Windsor Chariot 3 - CV 86/1 RS Bp User manual

86413740-D 02/22/17
Operating Instructions (ENG)
Models: CV86
1.012-596.0
CVC86
1.012-597.0
CVI86
1.012-600.0
Chariot 3 - CV 86/1 RS Bp
Vacuum

Warranty Registration
Thank you for purchasing a Kärcher North America product. Warranty registration is quick
and easy. Your registration will allow us to serve you better over the lifetime of the product.
To register your product go to:
http://warranty.karcherna.com/
For customer assistance:
1-800-444-7654
28.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp
Machine Data Label
Overview
The Chariot® CV86 is a battery powered, stand-on, wide area vacuum intended for commercial use. The Chariot®
CV86 brushes and vacuums debris from the floor and stores it in the debris tray and vacuum bag.

3
Table of Contents
Machine Data Label. . . . . . . . . . . . . . . . . . . . . . . . . .2
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3
How To Use This Manual . . . . . . . . . . . . . . . . . . . . .4
Safety
Safety Label Locations . . . . . . . . . . . . . . . . . . . . . . .5
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . .6
HAZARD INTENSITY LEVEL. . . . . . . . . . . . . . . . . .8
Operations
Technical Specifications . . . . . . . . . . . . . . . . . . . . .10
How This Machine Works. . . . . . . . . . . . . . . . . . . .12
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Pre-Run Machine Inspection. . . . . . . . . . . . . . . . . .19
Starting Machine. . . . . . . . . . . . . . . . . . . . . . . . . . .19
Emergency Stop Procedures . . . . . . . . . . . . . . . . .19
Normal Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . .20
To Begin Vacuuming. . . . . . . . . . . . . . . . . . . . . . . .20
To Stop Vacuuming . . . . . . . . . . . . . . . . . . . . . . . .21
Changing Vacuum Bag. . . . . . . . . . . . . . . . . . . . . .21
Debris Tray Removal . . . . . . . . . . . . . . . . . . . . . . .21
Debris Tray Installation . . . . . . . . . . . . . . . . . . . . . .21
Maintenance
Service Schedule . . . . . . . . . . . . . . . . . . . . . . . . . .23
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Charging Batteries . . . . . . . . . . . . . . . . . . . . . . . . .26
External Charger. . . . . . . . . . . . . . . . . . . . . . . . . . .27
On Board Charger. . . . . . . . . . . . . . . . . . . . . . . . . .27
Changing Batteries . . . . . . . . . . . . . . . . . . . . . . . . .28
Battery Charger Programming . . . . . . . . . . . . . . . .29
Brush Deck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Brush Removal & Bearing Cleaning . . . . . . . . . . . .31
Brush Installation . . . . . . . . . . . . . . . . . . . . . . . . . .31
Side Broom Removal . . . . . . . . . . . . . . . . . . . . . . .31
Belt Replacement . . . . . . . . . . . . . . . . . . . . . . . . . .31
Remove Brush Deck. . . . . . . . . . . . . . . . . . . . . . . .32
Replace Brush Deck Motor. . . . . . . . . . . . . . . . . . .32
Brush Deck Actuator Removal/Replacement . . . . .32
Deck Actuator Adjustment . . . . . . . . . . . . . . . . . . .33
Brush Motor Carbon Brush Replacement. . . . . . . .33
To Remove Vacuum Motor. . . . . . . . . . . . . . . . . . .34
Vacuum Motor Carbon Brush Replacement . . . . . .34
Circuit Protection. . . . . . . . . . . . . . . . . . . . . . . . . . .35
Drive Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Electric Brake Engagement . . . . . . . . . . . . . . . . . .37
Drive Motor Carbon Brush Replacement . . . . . . . .37
Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Controller Fault Codes . . . . . . . . . . . . . . . . . . . . . .41
Suggested Spare Parts. . . . . . . . . . . . . . . . . . . . . 42
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

4
How To Use This Manual
This manual contains the following sections:
• How to Use This Manual
•Safety
• Operations
• Maintenance
The HOW TO USE THIS MANUAL section will tell you
how to find important information for ordering correct
repair parts.
Parts may be ordered from authorized dealers. When
placing an order for parts, the machine model and
machine serial number are important. Refer to the
MACHINE DATA box which is filled out during the
installation of your machine. The MACHINE DATA box
is located on the inside of the front cover of this manual.
The model and serial number of your machine is
located on the back of the machine.
The SAFETY section contains important information
regarding hazardous or unsafe practices of the
machine. Levels of hazards are identified that could
result in product damage, personal injury, or severe
injury resulting in death.
The OPERATIONS section is to familiarize the operator
with the operation and function of the machine.
The MAINTENANCE section contains preventive main-
tenance to keep the machine and its components in
good working condition. They are listed in this general
order:
• Service Schedule
• Batteries
•BrushDeck
• Vacuum
• Drive Motor & Brake
• Troubleshooting
NOTE: The manual part number is located on the
lower right corner of the front cover.
Model:
Date of Purchase:
Serial Number:
Dealer:
Address:
Phone Number:
Sales Representative:
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

5
Safety
Safety Label Locations
These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible,
promptly replace them.
EMPLACEMENT DE L'ÉTIQUETTE DE SÉCURITÉREMARQUE : Ces dessins indiquent l'emplacement des
étiquettes de sécurité sur la machine. Si, à tout moment, les étiquettes deviennent illisibles, contactez votre
représentant autorisé pour un remplacement rapid.
WARNING LABEL
86244300
86244310
BATTERY CAUTION
86252520
86243830
OBC CAUTION
86392960
CAUTION
SEE VIEW A
VIEW A
86243830
86335010
BATTERY CAUTION
HANDS CLEAR
PINCH HAZARD
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

6
Safety
IMPORTANT SAFETY INSTRUCTIONS
When using this machine, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer's recommended components and attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into water, return it
to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.
This machine is not suitable for picking up hazardous dust.
Do not operate this machine near flammable fluids, dust or vapors.
Maintenance and repairs must be done by qualified personnel.
Disconnect battery before cleaning or servicing.
Before the machine is discarded, the batteries must be removed and properly disposed of.
Make sure all warning and caution labels are legible and properly attached to the machine.
During operation, attention shall be paid to other persons, especially children.
Before use all covers and doors shall be put in the positions specified in the instructions.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
This appliance has been designed for use with the brushes specified by the manufacturer. The fitting of other
brushes may affect its safety.
Do not use on surfaces having a gradient of over 10% (6 degrees).
Do not use without dust bag/or filter in place.
READ AND SAVE THESE INSTRUCTIONS
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

7
Safety
MESURES DE SÉCURITÉ IMPORTANTES
Lors de l'utilisation d'un appareil à batteries, il est nécessaire de respecter
systématiquement des mesures de sécurité de base, comme suit:
PRENEZ NOTE DE TOUTES CES MESURES AVANT D'UTILISER CETTE MACHINE.
Pour réduire les risques d'incendie, de chocs électriques, ou de blessures:
N'utiliser cette machine qu'en intérieur. Ne jamais l'utiliser à l'extérieur ou dans la pluie.
Utiliser cet appareil conformément aux instructions du présent manuel uniquement. N'utiliser que les composants
et les accessoires conseillés par le fabricant.
Lorsque la machine ne fonctionnant pas correctement, a fait l'objet d'une chute ou d'une détérioration, a été laissée
à l'extérieur, est tombée dans l'eau, la retourner au centre de service agréé.
Ne pas opérer la machine lorsque les conduits de ventilation sont bloquées. Débarrasser les débris des conduits,
car ils peuvent réduire l'écoulement d'air.
Cette machine n'est pas adaptée au ramassage de poussières dangereuses
Ne pas l'utiliser près de liquides, de poussières ou de vapeurs inflammables.
L'entretien et les réparations de la machine doivent être effectuées par un personnel qualifié.
Déconnecter les batteries avant de nettoyer la machine ou de la soumettre à un entretien.
Avant de se débarrasser de la machine, il est nécessaire de retirer les batteries et de les jeter correctement.
S'assurer que toutes les plaques d'avertissement ou de précaution sont lisibles et fixées correctement sur la
machine.
Durant la manoeuvre de la machine, prendre garde aux personnes environnantes et notamment aux enfants.
Avant l'utilisation de la machine, veiller à positionner tous les couvercles et portes comme indiqué dans les instruc-
tions.
Lorsque la machine est laissée sans surveillance, s'assurer qu'elle ne se déplace pas de manière accidentelle.
Cette machine ne doit être manoeuvrée que par un personnel expérimenté et qualifié.
Lorsque la machine est laissée sans surveillance, la mettre hors tension ou verrouiller l'interrupteur principal afin
d'empêcher un emploi non autorisé.
Cette machine a été conçue pour être utilisée avec des brosses spécifiées par le fabricant.
L'utilisation d'autres brosses peut affecter sa sûreté.
N'employez pas sur des surfaces ayant un gradient de plus de 10% (6 degrés).
Ne pas utiliser l’appareil si le filtre ou le sac à poussière n’est pas en place.
CONSERVER CES INSTRUCTIONS
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

8
Safety
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY.
The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper operating
condition. Following is information that signals some potentially dangerous conditions to the operator or the equip-
ment. Read this information carefully. Know when these conditions can exist. Locate all safety devices on the
machine. Please take the necessary steps to train the machine operating personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use
Kärcher North America approved replacement parts.
Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep battery
compartment open during charging. Keep sparks and flames away from the batteries. Do not smoke
around batteries.
Disconnect batteries before working on machine. Only qualified personnel should work inside machine.
Always wear eye protection and protective clothing when working on or near batteries. Avoid skin contact
with the acid contained in the batteries.
Never allow metal to lie across battery tops.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

9
Safety
Les symboles ci-dessous sont utilisés à travers ce manuel comme illustré dans leurs descriptions:
DEGRÉS DE RISQUES EN CAS DE DANGER
Il existe trois degrés de risques identifiés par les termes signalétiques -AVERTISSEMENTetATTENTION et POUR
VOTRE SÉCURITÉ. Le degré de risque est défini de la manière suivante:
AVERTISSEMENT - Dangers ou méthodes dangereuses qui POURRAIENT provoquer de graves blessures ou
entraîner la mort.
ATTENTION - Dangers ou méthodes dangereuses qui pourraient provoquer des blessures légères ou une détério-
ration du produit ou des biens immobiliers.
POUR VOTRE SÉCURITÉ: ce signe permet d'identifier les mesures de précaution à prendre pour assurer un bon
fonctionnement du matériel.
Rendre compte immédiatement d'une défaillance ou d'une détérioration de la machine. Ne pas utiliser la machine
si celle-ci ne fonctionne pas correctement. Lire soigneusement les informations ci-dessous signalant certains
dangers potentiels pour l'opérateur de la machine. L'opérateur doit être absolument au courant de ces dangers
potentiels. Localiser tous les dispositifs de sécurité sur la machine. Il est conseillé de prendre les mesures néces-
saires pour former le personnel opérateur.
POUR VOTRE SÉCURITÉ:
NE PAS MANOEUVRER LA MACHINE:
Lorsqu'on n'est pas expérimenté ou qualifié.
Lorsque le guide d'utilisation n'est pas été lu ou compris.
Dans des zones inflammables ou explosives.
Dans des zones où des objets peuvent tomber.
LORS DE L'ENTRETIEN DE LA MACHINE:
Éviter les parties amovibles. Ne pas porter de vêtements amples, tels que des vestes, des chemises ou des
vêtements avec manches lors de l'utilisation de la machine. Utiliser les pièces détachées Kärcher North America
homologuées.
Les batteries émettent le gaz d'hydrogène. L'explosion ou le feu peut résulter. Étincelles de subsistance et
flamme nue loin. Compartiment de batterie de subsistance ouvert en chargeant. Étincelles et flammes de
subsistance loin des batteries. Ne fumez pas autour des batteries.
Déconnecter les batteries avant de travailler sur la machine. La machine ne doit être confiée qu'à un
personnel qualifié. Porter systématiquement des lunettes et des vêtements de protection lors d'une inter-
vention sur les batteries ou aux alentours. Éviter tout contact de la peau avec l'acide contenu dans les
batteries.
Ne jamais placer d'objets métalliques sur le dessus des batteries.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

10
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal Power 1600 W
Rated Voltage 36 Volts DC
Rated Amperage 43 Amps
Batteries 3 X 12 Volt 205-234 @ 20 hr. rate
Battery Compartment Dimensions 21in. X 16in. X 17in. (533mm X 406mm X 432mm)
Propel Motor 0.75HP (560W)
Brush Motor 0.5 HP (373W)
Side Broom Motor 0.06HP (45W)
Bag Capacity 1006 in³ (16.5L)
Hopper Capacity 43.6 in³ (0.71L)
Brushes Two 28in (71cm) by 4in (10cm) dia.
Side Broom 13 inch (33cm)
Max Brush Speed 970 RPM
Max Side Broom speed 90 RPM
Vacuum Motor 0.94 HP (700W)
Max Flow Rate of vac motor 120 cfm (56.6 L/sec)
Vac bag full shut-off 14-16 inH2O (3.5 - 4.0 kPa)
Max suction vac motor 58.2 inH2O (14.5 kPa)
Weight (GVW) Gross weight with batteries and operator 958 Lb. (435 Kg)
Weight Empty no batteries or operator 361 Lb. (164Kg)
Tires 10in. (254mm) Solid grey non-marking
Foundation Pressure 61psi (420kPa)
Max Speed 3.65 MPH 5.88 Km/h
Frame construction Powder coated Steel
Brake Electrical Brake (engaged when operator steps of or E-
Stop activated)
Minimum Aisle U-Turn 66.92 in. (1700 mm)
Max rated climb and Descent 10% (6 degrees)
Sound Pressure at operators ear (IEC 60704-1) 71.1 dBA Uncertainty 2.8dBA Hard Floor Norm Clean
Sound Power (IEC 60704-1) 84.9 dBA Uncertainty 2.8dBA Hard Floor Norm Clean
Sound Pressure at operators ear (IEC 60704-1) 65.8 dBA Uncertainty 2.5 dBA Carpet Daytime Clean
Sound Power (IEC 60704-1) 84.7 dBA Uncertainty 2.5 dBA Carpet Daytime Clean
Vibration Hands (ISO 5349) 0.77 m/sec² Uncertainty .5 m/sec²
Vibration Feet (ISO 5349) 0.08 m/sec² Uncertainty .5 m/sec²
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

11
Operations
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
Cet appareil n'est pas prévu à l'usage des personnes (enfants y compris) avec des possibilités physiques, sensori-
elles ou mentales réduites, ou le manque d'expérience et de connaissance, à moins qu'ils aient été donnés la
surveillance ou l'instruction au sujet de l'utilisation de l'appareil par une personne chargée de leur sûreté. Des
enfants devraient être dirigés pour s'assurer qu'ils ne jouent pas avec l'appareil.
ITEM MEASURE
Height 50.0 inches (1270 mm)
Length 52.1 inches (1323 mm)
Width without deck 30.6 inches (777 mm)
Width of deck 31.9 inches (811mm)
Width with side broom 34.2 inches (869 mm)
WIDTH LENGTH
WITH SIDE BROOM
HEIGHT
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

12
Operations
How This Machine Works
The Chariot® CV86 is a battery powered, self-
propelled, vacuum intended for commercial use. The
appliance vacuums debris and dirt from the floor and
collects it in the debris tray and disposable bag.
The machine's primary systems are the brush system,
vacuum system, and operator control system.
The function of the brush system is to brush the floor.
The brush system consists of two cylindrical type
brushes, brush motor, brush deck, side broom, side
broom motor and controls. The front brush turns
clockwise when viewed from the right side of the
machine. The rear brush turns counterclockwise. Both
brushes work to agitatethe floor and to route the debris
up into the brush deck. The side broom rotates counter-
clockwise as viewed by the operator. The side broom
sweeps debris into the path of the brush deck.
The function of the vacuum system is to vacuum fine
dirt and debris into the vacuum bag, and large debris
into the debris tray. The vacuum system consists of the
debris tray, vacuum motor, vacuum filter and vacuum
bag. The debris tray captures the dirt off the floor as the
machine moves forward. The vacuum motor provides
suction to draw the fine dirt into the vacuum bag, and
the debris tray stores large debris.
The function of the operator control system is to control
the direction and speed of the machine. The directional
control system consists of the direction control drive
reset switch, throttle pedal, emergency stop switch,
steering wheel, propel controller, and drive wheel. The
directional control drive reset switch signals forward or
reverse direction and makes sure the operator is on
platform before machine will propel. The controller
interprets signals from the throttle pedal to command
the drive wheel to propel or slow the machine. The
steering wheel points the drive wheel in the direction
desired by the operator. The brake automatically
engages when the operatorsteps off theplatform, turns
the key off, or engages the emergency stop switch.
NOTE: Impact to machine may cause damage.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

13
Operations
Components
1. Control Panel - Drive
2. Control Panel - Vacuum
3. Pedal Platform
4. Rear Cover
5. Cover
6. Cover Lid
7. Brush Deck
8. Vacuum Bag
9. Side Broom
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp
12
3
45
6
7
8
9
UNDER LID

14
Operations
1
2
3
4
5
6
8
9
7
10
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

15
Operations
Controls
1. Key Switch
2. Emergency Stop Switch
3. Directional Control / Drive Reset Switch
4. Throttle Pedal
5. Horn Button
6. Steering Wheel
7. Function Mode Switch
8. Battery Discharge Indicator
9. Hour Meter
10. Vacuum System Status Indicator
1. Key Switch
Controls the power for machine functions.
To turn the machine power on, rotate key clockwise.
To turn the machine off, rotate key counterclockwise.
When the key is turned on the battery symbol will flash while the system runs self-diagnostics and returns the
brush deck and side broom to their raised positions, if necessary. The controller will not respond to other
commands until this routine is complete.
2. Emergency Stop Switch
This safety feature is designed to cut all power to the machine at any time and apply the brake.
To shut the machine power off, push the Emergency Stop Switch. This will also engage the brake and cause
the machine to stop immediately. Excessive emergency stop usage can cause premature brake wear; use only
when necessary.
To release the emergency stop switch, rotate the switch clockwise.
3. Directional Control / Drive Reset Switch
This safety feature is designed to ensure safe engagement of propel drive. Each time the machine power is
turned on, or each time an operator steps on to the platform, the Drive Reset Switch must be pushed before
machine will propel.
Controls the direction of travel of the vehicle. The lit arrow on the switch indicates direction of travel.
To travel forward, press the top of the switch.
To travel in reverse, press the bottom of the switch.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

16
Operations
4. Throttle Pedal
Controls the speed of the vehicle within the speed control setting selected. Pressing the pedal causes the
machine to travel in the direction selected by the Directional Control Switch.
To increase speed, increase pressure on the pedal.
To decrease speed, decrease pressure on the pedal.
5. Horn Button
The horn is activated by pressing the horn button.
6. Steering Wheel
The steering wheel turns the front wheel causing the machine to change direction.
7. Function Mode Switch
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

17
Operations
Slow Transport
This mode is used for machine transport. In this mode the machine will propel at slow speed. The
'floating' brush deck and side broom are in the up position. The brushes, side broom, and
vacuum are off.
Fast Transport
This mode is used for machine transport. In this mode the machine will propel at fast speed. The
'floating' brush deck and side broom are in the up position. The brushes, side broom, and
vacuum are off.
Deep vacuuming
This mode is used for deep vacuuming. In this mode the machine will propel at a slow speed.
The ‘floating’ brush deck and side broom are in the down position. The brushes will agitate, the
side broom will bring debris into the path of the deck. The vacuum will draw the dirt and debris
into the debris tray and the vacuum bag.
Light vacuuming
This mode is used for light vacuuming. In this mode the machine will propel at fast speed. The
‘floating’ brush deck and side broom are in the down position. The brushes will agitate, the side
broom will bring debris into the path of the deck. The vacuum will draw the dirt and debris into the
debris tray and the vacuum bag.
Daytime Vacuuming
This mode is used for daytime vacuuming. In this mode the machine will propel at a slow speed.
The ‘floating’ brush deck and side broom are in the down position. The brushes will agitate, the
side broom will bring debris into the path of the deck. The vacuum will draw the dirt and debris
into the debris tray and the vacuum bag. The brushes, side broom, and vacuum will operate at
reduced power.
Daytime Light Vacuuming
This mode is used for daytime light vacuuming. In this mode the machine will propel at fast
speed. The ‘floating’ brush deck and side broom are in the down position. The brushes will
agitate, the side broom will bring debris into the path of the deck. The vacuum will draw the dirt
and debris into the debris tray and the vacuum bag. The brushes, side broom, and vacuum will
operate at reduced power.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

18
Operations
8. Battery Charge Level Indicator
Indicates the charge level of the batteries.
The meter display is divided into 10 bars. Bars illuminated on the far right indicate full charge. Bars flashing
near the left side indicate the batteries should be recharged. Further operation of the machine could damage
the machine or the batteries.
When the machine is left overnight with less than a full charge, the display may initially indicate a full charge. It
will also indicate a full charge if the batteries are disconnected, then reconnected. After a few minutes of
operation the meter will give the correct charge level.
9. Hour Meter
Records the number of hours the brushes have been run. This information is useful in determining when to
service the machine.
10. Vacuum Bag Status Light
If vacuum operating conditions are good, light is green.
If vacuum operating conditions are poor, light flashes red for 1 minute, then turns solid red and vacuum opera-
tions are stopped.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

19
Operations
Machine Operation
Pre-Run Machine Inspection
Do a pre-run inspection to find possible problems that
could cause poor performance or lost time from break-
down. Follow the same procedure each time to avoid
missing steps.
NOTE: Perform Pre-run Machine Check before
operating machine. See Service Schedule in
Maintenance Section.
Starting Machine
FOR SAFETY: Before starting machine, make sure
that all safety devices are in place and operating
properly.
1. The operator should be on the pedal platform. The
throttle pedal must be in the neutral position.
2. Turn the machine power on by turning key switch
clockwise to the “ON” position.
3. Press the Drive Reset Directional Control Switch to
set the intended direction for travel.
4. Press lightly on the throttle pedal with right foot.
Emergency Stop Procedures
1. Push in emergency stop button. This will engage
the brake and cause the machine to stop immedi-
ately.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp

20
Operations
Normal Vacuuming
Plan the vacuuming pattern in advance. The longest
track is around the perimeter of the area to be cleaned.
For efficient operation, the runs should be the longest
possible without turning or stopping.
In order to achieve the best possible results, the area
which is to be cleaned should be picked up before
vacuuming. Large debris, strings and wire must be
removed to prevent being caught in brushes.
NOTE: Check and empty debris tray as needed
during operation.
If machine is allowed to stand in neutral with the
vacuum deck down for more than 2 seconds, the brush
motor stops. If either forward or reverse travel is
selected, the brush motor will continue once movement
of machine begins. Overlap the brush path and avoid
transporting over previously cleaned areas.
Recommended Path
To Begin Vacuuming
When operating the machine around people, pay
close attention for unexpected movement. Use
extra caution around children.
Lorsque vous utilisez la machine en présence de
gens, portez une attention particulière aux mouve-
ments inattendus. Soyez plus prudent, surtout en
présence d’enfants.
1. Stand on the operator platform.Throttle pedal must
not be depressed.
2. Turn key switch to turn machine power on.
3. Check position of Directional Control Switch to
ensure that machine is set to travel in direction
intended.
4. Rotate the Function Control Switch to one of the
four vacuum settings. Vacuum motor will turn on
within a few seconds.
5. Depress the throttle pedal to drive machine and
turn on brushes and side broom.
8.641-374.0 Operators Manual - Chariot 3 - CV 86/1 RS Bp
