Windsor EXP User manual

MODEL POWER SOURCE
EXP 115V ELECTRIC
EXPJ 100V ELECTRIC
98363 10/19/02
U
CARPET EXTRACTOR
Read these instructions before using the machine

MACHINE DATALOG
EXP 98363 10/19/02
2
MODEL-
DATE OF PURCHASE-
SERIAL NUMBER-
SALES REPERESENTIVE-
DISTRIBUTOR NAME-
OPERATIONS GUIDE NUMBER – 98363
©Copyright 1996 Windsor Industries, Printed in U.S.A.
TABLE OF CONTENTS
Cover Sheet......................................................... 1
Data Log / Table of Contents............................... 2
Information in this guide ...................................... 3
Safety................................................................... 4
Hazard Intensity Level ......................................... 5
Operations ........................................................... 6
Option Controls.................................................... 7
Operating Instructions ......................................... 8
Maintenance ........................................................ 9
Maintenance Cont................................................ 10
Troubleshooting................................................... 11
Wiring Diagram .................................................... 12
Service Schedule................................................. 13
Vac, Solution Tank, Control Panel Assembl
y
...... 14
Vac, Solution Tank, Control Panel Parts List .......15
Brush, Brush Motor, Frame Assembly .................16
Brush, Brush Motor, Frame Assembly
Parts List ..............................................................17
Pump Assembly ...................................................18
Pump Assembly Parts List ...................................19
Solution Lever, Main Handle Assembly ...............20
Solution Lever, Main Handle Assembly
Parts List ..............................................................21
Recovery Tank Assembly.....................................22
Recovery Tank Assembly Parts List ....................23
Solution Plumbing Spray Jet Assembly ...............24
Solution Plumbing Spray Jet Assembly
Parts List ..............................................................25
Spare Parts and Accessories...............................26
Warranty...............................................................27

INFORMATION IN THIS GUIDE
EXP 98363 7/1/96 3
This Owner’s Guide contains valuable information
about the operation, maintenance, service and part
numbers for repairs of your Windsor machine.
Please read this introductory page thoroughly to
become familiar with the contents of the owner’s
guide, making the information you are looking for
easier to locate.
The owner’s guide consists of multiple sections of
reference information, and the remainder contains
part information for ordering parts for the machine.
At the top of each page is the name of the particular
section. This way you can quickly locate each
section more easily.
REFERENCE SECTIONS
The reference information sections of this guide are
as follows; General Information, Operation,
Maintenance.
GENERAL INFORMATION
This section of the guide contains safety
precautions. The Safety Precautions are an
overview of the safety measures to be observed
when operating and maintaining the machine.
OPERATION
The Operation section of the guide contains the
information needed to operate the machine. There is
a complete list of instruments and controls on the
machine, an overview of machine operation, and
information on how to transport and store the
machine.
MAINTENANCE
The Maintenance section contains the information
on the suggested maintenance procedures and
adjustments to keeping the machine in top operating
condition. The section includes a maintenance
schedule and the areas of the machine to be
addressed. Each subject of maintenance is covered
in more detail in such areas as Lubrication, Motors
and Electrical System.
PART SECTIONS
To easily locate the part needed, please refer to The
Table of Contents for component locations to find
the general area where the part is located. Use the
information to quickly locate the correct component.
The remaining sections of the guide contain part
number information for ordering repair parts for the
machine. The guide contains part number
information on every machine model available.
Therefore there will be part number information in
your guide which you will not need to refer to when
placing an order.
ORDERING REPAIR PARTS
If you are in need of technical assistance contact
your WINDSOR Distributor or Service Center for
further assistance. Once you have located a part to
order, call your local WINDSOR distributor. Make
sure to have the machine’s serial number and your
Owner’s Guide with you to aid in ordering the correct
component(s).
NOTES:

SAFETY INSTRUCTIONS
EXP 98363 03/24/00
4
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
This machine is for commercial use.
To reduce the risk of fire, electric shock, or injury:
Connect to a properly grounded outlet. See Grounding Instructions.
Do not leave the machine unattended. Unplug machine from outlet when not in use and before
maintenance or service.
Use only indoors. Do not use outdoors or expose to rain.
Do not allow machine to be used as a toy. Close attention is necessary when used by or near
children.
Use only as described in this manual. Use only manufacturer’s recommended components and
attachments.
Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding
the machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or
dropped into water, return it to an authorized service center.
Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord
around sharp edges or corners.
Do not run machine over cord. Keep cord away from heated surfaces.
Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.
Do not handle the electrical plug or machine with wet hands.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is intended for cleaning carpet only.
Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
This machine is not suitable for picking up health endangering dust.
Turn off all controls before unplugging.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
SAVE THESE INSTRUCTIONS
!
WARNING:

HAZARD INTENSITY LEVEL
EXP 98363 03/24/00 5
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR
SAFETY. The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property
damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate
all safety devices on the machine. Please take the necessary steps to train the machine operating
personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use Windsor approved replacement parts.
.
!WARNING
!CAUTION

OPERATIONS
EXP 98363 7/1/96
6
HOW IT OPERATES:
This machine is a portable, easy to use carpet extractor
designed for use indoors, in a household or light
industrial environment.
When operating as a carpet extractor, cleaning solution
is dispensed onto the carpet and agitated by a rotating
brush. The solution is then extracted from the carpet by
a vacuum. The head on the brush is floating, allowing it
to automatically adjust to various carpet depths while
applying an effective brush pressure.
1. To avoid electric shock use indoors only.
2. To reduce risk of fire, do not use volatile
substances.
3. Use only cleaners intended for carpet
application.
INSPECTION:
Carefully unpack and inspect your extractor for shipping
damage. Each unit is operated and thoroughly
inspected before shipping, and any damage is the
responsibility of the carrier, who should be notified
immediately.
ELECTRICAL:
This extractor operates on a standard 15 amp 120 volt
AC circuit. This is the typical wall receptacle found in
household and light industrial environments. Voltages
below 105 volts or above 125 volts could cause serious
damage to motors. *Special voltage models available. A
wiring diagram is mounted inside the rear control panel
of machine. A copy of the wiring diagram is included in
this Owner’s Guide.
GROUNDING INSTRUCTIONS:
This appliance must be grounded. If it should
malfunction or break down, grounding provides a path of
least resistance for electric current to reduce the risk of
electric shock. This appliance is equipped with a cord
having an equipment-grounding conductor and
grounding plug. The plug must be inserted into an
appropriate outlet that is properly installed and grounded
in accordance with all local codes and ordinances.
Improper connection of the equipment-grounding
conductor can result in risk of electric shock.
Check with a qualified electrician or service
person if you are in doubt as to whether the outlet
is properly grounded. Do not modify the plug
provided with the appliance – I is will no fit the
outlet, have a proper outlet installed by a qualified
electrician.
This appliance is for use on a nominal 120-volt circuit,
and has a grounded plug that looks like the plug in “Fig.
A”. A temporary adaptor that looks like the adaptor in
“Fig . C” may be used to connect this plug to a 2-pole
receptacle as shown in “Fig. B”, if a properly grounded
outlet is not available. The temporary adaptor should be
used only until a properly grounded outlet (Fig. A) can
be installed by a qualified electrician. The green colored
rigid ear, lug, or wire extending from the adaptor must
be
connected to a permanent ground such as a properly
grounded outlet box cover. Whenever the adaptor is
used, it must be held in place by a metal screw.
EXTENSION CORDS:
If an extension cord is used, the wire size must be at
least one size larger than the power cord on the
machine: This extractor is equipped with a 25 ft. 16/3
power cord.
To avoid possible distortion of polyethylene
solution/recovery tanks, DO NOT USE WATER
TEMPERATURE THAT EXCEEDS 140 F (60 C).
CHEMICALS
Use only the suitable chemicals listed below.
Using incompatible chemicals will damage the
machine. Damages of this type are not covered
under warranty. Carefully read ingredients on
manufacturer’s label before using any product in
this machine.
Suitable Incompatible
Chemicals Chemicals
Alkalis Aldehydes; Butyls
Defoaming Agents Carbon Tetrachloride
Detergents Chlorinated Bleaches
Soaps Chlorinated Hydrocarbons
Vinegar Trichlorethylene
Hydroxides Phenols; Methyls (MEK)
Perchlorethylene (perc)
Aromatic Hydrocarbons
D-Limonene

OPTION CONTROL
EXP 98363 03/24/00 7
NOTE: Attach strain relief/cord
retainer to the power cord.
1. Make a loop in power cord approximately
12” from strain relief on machine.
2. Slide cord loop through slot
in retainer arm. Pull slack
cord back through slot to
secure. Attach retainer to
handle.
1 Brush Switch On/Off. Turns brush motor on and off.
2 Solution Switch On/Off. Turns solution pump on and off.
3 Vac Switch On/Off. Turns vacuum motor on and off.
4MainHandle.
5SolutionLever.Controls the amount of
flow of solution to the floor.
6 Brush Motor Circuit Breaker.
Protects brush motor from overheating.
7 Vac Motor Circuit Breaker. Protects the
vac motor from overheating.
8 Handle Adjustment Lever.
Adjusts the main handles angle.
9. Solution Tank Drain Hose.
10. Accessory Tool Connection. Solution connection for
accessory tools.
11. Accessory Hose Connection. Hose
connection for accessory tool.
12. Cord Hook.
VIEW:TOP ofCONTROL
123
7
5
4
6
12
9
VIEW: REAR ofMACHINE
8
VIEW:FRONT ofMACHINE
11
Recovery
Tank
Vacuum
Shoe / Brush
Housing
Dome
10
Solution
Tank

OPERATIONS
EXP 98363 03/24/00
8
I
OPERATING INSTRUCTIONS
A. FILLING THE SOLUTION TANK:
1.Remove clear dome from recovery tank.
2. Lift upper recovery tank frommachine and set
aside.
3.Use a clean bucket or hose to fill solution tank with
hot water. The solution tank holds 4 gallons (15.2
liters) of cleaning solution.
Do not use the recovery tank to fillthe solutiontank.Sed-
iment in the recovery tank candamage the solutionpump
andclogthesprayjets,renderingthemachineinoperable.
4.Add a non-foaming concentrate for use in hot
water extractors at the proportions noted on the
container.
Note: Periodically operate extractor with only hot water to re-
move chemical residue in carpet.
To avoid possible distortion of polyethylene solution/re-
covery tanks, DO NOT USE WATER WITH A TEMPERA-
TURE THAT EXCEEDS 140° F (60° C).
5. Place recovery tank back on machine.
6. Place dome on recovery tank. Make sure dome is
seated correctly to ensure propervacuum seal.
Use only the suitable chemicals listed above. Using in-
compatible chemicals willdamage the machine. Carefully
read ingredients on manufacturer’s label before using any
product in this machine.
I
I
OPERATING THE MACHINE
1. Vacuum the carpet and make sure it is cleared of
surface debris before cleaning.
2. Plug power cord into a grounded wall outlet.
Defeating the groundingpin on the power cord can result
in a severe electrical shock.
3. Turn on the pump, brush and vacuum
switches, listening for each motor to turn on.
NOTE: The vacuum and the brush are protected by circuit
breakers located on the back panel, below their respective
switch.
NOTE: If either of these motors does not respond to being
switchedon, resetthecircuit breakersbypressing them in,and
attempt to switch the machine on again.
OPERATING THE MACHINE
cont..
NOTE:Ifsolution does not dispense in an even pattern acros
s
the width of the machine, the spray jet may be clogged. Til
t
the machine back and remove the spray tip by pushing in an
d
turning it onequarter turn. Wash it thoroughly, andblow dry.
NOTE: Do not use pins, wire, etc. to clean spray jet nozzle a
s
this will deform the jet and destroy the spray pattern.
6. Begin with the machine at the edge of the carpet.
Actuate the solution lever while pulling the machine
backwards. Release solution lever at least 12
inches before the end of each cleaning pass. This
will ensure all dispensed cleaning solution is
extracted from carpet.
While operating machine,check for excessive foam build
-
up in the recovery tank. If excessive foam is present, add
a defoamer solution to recovery tank, or empty tank.
7. Empty recovery tank when approximately 3/4 full.
If the recovery tank is overfilled, the water will drain
back onto the carpet when the vacuum is switched
off.
8. Ventilate area after carpet has been cleaned.
Keep children and pets away and do not walk
on carpet until it is dry.
A Windbloweräfan can be used to reduce drying time.
III
OPERATING MACHINE WITH
ACCESSORY TOOLS
This extractor is easily adapted for use the following
Windsor accessory tools: DHT-UPH3-SW-SFW-SW/PRO
-
DDH-SPW
1. Lift flap on the front of vac shoe and insert hose cuff
into the vac shoe, ensuring that there is a tight fit.
2. Attach the solution hose from accessory tool to the
brass solution fitting on the front of machine.
3. Switch on the pump and the vacuum. The ap-
plication of cleaning solution is now controlled by
the lever on the accessory tool.
Do not switch on brush when operating themachine
with accessory tools. Carpet damage may occur.
NOTE: The solution pump is not intended to run dry. Whe
n
using the extractor for vacuum pick-up only, insure that th
e
pump switch is turned off.

MAINTENANCE
EXP 98363 03/24/00 9
PROTECT FROM FREEZING
If it becomes necessary to store in temperatures that could
dropbelow 40°F,the pumping system,hoses andvalves must
beprotectedfromfreezingwith a methyl hydratewindowwash-
er antifreeze solution
.
NOTE:Do not use ethylene glycol or cooling system
antifreezes.
1. Addon a gallonofwindow washer antifreeze
to the supply tank.
2. Turn on pump switch and spray until the
antifreeze solution fills the solution lines.
3. Drain out the leftover antifreeze from the
supplytank. Always allow the unit to reach
room temperatures before filling with hot
water or operating.
DAILY/REGULAR MAINTENANCE
Before making any adjustments or repairs to the
machine,disconnectthepowercordform electrical
source.
1. Empty unused cleaning solution from the
solutiontank.
2. Inspect and clean filter screens in solution tank, and
on top of tube in recovery tank.
3. Flush pumping system with 1 or 2 gallons of
clean, hot water.
4. Check spray jetfor fullspray pattern.
5. Empty the recovery tank and rinse with clean
water.
6. Check for and remove any lint or debris around
brush and vac shoe.
PERIODIC MAINTENANCE
1. After every 25 hours of operation, flush a white
vinegar solution (ONE quart vinegar to two
gallons of water) or anti-browning solution
(mixed as directed) through the extractor. This
will prevent build-up of alkaline residue in the
system.
2. If the spray jet becomes clogged, remove the
spray tip, wash it thoroughly, and blow dry.
NOTE:Do not use pins, wire, etc. to clean spray jet nozzle as
this willdeform the jet and destroy the spray pattern.
PERIODIC MAINTENANC
E
cont..
3. Periodically inspect all hoses, electrical cables, filters,
gasketsand connectionson your machine.Frayed or
cracked hoses should be repaired or replaced to
eliminate vacuum or solution pressure loss.
4. The electrical cable must be well insulated, if the cable
insulation is broken or frayed, repair or replace it
immediately. Don’t take chances with electrical fire or
shock.
5. The filter in the bottom of the solution tank must be
clean to allow free flow of cleaning solution. The screen
filter on the vacuum tube in the recovery tank must be
free of lint buildup to ensure full vacuum strength.
6. The dome gasket must be properly seated and free of
damage to create the air seal needed to extract water.
MAINTENANCE INSTRUCTIONS
Remove machine power cord from electrical source
beforemakingany adjustmentsorrepairstothe ma-
chine.
Only qualified maintenance personnel are to per-
form repairs.
BRUSH ASSEMBLY
1. Situate machinein order toaccessbottom cover.Remove
screws (6) and bottom cover. Remove screws (3) and
belt cover.
2. Loosen nuts at brush motor and slide motor forward
to reduce belt tension. Remove belt.
3. Remove lower brush stop on belt side (closest to you with
machine upside down) and rotate black plastic finger
guard toward rear of machine.
4. Remove one screw holding each brush bearing to
brush bracket.
5. With the blade of a screw drive, bend bearings
inward enough to disengage locating tabs.
6. Slide brush, axle, and bearing out of brush bracket.
7. Inspect/replace brush and bearings as required.
The brush is equipped with yellow wear indicator
bristles. The brush should be replaced when it
wears down to the height of the yellow bristles.
8. When reinstalling brush, checkbelt for proper
tension.
!WARNING
!WARNING
!WARNING

MAINTENANCE
EXP 98363 03/24/00
10
TO ACCESS PUMP AND BRUSH MOTOR
1. Situate machine in order to access bottom
cover. Remove screws (6) and bottom cover.
2. To remove brush motor, loosen nuts at brush
motor and slide motor forward to reduce belt
tension. Remove belt. Continue loosening nuts at
brush motor until free from brush bracket.
Disconnect wires.
3. To remove pump, loosen screws holding pump
mounting bracket to casting and remove as one unit.
Lift pump and mounting bracket up to gain access to
all hose clamps which need to be removed before
pump is free from machine. Disconnect wires.
TO ACCESS VAC MOTOR
1. Lift off recovery tank.
2. Remove screws (5) and lift off vac motor
cover.
3. Vac motor can be lifted out and electrically
disconnected.
4. When replacing the vac motor, make sure
the excess wire lengths do not get pinched
in the gaskets which seal the vac motor. If
need be, remove the rear control panel and
pull excess lead length out of the vac motor
compartment.
VAC MOTOR BRUSHES
1. To inspect motor brushes, remove vac
motor from tank by disconnecting wires.
Then remove black vac motor fan housing
and brush holder assembly. Brushes should
be replaced when worn to 3/8 inch or after about
750 operating hours. After second brush
replacement, the armature commutator should
be checked for pitting and concentricity. Vac
motors can be repaired, but such repairs should
be made by a qualified motor repair shop.
VAC MOTOR BRUSHES cont..
NOTE: When replacing electrical component parts refer
to Wiring Diagram for proper connection.
NOTE: The vac motor is protected by a circuit breaker
located in the switch panel. The breaker will only trip
under conditions of abuse.
SOLUTION VALVE CABLE ADJUSTMENT
The solution valve cable has been factory set so that
action of the solution lever moves the valve from fully
closed to fully open. As the machine operates the cable
will stretch and the lever will not be able to fully open the
valve. The play in the solution lever should be checked
periodically and adjusted when needed as described
below.
1. Loosen the lock nut at the point where the cable
enters the lever housing on the machine handle.
2. Turn the threaded end of the cable sleeve to
adjust. Threading the end further into the
housing will slacken the cable, increasing the
play in the lever. Threading the end out of the
housing will tighten the cable, decreasing the
play in the lever.
3. Tighten the locking nut against the housing after
adjusting the play as required.
4. If there is not enough thread adjustment
available, the cable length can be adjusted
directly at its connection to the solution valve.
This is accessed by removing the back control
panel.
SPRAY JET
Note: To prevent a clogged jet due to alkali build-up,
the spray system should be flushed with 1 to 2 gallons
of clean hot water at the end of each day.
1. Situate machine in order to access bottom cover.
2. The machine is equipped with a ”Quick Change”
jet that can be easily removed for cleaning. To
remove- push jet in and rotate 1/4 turn.
3. Wash jet and blow dry. Do not use pins or wire
to remove obstruction as this will change spray
pattern.
VAC MOTOR
location
ofbrushes
end cap
ground
3/8

TROUBLESHOOTING CHART
EXP 98363 03/24/00 11
No Power To Machine:
Dead electrical circuit breaker in fuse box
Faulty power cord
Power switch failure
Faulty circuit breaker
Internal wiring problem
Replace
Replace
Replace
Replace
Check for and correct any loose wire connections,
Vacu um Moto r Speed
Varies or Doesn’t Run:
Worn motor brushes
Motor worn out
Faulty switch
Faulty circuit breaker
Internal wiring problem
Turn brush motor and pump switches on with machine tilted rearward (brush
off floor). Lower machine back to carpet slowly.
Test circuit breaker for continuity/Replace if necessary.
Higher amp draws may indicate a mechanical problem. Find parts which are
not moving freely and repair or replace.
Nuisance Tripping of Circuit Breaker:
Faulty circuit breaker
Mechanical problem
Follow grounding instructions exactly.
Have an electrician inspect the building’s wiring.
Ensure that the machine’s wiring matches the appropriate wiring diagram.
Check for and correct any loose wire connections. Replace any wires or
components which are short circuiting.
Electrical Shock:
Equipment not grounding
Receptacle not grounded
Internalelectrical problem
Corrective Action:
Check building circuit breaker.
Replace power switch failureTest switch for continuity/Replace if necessary.
Test circuit breaker for continuity. Replace if necessary. With the machine
unplugged, check for, and correct, any loose wire
connections inside the machine at the switches and terminal block.
Loss Of Vacuum:
Loose vac dome
Incorrect seating of recovery tank.
Crack in dome or poor joint
Damaged dome gasket
Lint or dirt clogging vacuum intake screen
A
ccessory tool clogged
Internalelectrical problem
Accessory Tool Fitting Difficult to Connect:
Corrosion on fitting
Brush Not Turning:
Belt broken
Faulty switch
Faulty circuit breaker
Faulty brush motor
Worn Bearings:
Squealing or grinding sound in brush housing
Carpet Not Getting Clean:
Severe soil conditions
Carpet Too Wet:
Worn spray jet(s)
Carpet Not Getting Wet:
Solution filter screen clogged
Spray jet(s)clogged
Pump not running
Faulty pump
Solution valve adjustment
Incorrect jet orientation
Seat dome squarely over tank opening.
. Remove recovery tank, clean off seals on top of solution tank, and reseal
recovery tank.
Replace or repair using acrylic plastic cement only.
Replace gasket.
With power off clean vac intake screen found in dome.
Clean out tool, ensure free air flow.
Have a trained service technician inspect and repair the machine.
Clean with steel wool.
Remove and soak in acetic acid (white vinegar).
Lubricate lightly with silicone base lubricant.
Remove belt cover on right side of machine.
Inspect belt Replace if necessary.
Replace.
Replace.
If the belt, circuit breaker, and switch have been tested and found to be in
good working order, the brush motor may need to be replaced.
Replace bearings.
Make several passes at right angles to each other.
Use a pre-spray.
Replace spray jets which are producing more than a fine mist.
Clean solution filter screen located inside lower tank near the front.
Clean or replace jets. Do not use a wire to clean jet.
Damaged jets will cause over-saturation.
Check for and correct any loose wires
Repair or replace
Adjust solution valve cable until valve operates when handle is pulled.
Align slit in jet parallel with center line of brush.

WIRING DIAGRAM
EXP 98363 03/24/00
12
115V EXPERT
ORG
BLK
15

MAINTENANCE
EXP 98363 10/19/02 1
3
SERVICE SCHEDULE
MAINTENANCE DAILY WEEKLY QUARTERLY
Check machine for cord damage *
Check recovery dome and gasket for
damage and cleanliness *
Check brush – should be clean with no
lint or strings attached *
Inspect vac shoe for blockage; remove
fibers with coat hanger, etc. *
Check hoses for wear, blockages, or
damage *
Check handles, switches, and knobs
for damage *
Check vac motor intake filter and clean *
Run one gallon of water through
system *
Clean out recovery tank and check
float valve to make sure it moves freely *
Clean out solution tank and remove
and clean vacuum intake screen *
Clean outside of all tanks and check for
damage *
Run vac motor for at least one minute
to allow motor to dry *
Store with dome off tank to allow the
tank to dry *
Check all bearings for noise *
Check all gaskets for wear and leakage *
Check vacuum intake screen for
damage; replace if necessary *
Check pump pressure; observe spray
pattern and check with gauge if
necessary *
Check and clean solution screen *
Check belts for wear and replace as
necessary *
Check brush for wear; ensure bristles
are not damaged *
Check cables for fraying *
Check the spray bar (manifold) for
damage; replace if broken or bent *
Check condition of vac shoe and frame
for damage *
Check overall performance of machine *
Check vac motor carbon brushes *

VAC/SOLUTION TANK/CONTROL PANEL
EXP 98363 10/22/01
14
44(5)
45(5)
24
2
1
4
5
8A
41 43
10
12(2)
45(2)
16
25(3)
33
17
9
32(2)
23
31
14 6
38 48(2)
27
44(6)
13(2)
37
7
30
12
19
20
15
29
28 44 REF
45(6)
34
39(4)
42
31(2)
31
40(2)
11
36
18 47(2)
21(2)
22(2)
49
46
3(4)
35(4)
26(4)

VAC/SOLUTION TANK/CONTROL PANEL PARTS LIST
EXP 98363 10/22/01 15
REF PART NO. QTY DESCRIPTION SERIAL NO.
FROM NOTES:
1 35175 2 GASKET, TANK TO VAC COVER
2 27631 1 COVER, VAC MOTOR
3 70627 4 SCR, 1/4 X 1/2 PPHST HI-LO 443236
4 27759 1 CUFF, 1.5” BLACK HOSE
5 39276 1 HOSE, 1.5” X 14” VAC
6 57208 1 NUT PG11 METAL, 1.024 OD X 0.73 ID
7 70211 1 SCR, 10-32 X 3/4 PH. BLK NYLON
8A 53771 1 VAC MOTOR ASM, 115V EXP.
8B 53780 1 VAC MOTOR ASM, 100V EXP.
9 500551 1 LABEL, CONTROL PANEL MAIN
10 27632 1 CAP, VAC MOTOR
11 34331 1 FRAME/SOL EXP II
12 70532 3 SCREW, 10-32 X 1/2 PHMS BLK
13 14942 2 COVER, CIRCUIT BREAKER
14 72151 3 SWITCH, 125V SPST
15 14622 1 BREAKER, 1.5A CIRCUIT
16 27787 1 COVER, REAR (CONTROL PANEL)
17 14700 1 BREAKER, 15A 250 VAC 50 VDC 1000001018
18 03102 1 AXLE, WHEEL
19 23664 1 CORD ASM, 115V
20 73710 1 STRAIN RELIEF, PG11 METRIC TRUMPET
21 89048 2 WHEEL, 8” NON-MARKING
22 57196 2 HUBCAP, 1/2” DIA
23 14020 1 TERMINAL BLOCK
24 35169 1 GASKET, VAC COVER
25 27376 3 CLIP, SWITCH RETAINING
26 70393 4 SET SCR, 1/4-20 X 1.25L
27 70595 1 SCREW, 10-32 X 1 PHMS GRN
28 880041 1 WIRE ASM, PANEL TO BASE
29 20086 1 CLAMP, CORD
30 70547 1 SCREW, #10-32 X 1 PPHMS BLK
31 57104 4 NUT, #10-32 KEPS
32 57116 2 NUT, #6-32 KEPS
33 87100 1 WASHER, 3/8 INT. LOCK THIN
34 35222 1 GASKET, 2 ID X 2.75 X 3/8 THK PORON
35 35182 4 GASKET, FRAME
36 73864 1 STRAINER, 3/8” NPT 60 MESH
37 500226 1 LABEL, CIRCUIT BREAKER BRUSH
38 500225 1 LABEL, CIRCUIT BREAKER VAC
39 70517 4 SCREW, 8-32 X 1/2 FHMS SS
40 51254 2 LOCK, HANDLE EXPERT TANK
41 35193 1 GASKET, REAR COVER
42 67029 1 RECTIFIER, BRIDGE
43 50776 1 LABEL, FOR SAFETY
44 70626 11 SCR, 10-3/4 PPHST TYPE B BLK
45 87189 13 WASHER, .2 ID X .5 OD BLK SS
46 62717 2 PLATE, AXLE EXP
47 87146 2 WASHER, 1/2 ID X 1” OD X .08” NYLON
48 70235 2 SCREW, 6-32 X 1.0 PH BLK NYLON
49 20035 1 CLAMP, 7/16 DIA. NYLON UL 1000028686

BRUSH/BRUSH MOTOR/FRAME
EXP 98363 10/17/01
16
1
2
42
5
10(3)
11
13(2)
14 8(2)
16
17
18
19
21 22
24
10(5) 26
27
28
29
Part of
item 28
33
32
13
30
Housing
Brush brkt
30
13
33
32
Housing
Brush brkt
Diagram A
Diagram B
See
DiagramB
See
Diagram A
outside
of
machine
outside
of
machine
42
37
Inside rear wall of housing
See
Diagram C
8(4) 37
41(4) 9(4)
Housing
Diagram C *-left side only
23
636
40
39
7(2)
35(2)
4
Vac Hose
REF.(39276)
43
44
Wiring Asm.
REF. (88004)
39468
REF
12
20 34
13(2) 15

BRUSH/BRUSH MOTOR/FRAME PARTS LIST
EXP 98363 10/17/01 17
REF PART NO. QTY DESCRIPTION SERIAL NO.
FROM NOTES:
1 41279 1 HOUSING, BRUSH W/VAC SHOE
2 27674 1 COVER, ACCESS PORT
3 - - OPEN
4 35195 1 GASKET, .25 X .75 X 2.00 L
5 27759 1 CUFF, 1.5” BLACK HOSE
6 67138 1 RING, 3/8 EXTERNAL SNAP
7 57104 2 NUT, 10-32 W/STAR WASHER SHOE
8 57030 6 NUT, 10-32 NYLOCK
9 70557 4 SCR, 10-32 X 1” FHMS BLK
10 70532 5 SCR, 10-32 X 1/2 PPHMS BLACK
11 27636 1 COVER, BELT
12 20016 1 CLAMP, 1/4 ID HOSE
13 87139 4 WASHER, 3/16 FLAT
14 09113 1 BEARING, RIGHT
15 70740 3 SCR, 10-32 X 1/2 PTHMS BLK
16 64085 1 PULLEY, MOTOR
17 53608 1 MOTOR ASM, BRUSH DRIVE
18 140036 1 BRACKET ASM, BRUSH MOTOR
19 09114 1 BEARING, LEFT
20 140040 1 BRUSH
21 64086 1 PULLEY, BRUSH
22 11039 1 BELT, BRUSH DRIVE
23 03084 1 AXLE, BRUSH
24 35176 1 GASKET, BOTTOM COVER
25 - - OPEN
26 27639 1 COVER, BOTTOM
27 35171 1 GASKET, ACCESS PORT COVER
28 140087 1 BULKHEAD, 1/4 MPT X 1/4 BARB
29 56012 1 NIPPLE, 1/4 FPT QD
30 70303 2 SHOULDER BOLT, 1/4 OD X 5/8 L
31 - - OPEN
32 09117 2 BEARING, BRUSH BRACKET
33 57018 2 NUT, 10-24 HEX LOCK
34 70578 2 SCREW, 8-32 X 1” FHMS SS
35 70031 2 SCR, 10-32 X 1/4 PPHMS
36 87003 1 WASHER, 3/8 ID X 7/8 OD SS
37 62556 1 PLATE, GUARD ON LEFT SIDE ONLY
38 - - OPEN
39 70595 1 SCR, 10-32 X 1.0 PHMS GRN
40 20086 1 CLAMP, CORD
41 73781 4 HOSE, 5/16 X 3/16 ID CLR VINYL
42 70351 4 SCR, 10-32 X 3/8 HHTR W/STAR
43 70604 1 SCR, 10-32 X 5/8 PHMS BLK
44 87189 1 WASHER, .2 ID X .5 OD BLK SS
NOTE: The left and right sides of the machine are
assigned as if standing behind the machine in the
operator’s position.

PUMP ASSEMBLY
EXP 98363 03/27/00
18
7
11(2)
8
12
9
10
NOTE: Head of screw on this
hoseclamp shall pointtowards
center of pump headas shown.
Solution Tank
Valve
Accessory Port
2
1(2)
4
5(2)
6(2)
3
14
13
1

PUMP ASSEMBLY PARTS LIST
EXP 98363 03/27/00 19
REF PART NO. QTY DESCRIPTION SERIAL NO.
FROM NOTES:
1 20016 2 CLAMP, 1/4 ID HOSE
2 39510 1 HOSE, 3/8 WIREBOUND X 3”
3 39468 1 HOSE, 1/4 NYLOBRAID X 11.5”
4 39508 1 HOSE, 1/4 NYLOBRAID X 15”
5 70484 2 SCR, 10-32 X 5/8 PPHMS SS
6 87016 2 WASHER, #10 LOCK EXT. STAR
7 140034 1 BRACKET, PUMP
8 40009 1 HOSEBARB, 1/4 MPT X 1/4
9 40065 1 HOSEBARB, 1/4 MPT X 1/4 X 90°
10 65164 1 PUMP ASM, EXPERT
11 70581 2 SCR, 10-32 X 3/8 HHTFW/WASH
12 78024 1 TEE, 1/4 BRANCH
13 40033 1 HOSEBARB, 1/4 MPT X 3/8 90°
14 20042 1 CLAMP, 3/8 (D-SLOT)

SOLUTION LEVER/MAIN HANDLE
EXP 98363 03/27/00
20
1(3)
23
3
4(3)
5
6
7
8
9
Solution Lever
10
19
34(4)
14
15
16
17
11
18
13(2)
20
21
A
See Rear View
33
31
30A
30B
28
29(2)
32
A
B
VIEW A-A
42(2)
38
41REF
34331
REF
12
B
Rear View
43
42
22
26
40
35
39(2)
36
A
A
27 23(2)
41
37
12(2)
E
XP
E
R
T
