Windsor Sensor S15 User manual

SENSOR S15
WINDS OR^
n
980085 SENSOR S15 12/01/2002

IMPORTANT SAFETY INSTRUCTIONS
When using an electricalappliance, basic precautionsmust always be followed,
including the following.
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE
WARN I NG : T O reducethe risk of fire, electric shock, or injury:
1 ; Do not leave appliancewhen pluggedin. Unplugfrom outlet when not in use and before servicing.
2.
Do not use outdoorsor on wet surfaces.
3.
Do not use near small children. Do not allowto be used as a toy. Close attention is necessarywhen used
by or near children.
4. Use only as described in this manual. Use only manufacturer's recommended attachments.
5. Do not use with damaged cord or plug. If applianceis not working as it should has been dropped,
damaged, left outdoors, or dropped into water, return
it to a service center.
6
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pullcord around sharp edges
or corners.
Do not run applianceover cord. Keep cord away from heated surfaces.
7.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handleplug or appliancewith wet hands.
9.
Do not put any object into openings. Do not'use with any opening blocked; keep free of dust, lint, hair,
and anything that may reduce air flow.
10. Keep hair, looseclothing, fingers, and all parts of bodyaway from openings and moving parts.,
Do not
placefingers or other body parts under vacuum unless unplugged.
11.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
12.
Do not use without dust bag and/or filters in place.
13. Turn off all controls before unplugging.
14. Useextra care when cleaningon stairs.
15. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may
16. Machines can cause a fire when operated near flammable vapors or materials.
Do not operate this
17. Maintenanceand repairs must be done by qualified personnel.
18. Use only identicalreplacement parts. See instructionsfor Servicing of Appliances.
19. Do not use machineas a step.
20. If used on plush carpet or carpet with thick padding, do not leave machine in one place with machine
21.
Do not use the handle in the dust bag housing cover to carry the machine.
22. Always turn
off this appliance beforeconnecting or disconnecting motorizednozzle.
23. Brush may unexpectedlyrestart.To reducethe risk of injury from movingparts.
- Unplugbeforeservicing.
24. The vacuum has a manual reset thermal protector. The protector is reset by switching
off the vacuum.
The thermal protectorneedssome time to cool down after switching
off! Check the vacum for air blockages
or mechanicalfailures beforeswitchingon.
25. Storethe vacuum inadry placeat roomtemperature.When thevacuum is not in use, you should wrap the
cord on the cable hooks.
26. Any other servicingshould be performedby an authorized service representative.
be present.
machine near flammablefluids, dust or vapors.
turned on.
SAVE THESE INSTRUCTIONS

GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path
of least resistance, for electric current to reducethe risk of electric shock. This appliance is equipped
with a cord havingan equipment
- groundingconductorand grounding plug.The plug must beinserted
into an appropriate outlet that
is properly installed and grounded in accordance with
and ordinances. all local codes
WARNING
Improper connection of the equipment - grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance
- if it will not fit the outlet,
havea proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120
- volt circuit, and has a grounded plug that looks like the
plug illustrated in sketch
A. A temporary apaptor that looks like the adaptor illustrated in sketches B
and C may be used to connect this plug to a 2 - pole receptacle as shown in sketch B if a properly
grounded outlet is not available.The temporary adaptor should be usedonly untila porperly grounded
outlet (sketch
A) can be installed by a qualified electrician.The green colored rigid ear, lug, or the like
extending from the adaptor must be connected to a permanent ground such as a properly
grounded outlet box cover. Whenever the adaptor is used,
it must be held in place by a metal screw.
Note: In Canada, the use of a temporary adaptor is not permitted by the Canadian Electrical Code.
LIMITEDWARRANTY
WINDSOR warrantsto the original purchaser/user that this product is unconditionallyguaranteed free
from defects in workmanship and materials under normal use and service for a period of one year.
The vacuum motorand beltsare warranted for a period of twoyears.
WINDSOR will, at its option, repair or replace without charge, except for transportations costs, parts
that fail under normal use and service when operated and maintained in accordance with the
InstructionsManual. This warranty does not apply to normalwear or to items whose life is dependent
on their use and care.
This warranty is in lieu of all other warranties, expressed or implied, and releases WINDSOR from all
other obligationsand liabilities.
It is applicable only inthe U.S.A. and Canada, and is extended only to
the original usedpurchaserof this product. WINDSOR is not responsible for costs for repairs perfor
-
med by persons other than those specifically authorized by WINDSOR. This warranty does not apply
todamagefromtransportation,alterationsbyunauthorizedpersons, misuseor abuseof theequipment,
useof noncompatiblech m of the product.
If a difficulty develops
wi ro as purchased.

Important Safeguards
Read and follow all safety instructions.
Accidents duetomisusecanonlybepreventedbythose usingthe machine.
To guardagainst injury,basicsafety
precautionsshould be observed, includingthe following:
WARNING: ELECTRIC SHOCK COULD OCCUR IF USED
OUTDOORS
OR ON WET SURFACES
This vacuum cleaner isdesignedto besafewhen usedto performcleaningfunctions.Shoulddamage occurto
electrical or mechanical parts, cleaner should be repaired by WINDSOR or competent service station before
using in order to avoid further damage to machine or physical injury to user.
A damaged power cord could cause electrical shock and/or fire. To minimize this possibility observe the
following precautions:
Do not run cleaner over power cord.
Avoid closing doors on power cord, pulling it around sharp edges, or placing sharp
- edged objects
upon it.
Wind cord no tighter than is necessary to retain it on the cord hooks.
When disconnectingpower cordfrom electricaloutlet, grasp the plug. Pulling it out by the cord itself
can damage cord insulation and internal connections to plug.
Your vacuum cleaner creates suction and contains a revolving brush.
To avoid bodily injury from suction or
movingparts,vacuumcleanerbrushshouldnotbeplacedagainst,or incloseproximityof looseclothing,jewelry,
hair or body surfaces while cleaner is connected to electrical outlet. Cleaner should not be used to vacuum
clothingwhile it is being worn. Keep children away from machine when in operation or plugged in.
If used on plushcarpetor carpetwith thick padding,turn off unitwhen handle isinuprightposition.When using
accessory tools, keepfloor brush
off carpetbykeeping handleinlockedpositionand loweringhandlewith one
hand to raise brushoff floor. Operate accessories with other hand.
Always plugyourcleanerintoastandardwalloutlet.Useof extensioncordor lightsocketwithinadequatecurrent-
carrying capacity could result in electric shock or fire hazard.
Disconnectcleaner from electricaloutlet before servicing, such as changing bags or belts. You could receive
bodily injury from moving parts of machine should switchaccidentally beturned on. Disconnect cleaner from
electrical outlet before detaching powerhead.
Do not useyour vacuum cleaner inareas where flammable and/or explosive vapor or dust is presentto avoid
possibilityof fire or explosion. Some cleaning fluids can producesuch vapors. Areas on which cleaningfluids
have been used should be completely dry and thoroughly aired before being vacuumed.
To avoid fire hazard, do not pick up matches,fireplace ashes, or smoking materialwith cleaner.
Keepyourwork areawelllightedtoavoidpickingupharmfulmaterials(suchasliquids,sharpobjects, or burning
substances) and avoid tripping accidents.
Usecare when operating the cleaner
on irregularsurfacessuch as stairs. A falling cleaner could cause bodily
injuryand/or mechanicaldamage.Properstorageof machineinanout
- of - the - wayareaimmediatelyafterusewill
also preventaccidents caused by tripping over cleaner.
Store your vacuum indoors in a cool, dry area not exposed to the weather
to avoid electrical shock and/or
cleaner damage.
Exercisestrictsupervisiontopreventinjurywhen usingvacuumcleanernearchildrenorwhenchildisallowedto
operatevacuum cleaner. Do not allow childrento playwith vacuum cleanerand never leave cleaner pluggedin
and unattended.
!
SAVE THESE INSTRUCTIONS

Picture 1
n 11 12
3
24
4
17
16
21
2
1 Handlegrip
2 On/Off switch
3 Handleassembly
4 Retaining ring
5 Cover releaseflap
6 Dust bag housing
7 Front cover
8 Housingrelease button
9 Basewith brush
10 Cable
11 Attachmenttube handle
12 Hose
13 Carrying handle
14 Cable hook
15 Attachmenttube
16 Crevice nozzle
17 Upholsterynozzle
18 Pileadjustment knob
19 Foot pedal
Preparation
Placethe brush/suction headonaflat surface
with the neck (20) and the support lever (21)
upright. Hold the dust bag housing vertically
and place over neck and support lever. Push
firmly down
so that the housing release (8)
snaps closed.
Lift the catch (22) then slot the handle
assembly intothetop of the dust bag housing
(6) and pushfirmly down.
When the handle has been pushed down as
far as
it will go press catch (22) down. If the
handle is not pushedfully down the machine
will not work.
Insertattachmenttube (15) intothe channel at
the back of the machine. Locate the handle
grip (11) on the holder (23).
Push the black end of the hose into the
connecting tube (24),
so that it clicks into
place.
Insert crevice nozzle and upholstery nozzle
intothe recesses in the back of the machine.

IN Ill
A Filter level indicator
B Brush controller
Filter level indicator
The redwarning light (A) indicates a blockageor
afull bag,
so check:
a)
Is the dust bagfull?
b)
Is there a blockage inthe hose or power
head?
Ifthe red light is disregardedthe machine will
shut
off and the light will flash.
Brush controller
The electronic brush controller continuously
monitorsthe operation of the brush.
If the red light
(B) stays off, the operation of the
brush iscorrect.
If the redlight
(B) turns on in positions 1 - 4 of
the Pileadjustment knob adjust the brush by
turning the Pile adjustment knob to a lower
position.
Ifthe red light
(B) burns continuously in the
position
1, the brush must be changed for a
new one.
If the machineturns
off and the redlight (B) flas -
hes, the brushhas become blockedand is not
turning. Switchthe machine
off, unplug it from
the mains and clear the blockage.
If there is no blockage,and machineturns
off
with brush lightflashing, raisebrush to a higher
position.
When the machine is switchedon in the upright
position the brush automatically rises from the
carpet. To release the machine from the upright
position, press down the foot pedal
(19). The
brushwill automaticallylower. The handlecan be
loweredto an intermediatestop positionin order
to lift up the brush head. To lower the
handle to a horizontal position, the foot pedal
must be pressed a second time. The stop positi
-
on can be closed off by a slider on the swivel
neck
(25) so that the handle will go from vertical
to horizontalin one movement.
To vacuum in corners etc.:
take hold of the telescopic handle grip, lift, it
away from the machineand stretchout the hose.
After use insert the telescopic attachment tube
intotheback of the machine. Raisethe handle of
the machine and the hose will automatically
retract. To use the hose without the tube as
shown inthe right hand picture, the hosewill pull
out of the tube while the tube is fitted to the
machine. Alternatively, press the release catch
(27) on picture 2.
To vacuum under beds etc., the machinecan be
fittedwith an additional straight tune and the
floor nozzle.The machine
will then performas a
cylinder vacuum.
Never run over the cable with the brushlsuc-
tion head.
Always carrythe machineover steps and
sills.

28
29
30 -
@
31 -
Maintenance
CAUTION - Always unplug machine at
mains outlet before dismantling any part
of machine.
If red light (A) shows, change paper filter bag.
To do this first pull cover release
(5) picture 1
forward and lift the cover from the dust bag
housing. Slide the dust bag sealing plate
(28)
fromtheholder (29). Slidethesealingplate (28)
of anew bag intothe holderandpushfirmly in.
Insertcover intodust bag housing push is for
-
ward then lock it inplace by pushingdown the
cover release
(5).
The micro hygienefilter (30) needsto be chan -
ged when it becomes clogged with dust or
after approximately
20 paper bags have been
used.
To change the hygienefilter first remove
thecoverthen slidethefilter out at the bottom.
To replace
lift the lever and slide the new filter
in.
After
20 paper bags have been used also
change the exhaust filter
(32). To remove the
exhaust filter push the catch
(33) forward and
removethe filter cover
(34) and filter.
Insertthe newfilter and replacethefiltercover.
To changethe brushroller (35) pushthe button
(36), removethe slide plate (37), turnthe brush
clockwiseaquarter
of aturnand pullthebrush
roller out. Slide the new brush roller into the
brush housing and turn
it until it locates into
position. Push the button
(36) and press the
side plate
(37) back intoplace.
Underneaththe machine isan inspectiondoor
to check for blockages
(38).
Blockages in the neck (20 - picture 2) can be
checkedbyfirst lifting
off thedust bag housing
by pressingthe catch
(8). Then releasethefoot
pedal, lowerthe neck and check intothe tube
nextto the pedal.
Blockages in the hose can cleared by taking
the hose off the machine and replacing
it the
wrong way round in the connecting tube
(24)
holding it upright with one hand blocking the
top and switchingon the machine.
(If necessaty quickly lift your hand on and off
the end of the hose).
The guarantee is invalidated if take out
partsnot approvedby
WINDSOR, eg. bags,
filters, brush roller, etc., arefitted1

120 V GREY
1-
i
i
i
I
Z3-I
I
i
i
12
25
16
15
W
50
P O S . Product-
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
No.
5625 UL
5296
EW
5359 hg
2301
1
0532 EW
5160 bl
5161 hg
5162
01
03
0846
5256 ER
01 29
5187
0102
5040 hg
5045 hg
5803 hg
5319
5706 bl
5324
5360
5091
5800 WI
5300
5301 ER
5380 HG
51 64
5208
5210
1073
5099
5098 hg
01 87
5145 hg
5146
5144 hg
5424dg
5281 hg
1823 hg
5084
5255 ER
5266
5043
5289
51 63
5085 hg
5082 bl
5083
5215 UL
1491 JE
1092 JE
Description
Handlewith cable, cpl.
Handlegrip (incl. Pos.
7+ 10)
Grommet
Powersupply cord
Switch,cpl.
Switchcap, blue
Switchcap holder
Cableclamp
Screw C 3,9x16
DIN 7981
Antistatic
- wire, cpl.
Handlecable
Screw, M4x 12
Handletube
Screw F 3,9 x13
DIN 7981
Hose, cpl.
Extensiontube
Cover
Bag holder spring
Cover release, blue
Bagholdercpl.
(incl. Pos. 20+21)
Safetycatch
Safetycatch spring
Front cover cpl.
Paper bag
Micro HygieneFilter
Internalcover, compl.
(incl. Pos.43+44)
Cableclamp
Filtersafety catch
Return spring
Clamp
Handlelock plate
Lock catch
Lock pin 4 x 33,5
Carrying handle
Stop spring
Cablehook
Retainingring
Dust bag housing
Attachment clip
Spring for lockingrod
Internalcable
Cableclamp
Seal
Seal
Seal
Dustbag hous. bumper base
Dust bag housing locking
Lockingrod
Dust bag housing
Upholstery nozzle
Crevice nozzle

120 V GREY
Pos. Product - Description
No.
100 2832 WI Power head cover S 15, cpl
101 2846 Exhaustfilter
102 2820 BL Exhaustfilter cover
103 2827 UL Swivelneck assembly
104 2886 Malecontact holder
105 2494 Cableclamp
106 0102 Screw
F 3,9 x13 DIN 7981
107 2835 Bypass valve
108 0869 Internal cable
Swivel neck bearingr.h
109 2825
110 2824 Swivel neck support r.h
111 5479 Swivel neck support 1.h
112 5717 Swivel neck bearing1.h
113 2890 ER PCB Power supply
114 0864 Internal cable
11 5 5713 bl Brush roller release
117 5051 hg Axle assembly
118 5053 Axle
11 9 5059 dg Foot pedal
120 2010 Axle spring
121 5055 hg Wheel, cpl.
122 2014 Axle clamp
123 5814 Brush roller
124 5287 bl Bearing block righthand
125 2869 hg Rubbingplate
126 2868 or Accessdoor
127 5303 Access door axle
128 5304 Access door spring
129 2861 Pile adjustment axle
130
51 74 hg Pile adjustment wheel
131 2849 Axle clamp
132 01010 Screw AM4 x 16,
DIN 7985
133 2860 hg Cover
134 2833 Thrust member
135 2862 hg Pile adjustmentknob
136 2834 Thrust member
137 2856 Clamp
138 2867 Spring
139 2822 HG ChassisG2, cpl
140 2828 hg Front bottom date G2, cpl.
141 2830 hg Rear bottom plate G2, cpl.
142 0197 Screw M4x12
Z 1
143 5401 Wire tie
Wire tie144 5402
145 2842 hg Bumper, set
146 5469 Motor
1 OOOW / 120V
Carbonbrush set
147 5462 Motor pulley 2MR
148
5100 Rubber mounting
149 2826 BL Motor cover
150 2839 sw Cover for air channel
116 5103 SPW
(incl. Pos. 127+128)
(incl. Pos. 142)
051
17 S
Support lever
- 1 Support spring
153 5112 sw Motor pulley cover
154 2881 ER Computercontroller
155 0107 Screw C 2,9 x 13
156 0143 Washer 3,2 DIN 125
157 5465 Sensor (with red ring)
158 5117/1 Motor pulley
159 0104 Screw C 3,9x25
DIN 7981
160 5463 Belt2MR
- 310 - 6
161 5110 Belt219 3M HTDII - 6
162 5766 hg Bearing block 1.h cpl.
163 0103
~ Screw C 3,9x16 DIN 7981
164 0140 Washer 4,3
165
01 76 TL Screw AM4x30 DIN 7985 TL

1
2
I
U
I
C 2
1
WARNING ! Electricshock could occur
if used outdoorsor on wet surfaces!
Technical Details Wiring diagram
Vacuum motor. .......... 1200 Watt
Water lift
............... 2300 mm (SO " )
Air flow ................ 50 US (1 05 CFM)
Dust bagcapacity.
....... 5,3 liters
Working width ........... 378 mm (1 5 " )
Brushdrive ............. tooth belt
Brush speed
............ 2700 rpm
Flooradjustment
......... automaticallysensor
advised
Cable
................. 12,2 m (40 ft)
Weight.
................ 73 kg (16,4 Ibs)
Radiosupression. ........ EN 55014 Verf. 242/9
A Attachments
1 Upholstery Nozzle
2 Crevice Nozzle
B OptionalAttachments
1 Extension Hose
2 StraightTube
3 Dusting Brush
4 Upholstery Nozzle,special
5 Wall - and Floor Brush
C ServicePatts
1 Paper Bag
2 Micro - Hygiene - Filter
3 Exhaust Filter
3 Brush Roller
4 mv-
PPP
dm
WINDSOR" INDUSTRIES, INC.
1351 West StanfordAve.
Englewood, Colorado
801 10 USA
800 - 444 - 7654
303
- 762 - 1800
FAX: 303 - 762 - 0817
06748 - 09.2002
