Wincor Nixdorf BA73R User manual

BA73R
15" TFT LCD Monitor
Operating Manual

The reproduction, transmission or use of this document or its contents is not
permitted without express authority.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or
design, are reserved.
Delivery subject to availability; technical modifications possible.
Copyright© Wincor Nixdorf InternationalGmbH, 2007

BA73R
15" TFT LCD Monitor
Operating Manual
Edition Nov 2009

Contents
01750140681 FBA73R LCD Display –Operating Manual
Contents
Manufacturer’s Declaration and Approval...............................1
General Authorization................................................................................1
FCC-Class A Declaration...........................................................................1
Tested Safety ............................................................................................2
User Information........................................................................................2
Safety Instructions.....................................................................................3
Instructions for Maintenance......................................................................5
Warranty....................................................................................................5
Recycling...................................................................................................6
Introduction................................................................................8
Advantages at a Glance.............................................................................9
Unpacking and checking the Delivery Unit..................................................9
BA73R Components ................................................................10
Screen Module.........................................................................................10
Power adapter and power cord ................................................................11
Cables.....................................................................................................11
Capacitive Touch Screen (Option)............................................................12
General ...............................................................................................12
Touch Screen and Sleep Mode............................................................13
How to Operate ...................................................................................14
Cleaning Instructions...........................................................................14
Resistive Touch Screen (Option)..............................................................15
General ...............................................................................................15
Construction of the resistive Touch screen...........................................16
How to Operate ...................................................................................16
Cleaning Instructions...........................................................................16
Installing the BA73R (Table Top version).................................................17
Securing the screens (Tubular Stand Version) .........................................19
Adjustable Screen Angle..........................................................................20
Ergonomic Terminal Workplace ...............................................................21

Contents
BA73R LCD Display –Operating Manual 01750140681 F
Installation................................................................................22
Connecting the VGA cable.......................................................................22
Connecting the Touch cable (option)........................................................23
Cable routing...........................................................................................24
Software Installation.................................................................................25
Status LED information............................................................................25
On-Screen Display (OSD)........................................................................26
Locking and Unlocking OSD Menu.......................................................26
Input source.........................................................................................28
Display setting.....................................................................................29
Color setting........................................................................................30
Image setting.......................................................................................32
Tools menu..........................................................................................33
Audio setting........................................................................................35
Exit OSD Menu....................................................................................36
Technical Data..........................................................................37
Models.....................................................................................................37
Operating Conditions...............................................................................38
Touch Screen (optional)...........................................................................38
Display Specification................................................................................39
Display Mode...........................................................................................41
Interface Definition ..................................................................42
VGA interface..........................................................................................42
Touch Interface........................................................................................43

Manufacturer’s Certificate and Notes
1BA73R LCD Display –Operating Manual 01750140681 F
Manufacturer’s Declaration and Approval
General Authorization
This device fulfills the requirements of Electromagnetic
Compatibility (EEC) standards, 2004/108/EC and
2006/95/EC "Low Voltage Directive". Therefore, you will
find the CE mark on the device or packaging.
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
Le présent appareil numérique ne produit pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de la "classe
A" prescrites dans le Règlement sur le brouillage radioélectrique édicté
par le ministère des Communications du Canada.

Manufacturer’s Certificate and Notes
01750140681 FBA73R LCD Display –Operating Manual 2
Tested Safety
The BA73R has been awarded the GS symbol for
"Gepruefte Sicherheit" (test safety). BA73R fulfills the
requirements for ergonomy according to ISO9241-307
Additionally, the BA73R has also been awarded to cUL-and
UL-symbol.
User Information
Wincor Nixdorf (WN) does not accept responsibility for radio and TV
interference and faults that care caused by unauthorized changes that
have been made to the devices. Furthermore, cables or other devices
that have not been approved by WN may not be connected to the
device. The user is responsible for any faults and interference that are
caused as a result.
Repair work on the devices should only carried out by
authorized and specially trained personnel. Improper repairs
will lead to the loss of any guarantee and liability claims.
Extension boards with electrostatically endangered components can be
identified with this label.
If this monitor is to be used for office task, it’s required a specially
controlled luminous environment.

Safety Instructions
3BA73R LCD Display –Operating Manual 01750140681 F
Safety Instructions
This device conforms to the corresponding safety regulations for
information technology devices, including electronic office machines for
use in the office environment.
If the device is moved from a cold environment to a warmer room
where it is to be operated, condensation could occur. The device
must be completely dry before being put into operation. Therefore an
acclimatization time of at least two hours should be accounted for.
Lay all cables and supply lines so that nobody can tread on them or
trip over them.
Data cables should neither be connected nor removed during
electrical storms.
Protect the device from vibrations, dust, moisture and heat, and only
transport the device in its original packaging (to protect it against
impact and blows).
Take care to ensure that no foreign objects (e.g. paper clips) or
liquids can get into the inside of the device, as this could cause
electrical shocks or short circuits.
In case of emergencies (e.g. damaged housing, liquid or foreign
objects getting into the device), the device should be switched off
immediately, the mains plug of the BEETLE or PC should be
removed, and theWincor Nixdorf customer service should be
contacted.
If the LCD display element is broken and the liquid crystal solution
leaks out of the display and onto your hands, clothing etc, wash your
hands or clothing immediately with soap or alcohol, holding them
under running water for at least 15 minutes. If the liquid comes into
contact with your eyes, please consult a doctor immediately.
Generally you should connect IT-devices only to power supply
systems with separately guided protective earth conductor (PE),

Safety Instructions
01750140681 FBA73R LCD Display –Operating Manual 4
known as TN-S networks. Do not use PEN conductors! Please
also observe the recommendations of the norm DIN VDE 0100, part
540, Appendix C2, as well as EN50174-2, §5.4.3.

Instructions for Maintenance
5BA73R LCD Display –Operating Manual 01750140681 F
Instructions for Maintenance
Clean your BA73R regularly with an appropriate surface cleaning
product. Make sure that the device is switched off, connector cables are
unplugged and that no moisture is allowed to get into the inside of the
device.
Please observe the maintenance and cleaning instructions for each of
the BA73R components. These instructions can be found in their
respective chapters.
Warranty
Wincor Nixdorf guarantees a limited warranty engagement for 12months
beginning with the date of delivery. This warranty engagement covers all
those damages that occur despite a normal use of the product.
Damages because of
improper or insufficient maintenance,
improper use of the product or unauthorized modifications of the
product,
inadequate location or surroundings
will not be covered by the warranty. All parts of the product which are
subject to wear and tear (e.g. backlight of the LED) are not included in
the warranty engagement. Please order spare parts at the Wincor
Nixdorf customer service.

Instructions for Maintenance
01750140681 FBA73R LCD Display –Operating Manual 6
Recycling
Environmental protection does not begin when the time has come to
dispose of the BA73R; it begins with the manufacturer. This product was
designed according to our internal norm “Environmental conscious
product design and development”.
The BA73R is manufactured without the use of CFCs and CCHS and is
produced mainly from reusable components and materials. The
processed plastics can, for the most part, be recycled. Even the precious
metals can berecovered, thus saving energy and costly raw materials.
Please do not stick labels onto plastic case parts. This would help us to
re-use components and material. You can protect our environment by
only switching on your equipment when it is actually needed. If possible,
even avoid the stand-by-mode as this wastes energy, too. Also switch
your equipment off when you take a longer break or finish your work.
Currently at present, there are still some parts that are not reusable.
Wincor Nixdorf guarantees the environmentally safe disposal of these
parts in a Recycling Center, which is certified pursuant to ISO 9001.
So don’t simply throw your BA73R on the scrap heap when it has served
its time, but take advantage of the environmentally smart up-to-date
recycling methods!
Please contact your competent branch or the Recycling Centre
Paderborn (for European countries) for information on how to return and
re-use devices and disposable materials under the following fax number:
Fax. [phone]
Or send us an email to:

Instructions for Maintenance
7BA73R LCD Display –Operating Manual 01750140681 F
[e-mail]
Welook forward for your fax ormessage.

Introduction
01750140681 FBA73R LCD Display –Operating Manual 8
Introduction
The BA73R is a new addition to our range of flat-panel display. This
display features a standard analog RGB interface allowing connection to
PC's CRT output. There is no need to add a digital graphics adapter.
Using the BA73R provides you with a terminal-orientated, ergonomic
and customer-friendly cashier’s workplace. The BA73R can also be
optionally equipped with a Touch Screen.
The display can be applied in all trade market segments like specialist
retailers, departmental stores, self-service stores, petrol stations or in
restaurants. There is indeed a great deal of scope for implementing a
BA73R. Introduction
They can be used, for example, as:
an ordering terminal
an information terminal
a lottery terminal
a point-of-sale terminal
a training terminal.
The low-energy, flicker-free and low radiation colour monitor of the
BA73R is an Active-Matrix-Display in TFT-technology (Thin Film
Transistor). Therefore, it is especially suited for multimedia applications
as it offers brilliant colour representation, a better contrast ratio and a
high display speed.
The screens can be installed directly on the cashier’s desk or fastened
to a tubular stand. Furthermore, they can also be set up on the central
unit of a modular BEETLE system.

Introduction
9BA73R LCD Display –Operating Manual 01750140681 F
Advantages at a Glance
low footprint
ergonomic terminal workplace
key to customer service
basis for animation and multimedia
flicker-free and low radiation
high resolution
high brightness
very good contrast ratio
high brilliant colours (up to 16 millions)
wider viewing angle (less glare through crosslight)
Unpacking and checking the Delivery Unit
Unpack the parts and check to see whether the delivery matches the
information on the delivery note. The delivery comprises of the
respective screen module. Controllers and data cables, necessary for
operation, can be ordered separately. If damage has occurred during
shipping or if the package contents do not match the delivery note,
promptly inform your Wincor Nixdorf sales outlet. Transport the device
only in its original packaging (to protect it against impact and shock).

BA73R Components
01750140681 FBA73R LCD Display –Operating Manual 10
BA73R Components
Screen Module
The screen module represents the main unit of the BA73R. It comprises
of a TFT-LCD colour screen, the auto-scaling display Controller and an
inverter that generates the voltage for backlighting the screen. As an
option the screens are available with Touch Screen.
Remove the cable cover by
pushing it in the direction of
arrow (see picture) and then
taking it off upwards.
The TFT LCD flat screen is an XGA 15” that is flicker-free and free of
radiation and has only a low heat emission. The BA73R has a native
resolution of 1024 x 768, but it features high-quality advanced auto-
scaling display controllers that allow scaling from VGA to XGA.
WARNING:
If the display element is damaged and the liquid crystal solution leaks
out onto your hands or clothing, please wash your hands or clothing
immediately under running water for at least 15 minutes, using soap or
alcohol. If the liquid comes into contact with your eyes, consult a medical
doctor immediately.

BA73R Components
11 BA73R LCD Display –Operating Manual 01750140681 F
Power adapter and power cord
If the AC power adapter and power cord are not provided with the
display, user has to ensure that a certified AC power adapter and power
cord are used as required by the Safety Regulation of the country. The
power requirement of the display is shown under the section “Display
Specification”. Please refer to this when selecting a suitable AC power
Adapter.
Countries Safety Approvals
USA UL
Canada CSA
Germany VDE
Japan PSE
Taiwan BSMI
China CCC
For other countries not mentioned in the above list, please check with
the local authority.
Cables
Standard VGA cable, 1.8m
Touch Cable, 1.8m (option)

BA73R Components
01750140681 FBA73R LCD Display –Operating Manual 12
Capacitive Touch Screen (Option)
General The TFT Touch Screen works according to the principle of a change in
analog capacitance. It has a glass screen with a transparent, thin-film
overlay on the surface. This is fully sealed and protected by a further
layer of clear glass. Electrodes on the edges of the screen provide a
uniform low-voltage field. As soon as you touch the screen with your
finger the contact point is “recognized” by the change in capacitance.
Because this takes place very quickly -15 milliseconds after being
touched -the Touch Screen is optimally equipped for a number of
different requirements and applications.

BA73R Components
13 BA73R LCD Display –Operating Manual 01750140681 F
The programming interface of the screen is identical to the mouse
interface.
Touch Screen and Sleep Mode
Using the Touch Screen with a BEETLE Pentium CPU, an entry via
touch during sleep mode may lead to a faulty input. During sleep mode
nothing can be read from the LCD flat screen. Entries via touching the
screen will still be processed by the system, but without the system
“waking up”.
For these reasons it is not recommended to set the sleep mode. For
details please read the chapter “BIOS Setup” in the BEETLE User Guide.
!

BA73R Components
01750140681 FBA73R LCD Display –Operating Manual 14
How to Operate
The Touch Screen responds to the slightest contact, therefore you do
not have to apply much pressure when working with the screen. This not
only saves time, but is also kind to your joints! Touching the touch glass
has the same effect as clicking the left mouse button. You need only
apply a little pressure with the fingertip. In this capacitive process only
fingertip contact is recognized. The screen does not re-act in any way if
touched, for example, with a pencil or a glove.
Cleaning Instructions
The glass surface should be cleaned from time to time. Always turn off
the system before cleaning. The glass surface of your Touch Screen
should be cleaned with a mild, commercially available glass cleaning
product without any scrubbing material. All pH neutral materials (pH 6 to
8) are good for cleaning. Cleaners with pH values 9 to 10 are not
recommended. Cleaning with water and isopropyl alcohol is as well
possible. Do not use solvents containing acetic acid. Use a soft, fine-
meshed cloth to clean the surface. Dampen the cloth slightly and then
clean the screen.
