Wind Chaser WC166 User manual

INSTRUCTION MANUAL
PLEASE READ BEFORE USE AND SAVE
Innovative Products For Living

Fan
Misting
Fan
Misting
TM
OUTDOOR
OUTDOOR
CONTENTS
MODEL WC166
Before Initial Use 2
For Your Safety 3
Parts 4
Assembly 5
Operation and Cleaning 6
Storage 7
Troubleshooting 8
Limited Warranty 9

Read This Entire Instruction Manual Before Use!
For your reference:
Serial No. Date of Purchase
Name and Address of Dealer
Tool Needed For Assembly
Phillips or Flat Head Screwdriver
BEFORE INITIAL USE
Attach your purchase receipt here
PLEASE KEEP YOUR RECEIPT.
YOUR RECEIPT IS YOUR PROOF OF
PURCHASE AND IS NECESSARY FOR
WARRANTY SERVICE

FOR YOUR SAFETY
READ AND SAVE THESE IMPORTANT INSTRUCTIONS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Use fan only as described in this manual. Other uses not
recommended may cause fire, electric shock or injury.
2. This product is intended for household use only and not for
commercial or industrial use.
3. To protect against electrical shock, do not immerse unit, plug, or cord
in water or spray with liquids.
4. Close supervision is necessary when any appliance is used near
children.
5. Unplug fan from outlet when not in use, when moving fan from one
location to another or before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosives and/or flammable
fumes.
8. Do not place fan or any parts near an open flame, cooking or heating
appliance.
9. Do not operate fan with a damaged cord, plug or after the fan
malfunctions or has been dropped or damaged in any manner.
10. Do not let cord hang over the edge of a table or counter, or let it
touch hot surfaces.
11. To disconnect, grip plug and pull from wall outlet. Never yank on
cord.
12. Always use on a level surface.
13. Do not hang or mount fan on a wall or ceiling.
14. Do not operate without fan grills properly in place.
SAVE THESE IMPORTANT SAFETY INSTRUCTIONS.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL
SHOCK AND INJURY TO PERSONS, DO NOT USE IN A WINDOW.
WARNING: DO NOT USE THIS FAN WITH ANY ADDITIONAL
DEVICES TO ALTER/CHANGE THE SPEED OF THIS FAN (EX:
SOLID STATE SPEED CONTROL DEVICE).
SOLUCIÓN DE PROBLEMAS

GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment-grounding conductor and a ground-
ing plug. The plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk of electrocu-
tion. Check with a qualified electrician or service personnel if you are in doubt as to whether
the outlet is properly grounded. Do not modify the plug provided with the product. If it does
not fit the outlet, have a proper outlet installed by a qualified electrician. Do not use any type
of adaptor with this product.
GROUND FAULT CIRCUIT INTERRUPTER
(GFCI) PROTECTION
This fan is provided with a ground fault circuit interrupter (GFCI) built into the plug of the
power supply cord. This device provides additional protection from the risk of electric shock.
Should replacement of the plug or cord become necessary, use only identical replacement
parts that include GFCI protection.
PARTS
Set Screw
Control Box
Motor Housing
Oscillation Knob
Front Motor Housing
Rear Grill
Rear Grill Set Screw
Grill Lock Nut
Fan Blade
Blade Cap
Fan Shroud
Misting Hub
with 4 misting nozzles
Misting Line
Normal 3/4" swivel hose
adapter or spigot adapter
with filter washer
Waterproof Cover
Power Cord/GFCI Plug
Inner P e
Misting Line Hol
ol
der
Height Adjust Knob
Outer Pole
Threaded Connector
Base

ASSEMBLY INSTRUCTIONS
Important: Assemble the fan before plugging it in.
1. Screw threaded outer pole into threaded base;
Hand tighten until firmly secured; use no tools.
HEIGHT ADJUSTMENT: Loosen the height adjustment
knob (counter-clockwise), adjust the height to the
desired position and tighten the knob (clockwise).
2. Loosen the set screw on the back of the control box
and set the control box onto the inner pole. Then
tighten the set screw to secure the control box and
motor head to the inner pole. When adjusting the
inner pole, always keep the water proof cover
matched with the height adjustment knob.
3. Unscrew the grill lock nut by turning it counter-clock
wise. Unscrew the rear grill set screws (the two
screws at the 12 o‘clock and 6 o‘clock positions above
and below the motor shaft). Mount the rear grill (with
the handle in the upright position) to the motor housing
by matching its 3 holes to the 3 round pins on the front
motor housing. Then secure the rear grill set screws to
lock the rear grill to the front motor housing. Reinstall
and tighten the grill lock nut.
4. Insert the fan blade onto the motor shaft by matching
the slot of the blade with the D-shaped cut out on the
motor shaft. Secure the blade by screwing the blade
cap onto the shaft counter-clockwise.
12
3

5. Attach the fan shroud to the rear grill, using provided
screws and clips. The screws and clips are located “in”
the shroud. You will notice these screws and clips are
inserted all the way around the inner rim of the shroud.
Underneath the clips there are plastic protrusions. The
rear grill sits in between the clip and the plastic
protrusion. Loosen the screws and “shimmy” the
shroud onto the grill from the bottom. Some screws
and clips may have to be removed in order to slide the
shroud on; however, do not take all of them out as it is
hard to put them back into the shroud.
6. Push and twist one end of the 6 foot hose into the
Swivel Adapter. Insert screen washer into swivel
adapter and attach to outdoor hose or spigot.
IMPORTANT INFORMATION
THIS FAN IS INTENDED FOR OUTDOOR USE BUT MAY BE USED INDOORS
WITHOUT THE MISTING FEATURE. Place the fan on a level surface near
an electrical outlet. Place the fan out of the reach of children. Do not insert
anything into the grill. If moving the fan to a different location, switch it off and
unplug it from the socket.
Place the fan on a level surface. Plug the GFCI plug into a standard 120V AC
3-prong wall outlet. To operate, push the control button corresponding to the
desired speed. OFF, LOW, MED, HIGH. THE ANGLE OF THE FAN HEAD IS
NOT ADJUSTABLE.
Oscillation:
Press the knob down to make the fan oscillate or pull the knob up to stop
oscillation.
NOTE: If the fan head should become stalled or sticks at the end of the
oscillation cycle, gently turn the head 1 to 2 clicks in the opposite
direction.
MISTING
Attach the 3/4” hose adapter to any 3/4” (standard) garden hose or spigot.
Misting must be turned on/off from the water source.
DO NOT USE INDOORS WITH MISTING FEATURE!
BE SURE THE ELECTRICAL PLUG IS REMOVED FROM THE ELECTRICAL
SOCKET BEFORE ATTEMPTING ANY CLEANING OR MAINTENANCE.
Turn the system off and gently tap the nozzle with the head of a screwdriver to
loosen any sediment that may have accumulated. If tapping does not clear the
CLEANING INSTRUCTIONS
OPERATING INSTRUCTIONS

nozzle, unscrew it from the misting line for further cleaning.
Place nozzles in a container of vinegar or a household lime and scale remover
(such as Lime-Away™) for about 30 minutes. Make sure to stir or shake the
solution every few minutes to help loosen debris. Heavier deposits may require
longer soaking and/or additional scrubbing of the nozzles with a stiff non-metal-
lic brush.
After soaking, shake the nozzles. You should hear a rattling sound. If none is
heard, gently tap the nozzles against a solid surface to loosen any obstruction.
If this doesn’t clear the nozzles, they should be replaced. Check your packaging
for extra nozzles, or call WindChaser Products, Inc. to purchase replacement
nozzles.
IMPORTANT – Never attempt to clear nozzles with pins, nails or other metal
objects as this can damage the misting orifice.
Use only a soft moistened cloth with a soap solution to clean the fan.
Do not immerse the fan in water.
Do not use gasoline thinners or other chemicals to clean fan.
To dismantle for cleaning or long term storage, follow the assembly instructions in
reverse order. The fan blade may be washed in warm water using a little mild
detergent. Alternatively, it may be wiped clean with a soft damp cloth. Be sure it is
completely dry before re-fitting.
The front and rear grills, stand and base can be cleaned with a soft brush or soft
damp cloth.
For storage, clean fan carefully as instructed and store in its original box or cover
with plastic / cloth. Store the fan in a clean, dry place.
ELECTRICAL RATINGS
This product has been rated at 120VAC 60Hz 54W. If you experience a problem,
contact WindChaser customer service.
Do not attempt to open the motor housing of the fan; doing so may cause damage to
the fan or personal injury.
CAUTION
There are no consumer serviceable parts inside this fan. If you experience a
problem, please see warranty for information. Please do not attempt to open the fan;
doing so will void your warranty and could cause damage and personal injury.
STORAGE INSTRUCTIONS
PRTES

LIMITED WARRANTY
Three (3) Year Limited Warranty on Motor and One (1)
Year Limited Warranty on All Other Parts
This warranty applies to repair or replacement if a product is found to be defec-
tive in material or workmanship. This warranty does not apply to any damage
resulting from commercial, abusive and/or unreasonable use or supplemental
damage. Defects as a result of normal wear and tear will not be considered
manufacturing defects under this warranty. Read the instruction manual before
attempting to use this product. WindChaser Products, Inc. is not liable for inci-
dental or consequential damages of any nature. Any implied warranty of mer-
chantability or fitness for a particular purpose on this product is limited in dura-
tion to the duration of this warranty. Some states do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long an
implied warranty lasts, so the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights, and you also may have other
rights which vary from state to state. This warranty applies only to the original
purchaser of this product. WindChaser Products, Inc. will repair or replace this
product if it is found to be defective in material and/or workmanship. Defective
product should be returned to the place of purchase in accordance with store
policy. If you experience difficulty with your product after the expiration of the
store’s return policy, contact the Customer Service department at WindChaser
Products, Inc. (see below). This warranty does not cover damage resulting
from unauthorized attempts to repair or from any use not in accordance with its
manual.
