Wind Crest WSL Series User manual

Copyright 2006 Wind Crest by CNP Industries 1
Install Quick Specs are for planning purposes only. Please refer to the detailed installation instructions, prior to
making any cutouts.
Wall Mounted Hoods – Install Quick Specs
WSL Series Hoods - 27” Depth
Installation Type & Discharge Direction
Wall – vertical discharge
Discharge Size off Hood Top
14” x 4 ¼” rectangular
Discharge Transition – purchased
separately
See “Ventilation” section for options
Standard Features
•304 Series, 18 gauge stainless steel
•Halogen lighting (dual 50 watt lamps 30” to
48” widths/four 50 watt lamps 54” or
greater widths) with Hi/Lo setting
•Commercial-grade, high luster stainless
steel baffle filters
•All Stainless Steel Finish Hoods can be
installed Indoors or Outdoors (see
Installation Instructions)
•Widths: 30” to 60” in 6” increments
Finishes
•Stainless Steel (S)
•Stainless Steel with Polished Chrome
Accents (SPC)
Optional Upgrades
•250 Watt Heat Lamp Fixtures (add “H” to
hood model number) e.g. WSL304SH
•6” or 12” Canopy Extensions in matching
finish (Model(s): 6CE30S or 12CE30S for
30” wide hood in stainless steel finish).
NOTE: Specify desired canopy height,
width and finish when ordering.
•Chrome or Brass Rolled Pot Rails
(Model(s): ACCBRC or ACCBRB) – indoor
use only
•Stainless Steel Back Splash with drop-
down chrome racks supports a maximum
of 30 lbs. (BS plus width – e.g. BS30)
Hood Carton Weight:
WSL307 = 73 lbs. WSL487 = 100 lbs.
WSL367 = 81 lbs. WSL547 = 110 lbs.
WSL427 = 88 lbs. WSL607 = 120 lbs.
Wiring Access
27"
18"
12"
3"
30,36,42"
12"
18"
27"
48,54,60"
3"
Knockouts For
Dual Blowers
Wiring Access
14"
1"
4-1/4"
=widthofhood
13"
WSL Hoods
“BS” Warming Shelf Accessory with Chrome Racks
ULUL
LISTED7Z66 C

Copyright 2006 Wind Crest by CNP Industries 2
Install Quick Specs are for planning purposes only. Please refer to the detailed installation instructions, prior to
making any cutouts.
Wall Mounted Hoods – Install Quick Specs
WSL Series Hoods - 27” Depth (cont.)
Maximum Power Supply Required*
15 Amps @ 120 V AC, 60 Hz
20 Amps @ 120 V AC, 60 Hz (when used with
VEN150E remote ventilator)
*Electrical rating is maximum required for any
combination of ventilator, lighting and heat
lamps.
Outdoor Electrical Requirements
Damp outdoor installations require a fault
interrupter circuit connection.
Hood Lighting Rating
•30” to 48” widths: 100 watts w/halogen
lights or 600 watts w/halogen + heat lamps
•54” and 60” widths: 200 watts w/halogen
lights or 700 watts w/halogen + heat lamps
Ventilator Options
640 CFM, Internal Blower: VEN060I**
1000 CFM, Remote Blower: VEN100E
1500 CFM, Remote Blower: VEN150E
Ventilator Motor Ratings
VEN060I: 2.8 Amps @ 120 V AC, 60 Hz**
VEN100E: 8 Amps @ 120 V AC, 60 Hz
VEN150E: 12 Amps @ 120 V AC, 60 Hz
**Two VEN060I internal ventilators can be
installed in WSL hoods 48” or wider. This
installation requires part #10220 dual wire
harness. Refer to the installation instructions
for full details.
Ventilator Dimensions & Accessory
Transitions (see Ventilator section)
CUSTOMER SPECIFICATION:
Hood Width Specified & finish:
(e.g.WSL304S)
Add Keep Hot Lamps: (e.g. WSL304SH)
Add Special Edge Finish to Stainless
Models: (i.e. WSL304SHSPC)
Accessories Selected: (e.g. Back splash with
racks, chrome or brass rails, canopy
extensions)
12"
6", 12"
=widthofhood
Chrome/Brass
Rolled Pot Rail
Center Support
48, 54, 60" Models
1-7/8"
3/4"
Final Hood Model Selected:
Add Any Accessories:
Specify Ventilator Selected & Transitions:
“CE” Canopy Extensions (6” or 12” height) for
WSL hoods
