Operation Manual
ELECTRIC CHAIN SAWSHARPENER
ARTICEL 61029
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.
© y WilTec Wildanger Technik Gm H Seite 12
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury y means of fire or
electric shock we urge that our clients take some asic safety precautions when using this
device. Please read the operation instructions carefully and make sure you have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the
corresponding mains voltage on the type plate. If you have any doubts about the connection being
grounded, have it checked by a qualified professional. ever use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised
intervention the 2-year warranty is no longer valid! Keep these operation instructions safe.
© y WilTec Wildanger Technik Gm H Seite 13
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Specifications
Motor 230V,50Hz,220W
R/min 7500rpm
Table/Vise Angles 35 Degrees Right to Left
Arbor Diameter 10mm
Wheel Dimensions 100mm Dia. X 3.2mm Thick
Overall Dimensions 175mmW x 320mmL x 210mmH
Weight 1.60kgs
Save this manual
You will need the manual for safety warnings and precautions, assembly instructions, operating
and maintenance procedures, parts list and diagram. Keep the manual in a safe and dry place for
future reference.
Safety Warnings and Precautions
WARNING: When using tools, asic safety precautions should always e fol-
lowed to reduce the risk of personal injury and damage to equipment.
Read all instructions efore using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. O serve work area conditions. Do not use machines or power tools in damp or wet locations.
Don’t expose to rain. Keep work area well lighted. Do not use electrically powered tools in the pres-
ence of flammable gasses or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let them handle ma-
chines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust. Always
lock up tools and keep them out of reach of children.
5. Use the right tool for the jo . Do not attempt to force a small tool or attachment to do the work of
a larger industrial tool. There are certain applications for which this tool was designed. It will do the job
better and more safely at the rate for which it was intended. Do not modify this tool and do not use this
tool for a purpose for which it was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts.
Protective, electrically non-conductive clothes and no-skid footwear are recommended when working.
Wear restrictive hair covering to contain long hair.
7. Use eye and ear protection. Always wear approved impact safety goggles. Wear a full face shield
if you are producing metal filings or wood chips.
8. Do not overreach. Keep proper footing and balance at all times. Do not reach over or across run-
ning machines.
9. Maintain tools with care. Keep tools sharp and clean for better and safer performance. Follow in-
structions for lubricating and changing accessories. Inspect tool cords periodically and if damaged,
have them repaired by an authorized technician. The handles must be kept clean, dry, and free from
oil and grease at all times.
10. Avoid unintentional starting. Be sure the switch is in the OFF position when not in use and be-
fore plugging in.
11. Stay alert. Watch what you are doing, use common sense. Do not operate any tool when you are
tired.
© y WilTec Wildanger Technik Gm H Seite 14
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

12. Check for damaged parts. Before using any tool, any part that appears damaged should be care-
fully checked to determine that it will operate properly and perform its intended function. Check for
alignment and binding of moving parts, any broken parts or mounting fixtures, and any other condition
that may affect proper operation. Any part that is damaged should be properly repaired or replaced by
a qualified technician. Do not use the tool if any switch does not turn On and Off properly.
13. Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radi-
ators, ranges and refrigerator enclosures.
14. Replacement parts and accessories. When servicing, use only identical replacement parts. Use
of any other parts will void the warranty. Only use accessories intended for use of the tool.
15. Do not operate tool if under the influence of alcohol or drugs. Read warning labels on pre-
scriptions to determine if your judgment or reflexes are impaired while taking drugs. If there is any
doubt, do not operate the tool.
16. Use proper size and type of extension cord. If an extension cord is required, it must be of the
proper size and type to supply the correct current to the tool without heating up. Otherwise, the exten-
sion cord could melt and catch fire or cause electrical damage to the tool. This tool requires use of an
extension cord of 0 to 10 amps capability (up to 50 feet), with wire size rated at 18 AWG. Longer ex-
tension cords require larger sized wire. If you are using the tool outdoors, use an extension cord rated
for outdoor use.
17. Maintenance. For your safety, maintenance should be performed regularly by a qualified techni-
cian.
18. ever use the Electric Chainsaw Sharpener around flammable materials.
Note: Performance of this tool (if powered y line voltage) may vary depending on variations in
local line voltage. Extension cord usage may also affect tool performance.
Warning: The warnings, cautions, and instructions discussed in this instruction discussed in
this instruction manual cannot cover all possi le conditions and situations that may occur. It
must e understood y the operator that common sense and caution are factors which cannot
e uilt into this product, ut must e supplied y the operator of the tool.
Additional Safety Warnings
Grinding Wheel Warnings
1. Do not use a grinding wheel if it is chipped, cracked, or worn. You can check if the wheel has cracks
that are not visible to the human eye by hanging it up by the central hole and tapping it with a non-
metal object (ie: screwdriver handle). If it is in good condition it will produce a metallic sound. A dull
sound indicates a crack or break.
2. Only use grinding wheels that fit the arbor (7/8"). Do not try to change or modify the mounting hole
on a grinding wheel to make it fit.
3. Do not over-tighten the Nut (#3). Hand tighten it only. Over-tightening may cause the wheel to break
or disintegrate.
4. ever use the chain saw sharpener without the Grinding Wheel Cover (#2) in place.
5. Always test the Grinding Wheel (#5) by running it for a minute prior to contact with a chain.
6. Keep away from the wheel when it is turning, and make sure no one is standing close or in the line
of the wheel rotation trajectory.
7. If the grinding wheel vibrates, turn off the machine immediately and check that it is mounted se-
curely, and that is not damaged.
8. ever try to stop the grinding wheel with your hands, even if you are wearing safety gloves. The
wheel will cut through gloves and your hand causing serious injury.
9. ever operate tool without the Grinding Wheel Cover in place.
10. Replacement grinding wheel listed speed must meet or exceed RPM rating of the tool.
Warning!! This machine is designed to sharpen chain saw chains. Do not attempt to sharpen any
other tools and do not attempt to grind any other objects.
Unpacking
When unpacking, check to make that no parts contained in the parts list are missing.
Assem ly
© y WilTec Wildanger Technik Gm H Seite 15
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

1. When installing the sharpener on a workbench, make sure that the lock wheel (#46) is accessible
as shown in the mounting picture in FIGURE 1.
2. Bolt (bolts are not included) the unit directly to the workbench through the two 1/4" holes on the
ase (#40). The workbench must have a solid surface capable of supporting the weight of this sharp-
ener, the work-piece and assorted tools. See FIGURE 2.
Figure 1: Figure 2:
1/4” Hole with Bolt Base (#40)
Warning! Always unplug the unit before changing grinding wheels or when making any adjustments to the
Sharpener.
Mounting a Grinding Wheel
Refer to the assembly drawing and FIGURE 3 and FIGURE 4 below.
1.) Raise the Engine Casing (#12+24) and lock it in the up position by tightening the Screw (# 45).
2.) Remove the two screws holding the Grinding Wheel Cover (#2) and set the cover aside.
3.) Unscrew the ut (#3) that holds the Grinding Wheel (#5) in place.
4.) Install the new wheel on the Pressure Plate (#4) making sure it fits properly.
ote: Do not use a grinding wheel if it chipped, cracked, or worn. You can check if the wheel has
cracks not visible to the human eye by hanging it up by the central hole and tapping it with a non metal
object (i.e.: screwdriver handle). If it is in good condition it will produce a metallic sound. A dull sound
indicates a crack or break.
5.) Replace the ut (#3).
6.) Replace the Grinding Wheel Cover (#2).
7.) Release the Screw (#45) and lower the top housing.
8.) ever operate tool without the Grinding Wheel Cover in place.
Grinding Wheel (#5)
© y WilTec Wildanger Technik Gm H Seite 16
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
Screw (#45)
FIGURE 3 FIGURE 4
Pressure Plate (#4)
Engine Casing (#12+24)

Operation
Warning! Always unplug the unit while adjusting chain to be sharpened.
Refer to the assembly drawing on and the various photographs.
Note: Raise the top housing while adjusting the chain.
1. Clean the chain before sharpening it. Wash it with a non-flammable solvent. Don’t use gasoline to
dry the chain.
2. Lift up the Chain Stop (#53) and secure the chain in the Fixed Disk (#50). See FIGURE 6.
3. Lower the Chain Stop (#53) so that it is positioned on the tooth (blade) you want to start with. See
FIGURE 5.
Tip of Chain Stop positioned against tooth.
4. See FIGURES 5&6. Loosen the Lock Wheel (#46) to allow entire housing to turn. Rotate the hous-
ing to match the degree of angle you need on the Angle Gauge. Chains come in various sizes with
varying degrees of sharpening angles. Check with your chain manufacturer’s manual to determine
what degree you need to sharpen at. Once the degree is set, tighten the Lock Wheel (#46).
5. Lower the Engine Casing (#12+24) so that the Grinding Wheel (#5) skims the chain tooth.
6. Hold it at that position while you
tighten the Screw (#45) so that the
wheel will only go down to that point:
see FIGURE7.
7. Depending on the amount of material
you wish to remove, tighten or loosen
the Screw(#58) and set the Lock
ut: see FIGURE5.The Screw(#58) has a Lock ut,
which will determine how much material is removed.
Once you set the Lock ut, fully tighten the Screw(#58).
© y WilTec Wildanger Technik Gm H Seite 17
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
Chain Stop (#53)
FIGURE 5 FIGURE 6
Screw (#58)
Chain Stop (#53)
FIGURE 7
Screw (#45)

FIGURE 11
8. Lock the chain in the Fixed Disk
(#50) by turning the Screw (#52).
See FIGURE 8.The Screw (#52) should
be situated so that you can easily release
and tighten it . You will need to release it
each time you move to the next link, and
tighten it to sharpen each link.
9. If the chain has been repeatedly
sharpened, the chain depth limiting
gauges may need to be taken down
with a flat file(not included).
See FIGURES 8&9. File down
each gauge so that they are at
a lower level than cutting teeth.
1. Put on your protective gear and make sure the immediate area is clear of bystanders.
2. Plug in the Power Cord (#23) and press the green button on the Switch (#25) to turn on the
machine.
3. Slowly lower the grinding wheel as shown in FIGURE10. If you
notice slight errors in your settings, turn off the unit and unplug it before
you make your adjustments.
Note: A good grind occurs when the contact between the wheel and the
teeth are gradual and smooth. Do not stop too long time on each tooth.
4. After sharpening one tooth, turn off the machine. Lift the Engine Cas-
ing (#12+24), release the Screw (#52), and move the chain so that the
next link is positioned in the Chain Stop (#53). Tighten the Screw
(#52).Turn the machine ack on and continue sharpening the next
tooth. Repeat this process until you have sharpened all of the links set up
for this angle.
5. After you finish sharpening all of the teeth on the chain, turn off the ma-
chine by pushing the red button on the Switch (#25) and unplug the unit.
6. Loosen the Lock Wheel (#46) and reset the angle so that the first tooth
that hasn’t been sharpened is positioned against the Screw (#53) and
locked in as explained. See FIGURE 11.
7.As you did with the first half of the chain, be sure to lower the Engine
Casing (#12+24) so that the Grinding Wheel (#5) skims the chain tooth,
and lock it in place. Follow all of the steps from 2.) to 7.) double checking
everything before you plug in the machine and turn it on again.
Remem er to turn off the machine and unplug it if you need to
make any adjustments.
8. After you repeat all of the steps concerning the sharpening, your chain is ready to be mounted on
your saw.
© y WilTec Wildanger Technik Gm H Seite 18
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
FIGURE 8
FIGURE 9
FIGURE 10

Maintenance
1. Keep the Sharpener clean and free of dust, metal debris and dirt.
2. Check the grinding wheel before each use to make sure it isn’t damaged. Do not use a grinding
wheel if it is chipped, cracked, or worn. You can check if the wheel has cracks not visible to the human
eye by hanging it up by the central hole and tapping it with a non metal object (ie: screwdriver handle).
If it is in good condition it will produce a metallic sound. A dull sound indicates a crack or break.
3. Replace the grinding wheel when it grinds down to a diameter of 3 inches.
Parts List
Part# Description QTY Part# Description QTY
1 Safe Guard 30 Bolt
2 Grinding Wheel Cover 31 Clip
3 ut 32 Screw
4 Pressure Plate 33 Left Cover
5 Grinding Wheel 34 Flat Pad
6 Output Shaft 35 Screw
7 Bearing 36 Screw
8 Shaft Circlip 37 Handspike
9 Synchronous Belt 38 Spring
10 ut 39 Screw
11 Big Belt Wheel 40 Base
12 Left Engine Casing 41 ut
13 Bolt 42 Flat Pad
14 ut 43 Spring
15 Bearing 44 Flat Pad
16 Small Belt Wheel 45 Screw
17 Carbon Brush 46 Lock Wheel
18 Carbon Brush Holder 47 Spring Pad
19 Rotor 48 ut
20 Stator 49 Flat Pad
21 Bolt 50 Fixed Disk
22 Pressing Line Plate 51 ut
23 Power Cord 52 Screw
24 Right Engine Casing 53 Chain Stop
25 Switch 54 ut
26 ut 55 ut
27 Capacitance 56 Right Cover
28 Chain 57 ut
29 Bolt 58 Screw
PLEASE READ THE FOLLOWING CAREFULLY
THE MA UFACTURE A D/OR DISTRIIBUTOR HAS PROVIDED THE PARTS DIARAM I THIS MA -
UAL AS A REFERE CE TOOL O LY. EITHER THE MA UFACTURER OR DISTRIBUTOR MAKES
A Y REPRESE TATIO OR WARRA TY OF A Y KI D TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE A Y REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO
REPLACE A Y PARTS OF THE PRODUCT. I FACT, THE MA UFACTURER A D/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS A D PARTS REPLACEME TS SHOULD BE U DER-
TAKE BY CERTIFIED A D LICE SED TECH ICIA S A D OT BY THE BUYER.THE BUYER AS-
SUMES ALL RISK A D LIABILITY ARISI G OUT OF HIS OR HER REPAIRS TO THE ORIGI AL
PRODUCT OR REPLACEME T PARTS THERETO.OR ARISI G OUT OF HIS OR HER I STALLA-
TIO OF REPLACEME T PARTS THERETO
NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as re-
placement parts.
© y WilTec Wildanger Technik Gm H Seite 19
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

© y WilTec Wildanger Technik Gm H Seite 20
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
© y WilTec Wildanger Technik Gm H Seite 21
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
