SE 05
6.4.4 Preparatory tasks
Building installation
ƒUnpack the pump chamber.
ƒRemove the securing mechanisms.
ƒCheck the scope of delivery.
ƒCheck all components are in proper working condition.
CAUTION!Do not install defective components! Defective
components can lead to system failures!
ƒPrepare the installation location:
–Horizontal and flat installation surface!
–Space for an additional clearance area of at least 60cm
(2ft) provided!
–Fixation with dowels possible.
–Clean, free of coarse solids
–Dry
–Frost-free
–Well lit
ƒPlace accessories to one side and keep them for later use.
ƒKeep accessories available for later use:
–Chamber cover
–Y-piece
The pump chambers WS 40...D and WS 50...D have separ-
ate pipework for each pump. They therefore also have two
pressure connections.
–Switchgear
–Level control
Ground installation
ƒUnpack the pump chamber.
ƒRemove the securing mechanisms.
ƒCheck the scope of delivery.
ƒCheck all components are in proper working condition.
CAUTION!Do not install defective components! Defective
components can lead to system failures!
ƒSelect installation site:
–Outside buildings.
–Not in the immediate vicinity of living and sleeping areas.
–Pit depth and diameter.
CAUTION!Do not install in peaty soil! Peaty soil leads to
destruction of the tank!
–Ground water level
The pump chamber is anti-buoyant up to a max. ground
water level of 500mm (above the bottom edge of the
chamber base).
–Pay attention to local frost depths.
ƒPlace accessories to one side and keep them for later use.
ƒKeep accessories available for later use:
–Chamber cover
–Y-piece
The pump chambers WS 40...D and WS 50...D have separ-
ate pipework for each pump. They therefore also have two
pressure connections.
–Pump chamber extension (for height adjustment)
–Switchgear
–Level control
6.4.5 Install the pump chamber
Building installation
1
2
3
Fig.4: Install the pump chamber
1 Mounting bracket (2 pieces)
2
Fixation for mounting bracket:
ƒ4x M5x25 hexagon head screw
ƒ4x M5 hexagon nut
ƒ8x washers
3
Floor fixation: with
ƒ2x SXRL 10x80FUS long-shaft dowel
ƒ2x 7mm hexagon head screw
Install pump chamber so as to protect against buoyancy and twisting. Anchor the lifting
unit to the floor for this.
‡Preparatory tasks have been completed.
‡Installation site prepared according to consulting documents.
‡Enclosed fixation material can be used for the existing building ground. NO-
TICE!Observe the information on the building ground!
‡SW8 and SW13 wrench
1. Place the pump chamber at the installation site and align it with the pipework.
NOTICE!The pump chamber must be vertical!
2. Mount the mounting bracket on the chamber ribs (fixation for mounting bracket).
3. Mark the boreholes.
4. Place the pump chamber to one side.
5. Drill and clean the boreholes.
6. Insert the dowels (floor fixation)
7. Align the pump chamber with the boreholes.
8. Attach the pump chamber to the floor (floor fixation).

Installation and electrical connection en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 51
▶ Pump chamber installed so as to protect against buoyancy and twisting. Next step:
Connect the pressure pipe.
Ground installation
1
2
3
4
5
Fig.5: Excavating the pit
1 Ground
2 Underlay
3 Levelling layer
4 Min. pit diameter
5 Min. pit depth
To install the pump chamber, excavate the pit, taking into account the following points:
ƒObserve local regulations for earthworks in underground construction.
(Slope angle, pit lining etc.)
ƒMin. pit depth
Chamber height + 300mm (12in) underlay + 200mm (8in) levelling layer + height
of chamber cover
ƒPit diameter
Min. pit diameter at ground level 2m (6.5ft) larger than chamber diameter.
ƒPosition of the inlet, pressure and venting line
ƒPump chamber extension (300mm/12in) for height compensation to the surface
level.
ƒGround water
Pump out any groundwater with a ground water lowering system.
ƒConsider local frost depths.
‡Preparatory tasks completed.
‡Pit dimensions specified.
‡Prepare the on-site piping.
‡Height adjustment available.
‡Ground water lowering system installed.
1. Excavate the pit.
2. Install the load-bearing mineral mixture underlay properly and seal it (Dpr 97%).
3. Add a levelling layer of sand (non-cohesive, grain size 0...32mm) and level off.
4. Insert the pump chamber into the pit.
5. Align the pump chamber with the on-site piping.
6. Vibrate the pump chamber evenly into the levelling layer.
NOTICE!Vibrate the chamber base and base ribs completely into the levelling
layer!
7. Check the position of the pump chamber and correct if necessary:
- Pump chamber vertical
- Chamber cover flat to surface level
▶ Pump chamber installed. Next step: Connect the pressure pipe.
6.4.6 Connecting the pressure pipe
DrainLift WS 40E/50E Basic DrainLift WS 40D/50D Basic
2
2
2
Fig.6: Pressure connection

en Installation and electrical connection
52 WILO SE 05
2 Pressure connection
Observe the following information when connecting the pressure pipe:
ƒFlow rate in the pressure pipe: 0.7m/s (2.3ft/s) to 2.3m/s (7.5ft/s)!
ƒReducing the pipe diameter is not permitted!
ƒAll connections must be completely tight!
ƒLay the pressure pipe so that it is protected from frost.
ƒInstall the gate valve.
ƒBuilding installation: Install the pressure pipe as a “pipe loop” to avoid backflow
from the public sewer.
At its highest point, the bottom edge of the pipe loop must be above the locally de-
termined backflow level!
‡Pump chamber installed properly.
‡Pressure pipe installed correctly to the discharge port according to consulting doc-
uments.
‡Installation materials available:
1x clamp bolting or thread fitting
1. Push the clamp bolting onto the discharge port.
2. Insert the on-site pressure pipe into the clamp bolting.
3. Screw on the clamp bolting.
▶ Pressure pipe connected. Next step: Connect the inlet.
6.4.7 Connect the inlet The inlet can be in the areas indicated for the chamber wall, as desired.
min. 450
max. 620
min. 450
max. 620
Fig.7: Inlet areas
Note the following when connecting the inlet:
ƒConnect the inlet within the marked areas. If the inlet is outside the marked areas,
the following problems can occur:
–The connection leaks.
–Statics of the pump chamber are affected.
–Backflow into the inlet pipe.
ƒAvoid an inlet surge and air intake into the pump chamber. Lay the inlet properly.
CAUTION!Inlet surges or air intake into the pump chamber can cause the level
control device to malfunction!
ƒLay the inlet pipe with a slope to the pump chamber so that it can drain automatical-
ly.
ƒAll connections must be completely tight!
ƒInstall gate valve in the inlet!

Installation and electrical connection en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 53
50 mm
2 in
1
1
1
1
1
2
3
3
3
4
4
4
5
5
1234
Fig.8: Connect the inlet
1 Tank wall
2 Hole saw for drill
3 Inlet seal
4 Inlet pipe
5 Pipe clamp
‡Pump chamber installed properly.
‡Inlet pipe installed properly up to the pump chamber and according to consulting
documents.
‡Installation materials provided:
1x hole saw
1x drill
1x inlet seal
1x pipe clamp
1. Mark the inlet point on the pump chamber.
2. Use the supplied hole saw to cut the hole for the inlet into the pump chamber wall.
When drilling holes on the pump chamber, observe the following points:
- Observe the dimensions of the inlet surfaces. CAUTION!The drilled hole must
be completely within the marked inlet surfaces!
- Max. speed of the drill: 200rpm.
- Check the hole diameter: DN100 = 124mm (5in). NOTICE!Drill the connection
carefully. Impermeability of the connection depends on the drilled hole!
- Make sure the excess material in the drill bit is removed completely! If the excess
material removal rate decreases, the material will heat up too quickly and melt.
⇒ Stop the drilling process, allow the material to cool down and clean the hole
saw!
⇒ Reduce the speed of the drill.
⇒ Vary the feed pressure when drilling.
3. Deburr and smooth the cut surface.
4. Insert the inlet seal into the hole.
5. Push the pipe clamp onto the inlet seal.
6. Coat the inner surface of the inlet seal with lubricant.
7. Push the inlet pipe into the inlet seal.
Push the inlet pipe 50mm (2in) into the pump chamber.
8. Connect the inlet seal and pipe firmly to the pipe clamp. Tightening torque: 5Nm
(3.7ft·lb).
▶ Inlet connected. Next step: Connect the aeration and venting.
6.4.8 Connect the aeration and venting. The connection of an aeration and venting line is a specified requirement. Observe the
following points when connecting the aeration and venting line:
ƒFor building installation: Guide the aeration and venting line over the roof.
ƒAll connections must be completely tight.

en Installation and electrical connection
54 WILO SE 05
DrainLift WS 40E/50E Basic DrainLift WS 40D/50D Basic
5
5
Fig.9: Aeration and venting connection
5 Aeration and venting line connection
‡Pump chamber is installed properly.
‡On-site aeration and venting line is laid properly.
‡HT sleeve socket available
1. Open the aeration and venting connection piece: Sawing edge approx. 25mm.
2. Deburr and smooth the sawing edge.
3. Place the HT sleeve socket onto an open aeration and venting connection piece.
4. Insert the on-site aeration and venting pipe into the HT sleeve socket.
▶ Aeration and venting installed. Next step: Connect the emergency drain (only
building installation).
6.4.9 Connect the emergency drain
(only building installation)
NOTICE
Do not connect inlet to the emergency drain!
The pump chamber is pumped out via the emergency drain in the event of an acci-
dent. Do not connect inlets to the emergency drain! The pump chamber cannot be
drained in case of emergency otherwise!
In case of maintenance work or pump malfunction, the pump chamber can be emptied
via the emergency drain. It is recommended to install a diaphragm hand pump for this
purpose.
CAUTION!If the pumps malfunction, there is backflow into the inlet and the pump
chamber can burst! Shut off the inlet and drain the pump chamber.
DrainLift WS 40E/50E Basic DrainLift WS 40D/50D Basic
4
4
Fig.10: Emergency drain connection
4 Emergency drain connection
Observe the following points when installing a diaphragm hand pump:

Installation and electrical connection en
Installation and operating instructions Wilo-DrainLift WS 40/50 Basic 55
ƒSelect an installation height which is optimal for operation.
ƒConnect the diaphragm hand pump to the emergency drain (lowest point, almost
complete drain possible).
ƒA hole saw 30mm (1.3in) is required to open the drain connection.
ƒConnect the pressure pipe downstream of the gate valve on the pressure side.
Alternatively, the connection can be made via a pipe loop directly to the sewer.
ƒAll connections must be completely tight!
ƒObserve the installation and operating instructions for the diaphragm hand pump!
6.4.10 Connect the cable pipe (only
ground installation) The electrical connection cables can be routed to the outside via a separate cable pipe.
Alternatively, the connection cables can also be routed to the outside via the venting
line. Observe the following points when connecting the cable pipe:
ƒBefore connecting the cable pipe, pull in the threading strip.
ƒAll connections must be completely tight.
DrainLift WS 40E/50E Basic DrainLift WS 40D/50D Basic
6
6
Fig.11: Cable pipe connection
6 Cable pipe connection
‡Pump chamber is installed properly.
‡On-site cable pipe is laid properly.
‡HT sleeve socket available
1. Open the connection piece for the cable pipe: Sawing edge approx. 25mm.
2. Deburr and smooth the sawing edge.
3. Put the HT sleeve socket on the connection port.
4. Pull-in the threading strip.
5. Insert the on-site cable pipe into the HT sleeve socket.
▶ Cable pipe installed. Next step: Install the pump chamber extension (if necessary).
6.4.11 Fit the pump chamber extension A height compensation of 300mm (12in) can be achieved with the pump chamber ex-
tension.
50 mm
2 in
1
4
2
3
Fig.12: Fit the pump chamber extension
1 Pump chamber extension
2 Pump chamber
3 Fastening screw
4 O-ring
‡Height adjustment: 300mm (12in).
‡Pump chamber extension available.
‡Installation materials required:
- Fastening screw
- O-ring
1. Push the gasket (O-ring) over the thread of the pump chamber extension up to the
stop.
2. Screw the pump chamber extension onto the pump chamber.
3. Lock the pump chamber extension with the enclosed screw.
- Make a 3mm drilled hole approximately 50mm (2in) from the top of the pump
