Installation and operating instructions Wilo-Extract FIRST ... 5
English

1 Safety
1.1 About this manual
These instructions form part of the product. Compliance with the instructions
is essential for correct handling and use:
• Read the instructions carefully before all activities.
• Keep the instructions in an accessible place at all times.
• Pass the instructions on to a subsequent owner.
• Observe all product specifi cations.
• Observe the markings on the product.
The language of the original operating instructions is German. All other langu-
ages of these instructions are translations of the original operating instruc-
tions.
Failure to follow the instructions will result in:
• Danger to persons or damage to property.
• The loss of claims for damages.
1.2 Digital instructions
The digital version of the instructions is available on the following product
page:
http://qr.wilo.com/519
1.3 Identifi cation of safety instructions
In these installation and operating instructions, safety instructions are used for
material damage and personal injury. These safety instructions are illustrated
differently:
• Safety instructions for personal injury start with a signal word, have a corre-
sponding prefi xed symbol and are grayed out.
DANGER
Type and source of danger!
Impacts of the danger and instructions for prevention.
• Safety instructions for material damage start with a signal word and are repre-
sented without a symbol.
CAUTION
Type and source of danger!
Impacts or information
Signal words
• DANGER!
Non-compliance causes death or serious injury!
• WARNING!
Non-compliance can cause (serious) injury!
• CAUTION!
Non-compliance can cause material damage or even total loss.
6 WILO SE 2022-10 DIN A5
English

• NOTICE!
Useful information about handling the product
Symbols
The following symbols are used in these instructions:
General warning symbol
Warning - electrical voltage
Useful information
1.4 Personnel qualifi cations
• Persons aged 16 and over
• Have read and understood the installation and operating instructions
Children and persons with limited abilities in the household
This device can be used by children from 8 years of age as well as people
with reduced physical, sensory or mental capacities or lack of experience and
knowledge if they are supervised or instructed on the safe use of the device
and they understand the dangers that can occur. Children are not allowed to
play with the device. Cleaning and user maintenance must not be carried out
by children without supervision.
1.5 Personal protective equipment
The articles mentioned are recommendations. The articles can be replaced
with an identical article at any time. WILO SE assumes no liability for the items
mentioned.
Protective equipment: Transport, installation, removal and maintenance
• Safety shoes: uvex 1 sport S1
• Protective gloves (EN388): uvex phynomic wet
1.6 Transport and storage
• Wear protective equipment!
• Always carry the product by the handle. Never carry or pull on the connection
cable!
1.7 Installation
• Wear protective equipment!
• Do not install damaged or defective products.
Installation and operating instructions Wilo-Extract FIRST ... 7
English

1.8 Electrical connection
• Do not connect products with a damaged connection cable! Have the connec-
tion cable replaced by a qualifi ed electrician or the customer service.
• Mains connection with correctly installed protective earth conductor.
• Install the residual-current device (RCD) with 30 mA.
• Fuse protection at mains connection: max. 16 A
1.9 During operation
• The pumping of highly infl ammable and explosive fl uids (petrol, paraffi n, etc.)
in their pure form is strictly prohibited!
• If persons come into contact with the pumped fl uid (accessible basins), do not
commission the product.
Defi nition of “accessible basins”
Installation sites that can be walked on and directly accessed without tools
(e.g. ladders):
• Garden ponds
• Paddling pools
• Fountains, etc.
NOTICE! The specifi cations applicable to swimming pools also apply to
accessible basins.
1.10 Monitoring devices
The following monitoring devices must be provided by the customer if the
pump is connected to a power supply grid:
Circuit breaker
• Install the circuit breaker in accordance with the manufacturer instructions.
Observe local regulations.
• Further protection devices (e.g. overvoltage, undervoltage, or phase-failure
relay, etc.) must be provided on-site for sensitive power supplies.
Residual-current device (RCD)
• Adhere to the regulations of the local energy supply company! We recommend
using a residual-current device.
• If persons could come into contact with the product and conductive fl uids,
secure connection with a residual-current device (RCD).
1.11 Removal
• Wear protective equipment!
• Depending on the operating mode and duration, the housing parts become
hotter than 40 °C.
• Only touch the product by the carrying handle.
• Allow product to cool down.
• Clean the device thoroughly.
8 WILO SE 2022-10 DIN A5
English

1.12 Maintenance tasks
• Wear protective equipment!
• Only perform the maintenance work described in these installation and opera-
ting instructions.
• Carry out maintenance work in a clean, dry and well-lit location.
• Use only original parts obtained from the manufacturer. The use of any
non-original parts releases the manufacturer from any liability.
1.13 Operating fl uid
The oil is located in the sealing chamber. It serves to lubricate the seal on the
motor and pump side.
• Absorb leakages immediately.
• If major leakages occur, contact customer service.
• If the seal is defective, the oil enters the pumped fl uid and the sewer.
• Collect waste oil by type (unmixed) and dispose of it in accordance with regu-
lations at a certifi ed collection point.
• Skin contact: Rinse skin areas thoroughly with soap and water. If skin irritation
occurs, consult a doctor.
• Contact with eyes: Remove the contact lenses. Rinse eye thoroughly with
water. If eye irritation occurs, consult a doctor.
• Ingestion: Consult a doctor immediately! Do not induce vomiting!
2 Product description
2.1 Description
Multistage, self-venting, fully submersible pump.
Extract FIRST .. EM/A
With standard suction strainer for submerged installation above the tank/rain-
water storage tank bottom.
Extract FIRST SE .. EM/A
With side inlet connecting pieces to connect a fl oating extractor (SE).
For submerged installation above the tank/rainwater storage tank bottom.
The self-cooling motor, through which fl uid fl ows, also enables dry well
installation outside the tank/rainwater storage tank!
2.2 Type key
Extract FIRST SE 304 EM/A
Extract Product family
FIRST Series designation
SE Type of suction
[Empty] = free entrance via suction strainer
SE = side entrance (side suction inlet)
3Nominal fl ow in m3/h
04 Number of stages
EM EM - Single phase 230V
AIndex of technical evolution
Installation and operating instructions Wilo-Extract FIRST ... 9
English

2.3 Technicals data
Extract FIRST
Operating pressure max. [bar] 5
Minimum inlet pressure version [bar] 0.1 ... 0.5
Fluid temperatures max.
(immerged) [°C] 40
Input power P1See nameplate
Rated current INSee nameplate
Rated speed [1/min] 2860
Protection index, motor IP 68
Insulation class F
Frequency [Hz] 50
Voltage [V] 1~230 (±10%)
Cable length [m] 10
Switching frequency/h max. 20
Immersion depth max. [m] 5
Solid part size max. [mm] 0,2
Sand content max. [g/m3]50
Outline and pipe connections (Fig. 1), start-up pressure:
Extract FIRST ... P2 [kW] L [mm] Ø max.
[mm]
Start-up
pressure
[bar]
303 EM/A 0.75 527 160 2
304 EM/A 1.0 563 160 2.5
SE 303 EM/A 0.75 534 174 2
SE 304 EM/A 1.0 570 174 2.5
2.4 Scope of Supply
• Single phase pump with 10 m mains cable (H07RN-F) including shock-proof
plug
• Safety rope (10m)
• Installation and operating instructions
2.5 Accessories
Accessories must be ordered separately.
• Insulation valve
• Floating suction fi lter:
• suction coarse strainer,
• suction fi ne strainer
The use of new accessories is recommended.
For specifi cations and descriptions of accessories, see catalogue/data sheet.
10 WILO SE 2022-10 DIN A5
English

2.6 Product description (Fig. 2 und 3)
1. Supply cable
2. Shock-proof plug
3. Valve
4. Safety rope
5. Suction strainer
6. Floating suction fi lter
2.7 Design of pump and motor
The submersible pump is based on multi-stage and centrifugal design.
A mechanical seal protects the motor against the hydraulic part of the pump.
The SE type model are fi tted with a lateral suction support to allow the
connection of fl oating or fi xed suction fi lters.
The other models contain a suction strainer on the pump base.
The motor is equipped with an overheating protection which automatically
switches the motor off if it overheats. After suffi cient cooling, unplug the
mains plug and plug it in again - the pump restarts.
The pump reacts to a lowering of the water level and switches on and off
automatically.
The integrated electronics protect the pump from running dry.
If there is no withdrawal within 24 hours, the pump switches on automatically
for 2-3 minutes. This is to prevent the pump from blocking.
3 Application/use
CAUTION! Possible damage of the pump.This pumps are intended for use
with water only.
3.1 Intended use
Series Extract FIRST submersible pumps are suitable for the application areas
following:
• For not very deep wells, tank, cistern.
• Pumping and water distribution for:
• agricultural use (watering, irrigation),
• Pumped fl uids: non polluted, potable, cold, rain waters.
3.2 Improper use
The pump is not suitable for continuous use, e.g. for the operation of foun-
tains. (Continuous operation > 2 hrs reduces the lifetime of the pump).
The pump must not be used for emptying swimming pools.
The pump must not be used in drinking water applications.
4 Transport and storage
When receiving the material, check immediately that there has been no dama-
ge during the transport. If any defect has been stated, take the required steps
with the carrier within the allowed time.
CAUTION! If the delivered material is to be installed later on, store it in a
dry place and protect it from impacts and any outside influences (humidi-
ty, frost etc...).
Handle the pump carefully so as not to damage the unit prior to installa-
tion.
Installation and operating instructions Wilo-Extract FIRST ... 11
English

5 Installation and electrical connection
DANGER! Bodily injury!
Installation and electrical work in compliance with any local codes and by
qualifi ed personnel only
WARNING! Bodily injury!
Existing regulations for the prevention of accidents must be observed.
WARNING! Electrical shock hazard!
Dangers caused by electrical energy must be excluded.
National Electrical Codes, local codes and regulations must be followed.
5.1 Installation
CAUTION! Possible damage of the pump
Do not transport, hang or suspend the pump by the cable.
• The pump must be installed in frost-free place.
• Fix the safety rope in the middle of the handle in the superior part of the
pump.
• Connect the delivery pipe work.
• Use rigid metal pipes to hang the pump.
In a well
• Secure the pipes with brackets at the top of the well.
In a tank
CAUTION! Possible damage of the pump!
Only operate the pump in a vertical position!
• Fix the supply cable without constraint to the delivery pipe with the appropri-
ate bindings.
• Lower the pump and level it so that it is always immersed in water, maximum
depth: 5 m and freely suspended.
CAUTION! Possible damage of the pump!
Only operate the pump in a vertical position!
• Ensure that the well diameter is always constant and allows a free lowering of
the unit.
• Centre the pump in the middle of the well, tank or cistern.
• Ensure that the pump, the electric cable and the safety rope, in operation,
could not rub against the well sides or any other obstacle.
NOTE: Make sure that the pump is not in direct contact with the ground! It
could otherwise cause noise.
12 WILO SE 2022-10 DIN A5
English

• In their fi nal operating position, the suction strainer or the suction fi lter (SE
version) must have a minimum distance of 200 mm to the well bottom/tank
bottom.
• Ensure that the minimum water submersion is always 150mm over the suction
suction strainer of the pump when the pump is running (Fig. 2, 3, 4).
• The SE-type model can be installed out of water, because the motor is cooled
by the fl uid (Fig. 4).
NOTE: The pump has a valve for automatic venting in the upper part of the
housing (Fig. 6, Pos. A). This valve allows the pump to prime in a very short
time.
In the case of dry well installation of the SE version and generally when the
upper casing is not completely covered by water, a small amount of water
will leak out at this point. This is not a malfunction!
Because of the way the automatic venting works, dry installation is only
recommended outdoors (Fig. 4)!
%
$
Fig. 6: Pump topl
A Automatic venting
B Pressure setting; factory preset - DO NOT CHANGE!
• For outdoor installation, protect the delivery pipe work, the electric box, val-
ves, fl ap, electric controls from frost.
• If a fl oating tapping device (suction fi lter with hose connection) is used take
care to ensure that the length of the hose is adapted to the structural condi-
tions of the cistern (see Fig. 5). To prevent air from entering, the fi lter basket
must not reach the surface of the water.
5.2 Hydraulic connection
CAUTION! Possible damage of the pump
During the use of SE pump, fill the section hose with water before starting
the pump.
The Extract FIRST pumps are not self-priming.
• The pipework diameter cannot be inferior to the pump’s one on rigid threaded
steel pipework or a semi rigid polyethylene high density pipework.
• In the case of a semi rigid pipework the pump must be supported by a safety
rope fi xed to the carrying handle situated on the pump top.
Installation and operating instructions Wilo-Extract FIRST ... 13
English

5.3 Electrical connections
WARNING! Electrical shock hazard
The electrical connections and the inspections have to be done by a quali-
fi ed electrician and comply with the applicable local standards.
The power supply of the pump must include a circuit having a residual
current difference device (earth fault breaker) acting at no more than
30mA.
In case of cord damaged, make it replace by a qualifi ed electrician.
• Control the kind of current and the network voltage.
• Observe the specifi cations of the pump nameplate.
WARNING! Do not forget to connect the earth.
NOTE: The single-phase pumps have an integrated overcurrent protection.
• The pump with single-phase motor is cabled and has an integrated thermic
protection.
Do not connect the pump if:
• The connection cable is damaged.
Have the connection cable replaced by a qualifi ed electrician or the customer
service.
• A standalone inverter is in use.
Stand-alone inverters are used in autonomous power supplies, e.g. solar power
supply, and can generate overvoltages. Overvoltages can destroy the pump.
• A multiple plug socket or power strip is in use.
• An energy-saving plug is in use.
This reduces the energy supply to the pump and the pump may heat up too
much.
• Operation on start-up controls.
The pump is not suitable for operation on a frequency converter or a soft start
control.
14 WILO SE 2022-10 DIN A5
English

6 Starting up
6.1 Direction of rotation
Single-phase 230V: No reverse risk
6.2 Operation
CAUTION! Possible damage of the pump
NEVER allow the pump to run dry. The manufacturer’s guarantee does not
cover damage to the pump caused by dry running.
• Once again check all the electric connections, electric protection, rating of the
fuse(s).
CAUTION! Possible damage of the pump
DO not exceed the nominal current of the motor.
• After switching on, the pump switches on and off several times - fully auto-
matic venting.
NOTE: See chapter 2.3 for allowed tolerance
7 Maintenance
DANGER! Isolate from power supply before
checking the pump!.
The pump does not require particular maintenance.
• Measures, if the suction strainer is obstructed and the fl ow rate decreases
signifi cantly:
• Lift the pump.
• Clean the suction strainer under water with a brush.
• The repairs on the pump and the modifi cations of the electric connection will
be realised by a specialist or a after sales member only.
Installation and operating instructions Wilo-Extract FIRST ... 15
English

8 Problems, causes and remedies
Problems Causes Remedies
Pump does not start
up
Inadequate voltage or volta-
ge drop
Check voltage on start-up, an
insuffi cient cable cross-sec-
tion can cause a voltage drop
that prevents the motor from
operating normally.
Motor power cable break Measure the resistance
between phases. Re-assem-
ble the pump if required and
check the cable.
Motor protection ON Check the current set on
thermal relay and compare it
to the mentioned value
Important: if it trips repeti-
tively, do not insist (look at
the cause). Forcing the unit
to operation can damage the
motor (by overheating) in a
very short time limit.
No output or a very
low output
Very low voltage Check the power supply.
The suction strainer is ob-
structed
Reassemble the pump, clear
and clean it.
The valve is closed Open the valve.
No water or very low water
level in well/tank
Check this level ; it must be at
least 150mm above the suc-
tion strainer of pump (during
operating).
Air in the pump Check water cover and ensure
minimum water cover
Very frequent starts of
the pump
Leakage at pump or dischar-
ge pipe
Eliminate leakage, contact
customer service if necessary.
External bladder tank capaci-
ty is tow low or insuffi ciently
infl ated
Check and adjust pressures
(ON/OFF)
Check tank infl ation. This
pressure must be 0.3 bar
less than the pump starting
pressure.
Increase capacity with an
additional tank or change the
tank.
The non return valve leaked Contact the service.
16 WILO SE 2022-10 DIN A5
English

CAUTION! Possible damage of the pump
A common cause of faults is a silted-up or choked pump. The pump
without stand must hang sufficiently high above the bottom of the shaft
that it is not possible for it to silt up.
ON repeated trippings of the overload protector it will be necessary to
have the pump checked by a specialist or by WILO customer services.
If no solution can be found, please contact your plumbing and heating spe-
cialist or your nearest Wilo Customer Service or representative.
9 Assembly – Disassembly
CAUTION! Be careful not to mix parts.
Unplug the pump (see FIG. 9a and 9b)
10 Disposal
Your device contains valuable raw materials which can be recycled. Therefore,
please take your device to your local collection point in your town or district.
Subject to technical alterations!
Installation and operating instructions Wilo-Extract FIRST ... 17
English

WILO SE
Wilopark 1
D-44263 Dortmund
Germany
T [phone]
F [phone]
[email protected]
www.wilo.com
Pioneering for You
/RFDOFRQWDFWDW
ZZZZLORFRPFRQWDFW
