Windsor Versamatic Plus Assembly instructions

RG
Repair Guide ™
Manufactured by: Windsor Model: Versamatic Plus
Replacing the Power Cord
3. Pull the power
cord plate to
remove it.
7. Using a Phillips
screwdriver remove
the screw holding
the blue main
power cord in
place.
4. Using a # 7 nut
driver remove the
nut holding the
green ground wire.
6. Using needle
nose pliers, pull
the wires from the
back of the white
connector.
Tools needed:
A. Phillips screw-
driver.
B. Flat tip screw-
driver.
C. # 7 nut driver.
D. Needle nose
pliers.
5. Using a small flat
tip screwdriver,
loosen the 4 screws
in the white
connector.
2. Using a Phillips
screwdriver remove
the screw from the
power cord plate
on the back of the
vacuum.
1. Refer to this
picture when
reconnecting the
wires to the new
power cord.
These are general maintenance guidelines. Please consult your
owner’s manual prior to performing any repairs or maintenance on this machine.
*Before you begin: Turn the machine off and unplug it.

10. Pull the power
cord from the
handle to remove it
from the vac.
11. Reverse
process to install a
new power cord.
Refer to step 1 to
reconnect the wires
to the new power
cord.
RG
Repair Guide ™
9. Slide the strain
relief off the power
cord.
Manufactured by: Windsor Model: Versamatic Plus
Replacing the Power Cord
8. Pull up on the
strain relief to
remove the power
cord from the vac
body.
These are general maintenance guidelines. Please consult your
owner’s manual prior to performing any repairs or maintenance on this machine.
*Before you begin: Turn the machine off and unplug it.
