Windsor CLP12 User manual

Read these instructions before operating the machine
MODEL: CLP12
Operating Instructions
98630 08/19/03
EE
CARPET EXTRACTOR

TABLE OF CONTENTS
CLIPPER 98630 10/19/02
1
Data Log/Table of Contents..............1
Safety Instructions............................2
Grounding Instructions .....................3
Controls............................................4-6
Operations........................................7-13
Troubleshooting................................14
Wiring Diagram.................................15
Maintenance .................................... 16-18
Technical Specifications................... 19
Service Schedule. ............................ 20
Parts Lists........................................ 21-34
Spare Parts/Notes............................ 35
Warranty ....................................... 36
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is operated and thoroughly inspected
before shipping, and any damage is the responsibility of the carrier, who should be notified immediately.
MODEL
DATE OF PURCHASE
SERIAL NUMBER
SALES REPRESENTATIVE #
DEALER NAME

SAFETY INSTRUCTIONS
CLIPPER 98630 12/14/98 2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
This machine is for commercial use.
To reduce the risk of fire, electric shock, or injury:
Connect to a properly grounded outlet. See Grounding Instructions.
Do not leave the machine unattended. Unplug machine from outlet when not in use and before
maintenance or service.
Use only indoors. Do not use outdoors or expose to rain.
Do not allow machine to be used as a toy. Close attention is necessary when used by or near
children.
Use only as described in this manual. Use only manufacturer’s recommended components and
attachments.
Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding
the machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or
dropped into water, return it to an authorized service center.
Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord
around sharp edges or corners.
Do not run machine over cord. Keep cord away from heated surfaces.
Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.
Do not handle the electrical plug or machine with wet hands.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is intended for cleaning carpet only.
Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
This machine is not suitable for picking up health endangering dust.
Turn off all controls before unplugging.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
SAVE THESE INSTRUCTIONS
!
WARNING:

GROUNDING INSTRUCTIONS
CLIPPER 98630 12/14/98
3
THIS PRODUCT IS FOR COMMERCIAL USE ONLY.
ELECTRICAL:
In the USA this machine operates on a standard
15 amp 115V, 60 hz, A.C. power circuit . The amp,
hertz, and voltage are listed on the data label found
on each machine. Using voltages above or below
those indicated on the data label will cause serious
damage to the motors.
GROUNDING INSTRUCTIONS:
This appliance must be grounded. If it should
malfunction or break down, grounding provides a
path of least resistance for electric current to
reduce the risk of electric shock. This appliance is
equipped with a cord having an equipment-
grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is
properly installed and grounded in accordance with
all local codes and ordinances.
This appliance is for use on a nominal 115-volt
circuit, and has a grounded plug that
looks like the plug in “Fig. A”. A temporary adaptor
that looks like the adaptor in “Fig . C” may be used
to connect this plug to a 2-pole receptacle as
shown in “Fig. B”, if a properly grounded outlet is
not available. The temporary adaptor should be
used only until a properly grounded outlet (Fig. A)
can be installed by a qualified electrician. The
green colored rigid ear, lug, or the like extending
from the adaptor must be connected to a
permanent ground such as a properly grounded
outlet box cover. Whenever the adaptor is used, it
must be held in place by a metal screw.
Improper connection
of the equipment-
grounding conductor
can result in a risk of electric shock. Check with a
qualified electrician or service person if you are in
doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the
appliance - if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
!
WARNING:
NOTE: In Canada, the use of a temporary adaptor is no
t
p
ermitted by the Canadian Electrical Cod
e
PROPER GROUNDING
Metal Screw
Adaptor
Grounded Outlet Box
Fig. A Fig. B
Fig. C
Tab For Grounding Screw
Grounded
Outlet
Grounding Pin
Adaptor

CONTROLS/COMPONENT LOCATIONS
CLIPPER 98630 12/14/98 4
1. Main Handle. Used to pull and maneuver
machine.
2. Handle Adjustment. Used to adjust height of
handle, and allow machine to be used in
“PUSH” or “PULL orientation.
3. Electrical Cord.
4. Solution Switch. Turns on pump. Continuous
position (bottom) activates electro-valve to
dispense solution to floor through jets.
Intermittent position (up) requires operator to
depress 1 of 3 trigger switches to dispense
solution. Center position is off.
5. Brush Motor Switch. Turns on brush motor.
6. Vacuum Motor Switch. Turns on vacuum
motor.
7. Trigger Switches. Activates electro-valve to
dispense solution to floor through jets when
solution switch is in the intermittent position.
8. Brush Motor Circuit Breaker. 6 amp.
Breaker protecting brush motor.
9. Vacuum Motor Circuit Breaker. 15 amp.
Breaker protecting vacuum motor.
10. Recovery Dump Hose. Facilitates draining
dirty cleaning solution.
3
1
10
2
5
8946
7

CONTROLS/COMPONENT LOCATIONS
CLIPPER 98630 12/14/98
5
1
2
3
13
12
69
8
1. Solution Accessory Tool Hookup. Used for
various auxiliary cleaning tools.
2. Vacuum Hose Door. Used to connect
various auxiliary 1 ½ inch cleaning tool
vacuum hoses.
3. Brush Height Adjustment. Used to regulate
brush height from storage position to various
carpet heights.
4. Recovery Tank. Used to collect dirty
cleaning solution.
5. Solution Tank. Used to hold cleaning
solution.
6. Solution Dump Hose. Facilitates draining
excess cleaning solution from solution tank.
7. Recovery Tank Dome.
8. Solution Tank Lid.
9. Solution Tank Fill Hose.
10. Vacuum Shoe.
11. Brush Housing.
12. Front Lifting Handle.
13. Cleaning Solution Filter. 4
5
7
10
11

CONTROLS/COMPONENT LOCATIONS
CLIPPER 98630 12/14/98 6
1. Solution Intake Cover.
2. Vacuum Intake Cover.
3. Float Shut-Off.
4. Clean-Out Opening.
5. Pour Spout.
6. Lift Handle.
21
3
4
5
6
6

FILLING OPERATIONS
CLIPPER 98630 12/14/98
7
FILLING THE CLIPPER
NOTE: Use clean bucket of water to fill solution tank
Do not put defoamer, solvents, spotter or
prespray chemicals in the solution tank.
Do not allow water to spill into vacuum motor inlet. Dry
spillage from top of solution tank before replacing
recovery tank.
CHEMICALS
Suitable Chemicals Non-Compatible Chemicals
Alkalis Aldehydes
Detergents Aromatic Hydrocarbons
Hydroxides SP Butyls
Soaps Carbon Tetrachloride
Vinegar Clorox*
Chlorinated Bleaches
Chlorinated Hydrocarbons
Lysol*
Methyl Ethel Ketone (MEK)
Perchorethylene (perc)
Phenolics
Trichlorethylene
D-Limonene
STEP
1
STEP
2
STEP
3
STEP
4
RECOVERY TANK
SOLUTION
TANK
Remove solution
tank lid
Replace solution
tank lid
A
dd cleaning
chemical
12 – 24oz.
(356ml – 711ml)
FILL LINE 140°F
(
60°C
)
12 gal.
(45.5 ltr.)
or
A
dd water

OPERATIONS
CLIPPER 98630 12/14/98 8
Remove electrical cord and literature
from recovery tank. Fill solution tank
(see filling instructions page 7).
A
djust brush to proper setting. Note:
For good operation the brush must
skim the carpet. If circuit breaker
trips raise brush to prevent damage
to motor or carpet.
Plug cord into grounded outlet. Note:
Be sure dome is seated on recovery
tank, and float shut-off is installed
correctly.
Turn on brush and vacuum motor
switches (“ON”=“I”). Turn on solution
switch for continuous spray or set
switch to intermittent to allow use of
trigger switches.
STEP
1
STEP
2
STEP
3
STEP
4
CORRECT
INCORRECT
1/8in
(3mm)
SOLUTION VACUUM
CONT
INT BRUSH ONON

OPERATIONS
CLIPPER 98630 12/14/98
9
Select continuous setting to start
solution spray or select intermittent
setting to enable use of trigger
switches to start solution spray.
The intermittent setting requires the
operator to hold any one of the
three trigger switches in the “on”
position with the fingers, and is
typically used in small areas where
short cleaning passes are made.
The continuous setting allows the
operator to set the switch in the “on”
position with one touch, and is
typically used in large areas where
long cleaning passes are made.
Lower machine to floor.
A
djust handle to comfortable
operating position. Tip machine
back by main handle to move to
starting point.
STEP
5
STEP
6
STEP
7
INT
CONT

CLEANING PROCEDURE
CLIPPER 98630 12/14/98 10
Release intermittent trigger
switches or turn off continuous
setting on solution switch
approximately 1 foot before ending
cleaning pass.
Push down on handle to raise
vacuum shoe and brush before
moving to the next cleaning pass.
Overlap brush contact area
approximately 1inch.
STEP
1
STEP
2
STEP
3
Start at wall closest to power outlet.
For small areas, pull straight back
without pushing down on handle.
1in.
(25mm)
OFF
1ft.
(30cm)
1. This machine can be operated in either
direction. For smaller areas operate
the machine by pulling rearward.
2. For larger unobstructed areas, flip the
handle and use the machine’s brush
assisted propelling motion.
12

CLEANING PROCEDURE
CLIPPER 98630 12/14/98
11
STEP
5
STEP
6
A
fter cleaning, turn off all controls,
return brush to storage position and
carefully unplug machine.
STEP
4
STEP
1
Use right side of machine for cleaning
against walls.
OFF OFF OFF
SOLUTION
INTAKE COVER
VACUUM
INTAKE COVER
O
R
Start at wall closest to power outlet.
For large areas flip handle and operate
machine in parallel passes,
overlapping brush path. Clean
perimeter last.
During operation, observe the
following: The Clipper is equipped with
clear internal covers to facilitate
operator viewing of dirty solution and
vacuum air flow.
During operation, observe the vacuum
intake cover. Large amounts of water
or foam entering the vacuum system
can damage the vacuum motor. If you
notice either condition, shut down the
machine immediately. Empty
recovery tank and/or add defoamer to
recover
y
tank.

CLEANING PROCEDURE
CLIPPER 98630 12/14/98 12
To speed drying, use a
Windblowerfan.
Empty recovery tank by releasing
dump hose. Use a hose with cold
water to clean out the recover
y
tank. Also drain solution tank after
each use.
STEP
7
STEP
8
RECOVERY
DRAIN
SOLUTION
DRAIN

ACCESSORY TOOL USAGE
CLIPPER 98630 12/14/98
13
Turn on vacuum motor switch and
set solution switch to intermittent
position. Note: Be sure brush switch
is in off position and brush is in
storage position.
Squeeze handle on accessory tool
to begin cleaning.
STEP
3
STEP
4
STEP
1
STEP
2
Use only one of the following
acceptable accessory tools.
CST DDH DH DHT UPH-3
SW SW-PRO SFW 39504
Pull back collar and insert over
machine mounted fitting, then
release collar to lock into place.
Lift door on front of vacuum shoe
and insert 1 ½ inch hose cuff into
hole.
SOLUTION VACUUM
ON
OFF
INT BRUSH

TROUBLESHOOTING CHART
CLIPPER 98630 10/19/02 14
PROBLEM CAUSE SOLUTION
No Power, Nothing Runs
1. Is the cord plugged in.
2. Circuit breaker tripped in building.
3. Faulty switch.
4. Faulty power cord or pigtail.
1. Plug in cord.
2. Reset breaker
3. Call for service.
4. Call for service.
Vacuum Motor Will Not
Run
1.Vacuum circuit breaker tripped.
2.Faulty main vacuum switch.
3.Loose wiring.
4.Faulty vac motor.
1.Reset breaker
2.Call for service.
3.Call for service.
4.Call for service.
Vacuum Motor Runs But
Suction Is Poor
1.Debris lodged in vac shoe.
2.Dome gasket defective or missing.
3.Vacuum hose cracked or hose cuff loose.
4.Recovery tank full / float ball stuck in the up
position.
1.Remove debris from vac shoe.
2.Replace as necessary.
3.Replace or repair as necessary.
4.Turn off vac motor. Drain and rinse
recovery tank.
Poor Or No Water Flow
(Carpet Is Streaky)
1.Main pump switch off.
2.Jets clogged or missing.
3.Solution filter clogged.
4.Faulty solenoid.
1. Turn on.
2.Clean using a vinegar /water solution or
replace.
3.Drain solution tank and clean solution
filter.
4.Call for service.
Brush Does Not Spin
1.Brush switch off.
2.Brush circuit breaker tripped
3.Brush belt broken.
4.Faulty brush motor.
1.Turn on brush switch.
2.Reset circuit breaker.
3.Replace as necessary.
4.Call for service.

WIRING DIAGRAM
CLIPPER 98630 10/19/02
15

MAINTENANCE
CLIPPER 98630 10/19/02 16
PERIODIC MAINTENANCE
Twice a month, flush a white vinegar solution
(One quart vinegar to two gallons of water) or
anti-browning solution (mixed as directed)
through the extractor. This will prevent build-up
of alkaline residue in the system. If spray jets
become clogged, remove the spray tips, wash
them thoroughly, and blow-dry.
NOTE: Do not use pins, wire, etc. to clean
nozzles as this could destroy spray pattern.
Periodically inspect all hoses, electrical cables
and connections on your machine. Frayed or
cracked hoses should be repaired or replaced
to eliminate vacuum or solution pressure loss. If
the cable insulation is broken or frayed, repair
or replace it immediately. Don’t take chances
with electrical fire or shock.
DAILY / REGULAR MAINTENANCE
Before making any adjustments or repairs to
the machine, disconnect the power cord from
electrical source.
1. Empty unused cleaning solution from the
solution tank.
2. Inspect and clean filter screen in solution
tank.
3. Flush pumping system with 4 or 7 liters of
clean, hot water.
4. After each use, rinse tank with fresh water.
Periodically inspect the recovery tank and
decontaminate if necessary, using a
Hospital Grade Virucide or a 1-10 bleach to
water solution. Waste water should be
disposed of properly.
5. Check for and remove any lint or debris
around vac shoe.
6. Check spray jets for full spray pattern.
7. Remove lint and dirt build-up from brush
and housing.
NOTE: Brush removal.
A. To remove brush, grab and pull brush
out from end opposite drive belt
(operator’s right). Remove other end
from brush driver.
B. To install brush, line up slots in brush
core with pin in driver on drive belt side
(operator’s left) and push brush onto
driver. Then snap bearing end (opposite
end) of brush into retaining clip.
8. Check cooling air screen (located on frame
behind left wheel) for lint or debris.
9. Check float and shut-off screen and clean
as necessary.
NOTE: Always store machine with brush in
“Store” position.

MAINTENANCE
CLIPPER 98630 10/19/02
17
!WARNING: ONLY QUALIFIED
MAINTENANCE
PERSONNEL ARE TO
PERFORM THE FOLLOWING REPAIRS.
VACUUM MOTOR REPLACEMENT
1. Turn off all switches and unplug machine.
2. Remove recovery tank.
3. Remove the (2) screws that fasten the solution tank
to the frame, and tilt tank back to expose the inside
of the frame.
4. Locate the vacuum motor wires and disconnect at
the connector. Close the solution tank.
5. Remove the (6) screws holding the vacuum motor
cover (p/n 27809) to the solution tank.
6. Remove the vacuum motor.
7. Reverse process to install vacuum motor.
BELT REPLACEMENT
1. Turn off all switches and unplug the machine.
2. Remove recovery tank.
3. Remove the (2) screws that fasten the solution tank
to the frame, and tilt tank back to expose the inside
of the frame.
4. Remove solution hoses from fittings in pump.
5. Remove the (2) screws that fasten the pump to the
frame.
6. Reverse process to install pump.
62759
05016
WARNING: The green
ground wire must be
attached for safe
operation.
See wiring diagram.
Note: When replacing carbon vac motor brushes
loosen wire terminal BEFORE removing screws on
bracket.
Important:
These brushes wear quicker
as the length shortens due to
increased heat.
Spring inside brush
housing will damage motor
if brushes are
allowed to wear away
completely.
If armature commutator is not concentric, extremely
pitted, or grooved the motor will need to be replaced
or sent to a qualified service center to restore vac
performance.
Periodically check the length of the carbon brushes.
Replace both carbon brushes when either is less
than 3/8" long.
Note:
Place
stop in
groove.
3/8
End Cap
Carbon Brushes
115V
Vac Motor Carbon Brushes Replacement
Wire Terminal Wire
Terminal

MAINTENANCE
CLIPPER 98630 08/19/03
18
!
WARNING:
ONLY QUALIFIED MAINTENANCE PERSONNEL ARE TO PERFORM
THE FOLLOWING REPAIRS.
SOLUTION PUMP REPLACEMENT
1. Turn off all switches and unplug the machine.
2. Remove recovery tank.
3. Remove the (2) screws that fasten the solution tank to the frame, and tilt tank back to expose the
inside of the frame.
4. Remove solution hoses from fittings in pump.
5. Remove the (2) screws that fasten the pump to the frame.
6. Reverse process to install pump.
PUMP REPLACEMENT PARTS FOR FLOJET 100 PSI (65201)
Diaphragm
29219
Motor
53245
Valve Asm
84166
Pump Head
65204

TECHNICAL SPECIFICATIONS
CLIPPER 98630 10/19/02
19
POWER TYPE
ELECTRICAL: 115 V, 15 A, 60 HZ
ELECTRIC VACUUM MOTOR: (1) –3 stage, 1 hp, 99
cfm (2.80 cubic meters/min.) Waterlift –117” (297cm)
BRUSH: (1) 18” (45.7 cm.)
SOLUTION PUMP: 100 PSI, diaphragm style, internal
bypass
SOLUTION CAPACITY: 12 gallons (45.5ltr)
RECOVERY CAPACITY: 12 gallons (45.5ltr)
BRUSH SPEED: 1000 rpm
GENERAL DIMENSIONS/WEIGHT
Vacuum shoe: 20” (51 cm) cast
aluminum with spring loaded down
pressure
WHEELS: (2) 10” dia. (25 cm) wheels
by 2”
WEIGHT: 105lbs. (48kg)
LENGTH: 28” (71 cm)
HEIGHT: 46” (117 cm)
WIDTH: 24” (61 cm)
SOLUTION SPRAY: 2 quick change
jets.
POWER CABLE: 50’ (12.7 m) (14
gauge)
24”
(61cm)
28”
(71cm)
46”
(117cm)
