Windsor Arbor
Assembly & installation Instructions
General Information:
» Read through carefully before beginning assembly.
» When assembling components, place on a clean, flat,
non-abrasive surface to avoid scratches.
» In the event of missing or defective parts, please call our
customer service department directly at 1-877-258-6020
Tools required:
» Cordless Drill with #2 phillips bit
» Hammer
» Tape Measure
» Shovel
» Post Hole Digger (recommended)
Part # Description Qty
1 4” sq. x 84” Left Post 2
2 4” sq. x 84” Right Post 2
3 2” sq. x 29¾” Top/Bottom Cross Rail 4
4 2” sq. x 29¾” Center Cross Rail 8
5 ⅞x 1½ x 59½” Vertical Rail 6
6 1½” x 4” x 72” Arbor Top Rail 2
7 ⅞” x 1½” x 72” Overhead Rail 2
8 2” sq. x 26¾” Arbor Top Cross Rail 5
9 4” sq. Flat Post Cap 4
10 24” U-channel Ground Anchor 4
11 Hardware Kit (includes):
PVC Glue Can 1
4” Arbor Top End Cap 4
⅞” x 1½” Overhead Rail End Cap 4
1½” Kappet Screws 26
Kappet Screw Caps 26
1” Self-tapping White-hdead Screws 8
Parts List:
FIGURE 1
Product dimensions &
Part identification
FIGURE 2
Ground Anchor Layout
for installation

Lay out one right post (part 2).
Starting at bottom, insert one top/
bottom rail (part 3) and four center
rails (part 4).
Slide three vertical rails (part 5)
through center rails and into top/
bottom rail.
Insert one top/bottom rail (part 3) into
right post, sliding three vertical rails
into top/bottom rail.
Slide left post (part 1) over
corresponding top/bottom and center
rails. DO NOT screw arbor panel
together.
REPEAT steps 1-4 for the second
arbor panel.
1
2
3
4

With arbor panels lying down and
screw pilot holes of each arbor panel
facing out, slide two arbor top rails
(part 6) all the way through both
routed holes at the top of each arbor
panel.
Note: 2” sq. holes should line up with
2” sq. holes in the top of the arbor
panels. This will leave 7” of overhang
on each side of the arbor.
Insert five arbor top cross rails (part 8)
into arbor top rails and arbor panel
posts by carefully separating posts
just enough to insert the five rails.
When inserting rails, insert with screw
pilot holes facing up.
Note: Outer two arbor top cross rails
are inserted into posts, and then lock
into the arbor top rail.
Using 1½” kappet screws, screw
together both arbor panels. Be sure
that all parts are fully inserted into
posts before securing. Snap kappet
screw caps over screw heads.
5
6
7

Apply PVC glue to inner edges of the
four flat post caps (part 9) and place
on top of each post. Glue four 4” ar-
bor top end caps onto ends of each
arbor top rail. Glue four overhead rail
end caps onto ends of each overhead
rail.
Using 1½” kappet screws, insert
screws through holes of two
overhead rails (part 7). Fasten
screws to screw pilot holes of the five
arbor top cross rails. Snap kappet
screw caps over screw heads.
8
9

ARBOR INSTALLATION
Option 1
Slide one 24” steel u-channel ground anchor
into bottom of each post. Slide ground
anchor until it meets bottom cross rail. For
increased stability, unfasten bottom screws
separate bottom of arbor panel just enough
to slide ground anchor further into post. It is
recommended to leave at least 16” of
ground anchor exposed. Using 1” self-
tapping white-head screw, fasten post to
ground anchor.
Using ground anchor installation layout
drawing (figure 2), dig holes approximately
16” deep. Set arbor in holes and level.
Back fill with soil removed from holes. For
permanent installation fill with cement.
Option 2
Using ground anchor installation layout
drawing (figure 2), pound ground anchors
into ground according to dimensions. When
pounding into ground, use block of wood to
prevent ground anchor from bending.
Slide arbor over ground anchors. Using 1”
self-tapping white-head screw, fasten post
to ground anchor.
Option 3
Using ground anchor installation layout
drawing (figure 2), dig holes 16” deep
according to dimensions. Fill with cement
and place ground anchors in wet cement.
Be sure that ground anchors are straight
and in accordance with dimension of ground
anchor installation layout drawing. Allow
cement to dry. NOTE: There is very little
room for error with this installation method.
Slide arbor over ground anchors. Using 1”
self-tapping white-head screw, fasten post
to ground anchor.
10
