Operation Manual
Wet/dry Vacuum Cleaner 1600 W
62641
Similar to image, may vary depending on model
Read and follow the operating instructions and safety information before use.
Technical changes reserved!
Due to further developments, illustrations, functioning steps, and technical data can differ slightly.

© by WilTec Wildanger Technik GmbH Item 62641 Page 2
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless, and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously or
placing your order via the webshop.
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]
To return orders for exchange, repair, or other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 62641 Page 3
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
Introduction
Thank you very much for purchasing this quality product. To minimise the risk of injury, we ask you to
comply with a few basic safety precautions when using this product. Please read this operating manual
thoroughly and ensure that you have understood it. Keep the operating manual safely for future refer-
ence.
Safety instructions
•The device is only meant to be used in the household. It is not suitable for commercial or indus-
trial purposes.
•The device is not suitable for:
ocleaning water-sensitive floors, such as unsealed cork floors – Danger of damaging
the floors!
ovacuum cleaning sharp, pointy or bigger objects (shards, pebbles, etc.)
odo not use near explosive or easily flammable liquids – Danger of fire and explosion!
ocleaning carpets and carpet floors
•Never fill solvents, liquids containing solvents, or undiluted acids in the water tank.
•Only use the device with original spare parts, otherwise the device will be damaged and the
safety of the device affected.
•Only use the device as described in this operating manual. Any other use is considered as
improper.
•Do not use the device if it has dropped or been damaged otherwise. Only have the device
maintained or repaired by a qualified technician. Repair work carried out by unqualified people
can lead to injury or serious faults.
•Never immerse the device into water or other liquids.
•The device must always be switched off and disconnected from the mains supply before clean-
ing and maintaining it.
•Do not alter the device if it is still attached to the mains adapter/to the mains electricity supply.
•This device can be operated by children older than 8 years of age as well as people with limited
physical, sensory, or mental abilities or with lack of knowledge and experience if they are su-
pervised or have been informed about the safe use of the device and the dangers resulting from
it.
•Children are not allowed to play with the device.
•Children are not allowed to clean or maintain the device without being supervised.
•Keep the device and its electricity cable out of reach of children and animals.
•Keep sufficient distance to heating sources (e.g., cooker plates or ovens) as well as to open
fires to avoid damages to the device.
•Do not use the device in rooms where there are substances easy to ignite or toxic as well as
explosive vapours.
•Do not touch the device, electricity cable, and plug with wet hands.
•Keep body parts and clothing away of moving parts and openings of the device in operation.
Otherwise, these can be drawn in and cause injuries.
•Do not place any items into the openings of the device. Do not use the device if an opening is
blocked. Remove blockages of dust, lint, hair, etc., as these can reduce the suction power.
•When cleaning stairs, be especially careful!
•Switch the device off before changing equipment.
•Check the device for damage before every use. Do not use a damaged device.
•Fill the fresh water tank only with max. lukewarm water. Do not use any hot or boiling water.
Danger of burns!
•Do not fill in any acetic acid, descaling gent, essential oils, or similar into the fresh water tank
nor vacuum clean any.
•Protect the device from rain and store it in a dry place.
•Do not lift the mounted device upright by its handle. There is a danger of material damage.
•The multi-functional cleaner must only be connected to a socket with an according earthing.

© by WilTec Wildanger Technik GmbH Item 62641 Page 4
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
•The multi-functional cleaner is designed for use with a single-phase alternating-current of 230 V,
50 Hz and is protective insulated.
•Check if the existing mains voltage matches the stated voltage rating on the type label of the
device.
•The exchange of the connection cable or plug is only allowed to be carried out by a qualified
technician.
•Ensure that there is no water near electric parts of the multi-functional vacuum cleaner and there
is no water near people in the working area.
•In connection with the vacuumed air, explosive vapours and mixtures can form.
•Never vacuum clean the following substances:
odusts (reactive dusts), flammable or explosive liquids, and gases;
oin connection with acidic cleaning detergents and strong alkaline, reactive dusts, e.g.,
aluminium, zinc, magnesium, etc.;
ostrong acids and leaches if undiluted;
oorganic solvents, e.g., acetone, methanol, ethanol, petrol, etc.
Should you have questions regarding the use in combination with various materials, contact a qualified
professional for help.
Please note that dusts, materials with led-based varnish, minerals, metals, and some woods can be
harmful to your health. Inhaling and touching these can cause allergic reactions, irritations, or respiratory
diseases. We recommend a cautious handling and wearing the according protective gear. Inform your-
self thoroughly beforehand when processing wood, as certain dusts, e.g., oak or beech tree dusts, are
cancerous. Additives for wood processing, e.g., preservatives or chromate, together with dust are par-
ticularly problematic.
Due to the integrated filter bag and three-step HEPA filter system, the professional removal of dust is
no problem. The well-designed wheels of the cleaner enable an easy movement of the system, and the
extensive equipment makes the work for various areas easy. When using the cleaner for dry aspiration,
the first filter step catches coarse dirt in the dust bag, the second filter step is the water tank, the dust is
collected in the water. The third filter step is the HEPA filter, which removes the fine dust.
Replace the HEPA filter with a foam filter for wet vacuum cleaning.
Technical specifications
Power supply
220 V, 50 Hz
Power consumption (W)
1600
Suction power negative pressure (kPa)
approx. 18
Content of delivery
Name
Amount
Wet and dry vacuum cleaner
1
Hose
1
Telescopic bar
1
Floor brush
1
Round brush
1
Crevice nozzle
1
Operating manual
1

© by WilTec Wildanger Technik GmbH Item 62641 Page 5
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
Main components
№
Name
№
Name
1
Floor brush
8
Front intake
2
Telescopic bar
9
Push handle
3
Hose connection
10
Cable
4
Hose
11
Closing clip
5
Upper intake
12
Tank
6
Handle
13
Crevice nozzle
7
Switch
14
Round brush
Notes
The wet and dry cleaner has a double intake system, which enables the use
in various areas. The upper intake (fig. A) is designed for the use as a wet
cleaner or for the automatic vacuum cleaning.
The front intake (fig. B) is for the use as a wet cleaner. The connection not
used must be closed off with a cap.

© by WilTec Wildanger Technik GmbH Item 62641 Page 6
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
Operation instructions
1. Switching the device on/off
•Switching it on: Plug the mains plug into the socket and tilt the
switch into the “–” position to switch the multi-functional cleaner
on.
•Switching it off: Tilt the switch in the “O” position to turn the
cleaner off.
2. Installing the hose
Place the hose on the required connection and turn it clockwise. Close
the remaining connection with the cap.
3. Mounting the handle to the telescopic bar
Place the handle in the telescopic bar and turn it clockwise to orevent it
from sliding off.
4. Mounting the floor brush to the telescopic bar
Place the floor brush in the telescopic bar and turn it clockwise to pre-
vent it from sliding off.
5. Installing the front wheels
Tilt the cleaner, as seen in fig. 5 and install the wheels in the designated
intake.
6. Cable drum
The intake for the mains cable is located under the push handle. Unwind
the cable entirely when using the device.
7. Storing the equipment
On the upper side of the device, there are two intakes to store the equip-
ment.

© by WilTec Wildanger Technik GmbH Item 62641 Page 7
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
8. Blow-out function
On the front, there is a hose intake for the blow-out function. Place the
hose on the connection and turn it clockwise.
9. Tapping function for cleaning HEPA filter
Use the telescopic bar to remove the dust in the HEPA filter by tapping
it. The fixture can be found on the top, next to the handle. If there is a
power loss, we recommend tapping the filter 3–5 times.
10. Inserting the vacuum cleaner bag
Open the clear cover and insert the vacuum cleaner bag.
11. Exchanging or emptying the vacuum cleaner bag
Open the clear cover and exchange or empty the vacuum cleaner bag.
12. Taking the top off
Release the quick coupling on each side and lift the top.
13. Replacing the HEPA filter
After removing the top, as described in step 12, the HEPA filters can
easily be placed or exchanged.
14. Cleaning the HEPA filter
Remove the filter from the vacuum cleaner and clean it under a water
stream. Let the filter dry and re-place it.
15. Cleaning the equipment and connections
Remove the equipment to be cleaned and clean it thoroughly under run-
ning water. Then, re-mount it or store it in the designated intakes.

© by WilTec Wildanger Technik GmbH Item 62641 Page 8
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
16. Filling the water tank
Fill fresh water (without additives) into the tank up to the marking.
17. Speed regulation
The suction power can be adjusted via the speed regulation. Turn the
controller clockwise to increase the suction power and counter-clock-
wise to reduce the suction power.
18. Automatic dust suction
Connect the electric device with the suction hose and the mains plug of
the multi-functional cleaner.
22. Emptying the filter bag
Open the clear cover on the top of the cleaner.
23. Emptying the filter bag
Open the filter bag on the bottom by removing the cover and empty the
bag. Close it and place it back again.
24. Emptying the water container
Remove the upper part of the cleaner and remove the dirty water. Clean
the water container with clean water.
Notes:
•When using this vacuum cleaner to remove sanding dusts, check that the type of dust is suitable
for the vacuum cleaner.
•Switch the on/off switch to the “=” position after installing the connections. When turning the
connected electric device on, the vacuum cleaner will turn on with a short delay of approximately
1s. After using the electric device and switching it off, the vacuum cleaner will switch of after
approx. 10 s.

© by WilTec Wildanger Technik GmbH Item 62641 Page 9
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
Equipment
Part
Function
Floor nozzle
To clean carpets (dry cleaning) and hard surfaces (wet cleaning).
Crevice nozzle
For hard-to-reach areas, e.g., corners, radiators
Floor brush
To dust off highly sensitive furniture or scratch sensitive objects
Wet/dry nozzle
To vacuum moisture; can also be used as a floor nozzle

© by WilTec Wildanger Technik GmbH Item 62641 Page 10
http://www.WilTec.de
http://www.aoyue.eu 01 2022-1
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with do-
mestic waste.
The company WilTec Technik GmbH has been registered in the German registry EAR under the WEEE-
registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European Un-
ion and other European countries with a separate col-
lection system for these appliances).
The logo on the item or on its packaging points out that
this item must not be treated as normal household
waste but must be disposed of at a recycling collection
point for electronic and electrical waste equipment. By
contributing to the correct disposal of this item you help
protect the environment and the health of fellow human
beings. The environment and the health of living beings
are threatened by inappropriate disposal.
Recycling materials helps reduce the consumption of raw materials.
Additional information on recycling this item can be provided by your local community, municipal waste
disposal facilities or the shop where this item was purchased.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12/ 28
D-52249 Eschweiler
Important note:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instruction
manual requires the written permission of the WilTec Wildanger Technik GmbH.
