Operation Manual
Dethatcher
51704
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from ________________________________________
Name ________________
Firm _____________________
Tel/Fax __________________
I would like to report the following mistakes
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel: ++49 2403 55592-0
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our
clients take some basic safety precautions when using this device. Please read the operation
instructions carefully and make sure you have understood its content.
Keep these operation instructions safe.
© by WilTec Wildanger Technik GmbH Seite 2
http //www.WilTec.de
http //www.aoyue.eu November 2019 Version 5
http //www.teichtip.de

ASSEMBLY
1. Attach the Spring Tine (#17) to the Frame (#8) by using the Round Head Bolt M8x20 (#16), Hex ut
M8 (#6) and Lock Washer Ø8 (#7), then tighten.
2. Attach the Lift Handle (#1) to the Frame (#8) by using the Hex Bolt M5x30 (#5) and Hex ut M5
(#15), then tighten.
3. Attach the Adjusting Rod (#4) to the Frame (#8) by using the Hex Bolt M8x25 (#3), Hex ut M8 (#6)
and Lock Washer Ø8 (#7), then tighten.
4. Attach the Adjusting Frame (#14) to the Frame (#8) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
5. Insert the Plastic Cap (#18) to the Adjusting Frame (#14).
6. Attach the Connector (#11) to the Bracket (#12) by using the Hex Bolt M8x45 (#13), Hex ut M8
(#6) and Lock Washer Ø8 (#7), then tighten.
7. Attach the Connector (#11) to the Bracket (#12) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
8. Connect the Adjusting Steel Block (#2) with the Adjusting Rod (#4), adjust them for working depth.
9. The Hex Bolt M8x25 (#3), Hex ut M8 (#6) and Lock Washer Ø8 (#7) will use for connecting the
rake.
PARTS LIST
Part # Description QTY Part # Description QTY
1 Lift Handle 1 10 Hair Cotter Pin Ø3 2
2 Adjusting Steel Block 1 11 Connector 1
3 Hex Bolt M8x25 6 12 Bracket 1
4 Adjusting Rod 1 13 Hex Bolt M8x45 2
5 Hex Bolt M5x30 1 14 Adjusting Frame 1
6 Hex ut M8 22 15 Hex ut M5 1
7 Lock Washer Ø8 22 16 Round Head Bolt M8x20 15
8 Frame 1 17 Spring Tine 15
9 Pin 2 18 Plastic Cap 1
© by WilTec Wildanger Technik GmbH Seite 3
http //www.WilTec.de
http //www.aoyue.eu November 2019 Version 5
http //www.teichtip.de

DRAWING & PARTS LIST
© by WilTec Wildanger Technik GmbH Seite 4
http //www.WilTec.de
http //www.aoyue.eu November 2019 Version 5
http //www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
